Basic Operating Instructions

Dual Camera

Model No. HX-DC3

Please read these instructions carefully before using this product,

and save this manual for future use.

This document explains basic operations

of the unit. For more detailed explanation,

please refer to “Operating Instructions

(PDF format)” which is recorded in the

enclosed CD-ROM.

until

2013/1/21

VQT4U81

1AG6P1P6613--(S)

HX-DC3GCGAGN-VQT4U81_mst.book 1 ページ２０１２年１２月２６日　水曜日　午前１０時８分

2 VQT4U81

∫Concerning the battery

Information for Your Safety

WARNING:

To reduce the risk of fire, electric shock or product damage,

≥Do not expose this unit to rain, moisture, dripping or splashing.

≥Do not place objects filled with liquids, such as vases, on this unit.

≥Use only the recommended accessories.

≥Do not remove covers.

≥Do not repair this unit by yourself. Refer servicing to qualified

service personnel.

CAUTION!

To reduce the risk of fire, electric shock or product damage,

≥Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

≥Do not obstruct this unit’s ventilation openings with newspapers,

tablecloths, curtains, and similar items.

≥Do not place sources of naked flames, such as lighted candles, on

this unit.

The socket outlet shall be installed near the equipment and shall be

easily accessible.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above

60 oC or incinerate.

CAUTION

≥Danger of explosion if battery is incorrectly replaced. Replace only

with the type recommended by the manufacturer.

≥When disposing the batteries, please contact your local authorities

or dealer and ask for the correct method of disposal.

HX-DC3GCGAGN-VQT4U81_mst.book 2 ページ２０１２年１２月２６日　水曜日　午前１０時８分

VQT4U81 3

∫Product identification marking

-If you see this symbol-

Product Location

Dual Camera Battery holder

Information on Disposal in other Countries outside the

European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact

your local authorities or dealer and ask for the

correct method of disposal.

HX-DC3GCGAGN-VQT4U81_mst.book 3 ページ２０１２年１２月２６日　水曜日　午前１０時８分

4 VQT4U81

∫Cautions for use

For Australia and New Zealand

In the event of abnormal operation (e.g. if the unit emits smoke or an

unusual smell), immediately stop operating the unit and consult the

Panasonic Customer Care Centre on 132600.

Keep this unit as far away as possible from electromagnetic

equipment (such as microwave ovens, TVs, video games etc.).

≥If you use this unit on top of or near a TV, the pictures and/or sound on

this unit may be disrupted by electromagnetic wave radiation.

≥Do not use this unit near cell phones because doing so may result in

noise adversely affecting the pictures and/or sound.

≥Recorded data may be damaged, or pictures may be distorted, by

strong magnetic fields created by speakers or large motors.

≥Electromagnetic wave radiation generated by microprocessors may

adversely affect this unit, disturbing the pictures and/or sound.

≥If this unit is adversely affected by electromagnetic equipment and

stops functioning properly, turn this unit off and remove the battery or

disconnect AC adaptor. Then reinsert the battery or reconnect AC

adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

≥If you record near radio transmitters or high-voltage lines, the recorded

pictures and/or sound may be adversely affected.

About connecting to a PC

≥Do not use any other USB cables except the supplied one.

About connecting to a TV

≥Do not use any other AV cables except the supplied one.

≥Always use a genuine Panasonic HDMI mini cable (RP-CDHM15,

RP-CDHM30: optional).

∫About recording formats and compatibility of the unit

≥The unit is an MP4 format (MPEG-4 AVC file standard) Dual Camera

for recording high-definition motion pictures.

≥AVCHD and MPEG2 motion pictures are different formats, and are not

therefore supported by the unit.

∫Indemnity about recorded content

Panasonic does not accept any responsibility for damages directly or

indirectly due to any type of problems that result in loss of recording or

HX-DC3GCGAGN-VQT4U81_mst.book 4 ページ２０１２年１２月２６日　水曜日　午前１０時８分

VQT4U81 5

edited content, and does not guarantee any content if recording or editing

does not work properly. Likewise, the above also applies in a case where

any type of repair is made to the unit (including any other non-built-in

memory related component).

∫About Condensation (When the lens or the LCD

monitor is fogged up)

Condensation occurs when there is a change in temperature or humidity,

such as when the unit is taken from outside or a cold room to a warm

room. Please be careful, as it may cause the lens or LCD monitor to

become soiled, moldy, or damaged.

When taking the unit to a place which has a different temperature, if the

unit is accustomed to the room temperature of the destination for about

one hour, condensation can be prevented. (When the difference in

temperature is severe, place the unit in a plastic bag or the like, remove

air from the bag, and seal the bag.) When condensation has occurred,

remove the battery and/or the AC adaptor and leave the unit like that for

about one hour. When the unit becomes accustomed to the surrounding

temperature, fogginess will disappear naturally.

