Penner Bathing Spas Dream Spa Guide de démarrage rapide
Dream Spa
Parts and Service Manual
760748 Rev C 10-1-2021
Penner Patient Care
101 Grant St
Aurora, NE 68818
Service help call 1-800-732-0717 or 1-866-736-6377
www.pennerbathing.com
1
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
Table Of Contents
Models 760010-1,760010-2,770010-1,770010-2
760748 Rev C 10-1-2021
2
Table Of Contents
Dream Spa Operational Controls
Internal Spa Front View
Tempering Valve Adjustment
Dream Water Door Internals
Dream Water Door External Components
Aqua-Aire System
Drain Components
Plumbing Supply
Load Center
Comfort Warm System
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
11.
Operation Controls
Parts and Service Manual
760748 Rev C 10-1-2021
Penner Patient Care
101 Grant St
Aurora, NE 68818
Service help call 1-800-732-0717 or 1-866-736-6377
www.pennerbathing.com
3
Blower Motor Air Switch
Hot Temperature Valve-Kit
Fill Spigot-Kit
Cold Temperature Valve-Kit
Tub Fill Temperature Gauge (Comm. Only)
Shower Sprayer Temperature Gauge (Comm. Only)
Diverter Valve-Kit
Shower Sprayer
Label “Diverter”
Spa “Hot”
Spa “Cold”
1. 760495
2. 760150
3. 760150
4. 760150
5. 760535
6. 760535
7. 760150
8. 760156
9. 760720-3
10. 760720-4
11. 760720-5
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
8
7
5
4
3
2
1
Internal Spa View
Parts and Service Manual
760748 Rev C 10-1-2021
4
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
1. 350172
2. 350391
3. 350169
4. 560250
5. 760890
6. 350132
7. 360350
8. 360355
9. 400212
Overflow Escutcheon
Drain Screen
Drain Plug
Grab Bar
Water Door Assembly
Jets
Post-Safety belt loop (Comm. Only)
Rod-Safety belt loop (Comm. Only)
Safety Belt (Fastening Procedure
shown below)(Comm. Only)
1
8
7
6
5
4
3
2
9
Components of spa are referenced in relation to the front of the spa. The front
of the spa is as a person sits in the spa facing the controls.
Seat belt fastening steps shown.
Tempering Valve Adjustment
Max “Hot” Temperature Adjustment
760748 Rev C 10-1-2021
5
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
1. 760200
2. Allen Screw
3. Adjustment Cap
4. “Hot” Supply
5. “Cold” Supply
6. “Cold” Supply
7. Delivery
Tempering Valve
Allen Wrench supplied with valve
Partially remove, used as adjustment tool.
¾” NPT Supply inlet
¾” NPT Supply inlet
¾” NPT Supply inlet
¾” NPT Delivery outlet
7
4
3
2
1
5
6
Tempering Valve Adjustment Procedure
To adjust the max hot temperature, use the provided Allen
wrench to remove screw from cap of tempering valve. Take
cap part way off valve so only inner splines of cap make
contact with brass splines of valve. Rotate cap clockwise to
decrease hot water temperature. Rotate cap counterclockwise
to increase hot water temperature. This is done looking at the
face of the cap as mounted on the tempering valve.
Note: A little turn can make a big temperature adjust. Make
sure to test temp to avoid scalding. Using a known good
temperature gauge and to verify let water run on wrist.
