Pelgrim GVW301L/P01 Manuel utilisateur

EN User instruction EN 3 - EN 28

DE Anleitung DE 3 - DE 28

Pictograms used - Benutzte Piktogramme

Important information - Wissenswertes

Tip - Tipp

Contact a registered installer to fit your appliance

(see “Installation instructions”). Do not connect the

appliance to the electrical mains until the installation is

complete.

This appliance is intended to be used in household and

similar applications such as:

▷staff kitchen areas in shops, offices and other working

environments;

▷farmhouses;

▷by clients in hotels, motels and other residential type

environments;

▷bed and breakfast type environments.

For EN60335-1:

• This appliance can be used by children aged from

8 years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

• Children shall not play with the appliance. Cleaning and

user maintenance shall not be done by children without

supervision.

SAFETY INSTRUCTIONS

For IEC60335-1:

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

• Packaging material could be dangerous for children!

• This appliance is for indoor household use only.

• To protect against the risk of electrical shock, do not

immerse the unit, cord or plug in water or other liquid.

• Please unplug before cleaning and performing

maintenance on the appliance.

• Use a soft cloth moistened with mild soap, and then

use a dry cloth to wipe it again.

Earthing Instructions

• This appliance must be earthed. In the event of a

malfunction or breakdown, earthing will reduce the

risk of an electric shock by providing a path of least

resistance of electric current. This appliance is equipped

with an earthing conductor plug.

• The plug must be plugged into an appropriate outlet

that is installed and earthed in a ccordance with all local

codes and ordinances.

• Improper connection of the equipment-earthing

conductor can result in the risk of an electric shock.

SAFETY INSTRUCTIONS

• Check with a qualified electrician or service

representative if you are in doubt whether the appliance

is properly grounded.

• Do not modify the plug provided with the appliance, if it

does not fit the outlet.

• Have a proper outlet installed by a qualified electrician.

Use

• When loading items to be washed:

▷Locate sharp items so that they are not likely to

damage the door seal;

▷Warning: Knives and other utensils with sharp points

must be loaded in the basket with their points facing

down or placed in a horizontal position.

• Do not abuse, sit on, or stand on the door or dish rack

of the dishwasher.

• Do not operate your dishwasher unless all enclosure

panels are properly in place.

• Open the door very carefully if the dishwasher is

operating, there is a risk of water squirting out.

• Do not place any heavy objects on or stand on the door

when it is open. The appliance could tip forward.

• Some dishwasher detergents are strongly alkaline.

They can be extremely dangerous if swallowed.

Avoid contact with the skin and eyes and keep children

away from the dishwasher when the door is open.

• Check that the detergent powder is empty after

completion of the wash cycle.

SAFETY INSTRUCTIONS

• Do not wash plastic items unless they are marked

“dishwasher safe” or the equivalent.

• For unmarked plastic items not so marked, check the

manufacturer's recommendations.

• Use only detergent and rinse agents recommended for

use in an automatic dishwasher.

• Never use soap, laundry detergent, or hand washing

detergent in your dishwasher.

• The door should not be left open, since this could

increase the risk of tripping.

• If the supply cord is damaged, it must be replaced

by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

• During installation, the power supply must not be

excessively or dangerously bent or flattened.

• Do not tamper with controls.

• The appliance needs to be connected to the main water

valve using new hose sets. Old sets should not be

reused.

• To save energy, in stand by mode, the appliance will

switch Off automatically while there is no any operation

in 30 minutes.

SAFETY INSTRUCTIONS

EN 3

Your dishwasher

Introduction 4

Using your dishwasher

Description 5

Quick start 5

Control panel 6

Water softener 8

Adding salt 9

Preparing and loading dishes 9

Function of the rinse aid and dishwasher detergent 14

Filling the rinse aid reservoir 15

Filling the detergent dispenser 16

Programming the dishwasher

Wash cycle table 17

Saving energy 18

Starting a cycle wash 18

Changing the program mid-cycle 18

Forget to add a dish? 19

Maintenance

Filtering system 20

Cleaning the spray arms 21

Caring for the dishwasher 22

Cleaning the door 23

Errors

What should I do, if... 24

Error table 24

Technical data sheet 27

Your dishwasher and the environment

Disposal 28

CONTENTS

EN 4

Introduction

You have opted to purchase a Pelgrim dishwasher. Optimum user comfort and easy operation

were paramount during the development of this product.

This manual describes how you can get the most out of your dishwasher. It provides you with

information on how to operate the appliance, as well as background information about how it

works. You will furthermore also find maintenance tips.

The safety instructions that are relevant during the installation are included in the installation

guide. This is intended for the installation technician.

Read this manual before using the appliance. Keep this manual somewhere safe so that

subsequent users can also benefit from the information contained within.

You can find the most recent version of the instructions for use on our website.

YOUR DISHWASHER

EN 5

USING YOUR DISHWASHER

Description

Features and appearance of baskets and cutlery baskets may vary, depending on your

model.

1. Salt container

2. Corner spray arm

3. Detergent dispenser

4. Rainse aid reservoir

5. Lower spray arm

6. Filtering system

7. Top spray arm

8. Cutlery rack

9. Cup rack

10. Upper spray arm

11. Upper basket

12. Lower basket

Quick start

Please read the corresponding content in this manual for more details about the operation.

Inside Outside

1. Setting the water softener/loading the salt.

2. Removing larges residues on the cutlery/dishes.

3. Loading the baskets.

4. Filling the dispenser and the rinse aid reservoir.

5. Selecting a program and running the dishwasher.

910

EN 6

USING YOUR DISHWASHER

Control panel

14 52 36 107 9 118 8

AUTO ECO

Operation (push buttons)

1 On/off Press this button to turn on your dishwasher, the screen lights up.

2 Function Press this button to select a function. The corresponding indicator will be

lit.

3 Program Select the appropriate washing program, the selected program indicator

wil l be lit.

4 Delayed

start Press this button to set a delayed start (up to 24 hours). One press on this

button delays the start by one hour.

5 Alt Press this button for specifically cleaning the load in the selected basket.

You do not have to wait until the whole dishwasher is loaded completely.

The corresponding indicator will be lit.

6Auto door

open After washing, the door will open automatically to achieve better drying

effect. Press the Function and Program button together for over three

seconds to cancel the Auto open function for the current cycle.

Indicators

7 Function

indicator

AUTO

ECO

KOUD

Extra cleaning

To wash very dirty, hard to clean dishes. It can only be used with

Intensive, Universal, ECO, Glass and 90 min.

AUTO

ECO

KOUD

Turbo Speed+

Reduce the program time by up to 50%. It can only be used with

Intensive, Universal, ECO, Glass and 90 Min.

Auto open

This light will be lit every time when you switch on the dishwasher.

When you cancel the auto open function, this light will be unlit.
