Quick Reference Guide for

Number Display Service

KX-PW30CL2

KX-PW10CL2

Using a Number Display Service

This unit can work with NTT’s number display service. A contract with NTT (charge fee) and setting this unit are required.

Application for NTT contract

The line is constructed by NTT, and the service begins.

After 2-3 days (normally)

When you do not want to display your telephone number to the other party when calling, there are two methods available.

First choose the method and then you must apply to NTT.

1. Displaying for each call Up until now, the telephone number has been displayed to the other party.

To not display the telephone number, dial 184 before the other party’s

telephone number. The number will not be displayed for only that call.

2. Displaying for each line Up until now, the telephone number has not been displayed to the other party

for all calls. To display the telephone number, dial 186 before the other party’s

telephone number. The number will be displayed for only that call.

How the number is displayed

Set this unit to “ アリ ” (ON).

Number Display Service Functions

Setting up

1. Press (function).

2. Press .

3. Press (select) to select “ アリ ” (ON).

Searching for a phone number

くるくる電話帳

132

465

798

電話帳表示切換

ストップ

くるくる電話帳

くるくる電話帳 くるくる電話帳

1. Press (received call memory).

3. When finished, press (stop).

Rotate  (search dial) to the right.

(Rotating to the right will change the display from

the latest call and to the left, from the oldest one.)

Note:

If you do not set the unit to “ アリ” (ON), the first

bell will ring shorter than usual, even if you receive

the service.

When you cancel the service, select “ ナシ” (OFF)

in step 3.

●

“ ”

means new calls which have not been

checked.

Each time you press  (operation guide),

the display will change from the number to the

date and time.

Up to 14 digits can be displayed.

Note:

In step 1, if there are no calls in memory,

will be displayed.

When there are more than 30 calls in memory, they

will be erased from the oldest one, even if you have

not viewed them.

If the caller subscribes to a Dial-in Service,

- One of the numbers contacting the Dial-in Service

will be displayed.

- When subscribing to a Dial-in Service using

several telephone lines in a company, the phone

number displayed depends on the line being used.

The date and time of the call will be stored using the

time programmed in the unit. Program the correct

time.

●



●

Using the Number Display Service, this unit can store

phone numbers and the date and time of the calls in

memory. [Up to 30 calls, except 99 calls, can be stored

in (search dial).] By using (search dial), you

can search for the phone number, and the date and

time of a call on the display of the unit.

[When you have not answered (a) call(s)]

機能

1 3

選択

登録

4. Press (record).

ストップ

5. Press (stop).

ストップ

着信メモリー

Subscribe to NTT, and then set the display to

“ アリ” (ON).

NO.テ

ﾞ

ィスフ°レイ=アリ



チャクシンカ

ﾞ

アリマシタ

NO.テ

ﾞ

ィスフ°レイ=ナシ

機能

Changes each time you

press (function).

着信メモリー

チャクシンカ

ﾞ

アリマセン

132

465

798

ストップ

選択 機能登録



OFF



Number Display Service Functions

3Sending a fax with 

(search dial)

Calling with (search dial) 4

くるくる電話帳

くるくる電話帳 くるくる電話帳

Note:

You can also call using the following procedure.

1. Lift the handset, or press (speakerphone).

- Dial 184 or 186, if required.

2. Press (received call memory).

3. Rotate (search dial) until the number you

want to dial is displayed.

4. Press (start/copy) while a long beep is 

heard.

- If you dialed 184 or 186, press

(start/copy) when 3 beeps are heard.

●

Note:

If the line is busy, the unit will automatically redial

the number up to three times at one minute

intervals.

(Automatic Redialing)

If you want to dial 184 or 186 to send a fax, proceed

as follows.

1. Insert the document, and then lift the handset.

2. Dial 184 or 186.

3. Press (received call memory).

4. Rotate (search dial) until the number you

want to dial is displayed.

5. Press (start/copy) when 3 beeps are heard.

6. Press (start/copy) again.

●

1. Press (received call memory).

Rotate (search dial) until the number you

want to dial is displayed.

●Up to 14 digits can be displayed.

2. Insert the document (a beep will be heard), and

then select the resolution by pressing

(resolution).

●Insert the document FACE DOWN.

●Insert up to 5 sheets at a time.

3. Lift the handset, or press (speakerphone).

●You can also dial by pressing (start/copy).

(If a document is inserted, the unit will send a 

fax.)

5.Press (start/copy).

After the message is displayed, the unit will start to

send the fax.

4. Rotate (search dial) until the number you

want to dial is displayed.

4. Talk to the other party.

1. Open the document tray and adjust the guides.

3. Press (received call memory).

5. When finished, replace the handset, or press

(speakerphone).

スタート／コピー

スピーカーホン

Handset



スタート／コピー

スピーカーホン

画質

ｶﾞｼﾂ=ﾌﾂｳ

ｶﾞｼﾂ=ﾁｲｻｲ

ｶﾞｼﾂ=ｼｬｼﾝ

STANDARD

FINE

HALF TONE

くるくる電話帳

着信メモリー



画質

スタート／コピー

Document Tray

Handset

Adjust the

guides.

くるくる電話帳

着信メモリー

Number Display Service Functions

Printing a caller list

ex. If you receive a Dial-in Service:

1. Press (received call memory).

2. Press (start/copy).

3. When finished, press (stop).

Note:

When there are more than 30 calls in memory,

the unit will erase calls from the oldest one.

If you press (stop) in step 3, all calls will be noted

as viewed ones, so “ ” will not appear on the display.

will also not be displayed.

●

ストップ

スタート／コピー

132

465

798

ストップ

スタート／コピー

着信メモリー 着信メモリー

チャクシン

ｶﾞ

アリマシタ



No. 年月日  時分 相手局名 ダイヤルイン

1997.12.31

1997.12.30

15：30

13：54

8：30

09876543・・

01234567・・

コウシュウテﾞンワ

4321(オヤキ)

4320(コキ1)

4321(オヤキ)

着信

リスト 1998.1.1 12：00

マーク：ミカクニンノチャクシンメモリー

■No., 年月日(year/month/day), 時分(hour/minute)

The unit prints the date and time of the received calls from the most recent call. (up to 30 calls)

■ダイヤルイン(Dial-in)

The unit prints 4 digits after the phone number which contacts the Dial-in Service, whether

it was a voice or a fax call, and if the call was received by the main unit or the handset.

●If you do not subscribe to a Dial-in Service, disregard this section.

■相手局名(caller's phone number)

The unit prints the phone number of the caller. If the caller’s name or phone number cannot be

displayed, a message will be printed out instead. “ ”means the call has not been checked.

Up to 20 digits, including “ ”, can be printed.

Number Display Service Functions

Erasing a phone number

1. Press (received call memory).

2. Rotate (search dial) until the number you want

to erase is displayed.

3. Press (erase).

4. Press (start/copy).

5. When finished, press (stop). 

Erasing all of the phone numbers

消去

くるくる電話帳

ストップ

スタート／コピー

132

465

798

ストップ

消去

くるくる電話帳

スタート／コピー

着信メモリー

132

465

798

消去

スタート／コピー

着信メモリー

1. Press (received call memory).

3. Press (start/copy).

2. Press (erase).

消去

スタート／コピー

着信メモリー

You can erase phone numbers of the callers stored in the memory.
