Parkmate ClearView 7 Manuel utilisateur

7.0" Smart Screen Monitor

With 2-Channel Dash Camera

User Manual

ClearView 7 PM-72W

YOUR SAFETY COMES FIRST™

CONTENTS

Cautions 4

Warning 5

Micro SD card warning 5

1.0 Introduction 6

2.0 Package contents 6

3.0 Product overview 7

4.0 Micro SD card installation 9

5.0 Product installation 10

5.1 Windscreen suction mount...................10

5.2 3M adhesive suction mount..................12

6.0 Rear camera installation 14

6.1 Rear camera wiring ..............................16

6.2 Rear camera connection ......................16

6.3 Rear camera features ...........................17

7.0 Power connection 18

7.1 Auto power on/off ................................18

8.0 Micro SD card 19

8.1 Formatting inserted Micro SD card .......19

8.2 Micro SD card speciﬁcations ................19

9.0 Home screen 21

9.1 Dash camera........................................22

9.2 Apple CarPlay ......................................24

9.2.1 iPhone set-up ....................................24

9.3 Android Auto ........................................26

9.3.1 Android Auto set-up ..........................27

10.0 Audio output 29

10.1 PM-72W Speakers...............................29

10.2 Car Audio.............................................30

10.3 FM Transmitter .....................................32

10.3.1 FM Transmitter set-up........................33

10.4 AUX .....................................................33

11.0 Vehicles with bluetooth functionality 34

12.0 Settings 36

13.0 Reversing guidelines settings 37

14.0 Parking monitor 38

15.0 Troubleshooting 39

16.0 Warranty 40

CAUTIONS

• Please ensure you are using your Dash Camera

within your country's road laws.

• Please make sure you are familiar with your local

road legislation before use.

• The time and date need to be set before you

start recording.

• The notiﬁcations provided by this Dash Camera

are to be used as a guide only.

• Please drive according to the actual conditions

on the road.

• The system is for non-commercial use only, and

within the limits permitted by the relevant laws.

• Avoid using this product in the vicinity of any

devices that emit radio interference such as

microwave ovens.

• Please note that it is normal for this product to

get warm during use.

• Please ensure you maintain your focus on the

road and not on the monitor while driving.

WARNING

• Always power this product using the supplied

charger.

• Never dismantle this product.

• Do not dispose of this product in ﬁre.

• Disposal of this product should observe local

regulations.

MICRO SD CARD WARNING

• This product can only be used with Micro

SD Cards, Class 10 or above with 32GB to

256GB storage capacity. The Micro SD card

is not included and will need to be purchased

separately.

• Please format your Micro SD card before use.

(Please see Section 8.1 on page 19 for details

on how to format).

NOTE:

• Formatting the Micro SD card will delete all

information on the inserted Micro SD Card

• PM-72W does not support multi-touch on the

navigation menu. Please use the keys on the screen

for navigation.

1.0 INTRODUCTION

Thank you for purchasing a Parkmate ClearView 7

Wireless Smart Monitor with Dual Channel Dash

Camera. This product enables your smartphone

to be seamlessly connected via Bluetooth and

Wi-Fi for hands-free operation while driving. It

also comprises a built-in front Dash Camera and

a rear camera to facilitate hassle-free driving and

navigation.

Please read through these instructions before

attempting to install this product. For the latest

manual and product updates, please visit our

website at:

www.parkmate.com.au

www.parkmatehd.co.nz

2.0 PACKAGE CONTENTS

1. Smart 7.0” Monitor x1

2. FHD Rear Camera with 8m Cable x1

3. 3M Adhesive Mount x1

4. Magnetic Mount Holder x1

5. Phone Connection Adaptor x1

6. AUX Cable x1

7. User Manual x1

8. Suction Mount x1

9. Quick Start Guide x1

10. Anti Glare Protector x1

3.0 PRODUCT OVERVIEW

1. Display screen

2. AUX input

3. Micro SD card slot

4. Rear camera input

5. Microphone

6. Type-C connector (for power supply)

7. Front camera lens

8. 3M adhesive/magnetic mount

9. Speaker vent

10. Reset button - Press this button to restart the

device. (All pre saved information will be lost).

11. Power button - Long press to power on/off.

Short press to turn on/off display. (Recording

will continue).

4.0 MICRO SD CARD INSTALLATION

Please insert the memory card into the Micro SD

Card slot with the chip contact surface facing up.

Insert it until you hear a click sound.

5.0 PRODUCT INSTALLATION

There are two mounting options available for

installation:

1. Windscreen suction mount

2. 3M adhesive mount

5.1 WINDSCREEN SUCTION MOUNT

• Insert the magnetic mount holder at the back of

the ClearView 7.

• Clean the windscreen area where the suction

mount is to be mounted.

• Unlock the mount.

• Press the suction mount on the windscreen and

lock it.

Figure: 1
