Panasonic KX-PRD262 Manuel utilisateur

PNQW3918ZA CC1213WK0

Printed in Malaysia

Connections

Base unit

Run the telephone line cord ( ) and AC adaptor ( ) through the slot of the stand.

Connect the telephone line cord ( ) and AC adaptor ( ) to the jacks at the bottom of the unit until you

hear a click.

Connect the AC adaptor to the power outlet.

Connect the telephone line cord to the single-line telephone jack (RJ11C) until you hear a click.

A DSL/ADSL filter (not supplied) is required if you have DSL/ADSL service.

Note:

Use only the supplied Panasonic AC adaptor PNLV238.

Charger

Connect the AC adaptor plug to the charger until

you hear a click.

Connect the AC adaptor to the power outlet.

Note:

Use only the supplied Panasonic AC adaptor

PNLV233.

Model No. KX-PRL262/KX-PRD262

Quick Guide

PRL262_PRD262_QG(en).fm Page 1 Wednesday, December 18, 2013 11:04 AM

– 2 –

Battery installation/Battery charging

Charge for about 7 hours.

Note:

LUSE ONLY rechargeable Ni-MH batteries AAA (R03) size

().

LDo NOT use Alkaline/Manganese/Ni-Cd batteries.

LConfirm correct polarities (S, T).

LFollow the directions on the display to set up the unit.

LConfirm “Charging”is displayed

()

Operating tips

Soft keys

By pressing a soft key, you can select the feature

shown directly above it on the display. Pay attention

to the display to see what functions the soft keys are

assigned during operation.

Navigator key

−{^}, {V}, {<}, or {>}: Scroll through various lists

and items.

−v(Volume: {^} or {V}): Adjust the receiver or

speaker volume while talking.

−{<}k: View the phonebook entry.

−{>}REDIAL: View the redial list.

−{V} CID (Caller ID): View the caller list.

{V}

{^}

{<}{>}

PRL262_PRD262_QG(en).fm Page 2 Wednesday, December 18, 2013 11:04 AM

– 3 –

Date and time (Handset)

1{MENU}(right soft key) (1)1

2Enter the current month, date, and year. s{OK}

3Enter the current hour and minute (12-hour clock format).

4*: Select “AM”or “PM”. s{SAVE}s{OFF}

Recording your greeting message for the answering system

for the landline (Handset)

If you use a pre-recorded greeting message, you do not need to record your own greeting

message.

1{MENU}(right soft key) (3)2s{r}: “Yes”s{SELECT}

2After a beep sounds, hold the handset about 20 cm (8 inches) away and speak clearly into

the microphone (2 minutes max.).

3Press {STOP}to stop recording. s{OFF}

Link to cell

You can connect your base unit and cellular phone using Bluetooth®wireless technology, so that

you can make or answer cellular calls using your phone system. For more details, please visit our

Web site: http://www.panasonic.com/link2cell

1Cell line

2Cell phone service providers

Trademarks

LThe Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,

and any use of such marks by Panasonic Corporation is under license.

LAll other trademarks identified herein are the property of their respective owners.

PRL262_PRD262_QG(en).fm Page 3 Wednesday, December 18, 2013 11:04 AM

– 4 –

Pairing a Bluetooth cellular phone

1Handset:

For CELL 1: {MENU}(right soft key) (6241

For CELL 2: {MENU}(right soft key) (6242

LAfter the corresponding CELL indicator on the base unit starts flashing, the rest of the

procedure must be completed within 5 minutes.

2Your cellular phone:

While the corresponding CELL indicator is flashing, follow the instructions of your cellular

phone to enter the pairing mode.

LDepending on your cellular phone, it may ask you to enter the Bluetooth PIN (default:

“0000”). If your cellular phone shows PassKey confirmation on its display, follow the

directions to proceed.

3Handset:

Wait until a long beep sounds.

LIt may take more than 10 seconds to complete pairing.

LWhen the corresponding CELL indicator lights up, the cellular phone is connected to the

base unit. You are ready to make cellular calls.

