Panasonic KX-NT303 Manuel utilisateur

Thank you for purchasing a Digital Proprietary Telephone (DPT).

Please read this manual carefully before using this product and

save this manual for future use. For more details, please refer to the

manuals of the PBX.

Note: In this manual, the suffix of each model number is omitted unless

necessary.

Accessories (included)

*1 This telephone comes with the wall mounting adaptor already attached.

To remove the adaptor, refer to step 1 on page 17.

Handset: 1 Handset Cord: 1 Wall Mounting

Adaptor*1: 1

Screws for wall: 2 Telephone Line

Cord: 1

Quick Reference Guide

Model No. KX-DT333/KX-DT343/KX-DT346

Digital Proprietary Telephone

This unit supports the following optional devices and features:

Q: Available

*1 The availability of the Bluetooth Module depends on the software version of

the connected PBX. Consult your dealer for more details.

*2 For information on connecting, refer to the each included manual.

*3 When connecting DPTs via Digital XDP, this optional device cannot be

used.

Trademark:

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc.

and any use of such marks by Panasonic Corporation is under licence.

KX-DT333 KX-DT343 KX-DT346

Features

Display 3-Line 3-Line 6-Line

Flexible Buttons 24 24 24

LCD Backlight QQ

Options

KX-NT303 Add-on 12 Key Module QQ

KX-NT307 (PSLP1528) Bluetooth®

Module*1 *2 *3 QQ

KX-DT301 USB Module*3 QQ

KX-DT390 DSS Console (with 60

keys)*2 QQQ

Location of Controls

Location ofControls

ALCD (Liquid Crystal

Display)

BPAUSE: Used to insert a

pause when storing a

telephone number. This

button is also used for

programming this unit.

FWD/DND (Call Forwarding/

Do Not Disturb):

Used to set

Call Forwarding or Do Not

Disturb on your extension.

DCONF (Conference): Used

to establish a multiple party

conversation.

EINTERCOM: Used to make

or receive intercom calls.

FAUTO ANS (Auto Answer)/

MUTE: Used to receive an

incoming call in hands-free

mode or mute the

microphone/handset during a

conversation.

GAUTO DIAL/STORE: Used

for System/Personal Speed

Dialling or storing

programme changes.

LMN

<KX-DT346>

Location of Controls

HTRANSFER: Used to

transfer a call to another

party.

IREDIAL: Used to redial the

last dialled number.

JMESSAGE: Used to leave a

message waiting indication

or call back the party who left

the message waiting

indication.

KHeadset Jack

LFLASH/RECALL: Used to

disconnect the current call

and make another call

without hanging up.

MHOLD: Used to place a call

on hold.

NSP-PHONE

(Speakerphone): Used for

performing hands-free

operations.

OENTER: Used to assign the

selected item.

PMicrophone: Used for

hands-free conversations.

QNavigator Key: Used to

adjust the volume and the

display contrast or select

desired items.

RCANCEL: Used to cancel

the selected item.

SFlexible Buttons: Used to

seize an outside line or

perform a feature that has

been assigned to the key.

TLCD Panel: Can be adjusted

to the desired angle.

USoft Buttons (S1-S4): S1-

S4 (located from left to right)

are used to select the item

displayed on the bottom line

of the display.

VMessage/Ringer Lamp:

When you receive an

intercom call, the lamp

flashes green, and on an

outside call, the lamp flashes

red. When someone has left

you a message, the lamp

stays on red.

Settings

*1 If you hear your own voice through the handset or headset, decrease the

volume.

*2 For KX-DT343/KX-DT346 only.

Speaker volume

While in a hands-free

conversation

Press Up to increase

or Down to decrease

the volume.

Handset/Headset

volume*1

While using the handset or

headset

Ringer volume

While on-hook or receiving a call

LCD Contrast While on-hook

Ring Tone

LCD Backlight*2 While on-hook

PAUSE PAUSE

Press 2 times.

