Pentair ONGA Eco Select PANTERA evolution Manuel utilisateur

OWNER ’S MANUAL

Should the installer or owner be unfamiliar with the correct installation or operation of this

type of equipment you should contact the distributor/manufacturer for the correct advice

before proceeding with the installation or operation of this product. The pump operator or

owner must be provided with this owner’s manual.

ANTER

evolution

For the Installation, Operation and Service of the

PANTERA

evolution

Dual Speed Pool Pump

Onga and Pentair

Onga has been servicing the Australian and New Zealand markets with the highest quality water

movement products for 47 years. Established in 1967, Onga has a product to meet your every

water need.

Onga is part of the Pentair group, a global leader in swimming pool, spa and aquatic equipment.

The business has built a reputation as an innovation leader, providing high performance, reliable

and energy-efficient filters, controls, sanitizers, pumps, heaters, cleaners, and accessories for

residential and commercial pool owners and operators.

The Eco Select® brand identifies our most eco-friendly products

As the global leader in pool and spa equipment, we've made a strong commitment to develop and offer the

most environmentally responsible products available.

When you see the Eco Select brand on one of our products, you'll know it is our “greenest” and most

efficient product in that equipment category.

These products do the best job of saving energy, conserving water, reducing noise, or otherwise

contributing to a more environmentally responsible equipment system. In every case, a product that earns

the Eco Select brand is clearly our “greenest” and most efficient choice.

Eco Select

Table of Contents

Features and Benefits

Technical Information

Model Data

Hydraulic Performance

Dimensions

Installation

Pump Positioning

Piping

Pool Outlets

Electrical

Equipotential Bonding

Operation

Priming the Pump

Speed Selection

Other modes

Automation control

Service & Maintenance

Troubleshooting

Troubleshooting Guide

Spare Parts

Page

12,13

4, 5

12,13

Features & Benefits

The Pantera Evolution is the ideal pump for new or existing pools. Utilising efficient hydraulic design and

the latest technology in permanent magnet, electronic control two speed motors, the Pantera Evolution

has the perfect combination of efficiency and performance. The Pantera Evolution delivers energy savings

and the power when you need it. You will also have the peace of mind that you are doing your bit for the

environment and reducing your carbon foot print.

Dual speed pump, with 2 fixed speeds, allows you to efficiently filter your pool, saving energy with

the low speed mode and delivering extra power with the high speed mode for backwashing and

vacuuming.

2 pole / 4 pole induction motor delivers high efficiency and low noise levels.

Fault protected motor prevents damage by automatically shutting down the motor in the event of a

locked rotor or over current condition.

Low speed operation and efficient fluid dynamics make pump operation incredibly quiet.

Constructed of our durable, Australia made plastic pump components, so you can be sure it will

stand up to the harshest conditions.

A heavy-duty construction and a motor rated for continuous operation make the Pantera Evolution

a tough, long-lasting performer.

The high-capacity trap holds a large amount of debris, so you clean less often.

The transparent lid, features a self lubricated o-ring, so it can be hand tightened, making inspection

and cleaning a breeze.

Quick-disconnect plumbing unions.

Electronic control features high speed priming and 2hour high speed boost modes, for added

functionallity.

Drop in replacement for all LTP (Leisuretime) and PPP (Pantera) pool pumps.

Technical Information

Model: Pantera Evolution

RPM: Low 1450RPM (default factory setting)

High 2800RPM (default factory setting)

Electrical Rating: 230-240V 50Hz single phase

Rated Current: Low: 1.0A

High: 5.2A

Input Power (P1): Low: 223W

High: 1180W

Pump Power (P2): Low: 118W

High: 950W

IP Rating: IP25

Inlet (Suction): PVC Barrel Union to suit 40mm PVC pressure pipe

to AS/NZS 1477

Outlet (Discharge): ABS Barrel Union to suit 40mm PVC pressure pipe

to AS/NZS 1477

Max Total Head: 20m

Water Temperature Range: 5°C – 40°C

Maximum Ambient temperature: 5 5°C

Recommended pH Range: 7.2 - 7.8 (Guide Only)

Sound Power Level (Lwa): Low: 53dB

High: 69dB

Motor: 2 pole / 4 pole induction motor

Supply cord: 10A, H07RNF, 2m.

or 50mm spigot

Note:

The Low speed of the Pantera Evolution is not adjustable.