4{OFF}

Note:

LMake sure that your cellular phone is set to connect to this product automatically. Refer to your

cellular phone’s operating instructions.

Base unit: CELL indicators

Status Meaning

On A cellular phone is connected. Ready to make/receive cellular

calls.

Flashing −The cellular line is in use.

−Phonebook entries are being copied from a cellular phone.

−The base unit is searching for the paired cellular phone.

−The base unit is pairing a cellular phone.

−A cellular call is put on hold.

Flashing rapidly A cellular call is being received.

Light off −A cellular phone is not paired to the base unit.

−A cellular phone is not connected to the base unit.

Handset: Link to cell display items

WA cellular line is in use.

LWhen flashing: The cellular call is put on hold.

LWhen flashing rapidly: A cellular call is being received.

A cellular phone is connected.*1 Ready to make/receive cellular calls.

LWhen turned off: A cellular phone is not connected to the base unit.

*1 Corresponding cellular line(s) is(are) indicated next to the item.

uv −A cellular call is being done on that line.

−The cellular line is selected for the setting.

Link to cell

PRL262_PRD262_QG(en).fm Page 4 Wednesday, December 18, 2013 11:04 AM

– 5 –

Connecting/disconnecting the cellular phone

Auto connection to the Bluetooth devices (cellular phones)

The unit connects to the Bluetooth devices at regular intervals if the connection is lost. To change

the interval (default: “1 min”), see the operating instructions.

LWhen you are using a cellular line, the base unit loses its connection from other Bluetooth

devices (cellular phone). To automatically resume the connection to cellular phones, leave the

auto connection on.

Connecting/disconnecting the cellular phone manually

If you will not be using the paired cellular phone’s link to cell feature temporarily (for example, you

do not want the unit to ring when your cellular line receives a call), you can disconnect your

cellular phone from the base unit. If you want to use it again, reconnect the cellular phone to the

base unit.

LEven if a paired cellular phone was disconnected from the base unit, if it is brought within the

base unit’s range during the auto connection interval, it may automatically connect to the base

unit.

LA disconnected cellular phone is not unpaired from the base unit, so pairing it to the base unit

again is unnecessary.

Base unit:

To connect

Press {}and wait for a few seconds for the cellular phone and base unit to connect to each

other.

Handset:

1To connect/disconnect:

For CELL 1: {MENU}(right soft key) (6251 (A long beep sounds.)

For CELL 2: {MENU}(right soft key) (6252 (A long beep sounds.)

2{OFF}

Cellular line only mode (If you do not use the landline) (Handset)

If you do not use the landline, set the cellular line only mode to use this unit more conveniently.

If you turn on the “Cell line only mode”, disconnect the telephone line cord from the base

unit. Otherwise the “Cell line only mode”cannot be activated.

1{MENU}(right soft key) (157

2To turn on:

{r}: “On”s{SELECT}s{r}: “Yes”s{SELECT}

To turn off:

{r}: “Off”s{SELECT}

Link to cell

PRL262_PRD262_QG(en).fm Page 5 Wednesday, December 18, 2013 11:04 AM

– 6 –

Basic operations

Making/Answering calls (Handset)

Making cellular calls 1Dial the phone number. s{CELL}

LWhen the cellular line only mode is set, you can also press

{C}/{s} instead of {CELL}.

LWhen only 1 cellular phone is paired, the unit starts dialing.

2When 2 cellular phones are paired:

{r}: Select the desired cellular phone. s{SELECT}

Making landline calls Dial the phone number. s{C}/{s}

Answering calls {C}/{s}/{w}

To hang up {OFF}

To adjust the receiver/

speaker volume

Press {^} or {V} repeatedly while talking.

Making a call using the

redial list

1{>}REDIAL s{r}: Select the desired entry.

2To make a cellular call:

When only 1 cellular phone is paired: {CELL}

When 2 cellular phones are paired:

{CELL}s{r}: Select the desired cellular phone. s

{SELECT}

To make a landline call:

{C}

To adjust the ringer volume

(cellular line/landline)

Press {^} or {V} repeatedly to select the desired volume while

ringing.

