PASCO ES-9047 Manuel utilisateur

Instruction Sheet

for the PASCO

Model ES-9047

012-01525B

10/91

$1.00

Introduction

The PASCO Model ES-9047 Tapered Cylinder and

Plate contains an interesting shape for charge distribu-

tion demonstrations. The tapered conductive cylinder

measures 13 cm high, 6 cm in diameter at the base and

10 cm in diameter at the top. It is attached to a 25 cm

diameter plate by a plastic insulator. Terminals are

provided for electrical connection to both surfaces, the

cylinder and the plate.

Equipmemt Included:

• Cylinder

• Plate

• Insulating Spacer

• 6-32 Nylon Machine Screw

• 6-32 Hex Nut

Additional Equipment Recommended for Use with

the Tapered Cylinder and Plate:

• Power Supply ES-9049A

• Electrometer ES-9054B

• Faraday Ice Pail and Shield ES-9058

• Charge Producers and Proof Plane ES-9057

TAPERED CYLINDER AND PLATE

Assembly Procedure

To assemble your Tapered Cylinder and Plate:

➀Push the nylon machine screw from beneath

through the center-hole in the the plate.

➁Slide the insulating spacer over the screw.

➂Position the tapered cylinder over the insulated

spacer.

Tighten the hex nut over the screw to hold the

assembly.

scientific

Tapered cylinder

6-32 Hex nut

Plate Insulating spacer

6-32 Nylon machine screw

➃

012-01525B

scientific

Limited Warranty

PASCO scientific warrants this product to be free from

defects in materials and workmanship for a period of

one year from the date of shipment to the customer.

PASCO will repair or replace, at its option, any part of

the product which is deemed to be defective in mate-

rial or workmanship. This warranty does not cover

damage to the product caused by abuse or improper

use. Determination of whether a product failure is the

result of a manufacturing defect or improper use by the

customer shall be made solely by PASCO scientific.

Responsibility for the return of equipment for warranty

repair belongs to the customer. Equipment must be

properly packed to prevent damage and shipped

postage or freight prepaid. (Damage caused by

improper packing of the equipment for return shipment

will not be covered by the warranty.) Shipping costs

for returning the equipment, after repair, will be paid

by PASCO scientific.
