Palsonic DVD3000 Manuel utilisateur

DIGITAL VIDEO DISC PLAYER

MODEL: DVD3000

DVD / VIDEO CD / AUDIO CD PLAYER

USER MANUAL

DIGITAL VIDEO

DIGITAL AUDIO

DIGITAL

PALSONIC CUSTOMER SERVICE

TELEPHONE

AUSTRALIA: 1300 657 888

PALSONIC CORPORATION PTY LTD

1 JOYNTON AVE

WATERLOO NSW 2017 AUSTRALIA

FAX:(02)93137555

TEL:(02)93137111

Catalogue

Importont Safetyinformation ............................................................................2

Precautions ........................................................................................................5

Features .............................................................................................................6

Accessories .......................................................................................................6

Basic operation .................................................................................................6

Remote control unit...........................................................................................7

Front panel and back panel ...............................................................................8

Front panel display.............................................................................................9

Basic connection ...............................................................................................10

Optional audio connections ...............................................................................10

Remote control preparation ...............................................................................11

DVD play ..........................................................................................................11

Direct selection of scenes ..................................................................................13

Repeat play.........................................................................................................13

Convenient functions ........................................................................................14

Initial settings ....................................................................................................15

VCD play ..........................................................................................................17

KARAOKE play ...............................................................................................19

MP3and CD disc play........................................................................................20

Troubleshooting.................................................................................................21

SAFETY PRECAUTIONS

THIS LIGHTING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL

TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF

UNINSULATED "DANGEROUS VOLTAGE" WITHIN THE PRODUCT’S ENCLOSURE

THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF

ELECTRIC SHOCK TO PERSONS..

THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED

TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING

AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE

ACCOMPANYING THE APPLIANCE.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE. DANGEROUSE HIGH VOLTAGE ARE PRESENT

INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINETREFER SERVICING TO

QUALIFIED PERSONNEL ONLY.

CAUTION: TO PREVENT ELECTRIC SHOCK,MATCH WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

CAUTION: This Digital Video Player employs a Laser System.

To ensure proper use of this product, please read this user’s manual carefully and retain for

future reference. Should the unit require maintenance, contact an authorized service

location-see service procedure.

Use of controls, adjustments or the performance of procedures other than those specified

may result herein hazardous radiation exposure.

To prevent direct exposure to laser beam, do not try to open the enclosure.

Visible laser radiation when open and interlocks defeated.

DO NOT STARE IN BEAM.

WARNING: Change or modifications made to this equipment, not expressly approved by our

company,or parties authorized by our company, could void the user’s authority to

operate the equipment.

Important Safety Instruction

CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THE

USER’S MANUAL AND THOSE MARRED ON THE UNIT. RETAIN THE BOOKLET FOR FUTURE

REFERENCE.

This set has been designed and manufactured to assure personal safety. Improper use can result in electric

shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following

procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts

that can repaired by the user.

DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.

REFER SERVICING TO QUILIFIED SERVICE PERSONNEL ONLY.

1. Reading user’s manual

Please read the user’s manual carefully and follow the instruction to operate the unit.

2. Power Source

This product should be operated only from the type of power source indicated on the marking label. If you are

not sure of the type of power supply to your home, consult your product dealer or local power company.

3. Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product

and these opening must not be blocked or covered. The openings should never be blocked by placing the

product on a bed, sofa, rug or other similar surface. This product should not be placing in a built-in

installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s have been

adhered to.

4. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other

products (including amplifiers) that produce heat.

5. Water and Moisture

Do not use the product near water -for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a

wet basement; or near a swimming pool and the like.

6. Cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a

damp cloth for cleaning.

7. Power-Cord Protection

Power -supply cords should be routed so that they are not likely to be walked on or pinched by items placed

upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point

where they exit from the product.

8. Overloading

Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a

risk of fire or electric shock.

9. Lighting

For added protection for this product during storm, or when it is left unattended and unused for long

periods of time, unplug it from the wall outlet. This will prevent damage to the product due to lighting and

power-line surges.

10. Object and Liquid Entry

Never push objects of any kind into this product through opening as they may touch dangerous voltage

points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the

product.

