Panasonic KX-TD208E Caractéristiques techniques

Digital Super Hybrid

System

KX-TD208E

Product Description

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Contents

SYSTEM PARAMETERS 5

SYSTEM HARDWARE 6

CABINETS 6

SYSTEM COMPONENTS 7

KX-TD208E CENTRAL CONTROL UNIT 7

KX-TD20870CE PROPRIETARY TELEPHONE CARD 7

KX-TD20880CE 1 ISDN2 LINE CARD 7

KX-T30865E DOOR-PHONES 7

HAND-SET OPTIONS 8

HAND-SET FEATURES 8

HAND-SET TYPES 8

PARALLEL CONNECTION 9

XDP (EXTRA DEVICE PORT) 10

ANSWERING CALLS 11

FLEXIBLE RINGING ASSIGNMENT 11

DELAYED RINGING 11

GROUP RINGING 11

UNIFORM CALL DISTRIBUTION 12

TAM PICKUP 12

CALL PICK UP (EXCHANGE LINE / GROUP / DIRECT)13

OFF HOOK SIGNALLING 13

FLEXIBLE FUNCTION KEYS 14

FLEXIBLE NIGHT SERVICE 15

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

CALL CHARGE MANAGEMENT 16

OPERATOR FEATURES 17

HOLDING CALLS 18

SYSTEM HOLD 18

TRANSFERRING & INTERCOM CALLS 19

INTERNAL VOICE / TONE CALLS 19

TRANSFER ( SCREENED / UNSCREENED)19

CONFERENCE CALLS 19

HUNT GROUP 20

LOCATING CALLS 21

PAGING WITH MEET ME21

CAMP ON21

CALL WAITING 21

OUTGOING CALLS 22

POOLED EXCHANGE LINE ACCESS 22

TRUNK QUEUING ( EXCHANGE LINE CAMP ON)22

SPEED DIALLING - PERSONAL 22

SPEED DIALLING - SYSTEM 23

LAST NUMBER RE-DIAL 23

SAVE / REPEAT DIAL 23

LEAST COST ROUTING (LCR) 24

ISDN2 Q931 (EURO ISDN) INTERFACE 25

ISDN2 FEATURES 25

ISDN2 FEATURE DESCRIPTIONS 25

DIRECT DIAL IN25

CALL CHARGE INFORMATION 25

CALLING LINE IDENTITY 25

EURO (Q931) ISDN2 EXTENSIONS 26

CALL BARRING 27

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

CALL LOGGING INTERFACE 28

CALL LOGGING INDICATION 28

CALL LOGGING OUTPUT 28

OTHER FEATURES 29

FLEXIBLE LINE ASSIGNMENT 29

IDLE LINE PREFERENCE 29

PRIME LINE PREFERENCE 29

ACCOUNT CODES 30

HEADSET CONNECTION 30

EXTENSION LOCK 30

AUTOMATIC ANSWER 31

AUTOMATIC RECALL 31

ON HOOK DIALLING 31

ALARM 31

VOLUME AND LCD CONTRAST ADJUSTMENT 32

DUAL COLOUR LEDS32

MICROPHONE MUTE 32

DOORPHONE INTERFACE 32

DO NOT DISTURB 33

CALL FORWARDING 33

CALL FORWARD INDICATION ON DISPLAY 33

HUNT GROUPS 34

PULSE / DTMF DIALLING 34

EXCHANGE LINE TO EXCHANGE LINE TRANSFER 34

CALL FORWARD EXCHANGE LINE TO EXCHANGE LINE 35

AUTOMATIC CALL-BACK BUSY 35

BUDGET MANAGEMENT 35

CLASS OF SERVICE 36

PRIMARY / SECONDARY CLASS OF SERVICE 36

CONNECTED LINE IDENTIFICATION RESTRICTION 36

DATA LINE SECURITY 37

DIRECT DIAL IN (DDI) 37

DO NOT DISTURB (DND) 37

DND FOR DDI CALLS 38

EXTENSION CONNECTION 38

DAY / NIGHT SERVICE 38

NOTEBOOK FUNCTION 38

PAGING DENY 39

PRE-DIAL 39

PRIVATE CALL 39

QUICK DIALLING 39

DDI 40

INTERCEPT ROUTING 40

CALL TRANSFER TO EXTENSION 40

ISDN CONTROLLED CALL FORWARD (CFU/CFNR/CFB) 40

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

System Parameters

System Microprocessor 8 Bit CPU

System Memory 1.25 Megabit RAM

8 Megabit ROM

Digital Bandwidth (2 B+D) 8 Kilobytes/Second

Voice Channel 16Kbps

Data Channel 64Kbps

Signalling 64Kbps

Cabling (digital) 1 pair (2 wires)

Analogue (SLTs) 1 pair (2 wires)

Modulation Pulse code

Intercom Paths Non blocking

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

System Hardware

Cabinets

Note: This table shows the maximum values possible in the system, the actual values will depend upon the

configuration of the specific system and its components.