It is not recommended to use the Pantera Evolution where there is a suction lift greater than 10m, where

there are excessive pipe runs from pool to pump location, where the pool is greater than 50,000L and

where the sand filter is greater than 25" size.

Technical Information

Hydraulic Performance

Dimensions

Head (m)

Flow (L/min)

0.00

2.00

4.00

6.00

8.00

10.00

12.00

14.00

16.00

18.00

20.00

0 50 100 150 200 250 300 350 400 450

Pantera Evolution - Performance Chart

Low - 1450RPM

High - 2800RPM

Installation

The pump must be installed and serviced by a suitably qualified person in order to avoid

hazard. Incorrectly installed or tested equipment may fail, causing severe injury or property

damage.

These instructions are a guide only. Should you the installer or owner of the product be

unfamiliar with the correct installation or operation of this product you should contact a

suitably qualified person for advice.

Do not connect system to high pressure or mains water system.

This pump is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance by a person responsible for

their safety.

Children should be supervised to ensure that they do not play with the pump.

The Pantera Evolution is electrically connected. Ensure that it is isolated from electrical

supply during installation and any subsequent service work.

For best performance, allow pump

suction inlet height to be as far

below water level as possible and

allow the use of short, direct suction

pipe with minimum bends (to reduce

friction losses).

1. Plan the position of the pump

a) Have enough ventilation to keep ambient temperature below the motor's rated ambient temperature whenever the pump

is running. If installed in an enclosure/pump house, the enclosure must have adequate ventilation (200sq.cm min, inlet &

outlet) and air circulation Allow 200mm to keep rear of motor clear.

b) Have adequate floor drainage to prevent flooding and be protected from excess moisture.

c) Be solid, level, rigid and vibration free.

d) To reduce vibration and pipe stress, bolt pump to mount. Fixing holes accept 12mm fasteners.

e) Be within 2m of a power outlet for electrical connection (refer to AS/NZS 3000 for rules regarding connection of

electrical equipment in pool zones).

f) Allow adequate access for servicing pump and piping.

2. Piping

For best performance, allow pump

suction inlet height to be as far

below water level as possible and

allow the use of short, direct suction

pipe with minimum bends (to reduce

friction losses).

a) Use only Australian Standard PVC pressure pipe. For best performance use at least 50mm diameter pipe for all

connections to the pump. Never use a suction pipe smaller than pump suction connections (50mm) and use larger pipe

for long suction distances.

b) To avoid stress on the pump, support both suction and discharge pipes independently. Place these supports as close to

the pump as possible.

c) To avoid a strain left by a gap at the last connection, start all piping at the pump and run pipe away from the pump.

Installation

3. Pool Outlets

a) The pump suction system must provide protection against hazard of suction entrapment or hair

entrapment/entanglement. The pool outlet piping must be in accordance with the latest AS1926.3 standard

b) Suction outlet covers and skimmers must have been tested and found to comply with the latest AS1926.3 standard or

ASME/ANSI specification for Suction Fittings.

4. Electrical

a) Electrical installation shall be in accordance with the national wiring rules (AS/NZS 3000) taking into account its ratings

(Class I, IPX5). The pump is supplied with a standard Australian 10 amp plug and 2 metres of cord. Select the correct

Pool Zone for installation.

b) An RCD with maximum rated residual current of 30mA is required for the power supply to the pump. Additionally, if a

suitable socket outlet is not available a weatherproof socket must be installed by an electrician in a suitable location.

