Panasonic ES-EU20 Manuel utilisateur

Unauthorized copying and distribution is a violation

of law.

Order Number PCD1301X31CE

Epilator

Model No. ES-EU20

ES-EU10

Europe

CIS

TABLE OF CONTENTS

PAGE PAGE

1 Warning -------------------------------------------------------------- 2

2 Specifications ----------------------------------------------------- 2

3 Troubleshooting Guide ----------------------------------------- 3

4 Schematic Diagram ---------------------------------------------- 4

5 Exploded View and Replacement Parts List ------------ 5

1Warning

Caution:

• Pb free solder has a higher melting point that standard solder; Typically the melting point is 50 - 70°F (30 - 40°C) higher. Please

use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder-

ing iron, please be careful not to heat too long.

• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).

2 Specifications

3 Troubleshooting Guide

3.1. CHECK MAIN BODY AND ADAPTOR

NOTE: When charging, the unit does not operate even switching ON.

3.2. CHECK MAIN BODY AND ADAPTOR

1. Confirm the smooth operation when switching ON and OFF.

2. Confirm if the motor and disc may rotate when holding the disc slightly.

3. Confirm if there is no dirt or scratch.

4. Confirm if the main unit may operate approximately 25 minutes after fully charging.

4 Schematic Diagram

Model No. : ES-EU20 Exploded View

5 Exploded View and Replacement Parts List

Model No. : ES-EU20 Parts List

Safety

Ref.

No. Part No. Part Name & Description Q'ty Remarks

ES-EU20

1 WESEU20W3128 FRAME 1

2 WESEU20W1068 EPILATION HEAD FOR LEGS/ARMS 1

3 WESWD51L9397 TAPPING SCREW 3 K2-5

4 WESEU20W3368 MOUNTING BASE B 1

5 WESEU20W3278 HEAD RELEASE BUTTON 1

6 WES2047S9707 SCREW 1 K2-8

7 WER504L0966 O-RING 2 (2PCS/PK)

8 WES701S9706 SCREW 1 K2-12

9 WESWD94L6118 WASHER 1

10 WESEU20L0498 MOUNTING BASE A 1

11 WES2067L0997 HOUSING O-RING 1

12 WESEU20P3378 FRONT PANEL 1

13 WESEU20P3058 HOUSING 1

13 WESEU20P3059 HOUSING 1 only for CIS

14 WESEU20L1558 SWITCH CONNECTING PLATE 1

15 WESEU20L1668 SWITCH CAM 1

16 WES331B9257 TAPPING SCREW 2 K2-8

17 WESEU20L1008 MOTOR ASSEMBLY 1

18 WESSL41L2508 RECHARGEABLE BATTERY 1 Ni-Mh TYPE

19 WESEU20L0978 WASHER & O-RING SET 1

20 WESEU20L2108 MODULE 1

21 WESED90L2158 PLUG CHASSIS 1

22 WES2047L0327 O-RING A 2 (2PCS/PK)

23 WESWD51X3557 BIKINI COMB 1

24 WESED70W4038 FOIL FRAME 1

25 WES9753Y OUTER FOIL 1

26 WES9752Y INNER BLADE 1

27 WESED90W0788 SHAVER HEAD 1

28 WESEU20W7661 POWER ADAPTOR 1 C-2 PLUG (only for CIS)

28 WESEU20W7664 POWER ADAPTOR 1 C-2 PLUG

28 WESEU20W7660 POWER ADAPTOR 1 BF3 PLUG

29 WES2047H6767 CLEANING BRUSH 1

- WESEU20P8008 INDIVIDUAL BOX 1

- WESEU20P8009 INDIVIDUAL BOX 1 only for CIS

- WESEU20P8000 INDIVIDUAL BOX 1 only for U.K.

- WESEU20P8108 OPERATING INSTRUCTIONS 1

- WESEU20P8109 OPERATING INSTRUCTIONS 1 only for CIS

Model No. : ES-EU10 Exploded View

Model No. : ES-EU10 Parts List

Safety

Ref.

No. Part No. Part Name & Description Q'ty Remarks

ES-EU10

1 WESEU20W3128 FRAME 1

2 WESEU20W1068 EPILATION HEAD FOR LEGS/ARMS 1

3 WESWD51L9397 TAPPING SCREW 3 K2-5

4 WESEU20W3368 MOUNTING BASE B 1

5 WESEU20W3278 HEAD RELEASE BUTTON 1

6 WES2047S9707 SCREW 1 K2-8

7 WER504L0966 O-RING 2 (2PCS/PK)

8 WES701S9706 SCREW 1 K2-12

9 WESWD94L6118 WASHER 1

10 WESEU20L0498 MOUNTING BASE A 1

11 WES2067L0997 HOUSING O-RING 1

12 WESEU10P3378 FRONT PANEL 1

13 WESEU10P3058 HOUSING 1 P503

13 WESEU10P3059 HOUSING 1 only for U.K.

13 WESEU10P3050 HOUSING 1 only for CIS

14 WESEU20L1558 SWITCH CONNECTING PLATE 1

15 WESEU20L1668 SWITCH CAM 1

16 WES331B9257 TAPPING SCREW 2 K2-8

17 WESEU20L1008 MOTOR ASSEMBLY 1

18 WESSL41L2508 RECHARGEABLE BATTERY 1 Ni-Mh TYPE

19 WESEU20L0978 WASHER & O-RING SET 1

20 WESEU20L2108 MODULE 1

21 WESED90L2158 PLUG CHASSIS 1

22 WES2047L0327 O-RING A 2 (2PCS/PK)

23 WESEU20W7661 POWER ADAPTOR 1 C-2 PLUG (only for CIS)

23 WESEU20W7664 POWER ADAPTOR 1 C-2 PLUG

23 WESEU20W7660 POWER ADAPTOR 1 BF3 PLUG

24 WES2047H6767 CLEANING BRUSH 1

- WESEU10P8008 INDIVIDUAL BOX 1

- WESEU10P8009 INDIVIDUAL BOX 1 only for CIS

- WESEU10P8000 INDIVIDUAL BOX 1 only for U.K.

- WESEU20P8108 OPERATING INSTRUCTIONS 1

- WESEU20P8109 OPERATING INSTRUCTIONS 1 only for CIS