PRL262_PRD262_QG(en).fm Page 6 Wednesday, December 18, 2013 11:04 AM

– 7 –

Phonebook (Handset)

Adding entries 1{<}

s{MENU}

2{r}: “Add new entry”s{SELECT}

3{r}: “(Name)”s{SELECT}

4Enter the party’s name (16 characters max.). s{OK}

5{r}: Select the desired phone number location. s

{SELECT}

6Enter the party’s phone number (24 digits max.). s{OK}

7{r}: Select the desired label. s{SELECT}

LTo store 2 or 3 phone numbers, repeat steps 5-7.

8{r}: Select the current setting of the group (default: “Home”).

s{SELECT}

9{r}: Select the desired group. s{SELECT}

10{r}: “<Save>”s{SELECT}s{OFF}

Making calls 1{<}

s{r}: Select the desired entry.

2To make a cellular call:

When only 1 cellular phone is paired: {CELL}s{r}: Select

the desired phone number. s{CALL}

When 2 cellular phones are paired:

{CELL}s{r}: Select the desired phone number. s

{CALL}s{r}: Select the desired cellular phone. s

{SELECT}

To make a landline call:

{C} s{r}: Select the desired phone number. s{C}

Answering system for the landline (Handset)

Listening to messages To listen to new messages:

{MENU}(right soft key) (323

To listen to all messages:

{MENU}(right soft key) (324

Basic operations

PRL262_PRD262_QG(en).fm Page 7 Wednesday, December 18, 2013 11:04 AM

– 8 –

Using Bluetooth devices

Copying phonebook entries from a Bluetooth cellular phone (phonebook transfer)

You can copy phonebook entries from the paired cellular phones or other cellular phones (not

paired) to the unit’s phonebook.

1Handset: {MENU}(right soft key) (618

2Handset:

To copy from paired cellular phones:

{r}: Select the desired cellular phone. s{SELECT}

LCopied items are stored to the group (“Cell 1”or “Cell 2”) which the cellular phone is

paired to.

To copy from other cellular phones (not paired):

{r}: “Other cell”s{SELECT}s{r}: Select the group you want to copy to. s

{SELECT}

3When “Use the cell to transfer phone book”is displayed: Go to step 4.

When “Select mode”menu is displayed:

{r}: Select “Auto”or “Manual”. s{SELECT}

“Auto”: Download all entries from the cellular phone automatically. Go to step 5.

“Manual”: Copy entries you selected.

L“Select mode”menu is displayed only when the cellular phone supports PBAP (Phone

Book Access Profile) for Bluetooth connection.

4Cellular phone:

Follow the instructions of your cellular phone to copy phonebook entries.

LFor other cellular phones (not paired), you need to search for and select the base unit. The

Bluetooth PIN (default: “0000”) may be required. If your cellular phone shows PassKey

confirmation on its display, follow the directions to proceed.

LThe entries being copied are displayed on the handset.

5Handset:

Wait until “Completed”is displayed. s{OFF}

PRL262_PRD262_QG(en).fm Page 8 Wednesday, December 18, 2013 11:04 AM

– 9 –

Playing music from a Bluetooth device

This feature allows you to:

−use a Bluetooth device to play music through the base unit’s speaker.

−use the handset as a remote control when playing music from a Bluetooth device through the

base unit’s speaker.

Playing music through the base unit’s speaker

1Bluetooth device:

Use your Bluetooth device’s media player app to play music.

LThe music is played through the base unit’s speaker.

2Base unit:

Adjust the speaker volume by pressing

{

}

{

}

Using the handset as a remote control

Important:

LConfirm in advance that your Bluetooth device’s media player app is running.

1{MENU}(right soft key) ss{SELECT}

LThe music is played through the base unit’s speaker.

2Press {^} or {V} to adjust the base unit’s speaker volume.

