Parker SciCon II Instructions de montage
SciCon II™
Conductivity/Temperature Monitor &
Single-Use Sensor
Installation, Operating & Maintenance Instructions
ENGINEERING YOUR SUCCESS.
2
Parker has a continuous policy of product development and although the Company reserves the right to change
specification, it attempts to keep customers informed of any alterations. This publication is for general information only and
customers are requested to contact your local Bioscience Filtration Sales and/or Technical Support contact for detailed information and advice
on a product’s suitability for specific applications. All products are sold subject to the company’s Standard conditions of sale.
SciCon II™is a registered trademark of Parker Hannifin Corporation.
3
Contents
Precautions .......................................................................................................................................................... 4
Introduction.......................................................................................................................................................... 6
Calibration............................................................................................................................................................ 6
Warranty............................................................................................................................................................... 7
Standards ............................................................................................................................................................. 7
Installation & Start-up........................................................................................................................................ 7
Maintenance & Cleaning .................................................................................................................................... 7
Quick Setup Guide............................................................................................................................................... 8
SciCon II Monitor Specifications ....................................................................................................................... 9
SciCon II Sensor Specifications....................................................................................................................... 10
Documentation Software for PC...................................................................................................................... 11
Part A
SciCon II Monitor Hardware Overview........................................................................................................... 13
Front Panel: Data Entry & Display.................................................................................................................. 14
Back Panel: Interface Options ......................................................................................................................... 15
SciCon II Single-Use Conductivity/Temperature Sensors.......................................................................... 18
Part B
SciCon II Monitor Software Overview ............................................................................................................ 19
Main Menu.......................................................................................................................................................... 20
Reduced Pump Pulsation: Improved Sensor Precision............................................................................... 22
SciCon II Printout Format ................................................................................................................................ 22
RS232 Settings .................................................................................................................................................. 22
Appendix A
Sensor Performance Data................................................................................................................................ 23
Revision History:
Revision: Description: Author:
A Original, Based on SciLog SciCon Manual Arthur Dawson
4
Precautions
READ this manual BEFORE operating or servicing this equipment.
FOLLOW these instructions carefully.
SAVE this manual for future reference.
DO NOT allow untrained personnel to operate, clean, inspect, service or tamper with
this equipment.
ALWAYS DISCONNECT this equipment from the power source before cleaning or
performing maintenance.
CALL Parker Customer Service for parts, information and service.
WARNING
DISCONNECT ALL POWER TO THIS UNIT BEFORE INSTALLING, SERVICING,
CLEANING OR REMOVING THE FUSE. FAILURE TO DO SO COULD RESULT IN
BODILY HARM AND/OR PROPERTY DAMAGE.
CAUTION
OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC SENSITIVE DEVICES.
WARNING
ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS EQUIPMENT. EXERCISE
CARE WHEN MAKING CHECKS, TEST AND ADJUSTMENTS THAT MUST BE MADE
WITH POWER ON. FAILING TO OBSERVE THESE PRECAUTIONS CAN RESULT IN
BODILY HARM.
WARNING
FOR CONTINUED PROTECTION AGAINST SHOCK HAZARD, CONNECT TO
PROPERLY GROUNDED OUTLET ONLY. DO NOT REMOVE THE GROUND PRONG.
CAUTION
USE ONLY CLASS 2 LISTED AC/DC POWER SUPPLIES WITH THIS DEVICE.
Parker part number 070-017TOR, OR ITS EQUIVALENT IS RECOMMENDED.
5
Précautions
LISEZ ce manual AVANT de faire fonctionner ou d’entretenir cet équipment.
SUIVEZ attentivement ces instructions.
CONSERVEZ ce manuel pour future référence.
NE LAISSEZ PAS du personnel non qualifié utiliser, nettoyer, inspecter, entretenir, réparer ou
manipuler cet équipement.
DÉBRANCHEZ TOUJOURS cet équipement de la source de courant avant de nettoyer ou d’exécuter
l’entretien.
APPELEZ PARKER pour pièces détachées, renseignements et entretien.
