Hotwire®TDM SDSL Termination Units

Models 8777 and 8779

Installation Instructions

Document Number 8700-A2-GN10-40

March 2003

Product Documentation Online

Complete documentation for this product is available at www.paradyne.com.

Select

Support

→

Technical Manuals

→

Hotwire DSL Systems.

Select the following document:

8700-A2-GB20

Hotwire TDM SDSL Termination Units, Models 8777 and 8779, User’s Guide

To order a paper copy of a Paradyne document, or to speak with a sales

representative, please call 1-727-530-2000.

Hotwire TDM SDSL Termination Units

Hotwire®8777 and 8779 Termination Units are circuit card assemblies that contain

eight Time Division Multiplexer Symmetric Digital Subscriber Line (TDM SDSL)

interfaces and eight DSX-1 or G.703 interfaces. When the Hotwire 87xx TDM

SDSL Termination Unit is used in a Hotwire 8610/8810 Digital Subscriber Line

Access Multiplexer (DSLAM) chassis or 8620/8820 GranDSLAM chassis, it

transports up to 2064 Kbps signals over traditional twisted-pair telephone wiring.

Model . . . Has eight . . . And eight . . .

8777 TDM SDSL ports DSX-1 ports

8779 TDM SDSL ports G.703 ports

2March 2003 8700-A2-GN10-40

Installation Overview

Installation and configuration of the Hotwire 87xx TDM SDSL Termination Unit

consists of:



Installing the Termination Unit in the DSLAM.



Connecting to the DTE.



Connecting to a Main Distribution Frame (MDF).



Providing initial unit identity information or changing existing identity

information.



Configuring your unit using the Configuration Edit menus.

Before you install the unit, read the

Important Safety Instructions

on page 11.

Be sure to register your warranty at www.paradyne.com/warranty.

Planning the Installation

Review the following list to help plan for the installation.

❑Obtain the applicable cables; refer to

Cables You Need

on page 2

❑Make sure the Hotwire DSLAM chassis is installed and power is supplied to

the chassis.

❑After the Hotwire 87xx TDM SDSL Termination Unit is installed, there are

configuration procedures that must be performed before you can begin to use

the termination unit. Refer to the User’s Guide for detailed configuration

procedures.

Cables You Need

The following standard cables are used with this product.

For the network connection:



Plug-ended Telco 50-pin cable for connection from the Hotwire DSLAM rear

connector to the Main Distribution Frame (MDF) or other demarcation point.

Refer to your DSLAM documentation for more information.

For the DTE connection:



The 50-pin plug to

— 16 BNC connectors (for G.703; Feature No. 8700-F1-508) or

— 8 RJ48 connectors (for DSX-1 or G.703; Feature Number 8700-F1-509).

For more information refer to

Connector Pin Assignments

in the User’s Guide.

8700-A2-GN10-40 March 2003 3

Installing TDM SDSL Cards

A Hotwire TDM SDSL Termination Unit can be installed, removed, and replaced

from a DSLAM chassis without disrupting service to the other cards in the chassis.

HANDLING PRECAUTIONS FOR

STATIC-SENSITIVE DEVICES

This product is designed to protect sensitive components from damage

due to electrostatic discharge (ESD) during normal operation. When

performing installation procedures, however, take proper static control

precautions to prevent damage to equipment. If you are not sure of the

proper static control precautions, contact your nearest sales or service

representative.

Procedure

To install the unit:

1. Determine in which slot the unit will be installed. Verify that cards in adjacent

slots have been fastened.

2. Remove the filler plate from the installation slot and store for possible later

use.

3. Insert the unit:

—ForaHotwire 8610 DSLAM or 8620 GranDSLAM chassis – Hold the

unit horizontally, with the component side facing up, and insert it into the

left and right card guides.

02-17132

STACK

POSITION

INPUT

ESDESD

48VDC CLASS 2

OR LIMITED

PWR SOURCE

48V

RTN

ABBAB

DC FUSES

T4A, MIN. 48V PWR

ALM

FAN

OUTIN SERIAL ALM INTF MCP/1 23

MCP/

DSL

MANAGEMENT 10 BASE T

8610

TDM

SDSL

SYSTEM

Alrm

Test

PORTS

4March 2003 8700-A2-GN10-40

— For a Hotwire 8810 DSLAM or 8820 GranDSLAM chassis

–

Hold the

unit vertically, with the component side facing right, and insert it into the

top and bottom card guides.

4. Slide the unit into the slot until the power and network connectors seat firmly in

the mating connectors on the backplane.

