Paragon EC72 Series Manuel d'instructions
EC72, EC72D
GENERAL INSTRUCTIONS
http://waterheatertimer.org/Paragon-timers-and-manuals.html#EC
Replacement timer
http://waterheatertimer.org/Intermatic-ET-series-timers-and-manuals.html#ET1700
MAPLE CHASE COMPANY PRODUCT WARRANTY
The products manufactured by Maple Chase Company and used in commer-
cial, industrial or institutional applications are warranted to be free from defects
in workmanship or material under normal use and service for a period of one
(1) year from the date of purchase by the end user (whether separately or as a
component of other products), or eighteen (18) months from the date of manu-
facture of the Maple Chase Company products, whichever is less.
Maple Chase’s obligation under this warranty is limited to replacing or repair-
ing, free of charge, any product returned to Maple Chase with transportation
charges prepaid, providing that Maple Chase’s examination discloses to its
satisfaction that such product is defective.
This warranty does not apply to damage caused by misuse, neglect, accident
or mishandling, or to products which have been subject to repair by anyone
other than Maple Chase Company, opened or taken apart, or which have not
been properly installed or have been used other than in accordance with Maple
Chase’s instructions.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OR MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR
PURPOSE.
IN NO EVENT SHALL MAPLE CHASE COMPANY BE LIABLE TO PUR-
CHASER OR ANY THIRD PARTY FOR ANY LOSS OF PROFITS OR OTHER
INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES WHATSOEVER.
PRODUCT IMPROVEMENTS
Maple Chase Company reserves the right under its product improvement poli-
cy to change construction or design without obligation regarding previous
models, and furnish equipment when so altered without reference to illustra-
tions or specifications used herein.
2
CONTENTS
INTRODUCTION . . . . . . 5
PROGRAMMING CAPABILITIES . . . . . . 6
SPECIFICATIONS. . . . . . 7
EC72 INSTALLATION, BATTERY and WIRING . . . . . 11
EC72D INSTALLATION, BATTERY and WIRING . . . . . 14
FRONT PANEL DESCRIPTION . . . . . 19
GENERAL PROGRAMMING INSTRUCTIONS . . . . . 20
MOMENTARY OPTION . . . . . 22
PROGRAMMING TIME, DAY, and DATE . . . . . 24
PROGRAMMING EVENTS . . . . . 26
OVERRIDE . . . . . 29
PROGRAMMING HOLIDAYS . . . . . 30
MAINTENANCE . . . . . 33
APPLICATIONS . . . . . 34
TROUBLESHOOTING . . . . . 45
GLOSSARY . . . . . 46
INDEX . . . . . 47
3
4
EC72, EC72D
Electronic Time Controls
DESCRIPTION
The EC72 and EC72D are seven-day, two-channel time controls that
will switch two different electrical circuits according to a pre-set, time-
of-day program, thus providing precise control of those circuits from a
central location and common time base. Once programmed, the con-
trols will automatically turn loads ON and OFF according to your
schedule, compensating for changes in Daylight Savings Time, adjust-
ing for Leap Year and altering ON/OFF events on designated holidays.
APPLICATIONS
The EC72 Series provides ideal control for indoor and outdoor lighting,
heating, ventilation and air conditioning, and motors, pumps and fans
in convenience and retail stores, commercial buildings, industrial facil-
ities, schools and churches. The Momentary Option, accessed by clip-
ping a jumper wire, provides a two-second momentary contact closure
ideal for ringing school bells and church chimes or operating latching
relays. The 12-volt DC model is ideal for battery-powered applications
such as security systems, remote deer feeders and air sampling
machines.
Both Models possess identical programming capabilities. The differ-
ences between the controls lie in housing - the EC72 is enclosed in a
NEMA 1 indoor metal case, while the EC72D is a DIN model, housed
in an indoor plastic case.
5
The EC72D typically is used in indoor or outdoor panels. The EC72 is
used for indoor stand-alone applications.
PROGRAMMING CAPABILITIES
• True 7-Day Programming - each day of the week can be uniquely
programmed.
• 16 Events per Channel - up to 16 ON/OFF events can be pro-
grammed for each channel.
• Repeat Programming - simplifies programming and increases the
total number of events through daily repetition of certain ONs and
OFFs; creates a maximum of 112 events per week per channel.
• Holiday Programming - twelve single-day holidays and two holiday
durations are programmable by date.
• Daylight Saving Time - can be programmed for automatic
changeover in the spring and fall.
• Automatic Leap Year Correction
• Momentary Option - any EC72 Series model can be converted to a
momentary output control by clipping a jumper wire; all events
become ON events of two-second duration. (See page 22.)
• Manual Override - temporarily reverses current output state; begins
immediately when initiated and remains in effect until overridden
again or until the next programmed event; each channel can be over-
ridden independently.
6
SPECIFICATIONS
ELECTRICAL
Power Requirements
MODEL VOLTAGE HERTZ VA REQ.
EC72/24 24 Vac (+ 10 - 15%) 50/60 4
EC72/120 100-120 Vac 50/60 4
EC72/240 200-240 Vac 50/60 4
EC72/277 277 Vac 50/60 4
EC72D/12 12 Vdc — —
EC72D/24 24 Vac (+ 10 - 15%) 50/60 4
EC72D/120 100-120 Vac 50/60 4
EC72D/240 200-240 Vac 50/60 4
Output - Two SPDT relays with contacts rated as follows:
VOLTAGE RESISTIVE INDUCTIVE H.P. PILOT DUTY
12 Vdc .1A-15 a — — —
24 Vac 15 A 15 A 1/10 60 VA
120 Vac 15 A 15 A 1/3 345 VA
240 Vac 10 A 8 A 1/2 450 VA
277 Vac 10 A 8 A — 450 VA
Wiring - Terminals can accommodate 14 to 24 AWG wire.
ACCURACY
Time-of-day - Maintained time is as accurate as line frequency.
Resolution - One minute for time-of-day and programmed ON/OFF
events.
7
SPECIFICATIONS continued
POWER OUTAGE CARRYOVER
Program and Time-of-Day Backup - 100 hours of carryover with a 9-
volt alkaline battery. 275 hours of carryover with a 9-volt lithium bat-
tery (Ultralife, U9VL.) Battery not provided. During a power outage, the
time and program are maintained, but the output relays remain de-
energized.
ENVIRONMENTAL
The EC72 Series should be mounted indoors in an environment that is
free from excessive contaminants such as oil, moisture and dirt or in
an appropriate outdoor panel. For outdoor use, an EC72D can be
mounted in a NEMA 3 enclosure 4010EC (X9092) which must be pur-
chased separately.
PHYSICAL
Mounting
EC72D — Surface or DIN-rail (35mm, DIN-EN50022) with plug-in base
EC72 — NEMA 1 case mounting
Weight —EC72D — Approximately 1 lb 3 oz (0.54 kg)
EC72 — Approximately 2 lb (0.90 kg)
Dimensions - EC72D — Width 10.5 cm (4 1/8")
Height 10.5 cm (4 1/8")
Depth 7.6 cm (3")
* EC72 — Width 10.8 cm (4 1/4")
Height 20.0 cm (7 7/8")
Depth 7.6 cm (3")
* outside dimensions, including hinge and bracket
8
Figure 1. EC72 Series Dimensions
9
EC72
EC72D
Figure 2. EC72 Installation
10
Spring
Clip