ATTENTION
DÉBRANCHEZ TOUT COURANT DE CETTE UNITÉ AVANT DE FAIRE
L’INSTALLATION, D’EFFECTUER L’ENTRETIEN, LE NETTOYAGE OU AVANT DE
RETIRER LE FUSIBLE. NE PAS OBSERVER CES PRÉCAUTIONS RISQUERAIT DE
CAUSER DES BLESSURES CORPORELLES OU/ET D’ENDOMMAGER
L’ÉQUIPEMENT.
PRUDENCE
SOYEZ PRUDENT LORSQUE VOUS MANIPULEZ DES APPAREILS SENSIBLES À
L’ÉLECTROSTATIQUE.
ATTENTION
AUTORISEZ SEULEMENT LE PERSONNEL QUALIFIÉ À ENTRETENIR CET
ÉQUIPEMENT. SOYEZ PRUDENT LROSQUE DES VÉRIFICATIONS, TESTS ET
AJUSTEMENTS DOIVENT ÊTRE EFFECTUÉS SOUS TENSIONS. NE PAS
OBSERVER CES PRÉCAUTIONS RISQUERAIT DE CAUSER DES BLESSURES
CORPORELLES.
ATTENTION
POUR ASSURER UNE PROTECTION CONTINUE CONTRE UNE DÉCHARGE
ÉLECTRIQUE, BRANCHEZ UNIQUEMENT SUR UNE PRISE CORRECTEMENT
RELIÉE Á LA TERRE. NE RETIREZ PAS LA FICHE DE TERRE.
PRUDENCE
Utilisez la classe 2 énumérés AC / DC avec cet appareil. Parker part number
070-017TOR, Ou son équivalent est recommandé.
6
Introduction
You will find the SciCon II system easy to use. The state-of-the-art hardware and software design of the
SciCon II allows you to measure and document the conductivity of many filtration / separation processes.
With proper maintenance, the SciCon II monitor will provide many years of excellent service and
performance.
Please read the following instructions carefully!
Inspections: Remove the products carefully from the shipping container. Check the contents against the
purchase order to verify that all parts are included and undamaged.
Please do the inspection now, even if the products are not used immediately. Many carriers must receive
damage claims within seven days of delivery. Please retain all packing material so the unit may be shipped
safely, if necessary.
If assistance is required, please contact us at:
Parker Hannifin Corporation Parker Hannifin Manufacturing Ltd
Bioscience Filtration Bioscience Filtration
2340 Eastman Avenue Durham Road
Oxnard, California, USA 93030 Birtley, Co. Durham
toll free: 877 784 2234 DH3 2SF, England
phone: +1 805 604 3400 phone +44 (0)191 4105121
fax: +1 805 604 3401 fax +44 (0)191 4105312
email: bioscience.na@parker.com email: bioscience.emea@parker.com
www.parker.com/bioprocessing www.parker.com/bioprocessing
Parker customer service personnel will be able to serve you more efficiently if you have the following
information:
Serial number and model name of the equipment
Installation procedure being used
Concise list of symptoms
List of operating procedures and conditions in use when problem arose
Calibration
The SciCon II Monitor is a calibrated device and is calibrated with test equipment that is traceable to SI
(International System of Units) through NIST (National Institute of Standards and Technology).
A Calibration Certificate is included with each unit and has a one-year expiration date.
It is highly recommended that the monitor be calibrated on an annual basis or more often if your Metrology
Department deems it necessary.
Parker provides this Calibration Service, complete with a new certificate, showing the “as found” and “as left”
data. You may initiate an order for this online at solutions.parker.com/service
If a quote is needed, please contact your local Parker Sales Representative.
7
Warranty
Country specific information can be found at: www.parker.com/termsandconditions
Standards
IEC 61326-1:2006, 2012/07/10 Ed:2
IEC 61000-3-2:2014 Ed.4
IEC 61000-3-3:2013 Ed.3
Conforms to UL STD 61010-1:2012 Ed.3+ R: 29Apr2016
Certified to CSA STD C22.2 No 61010-1-12:2012 Ed.3+U1; U2
Installation & Start-Up
Installation of the SciCon II must be carried out only by trained personnel in accordance with the relevant
regulations and this operation manual.
Make sure that the technical specifications and input ratings of the SciCon II are observed. See “SciCon II
Specifications”.