CAUTION:

Do not force the unit into the slot. This could damage the backplane

connectors. If the card does not seat properly, remove the card and

reinstall it. If it still does not seat properly, call your service

representative.

The termination unit performs a power-on self-test. All of the LEDs turn ON

and OFF briefly. When the self-test is completed successfully, the SYSTEM

OK LED begins to pulse.

5. If the LED is not pulsing, refer to

Monitoring and Troubleshooting

in the User’s

Guide.

6. Secure the unit by fastening the screws at each end of the faceplate.

ALARMS

Major MinorFanBA

POWER

MCC

SYSTEM

Alm

Test

ETHERNET

Coll

99-16544

MGT

SERIAL

MGT

10BT

ALARM

SLOTS 1 - 6

SLOTS 7-12

SLOTS 13-18

LINES

-48V (A)

-48V INPUT

-48V (B)

RET (A)

RET (B)

FR GND

246810 12 14 16 18

1357911 13 15 17

LAN/WAN SLOT

M/HDSL

8785

SYSTEM

Alrm

Test

SYNC PORT

DSL PORT

LINK-UP

8700-A2-GN10-40 March 2003 5

Connecting to the DTE

Connection to the eight DTE ports of the Hotwire 87xx TDM SDSL Termination

Unit is through the 50-pin interface connector on its faceplate. Refer to

Connector

Pin Assignments

in the User’s Guide.

Procedure

To connect the Hotwire 87xx TDM SDSL Termination Unit to your DTE:

1. Insert and fasten the hex-head jackscrew included with the unit into the top nut

(the nut nearest the LEDs) on the 50-position connector on the faceplate.

2. Connect the 50-position connector of the cable to the connector on the

faceplate. Align one end of the cable connector with the card connector, then

push on the cable connector until it seats.

3. Fasten the captive screw in the top of the cable connector to the hex-head

jackscrew.

4. Secure the bottom of the cable connector to the unit using a cable tie.

5. Feed the cable through the Cable Guide if it is installed. When all cables are

installed, anchor them with cable ties to the rack, DSLAM, or Cable Guide.

6. Connect the terminating connectors to your DTE.

Connecting to an MDF

You can connect the Hotwire DSLAM chassis containing the Hotwire 87xx TDM

SDSL Termination Unit to an MDF or other demarcation point. Do not connect it to

a POTS splitter.

Procedure

To connect the Hotwire chassis containing the unit to an MDF:

1. Plug the Telco 50-pin cable into the appropriate line port on the chassis:

—ForaHotwire 8610/8620 DSLAM chassis – Line connectors are

numbered 1–3 on the back of the chassis. After installing the connector,

insert a cable tie through the tie mount to hold the cable in place.

—ForaHotwire 8810/8820 DSLAM chassis

–

Line connectors are

numbered 1–18 on the back of the chassis.

2. Make sure the other end of the cable is connected to the appropriate MDF or

demarcation point.

Refer to

Connector Pin Assignments

in the User’s Guide for pinouts.

NOTE:

If connecting the Telco 25-pair, 50-pin cable to an MDF, a converter may be

necessary for terminating the other end of the cable on a punchdown block

before cross-connecting to an MDF.

6March 2003 8700-A2-GN10-40

Front Panel LEDs

The following table describes the meaning and states of the LEDs on the

Hotwire 8777 or 8779 TDM SDSL Termination Unit’s front panel. PORTS LEDs

represent the DTE or DSL ports depending on the Port LEDs selection on the

Control screen.

NOTE:

Use the

Main Menu

→

Control

→

Port LEDs

branch of the Asynchronous

Terminal Interface to change the definition of the DSX-1 or G.703 LEDs to

DSL PORT and vice versa.

Type LED LED is . . .* Indicating . . .

SYSTEM OK

(Green)

Off

Slow cycling

Normal operation; card functioning normally.

No power to card, or card failure.

Unit is in minimum mode and a download is

required.

Alrm

(Amber)

Off

Device failure, Power-On Self-Test (POST) is not

complete, or an alarm was reported on a DSL,

DSX-1, or G.703 port.

No alarms.

Te s t

(Amber)

Off

Slow cycling

Loopback test or 511 test pattern in progress.

No tests.

POST in progress.

PORTS

(when

DSX-1

G.703

selected)

1–8

(Green)

Off

Slow cycling

Fast cycling

Recoverable signal present on the DSX-1 or G.703

network.

No signal on the port.

Yellow Alarm Indication (DSX-1) or Remote Alarm

Indication (G.703).

An OOF, LOF, EER, or AIS condition exists.

