Panasonic BB-HCM381CE Manuel utilisateur

ORDERNO.KMS0505064CE

NetworkCamera

BB-HCM381CE/BB-HCM381E

(forEurope)

 2005PanasonicCommunicationsCo.,Ltd.Allrightsreserved.

Unauthorizedcopyinganddistributionisaviolationoflaw.

IMPORTANTINFORMATIONABOUTLEADFREE,(PbF),SOLDERING

Ifleadfreesolderwasusedinthemanufactureofthisproducttheprintedcircuitboardswillbemarked

PbF.

Standardleaded,(Pb),soldercanbeusedasusualonboardswithoutthePbFmark.

Whenthismarkdoesappearpleasereadandfollowthespecialinstructionsdescribedinthismanual

ontheuseofPbFandhowitmightbepermissibletousePbsolderduringserviceandrepairwork.

1.ABOUTLEADFREESOLDER(PbF:Pbfree)

Note:

Intheinformationbelow,Pb,thesymbolforleadintheperiodictableofelements,willrefertostandard

solderorsolderthatcontainslead.

WewillusePbFwhendiscussingtheleadfreesolderusedinourmanufacturingprocesswhichismade

fromTin,(Sn),Silver,(Ag),andCopper,(Cu).

Thismodel,andotherslikeit,manufacturedusingleadfreesolderwillhavePbFstampedonthePCB.

Forserviceandrepairworkwesuggestusingthesametypeofsolderalthough,withsomeprecautions,

standardPbsoldercanalsobeused.

Caution

-PbFsolderhasameltingpointthatis50°~70°F,(30°~40°C)higher

thanPbsolder.Pleaseuseasolderingironwithtemperaturecontrol

andadjustitto700°±20°F,(370°±10°C).Incaseofusinghigh

temperaturesolderingiron,pleasebecarefulnottoheattoolong.

-PbFsolderwilltendtosplashifitisheatedmuchhigherthanitsmelting

point,approximately1100°F,(600°C).

-IfyoumustusePbsolderonaPCBmanufacturedusingPbFsolder,

removeasmuchoftheoriginalPbFsolderaspossibleandbesurethat

anyremainingismeltedpriortoapplyingthePbsolder.

-WhenapplyingPbFsoldertodoublelayeredboards,pleasecheckthe

componentsideforexcesswhichmayflowontotheoppositeside(See

figure,below).

1.1.SUGGESTEDPbFSOLDER

ThereareseveraltypesofPbFsolderavailablecommercially.Whilethisproductismanufacturedusing

Tin,Silver,andCopper,

(Sn+Ag+Cu),youcanalsouseTinandCopper,(Sn+Cu),orTin,Zinc,andBismuth,(Sn+Zn+Bi).Please

checkthemanufac

turer’sspecificinstructionsforthemeltingpointsoftheirproductsandanyprecautionsforusingtheir

productwithother

materials.

Thefollowingleadfree(PbF)solderwiresizesarerecommendedforserviceofthisproduct:0.3mm,

0.6mmand1.0mm.

1.2.HOWTORECOGNIZETHATPbFREESOLDERISUSED

MainBoard

TiltBoard

LensBoard

VideoBoard

CCDBoard

I/OBoard

2.FORSERVICETECHNICIANS

ICsandLSIsarevulnerabletostaticelectricity.

Whenreplacing,thefollowingprecautionswillhelptopreventrecurringmalfunctions.

1.Covertheplasticpartswithaluminumfoil.

2.Groundthesolderingirons.

3.Useaconductivematonthework-table.

4.DonotgraspICorLSIpinswithbarefingers.

3.CAUTION

3.1.SAFETYPRECAUTIONS

1.Beforeservicing,unplugthepowercordtopreventanelectricalshock.

2.Whenreplacingparts,useonlymanufacturer’srecommended

componentsforsafety.

3.Checktheconditionofpowercord.Replaceifwearordamageis

evident.

4.Afterservicing,besuretorestoretheleaddress,insulationbarriers,

insulationpapers,shields,etc.

5.Beforereturningtheservicedequipmenttothecustomer,makethe

followinginsulationresistancetesttopreventashockhazard.

3.2.BATTERYCAUTION

Dangerofexplosionifthebatteryisreplacedincorrectly.Replaceonlywiththesameorequivalenttype

recommendedbythemanufacturer.Disposeofusedbatteriesaccordingtothemanufacturer’s

Instructions.