The protection provided by this equipment may be impaired, if the SciCon II is used in a manner or for
purposes not specified by the manufacturer, Parker Hannifin Corporation.
Maintenance & Cleaning
The SciCon II
Conductivity/Temperature Monitor is maintenance free. The single-use sensors come pre-
calibrated from the factory and require no maintenance.
To remove dust, dirt and stains, the outer surfaces of the SciCon II
Monitor may be wiped using a soft, non-
fluffing cloth moistened with water. If required, you may also use a mild detergent or 2-propanol.
The single-use sensors may be sanitized with 0.1 Molar NaOH, or 2-propanol. They may be autoclaved twice
or may be gamma irradiated.
8
Quick Set-up Guide
Unpack the system from the box. The contents include:
1 Monitor
1 sensor to monitor cables (CBL-007)
1 power supply cord with 3 adapter clips (US, EU and UK versions)
Set-up:
1. Connect the power supply using the applicable adapter clip (US is shown)
2. Connect the sensor cables to monitor ports
3. Connect sensors to cables
4. Connect power supply to outlet
This completes the SciCon II Quick Set-up.
9
SciCon II Monitor Specifications
Dimensions W: 6.0¨ (15.2 cm); Height 2.75¨ (7.0 cm); D: 5.5¨ (14.0 cm)
Weight 1.5 lb. (0.69 Kg)
Enclosure Molded Plastic / Stainless Steel
Electrical
Power 100-240 V, 60/50 Hz AC Adaptor, 12 VDC, 500 ma Output, Center
positive. Use only Class 2 listed power supplies.
Battery BR2032, used for internal clock only, not user serviceable.
Sensor Choice of five sizes: Luer, 3/8" Barb, 1/2” Barb, 3/4” Tri-Clamp (TC)
Sanitary and 1” Tri-Clamp (‘Ladish’) Sanitary.
I/O Port - 1 ‘C/T Sensor’ Female Amphenol connector
I/O Port - 2 Output’ - Female DB25, four TTL outputs for alarms, four 4-20 ma
Analog output signals, 18 bit resolution.
I/O Port - 3 ‘Printer / PC’ - DB9FM, RS-232 output
I/O Port - 3 ‘Serial I/O’ - Female DB9 (disabled).
I/O Port - 4 ‘12VDC 500ma’ - DC Input for AC Adaptor.
I/O Port - 5 ‘USB’ RS-232 output, same data as ”Printer /PC” port.
Software
Pressure Mode
Captures stored calibration from sensors, digital display of
conductivity and temperature, analog display of conductivity, with
four user-definable alarms.
Temperature 4 – 60° C
Altitude Up to 2000 Meters
IP Rating IP50, Indoor dry environments, unit is wipe-down only
Environmental Rel. Humidity 0 – 95%
Voltage Fluctuation allowed: +/- 10%
Pollution Degree: 2
10
SciCon II Sensor Specifications
Power 5 VDC provided by SciCon II® Monitor.
Fluid Connections
Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,
3/4” Tri-Clamp (TC) Sanitary and 1” Tri-Clamp
(‘Ladish’) Sanitary.
Wetted Materials
Polysulfone transfer tube, Silicone gasket, and a
Sensing element composed of four gold plated
pins.
The four pins are of synthetic origin and animal
derived material free to the best of our
knowledge. All other fluid path components are
animal derived component free.
The pins have not been tested to USP 88 Class
VI. All other fluid path components are USP 88
Class VI.
Sensor Type 4-Electrode Conductivity Cell, gold plated pins.
Conductivity Range 1 μS/cm to 200 mS/cm;
Resolution: 0.1 μS/cm.
Accuracy
High range:
With 95% confidence, measurement will be ±5%
of reading for 100 μS - 150 mS (extended to 200
mS)
Low range:
With 95% confidence, measurement will be ±4
μS for 0-100 μS
Temperature Range 0 – 50° C
Temperature Accuracy +/- 0.5° C (At ambient)
Temperature Probe Thermistor
Pre-Calibration 0.10 M KCL Solution, 12.88 mS at 25.0° C
Sensor Microchip EPROM, Stores Sensor ID, and
Calibration Factor.
Sensor Connector & Cables Lockable and Waterproof.
