Panasonic TH-43JX800 Guide de démarrage rapide

Panasonic Corporation 2021

Unauthorized copying and distribution is

a violation of law.

Model No. LCD-202106

Order No. ITD2106901GE

2021 - LCD TV (Android TV)

Ver. 1.0

Revision History

Version Issued/Revised

date

Revised content

Ver. 1.0 7th. Jun. 2021 First version

INDEXINDEX

1.Lineup and Function Comparison

2.Function

3.Board Layout

4.Signal Flow and Troubleshoot of Picture Problem

5.Start up Operation

6.SOS Protection Circuit and Troubleshoot of

Power Problem

*Google, Google Play, YouTube, Android TV, Chromecast built-in and other marks are trademarks of Google LLC.

1. Lineup and Function Comparison

Model Name

(TX- )

HX800 - 88#/

HX90#

(LCD)

JX800 – 83#*

(LCD)

Android TV

my Home Screen Y (5.0) Android home

Google Play Store/Movies

Screen Saver NY

HDR HLG, HDR10,

HDR10+,

Dolby Vision

HLG, HDR10,

HDR10+ Adaptive

Dolby Vision

Dolby Atmos YN

Multi Window YN

Media Player Y (2.0) Y

Power LED Indicator YN

Web Browser YN (you can install from some

Apps from Google play store)

IP Home Control YN

Works with Google Assistant /Alexa Y (except -R) Only Google Assistant

Home Network Y (Server/Client) N

Swipe & Share YN

TV Anywhere Y(*2) N

In-House TV Streaming Y (Client) (except -B) N

USB-HDD recording Y (except -R) Y

Mirroring YY (iOS = only Chromecast

supported App)

Lineup and Comparison of the Functions (Europe) -1

The detail lineup and specification are different in each countries.

Model Name

(TX- )

HX800 - 88#/

HX90#

(LCD)

JX800 – 83#*

(LCD)

Android TV

Bluetooth

(Audio Link / Keyboard-Mouse)

Y (in/out) / Y Y (only out) / Y

Headphones /

switchable to Subwoofer

Y / N Y / N

Remote Controller IR / Bluetooth(only voice control) IR / Bluetooth

HDMI terminal,

HDCP

eARC /

Auto low latency mode

2.2

2.3

HDAVI control YN (CEC only)

USB2.0 /3.0 HX9** : 2 / 1

HX8** : 1 / 1

2 / 0

Common Interface 2 (only HX904)

Digital Audio Output (Optical) YY

Component video input YN

Lineup and Comparison of the Functions (Europe) -2

The detail lineup and specification are different in each countries.

Model Name

(TH- )

HX700/800*

HX750W

(LCD)

JX700/800*

JX900W

(LCD)

Android TV

my Home Screen Y (5.0) Android home

Google Play Store/Movies

Screen Saver NY

HDR HLG,HDR10,

HDR10+,

Dolby Vision

HLG, HDR10,

HDR10+ Adaptive(JX800, JX900W)

HDR10+ (JX700)

Dolby Vision

Dolby Atmos YN

360°Soundscape NN

Multi Window Y (except -W) N

Media Player Y (2.0) Y

Power LED Indicator YN

Web Browser YN (you can install from some Apps

from Google play store)

IP Home Control Y (only -U/Z) N

Works with Google Assistant /

Alexa

YOnly Google Assistant

Home Network Y (Server/Client) N

Swipe & Share YN

TV Anytime Y(*2, except –W) N

USB-HDD recording Y (Except -D/-L) Y

Mirroring YY (iOS = only Chromecast

supported App)

Lineup and Comparison of the Functions (Oceania/Asia/Middle East) -1

The detail lineup and specification are different in each countries.

Model Name

(TH- )

HX700/800*

HX750W

(LCD)

JX700/800*

JX900W

(LCD)

Android TV

Bluetooth

(Audio Link / Keyboard-Mouse)

Y (in/out) / Y Y (only out) / Y

Headphones /

switchable to Subwoofer

Y / Y Y / N

Remote Controller IR / Bluetooth(only voice

control)

IR / Bluetooth

HDMI terminal,

HDCP

eARC /

Auto low latency mode

2.2

2.3

HDAVI control (Viera Link) YN

USB2.0 /3.0 2 / 1 2 / 0

Digital Audio out (Optical) YY

Component video input YN

Lineup and Comparison of the Functions (Oceania/Asia/Middle East) -2

The detail lineup and specification are different in each countries.

• Firmware update is supported via the internet only.

It is unable to update by Web Download (USB memory).

Menu - Settings - Device Preference - About - System update

Note (Android TV model)

• After doing step “power off by remote AC plug off AC plug in”,

the screen is black and the Power LED is blinking orange about 30 sec.

The remote control don’t work during this duration. This is specification.

You can power on by remote after the Power LED turns red on.

2. Function