RCD tripping indicates an electrical problem. If RCD trips and will not reset have a qualified electrician inspect and repair

electrical system.

c) Incorrect voltage can cause fire or seriously damage pump and voids warranty.

d) Voltage at pump must not be more than 6% above or 10% below motor nameplate rated voltage or pump may overheat,

causing overload tripping and reduced component life. If voltage is less than 90% or more than 106% of rated voltage

when pump is running at full load, consult the power company.

e) If supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person in order

to avoid hazard.

Do not use extension leads as they

are unsafe in and around the

Pool Zone.

Hazardous voltage. Can shock,

burn or cause death.

To avoid dangerous or fatal electrical

shock, turn OFF power to pump and

remove plug from outlet before

working on electrical connections.

5. Equipotential bonding

If equipotential bonding is required (refer to local statutes and regulations), connect all metal parts of the swimming pool or

spa structure and to all electrical equipment, metal conduit, and metal piping in accordance with the wiring rules. Run a

wire from the equipotential bonding terminal on the pump (bottom, left motor bolt with serrated washer) to the pool

bonding structure.

Hazardous suction.

Can trap hair or body parts,

causing severe injury or death.

Do not block suction.

Operation

NEVER run pump dry. Running pump dry may damage seals, causing leakage and flooding.

Fill pump with water before starting motor.

Freezing conditions will damage the unit, as water expands as it freezes. Ensure that the

Pantera Evolution is located so that it is not prone to freezing, or ensure that the product is

disconnected and dried of water during cold conditions.

Trapped air in system can cause explosion. Ensure all air is out of the system before

operating or testing equipment

Fire and burn hazard. Modern motors run at high temperatures. To reduce the risk of fire,

do not allow leaves, debris, or foreign matter to collect around the pump motor. To avoid

burns when handling the motor, let it cool for at least 20 minutes before trying to work on

it.

Small children using pool must ALWAYS have close adult supervision

Pump suction is hazardous and can trap and drown or disembowel bathers. Do not use or

operate pump, pool/spas if a suction outlet cover is missing, broken, or loose. Follow the

guidelines below for a pump installation which minimises risk to users of pool and spas.

NEVER tighten or loosen trap lid while pump is operating.

It is not necessary to lubricate the o-

ring. The original equipment O-ring

contains a permanent internal

lubricant.

a) Before removing trap lid, SWITCH OFF POWER SUPPLY to pump.

b) CLOSE SHUT-OFF VALVES on suction and discharge pipes, if present.

c) Remove the trap lid (turn anti-clockwise)

d) Fill trap tank with water.

e) Check the lid o-ring and sealing surface, ensure there is no dust or debris on either, and replace the lid (turn clockwise to

tighten by hand only - no wrenches!).

f) Open the shut-off valves on the suction and discharge pipes, if present.

g) Release all air from filter, pump and piping system (refer filter owner's manual). In a flooded suction system (water

source higher than pump), pump will prime itself when suction and discharge valves are opened and air is released.

h) Switch on power to the pump to start.

I) Pump should start to prime now. Priming time will depend on vertical height of suction lift and horizontal length of

suction piping but is generally between 30 seconds to 2 minutes under normal installation conditions.

j) The Pantera Evolution will start slowly but ramp up to high speed for the first 2 minutes to assist priming. It will then

switch to the selected speed.

* Should the pump not prime, ensure that all valves are open, lint trap is clear of debris and suctions and suction pipe end is submersed

in water, and that there are no leaks in suction pipe. See troubleshooting guide.

1. Priming the pump

Operation

2. Speed selection

Speed / Application

Filtration and

water circulation

The Onga Pantera Evolution comes pre-programmed with the following default speeds:

1450RPM 2800RPM

Press for low speed Press for high speed

Off button

Press to turn power on/off.

If power is removed, motor will return to the last speed selected when power is restored.

Motor will remember ON/OFF state.

3. Other modes

If the default speed settings do not perfectly match the particular installation. They can be adjusted as follows.

Press & hold HIGH SPEED button for 5 seconds. Pump will go

to high speed for 2 hours then automatically will return to low.

Cleaning with a

suction cleaner

Backwashing

filter.

