Pepperl+Fuchs HID2891 Manuel utilisateur

HANDBUCH

PROZESSAUTOMATION

PROCESS AUTOMATION

MANUAL

ISO9001

0102

FREQUENCY CONVERTER

HID2891

With regard to the supply of products, the current issue of the following document is applicable:

The general terms of delivery for products and services of the electrical industry, as published by

the central association of the "Elektrotechnik und Elektroindustrie (ZVEI) e.V.",

including the supplementary clause "Extended reservation of title".

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

Table of contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

1. 2 Symbols used in this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3. 1 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

3.2 Explosion protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

4 Delivery, transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4. 1 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4. 2 Acceptance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4. 3 Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4. 4 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

5 Installation and mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5.1 Mounting the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

5. 2 Connecting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

5.3 Operating and display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5.4 Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6.1 Configuration on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

6.2 Configuration using a PC operating program . . . . . . . . . . . . . . . . . . . . . . . 18

6.3 Defining the device data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

6. 4 Behaviour of the current output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

6.5 Behaviour of the voltage output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

Table of contents

7 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

7.1 Fault current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

7.2 Fault voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

8 Maintenance and repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

9 Dismounting, storage and disposal . . . . . . . . . . . . . . . . . . . . . . 50

9.1 Dismounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

9.2 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

9.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

10 Factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

Introduction

1 Introduction

1.1 General

This manual describes the installation, initial operation and handling of the device. It renders

information on the safe operation of the device, fault elimination, maintenance and disposal.

The corresponding data sheets, declarations of conformity and/or EC-Type Examination Certificates

are part of this instruction manual. The instruction manual shall be valid only if all applicable

documents are taken into consideration. These documents can be downloaded at

www.pepperl-fuchs.com. For additional information, please refer to the contact addresses on the last

page of this instruction manual.

This instruction manual requires technical know-how and experience with plant installations and

explosion protection.

The devices are intended only for correct and intended use (see section 2). In case of any violation,

all guarantee and manufacturer's liability shall become void. Please observe the applicable laws and

guidelines for the use and intended purpose.

The device has been developed and manufactured under observation of all applicable European

standards and directives.

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

Introduction

1. 2 Symbols used in this document

In order to highlight safety-related and informative notes, we have defined the following categories.

Every note is marked by a symbol.

Danger!

This symbol indicates a warning about a possible danger.

In the event the warning is ignored, the consequences may range from personal injury to

death.

Warning!

This symbol indicates a warning about a possible fault or danger.

In case of non-observation injuries or severe material damage may result.

Caution!

This symbol warns of a possible fault.

In the event the warning is ignored, the consequences may course personal injury or

heaviest property damage.

This symbol brings important information to your attention.

This symbol marks an acting paragraph.

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

2 Intended use

This device is used to transmit and convert signals between field devices and the process control

system/the control unit.

The HiD2891 frequency converter is a 1-channel, bus-

powered device. It transfers and converts the input

frequency of a large number of signals (mechanical

contact, proximity switches, magnetic encoders, current

or voltage signal) from the potentially explosive area into

signals for the safe area.

The input signal is transferred to an insulated transistor

output with an open collector and is converted into an analog output signal proportional to the input

frequency.

The frequency alarm and error detection are reported via the relay output or error bus output.

The parameters of the analog output can be set to create a current sink or current source or as voltage

with two different voltage ranges. The device can be adjusted with the DIP switches or by control

program PACTwareTM.

The device is suitable for connecting field devices used in potentially explosive areas. In this device,

the field circuits are intrinsically safe and galvanically separated from the non-intrinsically safe circuits.

The device constitutes the electrical separation between the potentially explosive (field side) and the

safe area (process side) of a plant. The intrinsically safe input (field side) is securely separated in

conformity with EN 50020 from the output, programming input, and the supply (process side).

For more information (on certificates, data sheets and the instruction manual), please refer to our

website at www.pepperl-fuchs.com/pa (entry in product search: HiD2891).

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

3Safety

3. 1 General safety instructions

The device may be mounted, connected and operated only outside of the potentially explosive

area. Have the work carried out only by a trained expert in electric engineering.

Use the device for its intended use only (see section 2). Please observe the information rendered in

the instruction manual on installation, initial operation and handling of the device.

If faults can not be remedied, shut down the device. Secure the device against accidental operation.

Return the device to Pepperl+Fuchs for repair. Own interventions and modifications are potentially

hazardous, and any guarantee and manufacturer's liability shall become void.

Responsibility for adhering to local safety regulations and directives is held by the operator

3.2 Explosion protection

For matters concerning primary explosion protection, i.e. measures to

prevent or restrict formation of a potentially explosive atmosphere,

please refer to Directive 1999/92/EU (ATEX 137) and the corresponding

national regulations.

For matters concerning secondary explosion protection, i.e. measures to

prevent ignition by electrical apparatus of a potentially explosive

atmosphere, Pepperl+Fuchs are happy to provide their "Explosion

protection manual" for a nominal fee.

In particular, please observe DIN EN 60079-10, DIN EN 60079-14,

DIN EN 50014 and DIN EN 50020 as well as the corresponding national

regulations.

Pepperl+Fuchs also offer a seminar on the subject of explosion

protection.

PROCESS AUTOMATION

MANUAL

EXPLOSION PROTECTION

Int rinsi c Safety

Expl osion Protection

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

4 Delivery, transport and storage

4. 1 Scope of delivery

The scope of delivery comprises:

• The device

• The instruction manual (this document)

4. 2 Acceptance

Please check the packaging and contents for any damage. Please check the delivery in order to

ensure that all parts are available and the delivery conforms to your order. Compare the data on the

nameplate with the ordering data.

Data on the nameplate:

• Order designation and part number

• Supply voltage

• Input and/or output data

• Data on explosion protection and intrinsic safety (if applicable)

4. 3 Transport

Pack the device for transport to protect it against damage. The original packaging offers perfect

protection for the device.

4. 4 Storage

Pack the device for storage to protect it against impact and soiling. The original packaging offers

perfect protection for the device. Store the device in a dry environment protecting it against humidity

and aggressive media. The permissible storage temperature ranges from -20 °C to 70 °C

(253 ... 343 K).

DOCT-0964C 808987 03/2010

Frequency Converter HiD2891

5 Installation and mounting

5.1 Mounting the device

The device can be mounted on the termination boards of the H-system:

All HiD2000 devices can be connected to every mounting station and can be mixed on the termination

board.

Warning!

Fault or damage of the device caused by wrong mounting location.

In case of non-observation, the safety and function of the device as well as other devices

or plants are not ensured.

Select the mounting location according to the type of protection of the device (IP30).

Protect the device against foreign bodies of 2.5 mm or larger and against spraying

water.

Please observe the notes on the types of housing protection (IEC 60529).

For additional information on the termination boards, please refer to the instruction manual

HiD2000 and the "HiD2000 Termination Boards" manual on our website at

www.pepperl-fuchs.com/pa (entry in product search: HiD2891).

If you want to use a customised termination board, please contact your Pepperl+Fuchs

assistant.
