Patchwork Technology BlackBox Advance Manuel utilisateur
Patchwork Technology
BlackBox Advance Operating Instructions
(Downloadable)
PWdoc0040 v1.0
Contents
page
Mounting the Screen to vehicles windscreen
Mounting the Receiver
Connection Diagram
Main Unit
Connecting a switch to control coverage
area recording
Connecting a Weather station
Overview
Navigation Bar
Entering details and settings
Initial Setup Wizard
Home Screen
Program Sub Menu
Setup
Recording Details
Local Setting
GPS Options
Ports Setup
VRT Options
Save / Load Profiles
Advanced
Start Job
New Job
Farm / Field Recognition
Resume unplanned job
Planned job
Guidance Modes
Product Overview
Fitting Instructions
Unit Functions
Unit Setup
Starting a Job
5
7
8
9
9
10
11
12
13
13
13
15
16
17
18
19
22
23
26
29
31
32
33
34
34
35
35
36
Job Screen
Using WebTrack with
the BlackBox
Troubleshooting
Overview
Menu
Creating a Field Boundary Map
Starting a Field Boundary Map
Pausing the boundary mapping
Completing a field boundary map
Future use for the maps
Using Guidance and Coverage Area Recording
Using First Pass Guidance
Setting and Resetting a Guidance line
Using a guidance line
Using the Coverage Area Recording
Creating a WebTrack Account
Logging on to WebTrack
Downloading and Installing WebSync
Using ‘BlackBox Setup’ for recording jobs
Adding Details
Enhancing Details (Farm Fields)
Creating and Adding Form Items to Job
Types
Transferring data to and from WebTrack via
WebSync
37
39
40
40
41
41
41
42
42
42
43
43
46
47
48
49
49
50
50
52
54
page
5
Product Overview
The BlackBox unit can be upgraded by unlocking various areas of the software
allowing it to perform additional tasks. The Advance unit will be supplied with the
both the GO and Advance software unlocked, please see the following for
details on the different software versions:-
BlackBox Go
The Go software is a simplified version of the Advance software that enables the
use of Guidance and Area measurement only.
Features: Simple Setup
Multiple 3D Guidance modes
Farm / Field Recognition*
Resume Job*
BlackBox Advance
Further to the Go software capabilities the Advance software allows the
recording and storage of work done for record keeping, if used in conjunction
with WebTrack these records can be enhanced with Notes (see below). The
software is also the platform for adding additional hardware and software
features, including an Auto Steer and Boom Switching system.
Other Features include : Headland Warning
Weather Station Connection
Setup Profile Manager
Link up with Farm Management Software
Compatibility list: Muddy Boots
Pear Technology
Farmade GateKeeper
Notes (WebTrack required) –This allows the farm manager to add notes (form
items) to a specific job type and when that job type is selected on the BlackBox
the notes will appear for the operator to fill in on the Blackbox before the job is
completed.
*SD Card must be inserted
6
VRT
This upgrade allows the unit to send application rate information using variable
rate application maps to the controller attached to the implement. Adding
Variable Rate to the Blackbox is simple and the compatibility list of controllers is
extensive:
Amazone Amatron+ and Amados+
Bogballe 2003w, Uniq and Icon’
Raven 400, 600, 4000
LH Agro 5000, 500, 6000
Kuhn Quantron L, M, P, E
Kverneland Group
Passtronic
RDS Pro Series
Vaderstad
Dickey John
Teagle Tulip Centreliner
Auto Shut Off
With auto shut off setup on the unit, when driving into an area which has been
worked (indicated by the green area coverage recording in the job screen), a
signal will be sent to the controller to stop the implement working. After driving
out of the worked area the unit will send a new signal to the controller to start the
implement working again.
N.B. Function not fully compatible with Amazone controllers.
Product Overview
7
Mounting the Screen to vehicle windscreen
N.B. Supplied suction mount and ram arm my differ from the image below.
Ensure the area on the windscreen where the suction mount will be attached is
clean, and then push it on the windscreen turning the lever clockwise to lock it in
place.
The ram ball and suction mount are then connected together using the supplied
“Ram Arm”. This allows for multi-positional flexibility and is simply tightened with
the thumb screw.
Warranty Void if suction mount fails !! - Its is advised that the suction
mount is removed from the windscreen when the unit is not in operation
and reattached on a day to day basis.
For a more permanent fixing please detach the ram ball from the suction mount
and secure down in the vehicle.
Fitting Instructions
Tighten Screw
Turn Lever
8
Mounting the Receiver
Mount on the cab of vehicle, as close as possible width ways to the centre of the
vehicle with the red arrow pointing towards the direction of travel.
The bottom of the receiver is magnetised ready to attach to a metal surface. Use
the supplied metal plate for vehicle roofs that are not made of metal.
To fit, first clean a small area and ensure it is dry, then remove the plastic covers
from the self adhesive strips on the metal plate and stick to the vehicle roof.
The antenna will now stick to this plate and be held safely on the roof.
N.B. In many cases running the cable in through a window or door is acceptable,
please make sure that there is enough of a gap in the rubber to allow this,
otherwise the cable could be damaged and with no signal from the receiver the
BlackBox will not function correctly.
Fitting Instructions
9
.
Fitting Instructions
Connection Diagram
Main Unit
Warning - Please disconnect the unit from the power supply, if
you need to jump start your vehicle.
Guidance Screen
12v DC Plug
To 3-pin socket on
vehicle.
Receiver
10
Fitting Instructions
...Connection Diagrams
Connecting a switch to control area coverage recording
The BlackBox will need to be configured to work correctly with the switch, for
details see Ports Setup menu ‘On/Off’ on page 26.
1 2
3
Ref Description Part No.
1 Boom Sense Cable 03-05-0006
2 Switch (request when ordered) N/A
3 Relay (request when ordered) N/A
