Parrot JETT Manuel utilisateur

User Guide

Jumping Race Drone

JETT TUK TUK

MAX

Table Of Contents

.......................................................................................................................................................4

Before starting

...........................................................................................................................................................................................................4Charging the battery

...........................................................................................................................................................................................................5Switching the Parrot Jumping Race Drone on and off

...........................................................................................................................................................................................................5Downloading the application

...........................................................................................................................................................................................................5Connecting a smartphone

.......................................................................................................................................................6

Piloting

...........................................................................................................................................................................................................6Piloting screen

...........................................................................................................................................................................................................7Wheels position

...........................................................................................................................................................................................................7MiniDrone's positions

...........................................................................................................................................................................................................8Rolling

...........................................................................................................................................................................................................8Jumping

...........................................................................................................................................................................................................9Kicking

...........................................................................................................................................................................................................9Pre-programmed acrobatics

...........................................................................................................................................................................................................10Battery

...........................................................................................................................................................................................................10Talking through the MiniDrone

...........................................................................................................................................................................................................11Photos

...........................................................................................................................................................................................................11Videos

...........................................................................................................................................................................................................11Retrieving photos and videos

.......................................................................................................................................................12

Settings

...........................................................................................................................................................................................................12Media

...........................................................................................................................................................................................................12Piloting

...........................................................................................................................................................................................................12Speed

...........................................................................................................................................................................................................12Network

...........................................................................................................................................................................................................14Information

.......................................................................................................................................................15

Road plan

...........................................................................................................................................................................................................15Defining a road plan

...........................................................................................................................................................................................................17Managing road plans

.......................................................................................................................................................18

Drone Academy

.......................................................................................................................................................20

Updating

.......................................................................................................................................................21

General information

...........................................................................................................................................................................................................21Safety precautions and maintenance

...........................................................................................................................................................................................................21Warning regarding the invasion of privacy

...........................................................................................................................................................................................................21Battery

...........................................................................................................................................................................................................22Warranty

...........................................................................................................................................................................................................22Modifications

...........................................................................................................................................................................................................22Correct disposal of this product

...........................................................................................................................................................................................................22Declaration of Conformity

...........................................................................................................................................................................................................23Registered trademarks

4 Before starting

Before starting

Charging the battery

1. Insert the battery into the appropriate compartment (pictures A and B).

2. Connect the MiniDrone (pictures C and D):

To a 2.4 A minimum charger (not provided). The charging time is approximately

25 minutes.

To your computer using the USB cable (provided). The charging time is

approximately 1 hour and 30 minutes.

> The LED located next to the On/off button turns red while charging. Once the

MiniDrone is fully charged, the LED turns green.

To remove the battery:

1. Carefully lift the plastic part surrounding the battery.

2. Remove the battery using the two grips located at the back of the battery.

5Before starting

In order to ensure effective maintenance of the battery on the MiniDrone never

leave the battery installed in the compartment.

Switching the Parrot Jumping Race Drone on and off

Insert the battery into the battery compartment or press

the button to switch the MiniDrone on. Wait until the

MiniDrone indicates that it is ready to be used and its

LED eyes turn green.

Press the button to switch the MiniDrone off. The LED

eyes switch off.

Downloading the application

Connect to the App StoreSM or Google PlayTM and download the free FreeFlight3

application.

Connecting a smartphone

1. Carry out a Wi-Fi® search from your smartphone

if you are using an iPhone or an iPad select Settings > Wi-Fi

if you are using an AndroidTM smartphone select Settings > Wireless and

networks > Wi-Fi.

2. Select the MiniDrone's network.

3. Wait for your smartphone to connect to the Wi-Fi network of the MiniDrone.

This connection is generally represented by the Wi-Fi logo appearing on the

smartphone screen.

4. Start the FreeFlight3 application.

> The connection between your smartphone and the MiniDrone is established

automatically. A pop-up "Connected" appears. The MiniDrone performs a turn

and emits sounds.

If your smartphone does not connect automatically to the MiniDrone, press ,

then select the name of your MiniDrone in the list.

See the Settings > Wi-Fi section for further information.

6 Piloting

Piloting

1. Start the FreeFlight3 application.

2. Press FREE RIDE to pilot the MiniDrone. Press Voice transmission to pilot the

MiniDrone in Talkie Walkie mode. For further information, see Talking through

the MiniDrone.

> The piloting screen appears.

At any time you can press < to return to the main menu.

