Panasonic CZ-RTC5B Manuel utilisateur

Installation Instructions

High-spec Wired Remote Controller

Model No. CZ-RTC5B

English

Read through the Installation Instructions before you proceed

with the installation.

In particular, you will need to read under the “Safety

Precautions” on page 3.

WEB-ACXF60-26852-EN

H0318-20921

Panasonic Corporation

http://www.panasonic.com

Contents

Part Names ....................................... 2

Supplied accessories ...................... 2

Safety Precautions........................... 3

Speciﬁcations................................... 4

Installation Precautions................... 5

Mounting........................................... 7

Exposed type................................ 7

Embedded type ............................ 8

Setting............................................... 9

Language ..................................... 9

Clock ............................................ 9

Controller name............................ 9

Service contact........................... 10

RC. setting mode.........................11

Detailed settings..........................11

Auto address .............................. 12

Set elec. consumption ................ 12

Conﬁrming Information ................. 13

Test Operation ................................ 14

2 (EN)

Part Names

5) Cross key buttons

Selects an item.

Down

1) LCD screen

2) Return button

Returns to the

previous screen.

6) Menu button

Displays the menu

screen.

7) Operation

indicator

lluminates during

operation.

Blinks during alarm.

8) Start/Stop button

Starts/Stops operation.

3) Enter button

Fixes the selected

content.

4) Energy saving

button

Switches Energy saving/

Normal operation.

RightLeft

Note

Press centre No penNo glove

Supplied accessories

Screw

M3.8 x 16

(2)

Quick

Reference

(1)

Clamper

(1)

*Remote control wiring is not supplied. (ﬁeld supplied item)

Control panel

(EN)

Read before installation

Read the Installation Instructions

carefully to install the remote controller

correctly and safely.

Be sure to read the Safety Precautions

in particular before installation.

After the installation is complete,

perform test operation to conﬁrm that

no abnormality is present.

We assume no responsibility for

accidents or damages resulting from

methods other than those described in

the installation instructions or methods

without using speciﬁed parts.

Malfunctions that occurred due to the

unauthorised installation methods are

not covered by the product warranty.

Read the installation instructions

supplied with indoor units as well.

WARNING

This symbol refers to a hazard or unsafe

practice which can result in severe

personal injury or death.

CAUTION

This symbol refers to a hazard or unsafe

practice which can result in personal

injury or product or property damage.

WARNING

• Turn oﬀthe circuit breaker

of the units before

installation.

• Ask your dealer or

professionals for installation

and electric work.

• This controller shall be

installed in accordance with

National Wiring Regulations.

•

Connect and ﬁx the speciﬁed

cables for wiring securely.

• Do not allow the connection

to be exposed to the

external force of the cables.

•

Choose an installation location

that suﬃciently supports the

weight of the remote controller.

CAUTION

Do not use the remote

controller at the following

locations.

• Location where

condensation occurs

• Location where ﬂammable

gases, etc. may leak

• Location where corrosive

gases, etc. may leak

•

Location with lots of water or oil

droplets (including machine oil)

• Location where voltage

ﬂuctuation frequently occurs

• Location where there

is a machine producing

electromagnetic radiation

• Location where droplets of

organic solvents spread

• Location where acidic or

alkaline solutions or special

sprays are frequently used



Do not operate with wet hands.

Do not wash with water.

The English text is the original instructions. Other languages are translation of

the original instructions.

NOTICE

Safety Precautions

4(EN)

Rotation operation

It is possible to make rotation operation settings on this unit.

For more information, refer to the Operating Instructions.

Model No. CZ-RTC5B

Dimensions (H) 120 mm x (W) 120 mm x (D) 16 mm

Weight 180 g

Temperature/

Humidity range

0 ˚C to 40 ˚C / 20 % to 80 % (no condensation)

*Indoor use only.

Power Source DC16 V

(supplied with indoor unit)

Clock precision ± 30 seconds/month (at normal temperature 25 ˚C)

*Adjust periodically.

Number of connectable

indoor units Up to 8 units

Speciﬁcations

datanavi

This unit supports datanavi.

For details on the usage, supporting regions, etc.,

visit the following URL.

https://datanavi.ac.smartcloud.panasonic.com/global/

(EN)

Installation Precautions

Installation location

5 mm or more

50 mm or

1 to 1.5 m

Floor

Install at the height of 1 to 1.5 m from

the ﬂoor (Location where average

room temperature can be detected).

