Panasonic CF-T2 Series Manuel utilisateur

Personal Computer

Reference Manual

Model No. CF-T2 Series

XP 2000 We recommend that this Reference Manual be printed.

Read Me First

zIf the user has logged on without the administrator authority, some functions may not be

executable, and some screens may be not displayed as shown in this manual.

If this happens, log on with the administrator authority to enable these functions.

zThis manual covers two types of models, as distinguished by the type of LCD screen

(models with touchscreen and models without touchscreen).

zConfirm the latest information on optional products in catalogs, etc.

zNOTE

NOTE provides a useful fact or helpful information.

zCAUTION

CAUTION indicates a condition that may result in minor or moderate injury.

zWARNING

WARNING indicates a hazard that may result in moderate or serious injury.

zWindows XP

Information for Microsoft®Windows®XP Professional users. "Windows" or "Windows XP"

in this manual.

zWindows 2000

Information for Microsoft®Windows®2000 Professional users. "Windows" or "Windows

2000" in this manual.

Enter

This illustration means to press the [Enter] key.

This illustration means to press and hold the [Fn] key, then press the [F5] key.

z[start] - [Run]

This illustration means to click , then to click [Run]. For some applications, you may need

to double-click.

• In Windows 2000, [start] is displayed as [Start]

zFor U.S.A. and Canada

Information for CF-T2******M users.

zFor Hong Kong

Information for CF-T2******H users.

z⇒Operating Instructions

This illustration means to refer to the Operating Instructions.

zWindows XP screens are used in this manual when no specific OS (operating system)

notes are required.

Illustrations and Terminology in this Reference Manual

Read Me First

zSome of the illustrations in this manual may differ slightly in shape from the actual items in

order to make the explanation easier to understand.

zAbout the terminology used in this manual and the Setup Utility concerning the internal

LCD and an external display

*1 To display [Intel(R) 82852/82855 GM/GME Graphics Controller properties]:

Windows XP

Select [start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Extreme Graphics].

Windows 2000

Select [Start] - [Settings] - [Control Panel] - [Intel(R) Extreme Graphics].

This manual and the

Setup Utility

[Intel(R) 82852/82855 GM/

GME Graphics Controller

Properties]*1

To display the same screen

on both the LCD and external

display

Simultaneous display Intel(R) Dual Display Clone

Key Combinations

CAUTION

zDo not press the following key combinations repeatedly in (quick) succession. Also,

do not press different key combinations quickly one after another.

zDo not press the following key combinations while using the touch pad (external

mouse), touchscreen (only for models with touchscreen) or other keys.

NOTE

zDo not press the following key combinations until you log on to Windows and the hard

disk drive indicator turns off. Note, however, that the key combinations

and

are operable in the Setup Utility.

zThe key combinations below may not work while some applications are running.

Besides, the popup window may not be displayed depending on the state of the

application you are using (e.g., when [Command Prompt] is set to "Full Screen").

Key Functions Popup Window

(Displayed after logging

on to Windows)

LCD brightness control (down)

LCD brightness control (up)

Pressing this key combination adjusts the

brightness of LCD.

The brightness setting is stored in memory

separately under the condition the AC adaptor is

connected and under the condition the AC adaptor

is not connected.

Key Combinations

Display change

By pressing this key combination, you can select

either an external display, internal LCD or

simultaneous. (Îpage 69)

This key combination does not work when

[Command Prompt] is set to "Full Screen".

CAUTION

zDo not press another key until the display

destination has been completely switched.

zDo not press this key combination in the

following conditions.

• While MPEG files are playing.

• When the Extended Desktop is being

utilized.

NOTE

Windows XP

zWhen switching to a different user with the

Fast User Switching function, this key

operation may not work. In this case, log off

all users and restart the computer.

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Speaker on/off switch

Pressing this key combination turns on/off audio

from the internal speaker and headphone jack.

NOTE

zDisabling the speakers will also disable the

warning beep.

zSpeakers connected to the USB port

cannot be muted.

OFF

(MUTE)

Volume control (down)

Volume control (up)

Pressing this key combination adjusts the volume

of the internal speaker and headphone jack.

NOTE

zThis key combination cannot be used to

adjust the volume of the warning beep or

speakers connected to the USB port.

Power off using the standby function

Pressing this key combination causes the current

status of the computer to be saved to memory, and

powers off the computer. (Îpage 22)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

There are two Fn key functions as follows:

zFn key lock function

After

is pressed once, it stays in the "pressed" position until another key is pressed.

This is convenient when it is difficult to press two buttons simultaneously.

zPopup windows display ON/OFF

1Run the Hotkey Settings.

Windows XP

Select [start] - [All Programs] - [Panasonic] - [Hotkey Settings].

Windows 2000

Select [Start] - [Programs] - [Panasonic] - [Hotkey Settings].

Remaining capacity of the battery pack

Pressing this key combination displays the

remaining battery capacity on the screen.