11. Attachments

Do not use attachments not recommended by the product manufacturer as they may cause hazards.

12. Accessories

Do not use this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, cause

serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod,

bracket, or table recommended by the manufacturer’s instructions, and should use a mounting accessory

recommended by the manufacturer. A product and cart combination should be moved with care. Quick

stops, excessive force, and uneven surface may cause the product and cart combination to overturn.

13. Disc Tray

Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury ,

14. Burden

Do not place a heavy object on or step on the product. The object may fall, causing serious personal injury

and serious damage to the product.

15. Disc

Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious

personal injury and product malfunction.

16 Damage Requiring Service.

Unplug this product from the wall outlet and refer servicing to qualified service personal under the

following conditions:

a) When the power-supply cord or plug is damage.

b) If liquid has been spilled, or objects have fallen into the product.

c) If the product does not operate normally by following the operating instructions. Adjust only those

controls that are covered by the operating instructions as an improper adjustment of other controls

may result in damage and will often require extensive work by a qualified technician to restore the

product to its normal operation.

d) If the product has been dropped or damage in any way .

e) If the product has been exposed to rain or water .

f) Water the product exhibits a distinct change in performance-this indicates a need for service.

17. Servicing

18. Replacement Parts

Do not attempt to service this product yourself as opening or removing covers may expose you to

dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

When replacement parts are required, be sure the service technician has used replacement parts specified

by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may

result in fire, electric shock, or other hazards.

lPrecautions

Please read this precautions before operating this player.

n Power cord protection

To avoid any malfunction of the unit, and to avoid electric shock, fire or personal injury, please observe the

following.

lHold the plug firmly when connecting or disconnecting the

AC power cord.

lKeep the AC power cord away from heating appliances.

Never put any heavy object on the AC power cord.

Do not attempt to repair or reconstruct the AC power cord in any way.

Placement

Avoid placing the unit in areas of

Direct sunlight or heating radiators, or closed automobiles.

High temperature (over 35 C ) or high humidity (over 90%).

Much dust and without ventilation.

Or the internal parts may be seriously damaged.

Nonuse Periods

When the unit is not being used, please switch it off.

When the unit is unused for a long time, it should be unplugged from the AC outlet.

nNo fingers or other objects inside

Touching internal parts of this unit is dangerous and may cause serious damage to the unit. Do not try to

disassemble the unit.

lDo not put any other objects on the disc tray.

n Keep away from water/magnet.

lKeep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit, serious damage

may occur.

lNever bring a magnet or magnetized object near the unit.

n Placing

Place the unit in a horizontal position, and do not place anything heavy on it.

Condensation

Moisture may form on the lens in the following conditions:

lShort time after a heater has been turned on.

lIn a steamy or very humid room.

lWhen the unit is suddenly moved from a cold environment to a warm one.

If moisture forms inside this unit, it may not operate properly.

In this case, turn on the power and wait about one hour for the moisture to evaporate.

nWhen appear interfere in the TV if receiving broadcast

According to the difference of TV’s receiving condition, if receiving broadcast when turning on this unit,

interfere may be appeared on the TV screen. This is not mean this unit or TV have malfunction. Please turn

off the unit if you want to watch TV.

Dear customers:

Thank you for your purchasing of this DVD Player produced .

We strongly suggest you carefully read the Operating Instructions and take special note to the precautions

listed below before enjoying it.

l Features

DVD: a completely new dimension in video entertainment.

Subtitles may be displayed in one of a maximum of 32 languages *.

The audio soundtrack can be heard in up to 8 languages *.

The multi-angle function allows you to choose the viewing angle of scenes that were shot from a number

of different angles. (Limited to DVD discs recorded with multiple camera angles.)

*The number of the languages recorded is dependent on the disc.

nHigh quality digital audio

The DVD player include 5.1 channels (Dolby AC-3) stream output port which makes it possible to enjoy

Dolby Digital Surround sound by adding an optional AC-3 decoder.