Install vertically against the ﬂoor.

When installing more than 1 remote

controller next to each other, keep

distance of 5 mm on the right and left

and 50 mm on top and bottom.

Avoid the following locations for

installation.

• By the window, etc. exposed to

direct sunlight or direct air

• In the shadow or backside of objects

deviated from the room airﬂow.

• Location where condensation

occurs (The remote controller is not

moisture proof or drip proof.)

• Location near heat source

• Uneven surface

Keep distance of 1 m or more from

the TV, radio and PC. (Cause of fuzzy

images or noise)

Remote control wiring

Wiring diagram

Indoor unit

Terminals for RC wiring

RC wiring (ﬁeld supply)

• No polarity

Type of wiring

Use cables of 0.5 to 1.25 mm2.

Total wire length: 500 m or less

(The wire length between indoor units

should be 200 m or less.)

Number of connectable units

Remote controller: Max. 2

Indoor unit: Max. 8

Attention



Use the ﬁeld supplied RC wiring

with at least 1 mm in thickness of

insulation part including the sheath.

Regulations on wire diameters

diﬀer from locally to locally. For

ﬁeld wiring rules, please refer to

your LOCAL ELECTRICAL CODES

before beginning. You must ensure

that installation complies with

relevant rules and regulations.

Be careful not to connect cables

to other terminals of indoor

units (e.g. power source wiring

terminal). Malfunction may occur.

Do not bundle together with the

power source wiring or store in

the same metal tube. Operation

error may occur.

If noise is induced to the unit

power supply, attach a noise ﬁlter.

6(EN)

Wiring as shown below is prohibited.

R1 R2

12 12

R1 R2

(main)

Indoor unit Indoor unit Indoor unit

(sub)

RC wiring

When setting both the main and sub remote controllers

After installation, set one remote controller to [Main] and the other to [Sub] for [Main/

sub] for “Setting” (P.11).

When using the remote controllers* in combination, set this unit to [Main].

*CZ-RTC2, CZ-RTC4, CZ-RE2C2, CZ-RELC2

Using 1 indoor unit

R1 R2

12 12

RC wiring

(main)

(sub)

Indoor unit

Using more than 1 indoor unit

R1 R2

R1 R2 R1 R2

12 RC

(sub)

(main)

Indoor unit Indoor unit Indoor unit

RC wiring

Note

Remote controllers can be connected to any indoor unit for operation.

(EN)

1Remove the bottom case. Attention

Mounting the bottom case

Tighten the screws securely until

the screw heads touch the bottom

case.

(Otherwise, loose screw heads may

hit the PCB and cause malfunction

when mounting the top case.)

Do not over-tighten the screws.

(The bottom case may be deformed,

resulting in fall of the unit.)

Connecting the remote control wiring

Arrange the wires as shown in the illustration for in

step 2, avoiding unnecessary wires being stored in the

remote controller case.

(Caught wires may destroy the PCB.)

Avoid wires touching parts on the PCB.

(Caught wires may destroy the PCB.)

2Mount to the wall.

Flat-blade

screwdriver

Insert the

driver and

slightly turn.

Bottom

case

Mounting

Exposed type

Mount the top case.

Align the claws of the top

case and then align the

claws of the bottom case.

Preparation: Make 2 holes for screws using a driver.

Mount the bottom case to the wall.

Cut here with a

nipper and remove

the burr with a ﬁle.

Claw (2 places)

Screw

(Supplied)

Hole for screw

Claw (2 places)

Wall to which

the remote

controller is

ﬁxed

Connect the remote control

wiring

Arrange the wires along the groove

of the case.

Clamper

(supplied)

Pass through

the hole

Remote controller terminal board

Remove the coating. Approx. 6 mm

Remove the sheath. Approx. 160 mm

Make sure the wiring connection

is in the correct direction.

Bottom case

(Back side)

Top case

(Back side)

8(EN)

(mm)

2323

83.5

5-5x9

120

Embedded type

Preparation: Make 2 holes for screws using a driver.

2Connect the remote control

wiring

Mount the top case.

Align the claws of the

top case and then

align the claws of the

bottom case.