PORTS

(when

DSL

selected)

1–8

(Green)

Off

Slow cycling

Fast cycling

DSL link is up.

DSL link is down.

DSL training in progress.

OOF condition.

* Slow Cycling: LED turns off and on in equal duration once per second.

Fast Cycling: LED turns off and on in equal duration 5 times per second.

TDM

SDSL

8777

00-16604-01

SYSTEM

Alrm

Test

PORTS

8700-A2-GN10-40 March 2003 7

Logging In to the Hotwire DSLAM

You can log in to the Hotwire DSLAM system using either a local

VT100-compatible terminal or a remote Telnet connection.

After you enter your user ID and password, the system displays the Hotwire

Chassis Main Menu. See your DSLAM Management Communications Controller

(MCC) card documentation for information about selecting the unit from the MCC

card selection screen.

Asynchronous Terminal Interface Menu

The following illustration shows the paths to the Hotwire 87xx TDM SDSL

Termination Unit’s various ATI screens.

Main

Status Test

System and

Test Status

Performance

Statistics

Display

LEDs

Identity

Network

Error

Statistics

Network

Performance

Statistics

Configuration Control

Change

Identity

dminister

Logins

Download

Code

pply

Download

Port

LEDs

03-16607-04

Reset

utoRate

DSX-1/G.703

Statistics

Reset

Device

Default Factory

Configuration

Loader

Current Configuration

Edit/Display

Network

DSX-1/

G.703

Copy

Ports

System

Options

Management

and

Communication

Telnet

Session

General SNMP

Management

SNMP NMS

Security

SNMP

Traps

System

Clock

Cross

Connect

Set Cross

Connect Mode

ssign

Time Slots

Network and

DSX-1/G.703

Tests

Device

Tests

bort

Tests

Current

Network

Performance

Statistics

Inband

Management

Statistics

Inband

Management

Channel

Inband

Management

8March 2003 8700-A2-GN10-40

Entering Identity Information

After accessing your unit for the first time, use the Change Identity screen to

determine SNMP administrative system information that will be displayed on the

Identity screen of the Status branch. To access the Card Identity screen, follow this

menu selection sequence:

Main Menu

→

Control

→

Change Identity

Configuring the Unit

Configuration option settings determine how the unit operates. Use the

Configuration branch of the termination unit’s menu to display or change

configuration option settings.

The unit is shipped with factory settings in the Default Factory Configuration area.

If the factory default settings do not support your network’s configuration,

customize the configuration options for your application.

Accessing and Displaying Configuration Options

To display the configuration options, you must first load a configuration option set

into the edit area.

To load a configuration option set into the configuration edit area, follow this menu

selection sequence:

Main Menu

→

Configuration (Load Configuration From)

Make a selection by placing the cursor at your choice and pressing Enter.

If you select . . . Then . . .

Current

Configuration

The selected configuration option set is loaded and the

Configuration Edit/Display menu screen appears.

Configuration

Loader

The Configuration Loader screen is displayed allowing you to

upload or download configurations from a TFTP server.

Default Factory

Configuration

The default factory configuration is loaded and the Configuration

Edit/Display menu screen appears.

8700-A2-GN10-40 March 2003 9

Configuration Edit/Display

The Configuration Edit/Display screen is displayed when the current, customer, or

default configuration is loaded and allows groups of configuration options to be

displayed. To access the Configuration Edit/Display screen, follow this menu

selection sequence:

Main Menu

→

Configuration

→

Current Configuration

– or –

Main Menu

→

Configuration

→

Default Factory Configuration

NOTE:

The SNMP NMS Security Options screen is not available in IP Conservative

mode.

For more information on configuration option settings, see

Configuration Options

in the User’s Guide.

Select . . . To Access the . . . To Configure the . . .

Network Network Interface Options DSL interface ports.

DSX-1

G.703

DSX-1 Interface Options

G.703 Interface Options

DSX-1 interface ports

(Model 8777).

G.703 interface ports

(Model 8779).

Copy Ports Copy Ports Options DSL network and DTE

interface ports by copying

options from port to port.

System Options System Options General system options of

the unit.

System Clock System Clock Options LTU system clock options.

Cross Connect



Cross Connect Mode Options



Assign Time Slots Options

DS1 and DS0 cross-connect

ports.

Management

and

Communication



Telnet Session Options



General SNMP Management Options



SNMP NMS Security Options



SNMP Traps Options



Inband Management Channel

Options

Management support of the

unit through SNMP, Telnet,

and the Inband

Management Channel.

