Peak Scientific Precision SL A5 Mode d'emploi

Simple user maintenance guide

Desiccant capsule replacement

When to replace? Silica gel will darken as it becomes saturated.

Depending on usage a 12 week minimum lifetime is expected.

Step 1: Check Silica gel colour

via the window on the

left-hand side panel of the

generator (if blue/green it

needs to be replaced).

Step 2: Press and hold the

power button for 5 seconds to

shutdown and depressurize.

Now turn off the main power

switch at the back of the unit.

Step 4: Loosen and remove the

cap of the desiccant dryer by

placing the tool onto the cap

and turning counter-clockwise.

Step 5: Remove the saturated

desiccant capsule and replace

with a fresh capsule.

Step 6: Replace the cap and place

the tool on top, tighten with the

tool by turning it clockwise.

Step 8: Power up the generator using the main power switch

on the rear of the unit. Once diagnostics are complete, the

LEDs will be solid green and the generator will be ready to

deliver gas to the application. Press the front button to

supply gas to the application.

Precision SL A5 Quick INS Rev 2PN 3303233 RSID 3374

Step 7: Close the top panel.

Step 3: Open the top panel by

lifting gently.

*Failure to change the DI cartridge can lead to cell damage and will invalidate your warranty

Step 2: Open the top panel by

lifting gently.

Simple user maintenance guide

De-ionizer cartridge replacement

When to replace? Every 12 months from original installation.

Step 3:

The de-ionizer cartridge is

located in the water tank and can

be accessed by opening the top

panel.

Step 4: The de-ionizer cartridge

can be removed by turning the

cartridge counter-clockwise.

Step 5: Remove the de-ionizer

cartridge and replace with a fresh

cartridge.

Step 6: Fix replacement

de-ionizer cartridge in place by

turning clockwise.

Step 7: Close the top panel. The

de-ionizer cartridge will need to be

changed after 12 months.

Step 1: Press and hold the power

button for 5 seconds to shutdown

and depressurize. Now turn off the

main power switch at the back of

the unit.

Step 8: Power up the generator using the main power switch on

the rear of the unit. Once diagnostics are complete, the LEDs will

be solid green and the generator will be ready to deliver gas to the

application. Press the front button to supply gas to the application.

Please ensure Please ensure that you change the de-ionizer (DI) cartridge as soon as you unpack the

replacement. The DI cartridge needs to be wet when installed. If the DI cartridge has dried out it will

affect generator performance. To reactivate a dry DI cartridge, submerge it upside down in deionized

water so the air inside escapes, then fit as described in the following steps.
