Peavey PEAVY STUDIO PRO M2 Manuel utilisateur

EElleemmeenntt TTyyppee::

Pressure Gradient Transducer

PPoollaarr PPaatttteerrnn::

Selectable: omni, cardioid, figure 8

FFrroonntt--ttoo--bbaacckk RReeeeccttiioonn::

20 dB typical in cardioid pattern

RRaatteedd OOuuttppuutt IImmppeeddaannccee::

200 Ohms

RReeccoommmmeennddeedd LLooaadd IImmppeeddaannccee::

1000 Ohms

FFrreeqquueennccyy RReessppoonnssee::

30 – 20,000 Hz

SSeennssiittiivviittyy ((mmVV//ppaassccaall))::

12.5 mV/20 mV/15 mV*

SSeellff NNooiissee ((EEqquuiivvaalleenntt NNooiissee LLeevveell SSPPLL))::

20/16/18 dB* typical, A-weighted

(per IEC 651)

MMaaxxiimmuumm SSPPLL ffoorr 00..55%% TTHHDD::

145/140/144 dB* at 1 kHz

PPoowweerr RReeqquuiirreemmeennttss::

48 Volts

CCuurrrreenntt CCoonnssuummppttiioonn::

3.0 mA

CCoonnnneeccttoorr::

3-pin XLR

* omni, cardioid, figure 8

PPoollaarriittyy::

Positive pressure on diaphragm

produces positive voltage at pin 2

relative to pin 3

DDiimmeennssiioonnss::

2.280 inches (57.91 mm) maximum

body diameter, 7.80 inches

(198.12 mm) long

PPaacckkaaggiinngg::

Compact carrying case

NNeett WWeeiigghhtt::

1.2 pounds (545 grams)

OOppttiioonnaall AAcccceessssoorryy::

Studio Pro Shock Mount

FFeeaattuurreess

• Large gold-plated dual diaphragm

microphone

• Pressure-gradient transducer

• Switchable polar pattern

• Switchable low frequency roll-off

• Switchable 10 dB pre-attenuation

• Ideal as main and as support

microphone in most recording

situations

AApppplliiccaattiioonn HHiinnttss

• Announcer’s studio, vocal, and

instrument mic for broadcasting,

dubbing, voice-over

• Overhead

• Spot mic for

- wind instruments

- strings

- piano

- percussion

DDeessccrriippttiioonn

The Studio Pro M2 is a large format

side-address condenser microphone

with a unique frequency and

transient response. It has a

selectable polar response for omni,

cardioid or figure 8 patterns. It is an

excellent choice for most

applications in studios, for

broadcasting, film and television.

SPECIFICATIONS Peavey Studio Pro™M2

The Studio Pro M2 can be used as a

main microphone for orchestra

recordings, as a spot mic for single

instruments, and as a vocal microphone

for all types of music and speech.

The large gold-plated diaphragm capsule

has a very smooth frequency response

for all polar patterns. The microphone

can be used very close to a sound source

without the sound becoming unnaturally

harsh. By means of a switchable high-

pass filter, interference through subsonic

and low frequencies are reduced

remarkably. As such, this switch cuts the

low frequency response reducing the

proximity effect.

An additional switch is added for use in

high SPL applications. This 10 dB

attenuation switch enables the

microphone to handle sound pressure

levels up to 140 dB.

OOppeerraattiioonn

Position the M2 so that the side with the

LED and Peavey logo faces the source.

The M2 is equipped with three switches,

one for mic pickup patterns, one for high

SPL applications and the other for

reduction in proximity effect and to

reduce low frequencies that can make an

instrument sound dull or muddy.

Determine which of these conditions

you’re needing to mic and make the

appropriate selection. NNoottee:: IItt iiss nnoott

rreeccoommmmeennddeedd ttoo cchhaannggee aa sswwiittcchh

sseelleeccttiioonn wwiitthhoouutt ffiirrsstt rreedduucciinngg tthhee mmiixxeerr

ggaaiinn..The M2 is equipped with a swivel

mount to secure the microphone to a

floor or boom stand. The internal shock

mount provides good isolation but for

greater reduction of noise from external

vibrations use the optional elastic shock

mount which can be purchased from

your local authorized Peavey dealer.

33 ++ 22 YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY

NNOOTTEE::For details, refer to the

warranty statement. Copies of

this statement may be obtained

by contacting Peavey Electronics

Corporation, P.O. Box 2898, Meridian,

Mississippi 39301-2898.

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

-20

-10

Frequency Response: On-Axis

-10 dB

Low Cut

Omni On-Axis

Figure-8 On-Axis

Cardioid On-Axis

-90o

-60o

-30o

30o

60o

90o

Polar Response

6dB/div.

SPECIFICATIONS Studio Pro™M2

125 Hz 250 Hz 500 Hz

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

1 kHz 2 kHz 4 kHz

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

8 kHz

-90o

-60o

-30o

30o

60o

90o

CCaarrddiiooiidd PPoollaarr PPaatttteerrnnss

SPECIFICATIONS Studio Pro™M2

125 Hz 250 Hz 500 Hz

-270o

-300o

-330o

30o

60o

90o

120o

150o

180o210o

240o

-270o

-300o

-330o

30o

60o

90o

120o

150o

180o210o

240o

-270o

-300o

-330o

30o

60o

90o

120o

150o

180o210o

240o

1 kHz 2 kHz 4 kHz

-270o

-300o

-330o

30o

60o

90o

120o

150o

180o210o

240o

-270o

-300o

-330o

30o

60o

90o

120o

150o

180o210o

240o

-270o

-300o

-330o

30o

60o

90o

120o

150o

180o210o

240o

8 kHz

-270o

-300o

-330o

30o

60o

90o

120o

150o

180o210o

240o

FFiigguurree 88 PPoollaarr PPaatttteerrnnss

SPECIFICATIONS Studio Pro™M2

125 Hz 250 Hz 500 Hz

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

1 kHz 2 kHz 4 kHz

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

8 kHz

-90o

-60o

-30o

30o

60o

90o

OOmmnnii PPoollaarr PPaatttteerrnnss

Features and specifications sub ect to change without notice.

Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 (601) 483-5365 • FAX (601) 486-1278 • www.peavey.com