Avoid the

wire being

caught.

Claw (2 places)

Screw

(Supplied)

Hole for screw

Claw (2 places)

Mount the bottom case to the wall.

Pass the wire through the hole in the centre

of the bottom case.

Remote controller terminal board

Remove the coating. Approx. 6 mm

Make sure the wiring connection is

in the correct direction.

Bottom case

(Back side)

Top case

(Back side)

Dimensions

(EN)

Setting Language Clock Controller name

Preparation: Turn on the circuit breaker of units and then turn the power on. The

remote controller starts, and wait until the [Assigning] display disappears.

(If [Assigning] continues to blink for 10 minutes or more, check the

address setting of indoor units.)

Note To return to the previous screen

Press .

1Press .

Controller name

2Select [Initial settings].

▲▼→

3Select the item to set.

▲▼→

Language

4Set.

▲▼◄►→

Default setting :

English

Clock

4Set.

▲▼→►→

(Repeat)

2018

Controller name

4Set.

▲▼◄►→

(Repeat the same procedure for all

characters.)

• Up to 16

characters

(Space is

included in

the number of

characters.)

To change the character type

Select the character type with

▲▼◄►and press .

To enter space

Select [Space] with ▲▼◄►and press .

To delete 1 character

Select [BS] with ▲▼◄►and

press .

5Select [Conf].

▲▼◄►→

10 (EN)

Setting Service contact

1Press and hold the 3 buttons for

4 seconds or more simultaneously.

, , ►

2Select the item to set.

▲▼→

Service contact

3Select. (Name)

▲▼→Name

Contact number

4▲▼◄►→

(Repeat the same procedure for all

characters.)

• Up to 16 characters

(Space is included in the number of

characters.)

To change the character type

Select the character type with

▲▼◄►and press .

To enter space

Select [Space] with ▲▼◄►and

press .

To delete 1 character

Select [BS] with ▲▼◄►and

press .

5Select [Conf].

▲▼◄►→

6Select on the screen for step 3.

(Contact number)

▲▼→

7▲▼◄►→

(Repeat the same procedure for all

characters.)

•

Up to 16 characters

(Space is included

in the number of

characters.)

8Select [Conf].

▲▼◄►→

Autres manuels pour CZ-RTC5B

Table des matières

Autres manuels Panasonic Télécommande

Panasonic

Panasonic AW-RP50E Manuel utilisateur

Panasonic

Panasonic TNQ2AE007 Manuel utilisateur

Panasonic

Panasonic WVCU650 - SYSTEM CONTROLLER ADDENDUM Manuel utilisateur

Panasonic

Panasonic EUR7603Z50 Manuel utilisateur

Panasonic

Panasonic CZ-RWST2U Manuel utilisateur

Panasonic

Panasonic Lumix DMW-RSL1 Manuel utilisateur

Panasonic

Panasonic AK-HRP1015G Manuel utilisateur

Panasonic

Panasonic OneRemote RMB4 Manuel utilisateur

Panasonic

Panasonic EUR511151 Manuel utilisateur

Panasonic

Panasonic EUR7502XB0 - REMOTE GUIDE-SAHE200K Manuel utilisateur

Panasonic

Panasonic AJ-RC5 Manuel utilisateur

Panasonic

Panasonic WV-CU50E Manuel utilisateur

Panasonic

Panasonic aw-he40 series Manuel utilisateur

Panasonic

Panasonic CZ-RTC2 Manuel utilisateur

Panasonic

Panasonic WV-RC700A Manuel utilisateur

Panasonic

Panasonic CZ-RD514C Manuel d'installation et d'exploitation

Panasonic

Panasonic AWRP120 Manuel utilisateur

Panasonic

Panasonic CZ-RTC4 Manuel utilisateur

Panasonic

Panasonic CZ-01ESM11P Manuel utilisateur

Panasonic

Panasonic EUR7702KE0 Manuel utilisateur

Panasonic

Panasonic AW-RM50AG Manuel utilisateur

Panasonic

Panasonic CZ-RD52CP Manuel utilisateur

Panasonic

Panasonic Palmcorder PV-DRC9 Manuel utilisateur

Panasonic

Panasonic EUR7603Z20 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation

Invacare

Invacare G91S Manuel utilisateur