(CO)

PAUSE

STORE

INTERCOM AUTO DIAL

PAUSE

Automatic

Always ON

Always OFF

PAUSE

STORE

AUTO DIAL

STORE

AUTO DIAL

Features List

Icon Meanings

= Flexible button = Off-hook = On-hook

= Feature number = Talk = Confirmation Tone

Making Calls

Calling

To an extension To an outside party

Redial

Quick Dialling

One-touch Dialling

To store

To dial

Personal Speed Dialling

To store

To dial

(

)

C. Tone

extension no.

(

)

outside phone no.

REDIAL

quick dialling no.

(CO)

desired no.

(max. 32 digits)

*Enter outside line access

number before outside phone number.

STORE

AUTO DIAL

PAUSE PAUSE

assigned as a

One-touch Dialling button

(One-touch Dialling)

personal speed

dialling no. (2 digits)

desired phone no.*

(max. 32 digits)

*Enter outside line access number before

outside phone number.

C. Tone

STORE

AUTO DIAL

personal speed

dialling no. (2 digits)

Features List

During a Conversation

Useful Features

System Speed Dialling

To dial

Doorphone Call

Call Hold

To hold To retrieve a call at the holding extension

To retrieve an outside call from another extension

Call Transfer

Multiple Party Conversation

To add other parties during a conversation (i.e., conference)

To leave a conference

STORE

AUTO DIAL

system speed

dialling no. (3 digits)

doorphone no. (2 digits)

C. Tone

HOLD

(CO)

/INTERCOM

(CO)

C. Tone

outside

phone no.

To an extension

To an outside

party

extension no.

(CO)

TRANSFER

desired

phone no.

Talk to the

new party.

Talk with

multiple parties.

C. Tone C. Tone

CONF CONF

C. Tone

CONF

Features List

Setting the Telephone According to Your Needs

Before Leaving Your Desk

Do Not Disturb

Timed Reminder

To set

To cancel To stop or answer the ring back

Call Forwarding

Both Calls

Outside Calls

Intercom Calls

Set

Cancel C. Tone

24 H

12 H

hour/minute

(4 digits)

hour/minute

(4 digits)

Once

Daily C. Tone

C. Tone

INTERCOM

Busy

Cancel

No answer

Busy/

No answer

outside line

access no.

All calls

extension no.

outside

phone no.

Both Calls

Outside Calls

Intercom Calls

C. Tone

Features List

Making Use of the Voice Mail Service

Listening to a message

From your own extension

* If you have no password, you can skip

the last step.

Note:

VPS = Voice Processing System

From someone else’s extension

* If you have no password, you can skip

the last step.

Leaving a message

Mailbox Password*

VPS extension no.

End Call

KX-TVM series

KX-TVP series

Listen to Message

Deliver Message

Mailbox Management

Automated Attendant

Message Notification

Other Features

End Call

Listen to Message

Deliver Message

Check Mailbox Distribution

Automated Attendant

Mailbox Management

Other Features

mailbox no.

VPS extension no.

Mailbox Password*

mailbox no.

From your own extension

From someone else’s extension

* If you have no password, you can skip the last step.

Enter the desired mailbox number Leave

a message

To send the message immediately

To set the delivery time

Follow the guidance

(KX-TVM series)

(KX-TVP series)

VPS extension no.

Mailbox Password*

Features List

•Consult your dealer for more details regarding feature numbers.

•It is possible to assign flexible buttons as feature buttons.

•Control panel/button names and descriptions can be found in "Location

of Controls" on page 3.

Accessing Features Using the Display

Using the LCD Display

It is possible to access the following directories, logs, and menus by

pressing left or right on the Navigator Key while this unit is idle:

Entering Characters

You can enter alphabetic characters and digits using the dialling

buttons. Pressing a dialling button repeatedly displays different

characters, as shown in the following tables. While entering

characters, you can move the cursor with the left and right

Navigator keys and delete characters with the TRANSFER button.

To toggle between Table 1 and Table 2, press the Soft button (S1)

at any time while entering characters. For a list of available

characters, refer to the next page.

During playback

Repeat Voice Guidance

Exit

Incoming Call Log

Outgoing Call Log

Personal Speed Dialling Directory

System Speed Dialling Directory

Extension Number Directory

Feature Access
