SIPxNano™

IP-PBX Server

Quick Start Guide

1.0 What’s included with the SIPxNano™

The following items are included with the SIPxNano:

1.

NanoServ system computer and stand

2.

AC Power Adaptor

3.

Documentation CD

4.

This Quick Start Guide

Note

Refer to the Getting Started Guide on the CD-ROM for complete information on installation.

2.0 What you will need

The following items are NOT included, but you will need them to use the SIPxNano:

1.

Monitor

2.

Keyboard

3.

Mouse

4.

Separate PC

5.

Ethernet cable

Important

—This is a Class A device and is intended for use in a light industrial environment. It is not

intended nor approved for use in an industrial or residential environment.

Document Number: 09407U7-002, Rev. B

Part Number: 07MSIPxNANO-QS

Revised:

June 13, 2007

Sales Ofﬁce: +1 (301) 975-1000

Technical Support: +1 (301) 975-1007

E-mail: [email protected]

WWW: www.patton.com

2

SIPxNano Quick Start Guide

3.0 Before you begin

Note

The NanoServ chassis is within thermal and design limits but it does run warm. For proper operation

and cooling the system must have 2 cm or 1 inch of space for pen air around both side vents. In other

words, it cannot be laid down ﬂat on a table, and it cannot be standing ﬂat against a partition, etc.. If

mounted in some place, it must be mounted with stand off space about 1 inch. If mounted in a closed

enclosure, it will need 1 or 2 fans on the outer enclosure for proper air ﬂow inside.

Before you turn on the SIPxNano, follow these steps (see ﬁgure 1):

1.

Place the SIPxNano upright in the metal stand (included).

2.

Attach a VGA monitor (not included) into the VGA port on the rear panel.

3.

Attach the keyboard (not included) into the PS/2 port on the rear panel.

4.

Attach the mouse (not included) into the second PS/2 port on the rear panel.

5.

Attach the Ethernet cable (not included) into the RJ-45 port and connect the other end to the PC (not

included).

6.

Attach the power adapter (included), and plug it into the closest electrical outlet.

7.

Turn on the power switch on the rear panel.

Figure 1.

Rear panel of the SIPxNano

POWER SW DC-IN 5V

COM1

Audio Line-Out

Mic-In

Serial Port **

VGA Port

RJ-45 10/100 Ethernet Jack

USB Port

PS/2 Mouse (6-pin)

Parallel Port **

PS/2 Keyboard & Mouse (6-pin)

DC Power Jack (3-pin)

Power supply switch

** This feature is only

available for Model 6075.

SIPxNano Quick Start Guide

3

4.0 Running the reset script

When you turn on the SIPxNano for the ﬁrst time, you will need to run and conﬁgure a reset script before you

can access the webpage interface.

When you boot the system, a CLI prompt will appear asking for a login and password:

•

login:

root

•

password:

superuser

•

[root@SIPxNano ~]#

will appear. To run the reset script, type:

/recovery/linux/sipx_reset_cd

<Press enter>.

Note

Do

not

press “I” for Interactive Setup while running the reset script. Allow the reset script to run without

interruption.

After running the reset script, you will have the option to change the default settings such as the hostname, IP

address, netmask, gateway, nameserver, password, and timezone. If you would like to keep the default settings,

press <enter> at each prompt. Type ‘

yes’,

then press <enter>. The system will reboot.

Note

If you make a mistake while running the reset script or changing the default settings, type ‘

CTRL+C’

to

interrupt the reset script and start over.

After the system reboots for the second time, enter the login and password you set (or the default settings, if you

did not make any changes).

5.0 Accessing the system

Enter the

IP address

of the SIPxNano (in this example, 10.10.200.1) into a web browser on a separate PC. Be

sure that the PC is on the same subnet as the SIPxNano.

To log into the SIPxNano:

1.

After typing the IP address into a web browser, a welcome screen will appear.

Click on the

‘Conﬁguration’

link.

2.

Log into the webpage interface. The default login and password are:

User ID:

superadmin

PIN:

patton

3.

The SIPxNano homepage will appear.

4.

From the main page, on the main navigation menu at the top, you can access the conﬁguration pages for

setting up

Users

,

Devices

,

Features

,

System

, or

Diagnostics

.