Operating some

water features such

as jets or waterfalls.

Solar heating

5 sec

Press & hold

for 5 seconds. On each power cycle the pump will power up to

low-high-low-high, etc. This allows for different automated

schedules via chlorinator time clock.

LOW SPEED, HIGH SPEED buttons simultaneously

5 sec

2-Hour

High Speed

Boost

2-Hour

High Speed

Start

Low/High

Alternating

Mode

Will cancel the change and revert back to the original speed and

return to normal operation mode

5 sec

Once 2Hour high speed boost mode (No.1 above) is activated,

press & hold for another 5 seconds.

Pump will start at high speed for 2 hours every time.

Press either LOW SPEED or OFF button to cancel this mode.

HIGH SPEED button

Table des matières

Autres manuels Pentair Pompe de piscine

Pentair

Pentair 5P2R Manuel utilisateur

Pentair

Pentair OptiFlo Manuel utilisateur

Pentair

Pentair PUMP Manuel utilisateur

Pentair

Pentair INTELLIFLO WHISPERFLOVSD Manuel utilisateur

Pentair

Pentair STA-RITE SILENTFLO SF550100 Manuel utilisateur

Pentair

Pentair STA-RITE SWIMMEY Series Manuel utilisateur

Pentair

Pentair IntelliFlo VS+SVRS Manuel utilisateur

Pentair

Pentair Sta-rite EnviroMAX 1500 Guide de configuration

Pentair

Pentair maytronics ecoclear 800-VS Manuel utilisateur

Pentair

Pentair JWP SERIES Manuel utilisateur

Pentair

Pentair STA-RITE DYNA-PRO Manuel utilisateur

Pentair

Pentair IntelliFloXF Manuel utilisateur

Pentair

Pentair WhisperFlo Manuel utilisateur

Pentair

Pentair INTELLIFLO 100 Manuel utilisateur

Pentair

Pentair OPTIFLO 348195SR Manuel utilisateur

Pentair

Pentair WhisperFlo VS 800 Manuel utilisateur

Pentair

Pentair MYERS MSP7 Manuel utilisateur

Pentair

Pentair OptiFlo Manuel utilisateur

Pentair

Pentair WHISPERFLO VS 1500 Manuel utilisateur

Pentair

Pentair PUMP Instructions d'installation

Pentair

Pentair Sta-Rite EcoSelect Enviromax 800 Manuel utilisateur

Pentair

Pentair Teel 4RJ93 Instructions d'utilisation

Pentair

Pentair IntelliFlo VF Manuel utilisateur

Pentair

Pentair Ultra-Flow Manuel utilisateur

Manuels Pompe de piscine populaires d'autres marques

TIP

TIP STEAM 35000 INV Schéma de câblage

Jacuzzi

Jacuzzi J-HI27C Manuel utilisateur

PoolRite

PoolRite SQI 400 Manuel utilisateur

Calpeda

Calpeda NMP Manuel utilisateur

WilTec

WilTec 50374 Manuel utilisateur

Evolution

Evolution Evoflow Storm Eco-V Manuel utilisateur

AquaTools

AquaTools AT240701 Manuel utilisateur

Sibo

Sibo AquaForte RD352 Manuel utilisateur

CLS

CLS VICTORIA PLUS SILENT Manuel utilisateur

Pond One

Pond One Piranha 800 Manuel utilisateur

Hayward

Hayward VSP Manuel utilisateur

Resol

Resol DeltaSol B Pro Manuel utilisateur

Evolution Aqua

Evolution Aqua UniTech Perfect 5000 Manuel utilisateur

Outside Living Industries

Outside Living Industries Ubbink Heatermax Pool Guide de démarrage rapide

CPI

CPI Olympic 2P1815 Manuel utilisateur

Flotec

Flotec FP6121-01 Manuel utilisateur

Polygroup

Polygroup SUMMER WAVES SKIMMERPLUS SFX330 Manuel utilisateur

Sears

Sears 390.26280 Manuel utilisateur