Maximum port configurations

Exchange line ports 4

Extension ports 12

Max number of Digital keyphones 4

Max number of Analogue keyphones 4

Max number of SLTs 8

Max number of Extensions 12

Max number of ISDN2 Extensions

(Using P-MP) 8

Max number of ISDN2 (Channels) 2 (4)

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

System Components

KX-TD208E Central Control Unit

The central control unit is initially configured 1 ISDN2 line (2 channels) and 8 extension ports. The following

devices are built in:

3. RS232C call logging port

4. Ring generator

5. DTMF receivers

6. All system control

7. Doorphone circuit

8. Door release contact

KX-TD20870CE Proprietary Telephone Card

Interface card to allow connection of 4 proprietary telephones either digital (with XDP) or analogue 7000 series.

KX-TD20880CE 1 ISDN2 Line Card

Interface card to allow connection of 1 ISDN2 exchange line. This card can be used as to support ISDN2

extensions, up to 8 devices may be connected as extensions.

KX-T30865E Door-phones

The central control unit has an interface built in to support one door-phone. The door-phones are proprietary,

weather resistant units. There is also a relay for controlling a remote door-lock.

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Hand-set Options

1. Digital Proprietary Keyphones (KX-T7250E, KX-T7230E and KX-T7235E)

2. KX-T7000 Series Keyphones (KX-T7050E, KX-T7020E and KX-T7130E)

3. KX-T7310E, KX-T7315E and Single Line Devices

The Digital Super Hybrid System offers the choice of a wide range of key hand-set.

The features which are available to hand-set users will depend upon the type of hand-set being used.

Hand-set Features

Key features of the KX-TD208E hand-sets are:

One-Touch keys The one-touch keys provide single key access to personal speed dials or system

features allowing them to be called up with a single key press.

Flexible keys Flexible keys are used as line use indicators. Unused Flexible keys can be

programmed with other system functions or used as extension calling and busy lamp

field keys.

Dual colour LEDs The Flexible keys each have a dual colour LED which is used when the key is

programmed as a line, extension, message waiting or call forward call key to show

the status.

Message lamp Each key telephone can have an LED lamp which is used to give visual indication of

messages.

Distinctive HOLD key The HOLD key’s orange colour and prominent position make it easy to locate and

operate.

Volume control To adjust ringing, speaker and hand-set volumes independently..

LCD display Certain key telephone models have an alphanumeric display allowing the display of

information and messages which enhance its functionality.

Hand-set Types

The table below lists the KX-TD208E hand-set types and their key specifications.

Model Description Flexible

Keys One

Touch

Keys

Dual

colour

LEDs

Message

LED Alphanumeric

Display Handsfree Parallel

Connection XDP

KX-T7250E 0 key hand-set 6 0 4 4 4

KX-T7050E 12 key standard 12 4 4 4 4

KX-T7020E 12 key handsfree 12 4 4 4 4 4

KX-T7130E 12 key display 12 12 4 4 4 4 4

KX-T7235E 12 key large display 12 10 4 4 4 4 4 4

KX-T7230E 24 key executive 24 0 4 4 4 4 4 4

KX-T7220E 24 key handsfree 24 0 4 4 4 4 4

KX-T7315E SLT 0 8 4 4 4

KX-T7310E SLT 0 8 4 4

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Parallel Connection

Description

Proprietary telephones may have an SLT (Single Line Telephone) connected to the same extension port sharing

the same extension number. If the 7000 series has a paralleled SLT and both phones are off hook during a call,

a three way conference is established. If the combination of telephones is digital and an SLT if one telephone

goes off hook during a call the call will be transferred to it.

The connection can be made simply by plugging the SLT into the back of a digital telephone. The connection

can also be made by wiring the devices in parallel.

Benefits

An extension user with a keyphone could have a loud ringing bell, PC with modem or cordless telephone

connected to their extension. It can also provide a simple “dial up” LAN passing data through the system from

PC to PC or out onto the network

Extension 21

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

XDP (eXtra Device Port)

Description

When connecting an SLT in parallel with a digital proprietary telephone the SLT may operate as a separate

extension with it’s own extension number and programmable parameters. The SLT device can be simply

plugged into a digital keyphone or wired separately to a different part of the building.

Benefits

This feature can be used to double the maximum number of extensions which can be fitted to the available

ports. Example:

a 4 x 12 size system could have up to 16 individual extensions. Provides an easy and inexpensive way of

installing a new extension. The system offers total flexibility as to what may be connected e.g. cordless, credit

card verifiers etc.

Example

Extension 21

Extension 31

Extension 32

Extension 22
