Thank you for purchasing this Panasonic product.

■To ensure correct use of this lens, please read the operating instructions supplied

with the lens and the projector carefully.

■Before using this product, be sure to read “Read this rst!” (Page 3).

■Please save this manual for future use.

Commercial Use

Model No. ET-D3LEW10

ET-D3LET30

ET-D3LET40

DPQX1300ZB/X1

Zoom Lens 　　　　　　　　　

Operating Instructions

ENGLISH

ET-D3LEW10

ET-D3LET40

ET-D3LET30

2-ENGLISH

Read this rst! ......................................................................................3

Before Use.............................................................................................4

Preparation............................................................................................5

Before replacing the projection lens........................................................ 5

Attaching and Detaching the Lens .......................................................... 5

Peripheral focus adjustment function (ET-D3LEW10)............................. 6

Lens calibration ....................................................................................... 7

Projection relationships.......................................................................8

Lens shift ranges..................................................................................9

Specications .....................................................................................10

Dimensions .........................................................................................10

Projected image size and Projection distance.......Appendix / Annexe / 付録 1

The "Appendix" can be found after the Japanese language section ( 日本語 ).

█ Contents

ENGLISH-3

Read this rst! Always follow these precautions

WARNING:

Do not look at or place your skin into the light emitted from the lens while the

projector is being used.

Doing so can cause burns or loss of sight.

zStrong light is emitted from the projector’s lens. Do not look at or place your hands

directly into this light.

zTurn off the power when moving away from the projection lens or projector.

Do not project an image with the lens cover attached.

zDoing so can cause re.

CAUTION:

Before replacing the projection lens, be sure to turn off the power and

disconnect the power plug from the wall outlet.

zUnexpected projection of light may cause injury to eyes.

zReplacing the projection lens without removing the power plug may result in electric

shock.

Do not stand in front of the lens while the projector is being used.

Doing so can cause damage and burns to clothing.

zStrong light is emitted from the projector’s lens.

Do not place objects in front of the lens while the projector is being used.

Doing so can cause re, damage to the object, or malfunction of the lens and

projector.

zStrong light is emitted from the projector’s lens.

Do not open the desiccant bag. Do not eat the contents.

Inadvertently ingesting desiccant could be harmful.

zIf the desiccant gets into your eyes or mouth, immediately rinse with plenty of water

and seek medical attention.

zKeep desiccant out of the reach of children.

WARNING (North America)

A projector would become Class IIIb laser product when this lens is used under the

condition that throw ratio is greater than 3.0, and if used without lens hood. If you use

under this condition, you must receive variance approval letter from FDA before usage.

Class IIIb levels of laser radiation are considered to be an acute hazard to the skin and

eyes from direct radiation.

Note

zThe lens hood needs to be mounted to the projector when this lens is used under the

condition that throw ratio is greater than 3.0 in the North America region. Always ask a

qualied technician or your dealer to mount the lens hood.

For the assembly and attachment, refer to the separate document “Mounting the lens hood”.

The components and document of the lens hood may not be supplied depending on the

country or region where you purchased the product.

4-ENGLISH

This zoom lens is a projection lens equipped with an EEPROM*1 and stepping motor.

*1 EEPROM: Electrically erasable programmable read-only memory

■Supported projectors

PT-RQ32K / PT-RZ31K / PT-RS30K / PT-RQ22K / PT-RZ21K / PT-RS20K

Note

zSome of the alphabet letters at the end of projector model numbers may be omitted in this

manual.

zModels other than the above may also be supported. Refer to the operating instructions for

your projector or the Panasonic website (https://panasonic.net/cns/projector/).

zIf the projector you are using is PT-RQ32K / PT-RZ31K / PT-RS30K / PT-RZ21K /

PT-RS20K, you may not be able to use the projection lens depending on main version of

the rmware. If main version of the rmware is the version number shown below, update to

the latest rmware before use.

- PT-RQ32K / PT-RZ31K / PT-RS30K: Earlier than 3.00

- PT-RZ21K / PT-RS20K: Earlier than 2.00

For details on the update procedure, refer to the latest rmware information on the

Panasonic website (https://panasonic.net/cns/projector/pass/).

zThe main version of the rmware can be checked in the [STATUS] screen.

■Supplied Accessories

Make sure that the following has been provided.

Part name Appearance

Lens cover

1 each for front and rear

zThe product is delivered

with a lens cover attached.

zThe shape and size of the

lens caps are different for

each product.

Before Use

ENGLISH-5

Attaching and Detaching the Lens

For details on attaching and detaching the projection lens, refer to the operating instructions

of the projector.

Preparation

Before replacing the projection lens

Return the projection lens to the home position before replacing or removing it.

For details on how to return the lens to the home position, refer to the operating instructions

of the projector.

Attention

zMake sure that the projector power supply is switched off before attaching or detaching the

projection lens.

zAfter removing the projection lens, store it safely away from vibration or impacts.

z Do not touch the electrical contacts of the projection lens with your ngers. Dust and dirt on

the contacts may cause contact malfunctions, while static electricity may damage the unit.

zDo not touch the surface of the lens with bare hands. Finger prints and dirt on the surface

of the lens will be magnied by the lens and lower the quality of the projected image. Place

the supplied lens cover on the zoom lens when the projector is not in use.

zThe lens is made of glass. The lens could be damaged if brought into contact with or

rubbed against hard objects. Handle the lens carefully.

zUse a clean, soft and dry cloth to wipe away dust and dirt from the projection lens.

Do not use uffy cloths containing oil, water or dust for cleaning. The lens is easily

damaged, so do not apply excessive pressure when wiping it.

6-ENGLISH

Preparation (continued)

Peripheral focus adjustment function (ET-D3LEW10)

When yo

u change the size of the projected image, the focal balance between the center

and peripheral areas of the screen may shift. This shift in balance tends to increase

proportionally with smaller throw ratios.

The ET-D3LEW10 is equipped with a peripheral focus adjustment function to correct the

shift

in focal balance between the center and peripheral areas of the screen.

1) Operate the projector to align

the focus of the center of the

projected image.

2) Loosen the lock knob by

turning it counterclockwise.

Note

zThe screen sizes displayed on the lens are approximate guides.

3) Turn the peripheral focus

adjustment ring in the

directions of the arrows

to align the focus of the

peripheral areas of the image.

4) Tighten the lock knob by

turning it clockwise.

The illustrations in this procedure depict

use of the PT-RZ21K as an example.

■Adjusting the focus

ロックつまみ

周辺フォーカス調整リング

Peripheral focus adjustment ring

Lock knob

ENGLISH-7

Lens calibration

Perform lens calibration after attaching the lens.

The illustrations in this procedure depict

use of the ET-D3LEW10 as an example.

1) Press the <MENU> button.

2) Use the ▲ and ▼ buttons to

select [PROJECTOR SETUP],

and press the <ENTER>

button.

zThe [PROJECTOR SETUP] screen

appears.

3) Use the ▲ and ▼ buttons to

select [LENS], and press the

<ENTER> button.

zThe [LENS] screen appears.

4) Use the ▲ and ▼ buttons to

select [LENS CALIBRATION],

and press the <ENTER>

button.

zThe [LENS CALIBRATION] screen

appears.

5) Use the ▲ and ▼ buttons to

select [SHIFT/FOCUS/ZOOM],

and press the <ENTER>

button.

zThe conrmation screen appears.

6) Use the and buttons to

select [OK], and press the

<ENTER> button.

zLens calibration starts.

zThe projection lens moves to the

home position after adjustment range

calibration is complete.

1/2

PROJECTOR SETUP

PROJECTOR ID ALL

PROJECTION METHOD

LENS

OPERATION SETTING NORMAL

LIGHT OUTPUT 100.0%

BRIGHTNESS CONTROL AUTO

STANDBY MODE NORMAL

NO SIGNAL SHUT-OFF DISABLE

NO SIGNAL LIGHTS-OUT DISABLE

INITIAL STARTUP LAST MEMORY

STARTUP INPUT SELECT LAST USED

DATE AND TIME

SUB MENU

MENU SELECT

ENTER

SUB MENU

MENU SELECT

ENTER

LENS

LENS TYPE ET-D3LEW10

LENS INFORMATION SETTING

LENS MEMORY

LENS HOME POSITION

ACTIVE FOCUS OPTIMIZER

LENS CALIBRATION

EXECUTE

MENU SELECT

ENTER

LENS CALIBRATION : ET-D3LEW10

SHIFT/FOCUS/ZOOM

SHIFT/FOCUS

ZOOM

LENS CALIBRATION : ET-D3LEW10

Proceed LENS CALIBRATION,

and return to HOME POSITION.

EXECUTE

CHANGE

ENTER

CANCEL

Note

zIf lens calibration is not performed, the available zoom range will be narrowed.

Preparation (continued)

8-ENGLISH

Projection relationships

The dimensional relationship between the screen and the projector is shown below.

■Dimensional relationship diagram

Note

zThis diagram assumes that the size and position of the projected image will be adjusted so

that the image lls the entire screen.

zThis illustration is not drawn to scale.

L Projection distance

LW Minimum distance

LT Maximum distance

L1 Lens protrusion dimension

SH Projected image height

SW Projected image width

SD Projected image size

zDimension for L1 (approximate values) (Unit: m)

Projector model Dimension for L1 (approximate value)

ET-D3LEW10 ET-D3LET30 ET-D3LET40

PT-RQ32K / PT-RZ31K / PT-RS30K 0.18 0.15 0.10

PT-RQ22K / PT-RZ21K / PT-RS20K 0.21 0.18 0.13

Note

zThe illustrations of projectors in this manual are for informational purposes only and do not

represent a specic projector model. Congurations may vary with the model.

Attention

zTo prevent obstruction of the intake and exhaust vents, install the projector with a

clearance at least 500 mm (1 ft. 7 in.) from walls and objects.

If you are installing the projector in a sealed space, be sure to provide additional air

conditioning equipment and ventilation equipment. Insufcient ventilation will result in an

accumulation of heat and may activate the projector's protection circuit.

zAvoid setting up in places which are subject to sudden temperature changes, such as near

an air conditioner or lighting equipment (studio lamps, etc.).

■Dimensional relationship

For details on the projection distance (L), refer to “Projected image size and Projection

distance” and “Projection distance formulas” in the Appendix.

L (LW/LT)

SW SH

投写画面

スクリーン

Projected image

Screen

ENGLISH-9

After moving the lens to the home position according to “Lens calibration” on page 7,

you can use the position of the projected image at that position (i.e., the standard

projection position) as a basis, and use the lens shift adjustment function on the projector

to adjust the position of the projected image within the respective lens shift ranges.

Perform lens shift adjustment within the ranges shown in the following illustrations.

Moving the lens outside of the adjustment ranges may alter the focus. This occurs due

to limitations in lens movement that are intended to protect the optical components.

The following illustrations depict lens shift ranges for oor installations of the projector.

PT-RQ32K / PT-RQ22K

PT-RZ31K / PT-RZ21K

PT-RS30K / PT-RS20K

Note

zThe home position of the projector a point of origin position for the lens shift (i.e., vertical and

horizontal positions of the lens) based on the results of lens calibration. It is not the optical

center position of the screen.

0.29H0.29H

0.15V0.15V

0.59V

Projected image

width H

Projected image height V

Standard projection position

0.2H

0.12V0.12V

0.55V

Projected image

width H

Projected image height V

Standard projection position

0.3H

0.1V0.1V

0.5V

Projected image

width H

Projected image height V

Standard projection position

Lens shift ranges

10-ENGLISH

Dimensions

Specications

(Unit: mm)

Model number Dimensions

ET-D3LEW10

Ø 154 (6-1/16")

Ø 130 (5-1/8")

354 (13-15/16")

ET-D3LET30

Ø 130 (5-1/8")

Ø 154 (6-1/16")

322 (12-11/16")

Check the specications of each projection lens, and use the appropriate lens for your

intended use.

Model No. ET-D3LEW10 ET-D3LET30 ET-D3LET40

F value 2.5 2.5 2.5

Focal Length (f) 26.6 mm (1-1/16") -

36.4 mm (1-7/16")

50.4 mm (1-31/32") -

98.0 mm (3-27/32")

96.6 mm (3-13/16") -

154.9 mm (6-3/32")

Dimensions*1

Width 154 mm (6-1/16") 154 mm (6-1/16") 154 mm (6-1/16")

Height 154 mm (6-1/16") 154 mm (6-1/16") 154 mm (6-1/16")

Depth 354 mm (13-15/16") 322 mm (12-11/16") 279 mm (10-31/32")

Net Weight Approx. 6.2 kg (13.7 lb) Approx. 5.8 kg (12.8 lb) Approx. 5.0 kg (11 lb)

*1: Excluding protrusions.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Objectif de l'appareil photo

Panasonic

Panasonic AK-LZ20M85G Manuel utilisateur

Panasonic

Panasonic Lumix S-R24105GK Manuel utilisateur

Panasonic

Panasonic VWCLT2 Manuel utilisateur

Panasonic

Panasonic Lumix H-H020A Manuel utilisateur

Panasonic

Panasonic 5025232891795 Manuel utilisateur

Panasonic

Panasonic ET-ELW22C Manuel utilisateur

Panasonic

Panasonic WV-LA210C3 Manuel utilisateur

Panasonic

Panasonic WV-LZ62 Manuel utilisateur

Panasonic

Panasonic H-HS043 Manuel utilisateur

Panasonic

Panasonic Lumix H-HS12035 Manuel utilisateur

Panasonic

Panasonic WV-LA12A Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FX01 Manuel d'utilisation et d'entretien

Panasonic

Panasonic AW-S14 X BRM Manuel utilisateur

Panasonic

Panasonic ET-D3QW300 Manuel utilisateur

Panasonic

Panasonic DMWLWA52 Manuel utilisateur

Panasonic

Panasonic L-X025 - Leica D Summilux Lens Manuel utilisateur

Panasonic

Panasonic AG-LA7200G Manuel utilisateur

Panasonic

Panasonic S-S24 Manuel utilisateur

Panasonic

Panasonic H-HSA12035PP Manuel utilisateur

Panasonic

Panasonic Lumix DMC-GH2 Manuel utilisateur

Panasonic

Panasonic WV-LA2R8C3B Manuel utilisateur

Panasonic

Panasonic LUMIX S PRO R1635 Manuel utilisateur

Panasonic

Panasonic ET-DLE060 Manuel utilisateur

Panasonic

Panasonic Lumix G Vario H-FS1442AKA Manuel utilisateur

Manuels Objectif de l'appareil photo populaires d'autres marques

THORLABS

THORLABS ELL15 Manuel utilisateur

FUJICA

FUJICA ZC1000 Manuel utilisateur

Tamron

Tamron A09 Manuel

Sony

Sony SEL-55210 Manuel utilisateur

Sony

Sony VCL-HG2037 Manuel utilisateur

Honeywell

Honeywell HLM25V6F12 Manuel utilisateur

Sony

Sony VCL-ST30 Manuel utilisateur

Canon

Canon FD 35 - 70 mm Manuel utilisateur

Sony

Sony SAL-85F14Z - 85mm f1.4 Carl Zeiss Planar T Coated Telephoto... Manuel utilisateur

ARRI

ARRI Lenses Manuel utilisateur

Nikon

Nikon AF-S VR 24-120 f/3.5-5.6G IF-ED Manuel utilisateur

Rokinon

Rokinon DS50M-C Manuel utilisateur

Olympus

Olympus M.Zuiko Digital ES 300mm f4.0 IS PRO Manuel utilisateur

Sony

Sony VCL-DE07T Manuel utilisateur

Canon

Canon FD Lens Manuel

Tamron

Tamron A036 Manuel utilisateur

Samsung

Samsung 20-50mm F3.5-5.6 ED II Manuel utilisateur

Tamron

Tamron 272E Manuel utilisateur