Thelithiumbatteryisacriticalcomponent(typeNo.BR-2032-1VC).Pleaseobservefortheproper

polarityantheexactlocationwhenreplacingitandsolderingthereplacementlithiumbatteryin.

3.3.TRADEMARKS

-Adobe,AcrobatandReaderareeitherregisteredtrademarksor

trademarksofAdobeSystemsIncorporatedintheUnitedStatesand/or

othercountries.

-EthernetiseitheraregisteredtrademarkoratrademarkofXerox

CorporationintheUnitedStatesand/orothercountries.

-Microsoft,WindowsandActiveXareeitherregisteredtrademarksor

trademarksofMicrosoftCorporationintheUnitedStatesand/orother

countries.

-PentiumisatrademarkorregisteredtrademarkofIntelCorporationor

itssubsidiariesintheUnitedStatesandothercountries.

-SDmarkisatrademarkoftheSDCardAssociation.

-ScreenshotsreprintedwithpermissionfromMicrosoftCorporation.

-Allothertrademarksidentifiedhereinarethepropertyoftheirrespective

owners.

3.4.INSULATIONRESISTANCETEST

1.UnplugtheACpowercordandshortthetwoprongsoftheplugwitha

jumperwire.

2.MeasuretheresistancevaluewithohmmeterbetweenthejumperedAC

plugandeachexposedmetalcabinetpart,suchasscrewthreads,etc.

Note:

Someexposedpartsmaybeisolatedfromthechassisbydesign.Thesewillreadinfinity.

3.Ifthemeasurementisoutsidethespecifiedlimits,thereisapossibility

ofshockhazard.Theequipmentshouldberepairedandrechecked

beforeitisreturnedtothecustomer.

3.5.POWERCAUTION

Thepowersocketwalloutletshouldbelocatednearthisequipmentandbeeasilyaccessible.

3.6.PRECAUTIONSFORUSERSINTHEUNITEDKINGDOM

FORYOURSAFETY,PLEASEREADTHEFOLLOWINGTEXTCAREFULLY.

Thisapplianceissuppliedwithamouldedthreepinmainsplugforyoursafetyandconvenience.A3

ampfuseisfittedinthisplug.Shouldthefuseneedtobereplaced,pleaseensurethatthereplacement

fusehasaratingof3ampsandthatitisapprovedbyASTAorBSItoBS1362.

CheckfortheASTAmark ortheBSImark onthebodyofthefuse.

Iftheplugcontainsaremovablefusecover,youmustensurethatitisrefittedwhenthefuseis

replaced.Ifyoulosethefusecover,theplugmustnotbeuseduntilareplacementcoverisobtained.A

replacementfusecovercanbepurchasedfromyourlocalPanasonicDealer.

IFTHEFITTEDMOULDEDPLUGISUNSUITABLEFORTHESOCKETOUTLETINYOURHOMETHEN

THEFUSESHOULDBEREMOVEDANDTHEPLUGCUTOFFANDDISPOSEDOFSAFELY.THEREISA

DANGEROFSEVEREELECTRICALSHOCKIFTHECUTOFFPLUGISINSERTEDINTOANY13AMP

SOCKET.

Ifanewplugistobefitted,pleaseobservethewiringcodeasshownbelow.Ifinanydoubt,please

consultaqualifiedelectrician.

IMPORTANT:THISAPPLIANCEMUSTBEEARTHED.

Howtoreplacethefuse:Thewiresinthismainsleadarecolouredinaccordancewiththefollowing

code:

Blue:Neutral

Brown:Live

Asthecoloursofthewireinthemainsleadofthisappliancemaynotcorrespondwiththecoloured

markingsidentifyingtheterminalsinyourplug,proceedasfollows.

ThewirewhichiscolouredBLUEmustbeconnectedtotheterminalintheplugwhichismarkedwith

theletterNorcolouredBLACK.

ThewirewhichiscolouredBROWNmustbeconnectedtotheterminalintheplugwhichismarkedwith

theletterLorcolouredRED.

Undernocircumstancesshouldeitherofthesewiresbeconnectedtotheearthterminalofthethreepin

plug,markedwiththeletterEortheEarthsymbol .

HowtoReplacetheFuse

1.Inserttheflatheadscrewdriverintothegrooveeitherendofthefuse

carrier.

2.Detachthefusecarrierandchangethefuse.