∫Cards that you can use with this unit

SD Memory Card, SDHC Memory Card and SDXC Memory Card

≥4 GB or more Memory Cards that do not have the SDHC logo or 48 GB

or more Memory Cards that do not have the SDXC logo are not based

on SD Memory Card Specifications.

≥Refer to page 13 for more details on SD cards.

∫For the purposes of these operating instructions

≥SD Memory Card, SDHC Memory Card and SDXC Memory Card are

referred to as the “SD card”.

≥Functions that can be used for motion picture recording/motion picture

playback are indicated by in these operating instructions.

≥Functions that can be used for still picture recording/still picture

playback are indicated by in these operating instructions.

≥Functions that can be used for audio recording/audio playback are

indicated by in these operating instructions.

≥Pages for reference are indicated by an arrow, for example: l00

≥“File” is used to mean “scene”, “still picture” and “audio file”.

HX-DC3GCGAGN-VQT4U81_mst.book 5 ページ２０１２年１２月２６日　水曜日　午前１０時８分

6 VQT4U81

Information for Your Safety..... 2

Accessories.............................. 7

Optional accessories........... 7

Preparation

Power supply............................ 8

Inserting/removing

the battery ........................... 8

Charging the battery ......... 10

Charging and recording

time ................................... 12

Recording to a card ............... 13

Cards that you can use

with this unit ...................... 13

Inserting/removing

an SD card ........................ 13

Turning the unit on/off........... 15

Setting date and time............. 15

Basic

Recording motion pictures.... 17

Recording still pictures ......... 18

Recording audio ..................... 19

Intelligent Auto Mode............. 19

Motion picture/Still picture/

Audio playback....................... 20

Watching Video/

Pictures on your TV ........... 21

Using the menu screen.......... 22

Language selection ........... 24

Formatting ......................... 24

Using the zoom....................... 24

Double range zoom ........... 25

Others

About copyright...................... 26

Specifications ......................... 27

Limited Warranty

(ONLY FOR AUSTRALIA) .... 31

Contents

∫How to open the Operating Instructions

(PDF format)

When you insert the CD-ROM and open the [INDEX.pdf] in the CD-

ROM, the Operating Instructions list will be displayed. Click the

document name of the Operating Instructions you would like to open.

≥Adobe Reader is required to view the PDF file. Please download it

from the homepage of Adobe Systems Incorporated.

HX-DC3GCGAGN-VQT4U81_mst.book 6 ページ２０１２年１２月２６日　水曜日　午前１０時８分

VQT4U81 7

*1 Keep the lens cap out of reach of children to prevent swallowing.

*2 To prevent the unit from dropping, be sure to attach the handstrap.

Optional accessories

Some optional accessories may not be available in some countries.

Accessories

Check the accessories before using this unit.

Product numbers correct as of Dec. 2012. These may be subject to

change.

Battery pack

VW-VBX070

Lens cap*1

VFC4701

Lens cap strap

VFC4702

AC adaptor

(GA)

AVSK0751

(GC)

BVSK0752

(GN)

CVSK0753

Handstrap*2

VFC4627

AV cable

VFA0543

CD-ROM

Software

USB cable

VFA0554

CD-ROM

Operating

Instructions

VFF1167

Battery pack (lithium/VW-VBX070)

HDMI mini cable (RP-CDHM15, RP-CDHM30)

HX-DC3GCGAGN-VQT4U81_mst.book 7 ページ２０１２年１２月２６日　水曜日　午前１０時８分

8 VQT4U81

∫About batteries that you can use with this unit

The battery that can be used with this unit is VW-VBX070.

Inserting/removing the battery

≥Press the power button to turn off the unit. (l15)

1Open the battery/card cover.

Preparation

Power supply

It has been found that counterfeit battery packs which look very

similar to the genuine product are made available to purchase in

some markets. Some of these battery packs are not adequately

protected with internal protection to meet the requirements of

appropriate safety standards. There is a possibility that these battery

packs may lead to fire or explosion. Please be advised that we are not

liable for any accident or failure occurring as a result of use of a

counterfeit battery pack. To ensure that safe products are used we

would recommend that a genuine Panasonic battery pack is used.

Slide while pushing the battery/

card cover.

2Open the battery/card cover.





HX-DC3GCGAGN-VQT4U81_mst.book 8 ページ２０１２年１２月２６日　水曜日　午前１０時８分

VQT4U81 9

2Insert the battery, taking care to match up the

terminal markings.