10 March 2003 8700-A2-GN10-40

Configuring Cross-Connections

The Hotwire cross-connect system allows you to connect the DSX-1 or G.703

ports to the DSL ports in a variety of ways:



DS1 Bypass mode – The entire DSX-1 or G.703 interface is connected to the

DSL interface.



DS1 Cross-Connect mode – The entire DSX-1 or G.703 interface is

connected to the DSL interface through cross-connect circuitry. Ports can be

switched through software.



DS0 Cross-Connect mode – Any time slot of any DSX-1 or G.703 interface

can be connected to any time slot of any DSL interface. Time slots can be

individually allocated for voice or data.

Configuration of the cross-connections consists of the following steps:

❑Determine how the ports will be connected and configured.

❑On the Network Interface Options screen, enable if necessary the DSL ports

that will be in the cross-connection. The ports are enabled by default.

❑On the DSX-1 or G.703 Interface Options screen, enable the DSX-1 or G.703

ports that will be in the cross-connection. For G.703, specify whether Time

Slot 16 is used for signaling (voice mode).

❑On the System Clock screen, configure the system clock.

❑On the Cross-Connect Mode screen:

— Define all DS1 Bypass ports

— Define all DS1 Cross-Connect ports

— Define all DS0 Cross-Connect ports

❑On the Assign Time Slots screen, configure the DS0 cross-connections.

IMPORTANT:

All DSL time slots are available for cross-connect regardless of DSL line

rate, but all time slots are only available for data transport if the DSL line

rate is the full rate (1552 for DSX-1 or 2064 for G.703). Only configure

time slots that will be used.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Paradyne Multiplexeur

Paradyne

Paradyne Hotwire 8776 Manuel utilisateur

Paradyne

Paradyne HotWire 8600 Manuel utilisateur

Paradyne

Paradyne Hotwire 8776 Manuel utilisateur

Paradyne

Paradyne BitStorm 4800 Express Manuel utilisateur

Paradyne

Paradyne Hotwire 8799 Manuel utilisateur

Paradyne

Paradyne Hotwire 8774 Manuel utilisateur

Paradyne

Paradyne MUM-2000 Manuel utilisateur

Paradyne

Paradyne 8540 Manuel utilisateur

Paradyne

Paradyne Hotwire 8810 Manuel utilisateur

Paradyne

Paradyne SIM2000 Manuel utilisateur

Paradyne

Paradyne Hotwire 8786 Manuel utilisateur

Paradyne

Paradyne TIM1500 Manuel utilisateur

Paradyne

Paradyne Hotwire 8774 Manuel utilisateur

Paradyne

Paradyne Hotwire 8786 Manuel utilisateur

Paradyne

Paradyne Hotwire 8799 Manuel utilisateur

Paradyne

Paradyne COMSPHERE 3611 Manuel utilisateur

Paradyne

Paradyne BitStorm 4800 Express Manuel utilisateur

Paradyne

Paradyne HotWire 8800 DSLAM Manuel utilisateur

Paradyne

Paradyne HOTWIRE 8610 DSLAM Manuel utilisateur

Paradyne

Paradyne BitStorm 2461 Manuel utilisateur

Paradyne

Paradyne HOTWIRE 8610 DSLAM Manuel utilisateur

Paradyne

Paradyne 9161 Single T1 Manuel utilisateur

Manuels Multiplexeur populaires d'autres marques

Campbell

Campbell AM416 Manuel utilisateur

Panasonic

Panasonic WJFS616 - SWITCHER Manuel utilisateur

Lanex

Lanex TM-77 Manuel utilisateur

Bosch

Bosch VSS8394/01T Manuel utilisateur

Quark-Elec

Quark-Elec QK-A035 Manuel utilisateur

ADTRAN

ADTRAN Frameport 768 Manuel utilisateur

Elo TouchSystems

Elo TouchSystems E247 Manuel utilisateur

RFL Electronics

RFL Electronics 9508D UCC Manuel utilisateur

Miranda

Miranda AMX-101i Mode d’emploi

ShipModul

ShipModul MiniPlex-AIX NMEA-0183 Manuel utilisateur

GE StoreSafe SDVR-10 Manuel utilisateur

Pickering

Pickering 40-613 Manuel utilisateur

Pickering

Pickering 40-667C Manuel utilisateur

American Fibertek

American Fibertek MTX-8410C Manuel utilisateur

ADC

ADC HiGain ELU-319 5E Manuel utilisateur

American Fibertek

American Fibertek MTX-8810C-SL Manuel utilisateur

Pickering

Pickering PXI 40-740 Manuel utilisateur

Viessmann

Viessmann 5229 Manuel utilisateur