When the

battery pack is

inserted in the

computer

(example)

When the

battery pack is

not inserted in

the computer

F10

Power off using the hibernation function

Pressing this key combination causes the current

status of the computer to be saved to the hard

disk, and powers off the computer. (Îpage 22)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Hotkey Settings

Key Combinations

2Set the parameters.

A. Use Fn key lock

Add the check mark if you want to enable the Fn key lock function. The following

Fn key lock function will then be enabled.

zTo use

only once:

1Press

once. (Locked)

2Press another key for combination. (Lock released)

zTo use

successively:

1Press

twice. (Locked)

2Press another key for combination.

Fn key remains locked until

is pressed once more.

B. Notification

This setting is only available when [Use Fn key lock] is checked.

[Make sounds when Fn key is pressed]*1

Notifies the user with a sound when

is locked or released.

[Show status on screen]:

Displays the Fn key status on the taskbar.

is locked

is not locked

C. Disable popup

Add the check mark if you want to turn the popup window display function OFF.

The full-screen display of [Command Prompt] screen or MPEG files may change

to a window display if

*2 keys are pressed. To prevent this, turn the

popup window display function OFF.

3Select [OK].

NOTE

zThe Fn key lock function also works with

and other keys (e.g. Î, Í) aside from

*2.

zEach user can select separate settings for whether or not to use the Hotkey settings.

*1 If MUTE is set, you will not hear a beep.

*2 "

" indicates any function key from

F10

LED Indicators

Power status zNot lit

Power off / Hibernation mode

zGreen

Power on

zBlinking green

Standby mode

Battery pack status zNot lit

Battery pack is not connected or charging not being performed.

zOrange*1

Charging in progress.

zGreen*1

Fully-charged.

zRed

The battery level is very low (the charge is less than approx. 9%

capacity).

Connect the AC adaptor. You can use the computer when the battery

indicator light is orange. If you do not have an AC adaptor, save your

data and power off your computer. After replacing the battery pack with

a fully charged one, turn your computer on.

zBlinking red*1

Battery pack or charging may not be working properly. Quickly save

your data and power off your computer. Remove the battery pack and

disconnect the AC adaptor, then connect them again. If the problem

persists, contact your technical support office. Possible failure in the

battery pack or charging circuit.

zBlinking orange*1

Battery cannot be recharged temporarily because the internal

temperature of the battery pack is outside of the acceptable temperature

range for recharging. Once the allowable range requirement is satisfied,

charging begins automatically. Your computer can be used normally in

this state.

Caps Lock This indicator lights green when

Caps Lock

is pressed. Subsequent non-

shifted input is capitalized.

LED Indicators

*1 When the AC adaptor is connected.

NumLk

(Numeric key)

These indicators light green when

NumLk

is pressed. When the green

light is on, if the

is pressed along with keys on certain other segments of

the keyboard, then those keys will operate as numeric keys. The [Enter] key

functions differently depending on the application.

ScrLk

(Scroll lock)

This indicator lights green when

ScrLk

are pressed. Scroll lock

functions differently depending on the application.

Hard disk drive status This indicator lights when the hard disk drive is accessed.

SD memory card status This indicator lights when the SD memory card or MultiMedia Card is

accessed.

Autres manuels pour CF-T2 Series

Table des matières

Autres manuels Panasonic Ordinateur portable

Panasonic

Panasonic CF-73ECLTXKM - Toughbook 73 - Pentium M 1.4... Manuel utilisateur

Panasonic

Panasonic Toughbook CF-29N3LG6BM Manuel utilisateur

Panasonic

Panasonic ToughBook CF-72 Series Manuel utilisateur

Panasonic

Panasonic Toughbook CF-T5MWETABM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-19DDGZXVM Manuel utilisateur

Panasonic

Panasonic CF-AX3 Series Manuel utilisateur

Panasonic

Panasonic Toughbook CF-F8EWAZZJM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-48 Series Manuel utilisateur

Panasonic

Panasonic CF-C2 series Manuel utilisateur

Panasonic

Panasonic CF-74 Series Manuel utilisateur

Panasonic

Panasonic Toughbook CF-19KDRAG6B Manuel utilisateur

Panasonic

Panasonic Toughbook CF-H1ADBBZCM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-52AJCBDBM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-T7BWATAAM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-18NHHZXBM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-18DDAZXMM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-Y4HWPZZBM Manuel utilisateur

Panasonic

Panasonic The Toughbook 31 Manuel utilisateur

Panasonic

Panasonic Toughbook CF-51PF66EBM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-30CTQAZBM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-Y7BWAZAJM Manuel utilisateur

Panasonic

Panasonic CF-37 Series Schéma de câblage

Panasonic

Panasonic Toughbook CF-29CTKGZKM Manuel utilisateur

Panasonic

Panasonic Toughbook CF-18 Series Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel
