Safety Instructions
About your LCD
LCD quick reference guide
Controls
Switching on and off the unit
Volume Control
IR sensor
Input Selector
Mute
Indicates the unit is on
and warming up (60 sec)
Indicates the unit is working
Volume level is 0
Indicates 42 volume level
Volume range is 0 to 99
Indicates the input 3 has
been selected out of 7
Indicates the mute mode
has been activated
63
Your Logos has no wording printed on the
front panel and on the remote control. These
are designer's choices, in order not to spoil
the style of the Logos. Controls are designed
to be intuitive, so that users become familiar
with all the controls very quickly.
To switch the unit on, press the button 1.
As soon as the unit is turned on, the LCD 4
indicates the letter P for around 60 seconds;
after that time, the unit is working and the
LCD 4 displays the volume control.
To switch the unit off, press the button 1.
The volume can be operated both by turning
the dial 3 and via the remote control. By
pressing the button 6, the volume increases;
by pressing the button 7, the volume de-
creases. The volume level is indicated by
the LCD 4 with two digits, from 0 to 99.
When using the remote control, always
direct it towards the IR sensor 5.
Inputs can be selected both by pressing the
button 2 on the front panel or by pressing
the button 9 on the remote control. By repe-
titely pressing one of the above-mentioned
buttons, the various inputs are selected as
indicated on the LCD 4 (A1 to A7)
Mute function can be operated by pressing
the button 8 on the remote control. When in
mute mode, the LCD 4 displays --.
Your Logos is provided with a liquid crystal
display to indicate various functions, as
described below. The brightness of the LCD
increases each time one control function is
operated, and automatically decreases after
around 5 seconds from the last operation.
Please read carefully the following safety
instructions, which have been included in
compliance with international safety
standard regulations.
1. Read instructions before the appliance is
operated. Retain user's manual for future
reference.
2. To prevent fire or shock hazard do not
expose your Logos to rain or moisture.
3. This unit contains voltages that can cause
serious injury or death. Do not operate it with
its cover removed.
No user-serviceable parts are inside.
Service should only be performed by
authorized Pathos personnel. Users
are not allowed to perform any service
to this appliance.
In case of fuse replacement, please refer to
your Pathos authorized dealer or to your
nearest service centre.
The authorized personnel should follow
these instructions:
1. Before replacing fuses, disconnect the AC
2. For continued protection against fire
hazard, replace fuses only with the same
type and rating.