Using Bluetooth devices

PRL262_PRD262_QG(en).fm Page 9 Wednesday, December 18, 2013 11:04 AM

– 10 –

Frequently asked questions

Question Cause/solution

Why is _displayed? LThe handset is too far from the base unit. Move closer.

LThe base unit’s AC adaptor is not properly connected. Reconnect

AC adaptor to the base unit.

LThe handset is not registered to the base unit. Register it.

1Handset: {MENU}(right soft key) (13)

2Base unit: Press and hold {x} for about 5 seconds.

3Handset: Press {OK}, then wait until a long beep sounds.

Why am I unable to pair a

cellular phone to the base

unit?

Depending on the compatibility of the cellular phone, you may not be

able to

pair

it to the base unit. For more information, please visit

http://www.panasonic.com/link2cell

LConfirm that the Bluetooth feature of your cellular phone is turned

on. You may need to turn this feature on depending on your

cellular phone.

How can I increase the

handset volume level?

LPress the navigator key {^} repeatedly while talking.

Why is the conversation

noisy or cutting off?

LTry to relocate the base unit so that distance to the handset is

minimized.

LIf the same problem occurs even if the handset is next to the base

unit, please visit: http://www.panasonic.com/support

Can I add another

accessory handset to my

base unit?

LYes, you can add up to 6 handsets (including the handset(s) sold

with your base unit) to a single base unit.

LTo purchase additional accessory handset(s) (KX-PRLA20),

please visit: http://www.pstc.panasonic.com

TTY users (hearing or speech impaired users) can call 1-866-605-

1277.

Can I keep the batteries

charging all the time?

LYou can leave the handset on the base unit or charger anytime.

This will not harm the batteries.

How can I answer a call

waiting call (2nd call)?

LPress {CALL WAIT}when you hear the call waiting tone.

PRL262_PRD262_QG(en).fm Page 10 Wednesday, December 18, 2013 11:04 AM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Téléphone

Panasonic

Panasonic KX-T2322A Manuel utilisateur

Panasonic

Panasonic KX-TG2631 Manuel utilisateur

Panasonic

Panasonic KX-TG2312 Manuel utilisateur

Panasonic

Panasonic 4LINE KX-TGWA40 Manuel utilisateur

Panasonic

Panasonic KX-T7625 - Digital Proprietary Speakerphone 24... Manuel utilisateur

Panasonic

Panasonic 600 BASE UNIT Manuel utilisateur

Panasonic

Panasonic EASA-PHONE KX-T123211D Manuel utilisateur

Panasonic

Panasonic EASA-PHONE KX-T123211D Guide de dépannage

Panasonic

Panasonic KX-HDV230 Manuel utilisateur

Panasonic

Panasonic KX-TG3721BXB Manuel utilisateur

Panasonic

Panasonic KX-DT 333 Series Manuel utilisateur

Panasonic

Panasonic KX-TPA60 Manuel utilisateur

Panasonic

Panasonic KX-TG2208 Instructions d'utilisation et d'installation

Panasonic

Panasonic KX-TG6511TRB Manuel utilisateur

Panasonic

Panasonic KX-PRW130C Manuel utilisateur

Panasonic

Panasonic KX-DT 333 Series Manuel utilisateur

Panasonic

Panasonic KX-TC1851B - 900 MHz DSS Cordless Phone Manuel utilisateur

Panasonic

Panasonic KX-T2371MXW Manuel utilisateur

Panasonic

Panasonic KX-TG7322AL Manuel utilisateur

Panasonic

Panasonic KX-TS550LXB Manuel utilisateur

Panasonic

Panasonic KX-DT 333 Series Manuel utilisateur

Panasonic

Panasonic KX-UTG 300B Manuel utilisateur

Panasonic

Panasonic KX-TDE200 Manuel utilisateur

Panasonic

Panasonic KXTG2583B - 2.4 GHZ CORDLESS PHO Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur

Ericsson

Ericsson Dialog 3213 Manuel utilisateur

Yealink

Yealink VP530 Manuel utilisateur