Piloting screen

N°

Description

N°

Description

1

Last screen

9

Long jump

2

Settings

10

MiniDrone's position

3

Stopping a pre-programmed

acrobatic

11

Wi-Fi range

4

Pre-programmed acrobatics

12

Left joystick

7Piloting

5

Walkie Talkie

(Voice transmission mode

only)

13

Speed needle

6

Video recording

14

Right joystick

7


15

Plugged / unplugged phone

headset

8

High jump

16

Battery level

Wheels position

Before you start slelect the piloting mode for the MiniDrone

by bringing the wheels together you are making the MiniDrone more

responsive

by separating the wheels you are improving the MiniDrone stability.

MiniDrone's positions

Press the key to switch to Jumper or Kicker position. Press down for 2 seconds

on the key to switch to Auto-balance position.

Jumper position enables you to perform jumps forwards and upwards. The Kicker

position enables you to push away objects located in its path. Auto-balance

position makes it easier for you to negotiate certain obstacles.

In order to avoid excessive wear to the rubber pad, use the Auto-balance position

when you are rolling over rough surfaces.

8 Piloting

Rolling

Use the left-hand joystick to pilot the MiniDrone forwards or backwards.

Hold the left-hand joystick and tilt the smartphone to the left or right to

direct the MiniDrone to the left or right.

On the screen drag one finger from the center of the

joystick towards or in order to perform a quarter

turn to the left or right.

Drag one finger from the center of the joystick towards

in order to perform a half turn via the left or right.

Drag one finger from the center to the top part of the

joystick in order to perform the last pre-programmed acrobatic selected. For

further information, see Pre-programmed acrobatics.

Jumping

Set the MiniDrone to the Jumper position to perform jumps, then:

Press to perform a high jump,

Press to perform a long jump.

When the battery is low it is no longer possible to perform jumps.

Before performing a jump the spring of the MiniDrone needs to be compressed.

This compression may be performed just before a jump in which case a delay of

several seconds is necessary before executing.

You also have the option of anticipating the jump by dragging the key to the

left to compress the spring, whilst continuing to use the MiniDrone. Once the

cursor has returned to its original position you will be able to:

jump forwards without delay by pushing ,

jump upwards with a substantially reduced delay by pushing .

The jump function is prohibited as soon as you take hold of the MiniDrone .

Warning: Avoid having the MiniDrone fall from a height greater than 1m. In order to

limit the risk of damage we recommend that you descend in stages of

approximately 80cm at a time. Avoid making the MiniDrone jump if it is located on

a fragile surface (e.g. a glass coffee table).

9Piloting

Kicking

Set the MiniDrone to Kicker position to push an object away.

Before pushing an object away the spring of the MiniDrone needs to be

compressed. This compression may be performed just before kicking in which

case a delay of several seconds is necessary before executing.

You also have the option of anticipating the kick by dragging the key to the left

to compress the spring, while continuing to use the MiniDrone. Once the cursor

has returned to its original position you will be able to push the object away

without delay. To do so:

1. Ensure that the pad of the MiniDrone is in contact with the object to be kicked.

2. Press .

The Kick function is prohibited as soon as you take hold of the MiniDrone .

Pre-programmed acrobatics

Press to display the list of pre-programmed acrobatics.

Icon

Name

Description

Boost

The MiniDrone accelerates

Spin

The MiniDrone rotates on its axis for 2 seconds

Tap

The MiniDrone tapes its jump spring on the floor

Slow shake

The MiniDrone executes a quarter turn to the right, then to

the left, then right

Metronome

The MiniDrone rotates on its axis to the right, then to the

left

Ondulation

The MiniDrone performs an auto-balance position then

returns to normal position

Spin Jump

The MiniDrone rotates on its axis, then perform a jump

Slalom

The MiniDrone slaloms

Press the corresponding icon to launch the acrobatic you want.

10 Piloting

Press to interrupt acrobatics in progress.

To launch the last selected pre-programmed acrobatic,

drag one finger from the center to the top part of the left

joystick.

To reach the maximum speed accelerate until the speed

needle reaches its highest point then activate Boost ( ).

Battery

The

icon indicates the battery charge level of the MiniDrone. The battery life of

the MiniDrone is around 20 mins.

The number of jumps performed can have a considerable impact on the battery life

of the MiniDrone.

When the battery is low, the indicator

turns red and the MiniDrone emits a

series of beeps. It is then no longer possible to perform jumps.

Talking through the MiniDrone

The embedded speaker and microphone allow you

to speak through the MiniDrone.

1. Connect your smartphone earphones to your

phone.

> The icon located at the bottom right of the

screen turns .

2. Press to activate Walkie Talkie mode.

> The icon turns blue and the MiniDrone repeats what you say.

You cannot record a video and activate the Walkie Talkie mode simultaneously.

When you connect your earphones the video recording stops automatically the

icon turns black.

When the Voice transmission mode is activated the video record stops.

The earphones supplied with your smartphone must support hands-free calling for

this feature to work i.e. include a microphone.