Water Door Internal Components
Parts and Service Manual
760748 Rev C 10-1-2021
6
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
1. 760300
2. 760255
3. 760260
4. 760258
5. 760425
6. 760465
7. 760335
8. 760338
9. 760326
10. 760324
11. 760330
12. 360435
13. 760328
14. 760332
15. 360425
16. 360465
17. No #
Lock Pin (Qty 2)
Bushing-Pin (Qty 2)
Nut-Pin Bushing Long (Qty 2)
O-ring (Qty 2)
Clevis Pin ¼” x 1” SS (Qty 2)
Cotter Pin 3/32” x ½” SS (Qty 2)
Hinge
Hinge Screw (Qty 16)
Upper Push Bar
Torque Arm
Vertical Push Link
Spring
Lower Push Link
Lower Pivot Arm
Clevis Pin 3/8” x 1” (Qty 3)
Cotter Pin 5/32” x 1” SS (Qty 4) Not Shown
Clevis Pin 3/8” x 1 ¼”
1
10
9
8
7
6
5
43
2
14
13
11
12
17
15
Spindle Plate
Nut-1/4” x 20 (Qty 3) Not Shown
Hub Assembly-Top
Spindle Bushing
Hub Top-Outer (Includes Dowels Pins
760440 (Qty 2) and 760445 (Qty 1))
Washer-Retaining
Head Cap Screw ¼”-20 x ½”
Roll Pin ¼” x ½” (Qty 2)
1. 760321
2. 107001
3. 760320
4. 760275
5. 760287
6. 360475
7. 200700
8. 760310
4
5
7
8
Water Door External Components
Parts and Service Manual
760748 Rev C 10-1-2021
7
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
Door Handle
Snap Cap
¼”-20x1/2” Head Cap Screw
Brass Retaining Washer
Spacer Ring
Roll Pins (Qty 2)
Door Seal
Door Seal Replacement Kit
Door Hinge
Hinge Screw (Qty 16)
Fascia Screw ¼”-20x3”
1. 760297
2. 760492
3. 200700
4. 360475
5. 360480
6. 760310
7. 360125
8. 360125K
9. 760335
10. 760338
11. 760220
The door assembly can be easily removed from the spa by using a #2
Phillips screwdriver and removing the screws on the spa side hinge leaf.
1
2
6
4
Both fascia pieces can be taken off by removing the screws. Two(2) screws on the smaller fascia and four(4) on the
larger fascia. The door fascia has three, ¼”-20x3” stainless truss head screws. To remove this cover, pop out the snap
cap on the handle and using a 7/16” socket and extension you can remove the retaining screw. This allows the handle
and hub to slide out of the door. Now the three screws on the fascia can be removed for access to inside of water
door.
5
7
9
11
12
13
14
12. 760896-C
13. 760894-C
14. 760898-C
Fascia-Back
Fascia-Door Cover
Fascia-Front
Fascia Removal Video
Aqua Aire System
Air Manifold-Jet Assembly-Blower Motor
760748 Rev C 10-1-2021
8
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
Check Valve Assembly
Blower Motor
Hose Clamps (Qty 2) Not shown
Hose Flex
Airline Tubing (Qty 27 feet)
T-Fitting (Qty 8)
90°Fitting (Qty 5)
Jet Assembly
Internal Jet Replacement Kit
Cap-Black Jet
1. 760406
2. 760602
3. 590758
4. 360603
5. 350276
6. 360650
7. 360655
8. 350132
9. 350134
10. 360644
1
8
7
6
5
4
3
2
3
10
9
Air Jets can be cleaned from hard build up by using a 21/64 drill bit and a ¼ drill bit. Run the bits through the jet body
after removing the cap and internal check valve components. The 21/64 bit will bottom out on a shoulder in the jet
body. The ¼ bit will run all the way through to the tee fitting. DO NOT USE POWER TOOLS. Run drill bits by hand.
Drain Components
Parts and Service Manual
760748 Rev C 10-1-2021
9
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
Overflow tube
Beveled rubber washer
Hose clamp
Hose-Grey overfill
Nut 2” slip joint (Qty 2)
Washer 2” Rubber Slip Joint (Qty2) Not shown
Tee-Drain New Plastic
Washer 1 7/8”x2” Rubber
Base Shoe Basket, Chrome
Base Shoe Assembly
Removal Tool-Chrome Basket
1. 350174
2. 350173
3. 590758
4. 390410
5. 1050481
6. 1050501
7. 1050461
8. 1050345
9. 1050401
10. 140365
11. 140370
8
10
7
6
5
4
3
2
1
3
6
9
11
A removal tool may be ordered to tighten or
loosen Base Shoe Basket from Base Shoe
Assembly. DO NOT overtighten as this may
cause the Base Shoe Assembly to crack and
cause leaks.
Plumbing-Supply
Parts and Service Manual
760748 Rev C 10-1-2021
10
1-800-732-0717 www.pennerbathing.com 1-866-736-6377
Thermometers (Commercial use only Qty 2)
Adaptor (Commercial use only-for thermometers)
Washer-for adaptor(760540) and shower hose
Air Push Button (for Blower motor)
Shower Hose
Cold Main Supply ¾”line-72”length
Hot Main Supply ¾”line-72”length
1. 760535
2. 760540
3. 760545
4. 760495
5. 760158
6. 390100
7. 390100
8. Cold Valve supply
9. Hot Supply (Temper Controlled)
10. Hot to Diverter Valve
11. Cold to Diverter Valve
12. Waterfall Fill Supply
1
1
7
6
5
4
32
11
10
9
8
12