Aterminal markings

≥

Insert the battery so that the terminal markings face up. It is possible to mistakenly

Insert the battery upside down, so be sure to check the orientation carefully.

3Close the battery/card cover.

≥Securely close it until it clicks.

Removing the battery

Press and hold down the power button to turn off the unit, then pull up and

remove the battery.

≥Always check that the LCD monitor and status indicator lamp are off.

≥Keep the battery pack out of reach of children to prevent swallowing.



HX-DC3GCGAGN-VQT4U81_mst.book 9 ページ２０１２年１２月２６日　水曜日　午前１０時８分

10 VQT4U81

Charging the battery

The unit is in the standby condition when the AC adaptor is connected.

The primary circuit is always “live” as long as the AC adaptor is

connected to an electrical outlet.

Important:

≥The AC adaptor and USB cable are for use with this unit only. Do

not use them with other equipment. Similarly, do not use AC

adaptors and USB cables from other equipment with this unit.

≥The battery is charged while the unit is off or in the Standby Mode.

The battery cannot be charged while the unit is recording or

playing back.

≥It is recommended to charge the battery in a temperature between

10 oC and 30 oC. (The battery temperature should also be the

same.)

AStatus indicator

BAC adaptor

CTo the AC outlet

≥Insert the plugs as far as they will go.

When this unit is purchased, the battery is not charged. Charge

the battery fully before using this unit for the first time.











HX-DC3GCGAGN-VQT4U81_mst.book 10 ページ２０１２年１２月２６日　水曜日　午前１０時８分

Autres manuels pour HX-DC3

Table des matières

Autres manuels Panasonic caméscope

Panasonic

Panasonic AG-HMC150 Manuel utilisateur

Panasonic

Panasonic VDR-D160EB Manuel utilisateur

Panasonic

Panasonic Palmcorder PalmSight PV-L681 Manuel utilisateur

Panasonic

Panasonic HC-W580 Instructions d'installation et d'entretien

Panasonic

Panasonic AG-DVC62 Manuel utilisateur

Panasonic

Panasonic HC-V785 Manuel utilisateur

Panasonic

Panasonic PVL354 - VHS-C CAMCORDER Manuel utilisateur

Panasonic

Panasonic ENA Manuel utilisateur

Panasonic

Panasonic AJ-HDX400 Manuel utilisateur

Panasonic

Panasonic HC-X1000PP Manuel utilisateur

Panasonic

Panasonic PV-L552H Manuel utilisateur

Panasonic

Panasonic HC-V787 Manuel utilisateur

Panasonic

Panasonic VariCam AJ-HPX3700G Manuel utilisateur

Panasonic

Panasonic SDR-S100E Manuel utilisateur

Panasonic

Panasonic AK-HC3800GS Manuel utilisateur

Panasonic

Panasonic AG-DVC7P Manuel utilisateur

Panasonic

Panasonic NV-GS230EB Manuel utilisateur

Panasonic

Panasonic AG-HMC151EJ Manuel utilisateur

Panasonic

Panasonic AK-HC1800G Manuel utilisateur

Panasonic

Panasonic NV-GS 8 EGE Manuel utilisateur

Panasonic

Panasonic AG-AC30PJ Manuel utilisateur

Panasonic

Panasonic AJ-PX800G Manuel utilisateur

Panasonic

Panasonic HC-W570 Caractéristiques techniques

Panasonic

Panasonic NV-GS85GC Manuel utilisateur

Manuels caméscope populaires d'autres marques

Toshiba

Toshiba CAMILEO Z100 Manuel utilisateur

Canon

Canon RC 260 Manuel utilisateur

Sony

Sony Handycam DCR-DVD7E Manuel utilisateur

Brinno

Brinno TimeLapse TLC200 Manuel utilisateur

JVC

JVC GR-SXM68AC Guide de démarrage rapide

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur

MYDLINK

MYDLINK DCS-6100LH Manuel utilisateur

Sony

Sony video Hi8 Handycam CCD-TR555 Manuel utilisateur

SECURECOM

SECURECOM V-5014B Manuel utilisateur

Sharper Image

Sharper Image U-VIDEO Manuel utilisateur

JVC

JVC AA-V15EG Manuel utilisateur

Canon

Canon LEGRIA HV40 Manuel utilisateur

Sony

Sony Handycam DCR-VX2000 Manuel utilisateur

RCA

RCA CC616 Manuel utilisateur

ATIK Cameras

ATIK Cameras Horizon Manuel utilisateur

Sony

Sony Handycam HDR-CX580V Manuel utilisateur

Sharp

Sharp ViewcamZ VL-Z8H Manuel utilisateur

Philips

Philips M620/21 Manuel utilisateur
