Parkside PDS 30 A1 Manuel utilisateur

EXTENDABLE CEILING SUPPORT ROD PDS 30 A1

EXTENDABLE CEILING SUPPORT ROD

Operating instructions

DECKENSTÜTZE

Bedienungsanleitung

ÉTAI

Mode d’emploi

PLAFONDSTEUN

Gebruiksaanwijzing

IAN 353782_2010

CV_353782_PDS30A1_LB6.indd 1-3 01.02.2021 09:17:24

GB/IE/NI Operating instructions Page 1

FR/BE Mode d'emploi Page 9

NL/BE Gebruiksaanwijzing Pagina 17

DE/AT/CH Bedienungsanleitung Seite 25

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of

the device.

Avant de lire le mode d'emploi, ouvrez la page contenant les illustrations et familiarisez-vous ensuite avec

toutes les fonctions de l'appareil.

Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het

apparaat.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen

Funktionen des Gerätes vertraut.

CV_353782_PDS30A1_LB6.indd 1-3 01.02.2021 09:17:24

CV_353782_PDS30A1_LB6.indd 4-6 01.02.2021 09:17:24

GB│IE│NI │ 1 ■

PDS 30 A1

Contents

Information on these operating instructions ........................2

Intended use ..................................................2

Technical details ...............................................2

Safety instructions .............................................3

Parts and operating components .................................4

Usage........................................................4

Storage ......................................................6

Maintenance ..................................................6

Cleaning......................................................6

Disposal ......................................................6

Disposal of the appliance .................................................. 6

Disposal of the packaging.................................................. 6

Service .......................................................7

Importer......................................................7

IB_353782_PDS30A1_LB6.indb 1 21.01.2021 15:10:55

■ 2 │ GB│IE│NI PDS 30 A1

Information on these operating instructions

Congratulations!

You have purchased a high-quality product. Familiarise yourself with the product

before using it for the ﬁrst time. To do this, read the following operating

instructions and the safety instructions thoroughly. Use the product only as

described and for the range of applications speciﬁed. Keep these operating

instructions in a safe place. Please pass this manual on to any future owner.

Intended use

The ceiling prop is intended exclusively for private use as a support during

overhead work in dry and interior construction. The prop is not designed for use

on stairways or sloping ground. Commercial or industrial use is not permitted. No

liability will be assumed in cases of improper use.

No liability will be assumed for damage caused by misuse or improper handling,

the use of force or unauthorised modiﬁcation. The risk is borne solely by the user.

Technical details

Dimensions

Height extensible between 137 cm and 290 cm

∅ Upper bar 12 mm

∅ Lower bar 25 mm

∅ Tube 32 mm

Weight

Net weight approx. 3.0 kg

Maximum load at an

inclination of 90° 30 kg

IB_353782_PDS30A1_LB6.indb 2 21.01.2021 15:10:56

GB│IE│NI │ 3 ■

PDS 30 A1

Safety instructions

CAUTION! RISK OF INJURY!

► Check the prop before every use to make sure it is

in perfect condition. If you notice any damage you

may no longer use the prop.

► Ensure that the prop locking screw is always tightly

fastened when under load and that both locking

bolts are completely engaged.

► Only use the prop on clean, non-slip and level

ground and in a stable position.

► Check the prop before every use to make sure it is in

perfect technical condition.

► Never remain under supported loads.

CAUTION! PROPERTY DAMAGE!

► Only use the prop for short-term erection and not for

permanent propping of ceilings, beams etc.

► Please note that the prop or the supporting material

can be damaged by high pressure.

► Never place more than 30 kg payload on the prop

at an inclination of 90°. At a lower inclination, the

max. load of the prop is lowered signiﬁcantly.

► Use the prop only at an inclination between 65°

and 90°.

► Never use the prop for purposes other than those

described in these instructions.

IB_353782_PDS30A1_LB6.indb 3 21.01.2021 15:10:56

■ 4 │ GB│IE│NI PDS 30 A1

Parts and operating components

(See fold-out page for illustrations)

The ceiling prop PDS 30 A1 consists of the following parts:

▯ Rubber pad 1

▯ Upper bar 2

▯ Pump lever 3

▯ Lower bar 4

▯ Locking screw 5

▯ Tube 6

▯ Locking bolt 7

▯ Locking lever 8

Usage

♦ Loosen the locking screw 5(Fig. A).

♦ If necessary, press the two locking bolts 7out of their detent (Fig. B) and

pull the lower bar 4out up to the required height until the rubber pad 1

is located under the load to be supported (Fig. C).

♦ Allow the two locking bolts 7 to engage completely in the tube 6detent.

Use the red line which marks the position of the locking bolts 7 (Fig. D)

on the lower bar 4as an orientation aid.

♦ If the length of the lower bar 4is insuﬃcient, push the locking lever 8

upwards (Fig. E) and pull the upper bar 2 out to the required height.

♦ Re-tighten the locking screw 5(Fig. F).

♦ To make ﬁne adjustments to the height, press the pump lever 3 several times

until the rubber pad 1is located ﬁrmly under the load to be supported

(Fig. G).

♦ To loosen and remove the prop, press the locking lever 8upwards until the

upper bar 2has been completely retracted (Fig. H).

♦ Loosen the locking screw 5(Fig. A).

♦ Hold the tube 6ﬁrmly with one hand and press the engaged locking bolts 7

out of their detent (Fig. B).

♦ Push the lower bar 4 back inside completely.

IB_353782_PDS30A1_LB6.indb 4 21.01.2021 15:10:56

GB│IE│NI │ 5 ■

PDS 30 A1

A B

IB_353782_PDS30A1_LB6.indb 5 21.01.2021 15:10:57

■ 6 │ GB│IE│NI PDS 30 A1

Storage

♦ Store the prop in a dry location and in a lying position so that it cannot fall

over.

Maintenance

♦ The prop is maintenance free.

Cleaning

♦ Clean the prop using a brush or a slightly damp cloth.

Disposal

Disposal of the appliance

Dispose of the product via an approved waste disposal company or your

municipal waste disposal facility. Please comply with all applicable regulations.

Please contact your waste disposal facility if you are in any doubt.

Your local community or municipal authorities can provide information on how to

dispose of the worn-out product.

Disposal of the packaging

The packaging materials have been selected for their environmental friendliness

and ease of disposal, and are therefore recyclable.

Dispose of packaging materials that are no longer needed in accordance with

applicable local regulations.

Dispose of the packaging in an environmentally friendly manner.

Note the labelling on the packaging and separate the packaging material

components for disposal if necessary. The packaging material is labelled with

abbreviations (a) and numbers (b) with the following meanings:

1–7: plastics

20–22: paper and cardboard

80–98: composites.

IB_353782_PDS30A1_LB6.indb 6 21.01.2021 15:10:57

GB│IE│NI │ 7 ■

PDS 30 A1

Service

Service Great Britain

Tel.: 0800 404 7657

E-Mail: [email protected]

Service Ireland

Tel.: 1890 930 034

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (oﬀ peak))

E-Mail: [email protected]

IAN 353782_2010

Importer

Please note that the following address is not the service address. Please use the

service address provided in the operating instructions.

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

IB_353782_PDS30A1_LB6.indb 7 21.01.2021 15:10:59