4

SIPxNano Quick Start Guide

6.0 Additional Information

Refer to the

SIPxNano Getting Started Guide

located on the CD-ROM shipped with your SIPxNano system

and available online at <

www.patton.com/manuals>

for detailed information about:

•

Installing, conﬁguring, operating, and troubleshooting.

•

Warranty, trademark & compliance

Note

Speciﬁcations are subject to change without notice.

Refer to the

NanoServ User’s Manual

available online at <

www.patton.com/manuals>

for more infor-

mation about the NanoServ system.

Refer to the

CentOS

website at

<http://www.centos.org>

for information about the CentOS operating

system.

A.0 Compliance & Safety Information

A.1 Compliance

EMC Compliance:

•

FCC Part 15, Class A

•

EN55022, Class A

•

EN55024

Safety Compliance:

•

IEC/EN 60950-1

A.2 Radio and TV interference (FCC Part 15)

This equipment generates and uses radio frequency energy, and if not installed and used properly—that is, in

strict accordance with the manufacturer's instructions—may cause interference to radio and television recep-

tion. This equipment has been tested and found to comply with the limits for a Class A computing device in accor-

dance with the speciﬁcations in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable

protection from such interference in a commercial installation. However, there is no guarantee that interference

will not occur in a particular installation. If the equipment causes interference to radio or television reception,

which can be determined by disconnecting the cables, try to correct the interference by one or more of the fol-

lowing measures: moving the computing equipment away from the receiver, re-orienting the receiving antenna,

and/or plugging the receiving equipment into a different AC outlet (such that the computing equipment and

receiver are on different branches).

SIPxNano Quick Start Guide

5

A.3 CE Declaration of Conformity

We certify that the apparatus described above conforms to the requirements of Council Directive 89/336/EEC,

as amended by Directives 92/31/EEC and 93/68/EEC on the approximation of the laws of the member states

relating to electromagnetic compatibility; and Council Directive 2006/95/EC on the approximation of the laws of

the member states relating to electrical equipment designed for use within certain voltage limits.

The safety advice in the documentation accompanying this product shall be obeyed. The conformity to the above

directive is indicated by the CE sign on the device.

A.4 Authorized European Representative

D R M Green, European Compliance Services Limited.

Oakdene House, Oak Road , Watchﬁeld, Swindon, Wilts SN6 8TD, UK

A.5 Safety Information

•

This device contains no user serviceable parts. The equipment shall be

returned to Patton Electronics for repairs, or repaired by qualiﬁed ser-

vice personnel.

•

The external power adapter shall be a listed Limited Power Source.

Ensure that the power cable used meets all applicable standards for the

country in which it is to be installed, and that it is connected to a wall

outlet which has earth ground. The mains outlet that is utilized to

power the devise shall be within 10 feet (3 meters) of the device, shall

be easily accessible, and protected by a circuit breaker.

•

Hazardous network voltages are present in WAN ports regardless of

whether power to the unit is ON or OFF. To avoid electric shock, use

caution when near WAN ports. When detaching the cables, detach the

end away from the device ﬁrst.

•

Do not work on the system or connect or disconnect cables during peri-

ods of lightning activity.

In accordance with the requirements of council directive 2002/96/EC on Waste of

Electrical and Electronic Equipment (WEEE), ensure that at end-of-life you separate

this product from other waste and scrap and deliver to the WEEE collection system in

your country for recycling.

The Interconnecting cables shall be acceptable for external use and shall be rated for

the proper application with respect to voltage, current, anticipated temperature, ﬂam-

mability, and mechanical serviceability

WARNING

CAUTION

6

SIPxNano Quick Start Guide

•

To prevent shock or ﬁre hazard, do not expose your SIPxNano

to rain or moisture.

•

Never install your SIPxNano in wet locations.

•

To avoid electrical shock, do not open the case. Contact the fac-

tory ofﬁces for qualiﬁed personnel servicing.

•

Never touch un-insulated terminals or wire unless your power

adaptor and display monitor are disconnected.

•

When using the system, avoid using or installing the modem to

the serial port during a storm or lightning.

•

Do not use the modem or a telephone to report a gas leak in the

vicinity of the leak.

•

USB cables are not supplied.

WARNING

SIPxNano Quick Start Guide

7

NOTES

____________________________________________________________________

8

SIPxNano Quick Start Guide

NOTES

____________________________________________________________________

The information in this document is subject to change without notice. Patton Electronics assumes no

liability for errors that may appear in this document.