With the linear PCM sound of 48kHz/16bit-96kHz/24bit, audio quality exceeding that of audio CDs

becomes possible.

lModel DVD3000 player feature AC-3 5.lch audio output.

nMany convenient features

Direct access to favorite scenes (title/chapter/time)

The player equipped with microphone jacks and echo level controls for enjoying KARAOKE.

Chinese or English menu select optionally.

Parental lock settings to prevent play of discs unsuitable for some audiences [Limited to some DVD discs]

nCompatible with PAL DVD discs and NTSC DVD discs

lThis DVD player can play discs in either PAL or NTSC system for it has system transfer function.

nThis player can play SVCD, CVD, VCD and audio CD discs as well as DVD discs.

lAccessories

A remote control unit

An audio/video connect cord

An user manual

A scart cord

lBasic operation

1. Preparation

A. Before playing DVD orVCD discs, please turn on the TV and select the correct video input.

B. If you want to enjoy the sound through audio speaker system, please turn on the audio system and select

the correct audio input.

C. If there is no audio system to playback Dolby AC-3 digital sound, please press the key SETUP in the

remote control unit to set the “audio output” to analogue status (through the in remote control

unit). After setting up, press keys SETUP to exit.

(Analogue audio output is the default setting in the factory).

2. Simple playback

A. Press the button POWER in the front panel and the power supply indicator will illuminate, the TV will

display the initiate image.

B. Press the button OPEN/CLOSE in front panel (or the key in remote control unit) to open the disc tray .

C. Place a disc onto the tray, position it with the printed title side facing up.

D. Press the button PLAY in front panel [or the key, (confirm/play) in remote control unit3

lRemote control unit

E. Enjoy the disc content......, you can press the

remote key listed below to help enjoying freely:

(1)press key (pause): to pause the playing,

press key again, the player will work again.

(2)press the key VOL(+),(-) in remote control

unit will change the DVD audio output level.

(3)ZOOM key: The image in TV display will

zooming up from the center, press the key again,

the zoom rate will be doubled, press it third time,

the player will return to normal play. In zoom

status, press remote key will change

the focus position.

(4) or ( fast forward or fast backward)

key: allow you to scan the disc soon, press

confirm/play) key, the player will return to

normal play.

(5) II key ( slow play): slow down the display

speed, press, (confirm/play) key, the player

will return to normal play.

or (skip)key: select previous or

next chapter/title

F. Press the button STOP in front panel or then

(stop) key in remote control unit, the player will

stop in current position, the display will show

"PRESS PLAY TO CONTINUE". If you want

to enjoy the playing after a while, press PLAY,

otherwise, press STOP to end the playing.

G. Press the button OPEN/CLOSE in front panel or

the (open/close) in remote control unit,

the disc tray will be opened.

H. Take off the disc with care and press the

OPEN/CLOSE button or the keyr (open /close)

in remote control unit, the disc tray will be

closed.

I. Press the button POWER in front panel, the

power indicator in DVD player will switched

off.

Notes

Due to the reason, the DVD player may

function with a little differences. This is not the

malfunction of the player.

Note: shape of the remote control unit may be changed,

this figure only for reference.

This instuction include the function explained of all

remote key.

lFront panel and back panel

DVD 3000

2 46 7

13 10 9 15

(1) POWER SWITCH

(2) MIC 1 JACK

(3) MIC VOL LEVEL

(4) MIC 2 JACK

(5) MIC ECHO LEVEL

(6) VFD

(7) DISC TRAY

(8) OPEN/CLOSE

(9) PLAY

(10) PAUSE

(11) PREVIEW

(12) NEXT

(13) STOP

(14) FAST REVERSE

(15) FAST FORWARD

(1) ELECTRICAL SPDIF OUTPUT (7) Dolby 5.1 CH SUBWOOFER AUDIO UTPUT

(2) MIXED AUDIO(L) OUTPUT (8) Dolby 5.1 CH SURROUND AUDIO(L) OUTPUT

(3) MIXED AUDIO(R) OUTPUT (9) Dolby 5.1 CH SURROUND AUDIO(R) OUTPUT

(4) Dolby 5.1 CH FRONT AUDIO(L) OUTPUT (10) S-VIDEO OUTPUT

(5) Dolby 5.1 CH FRONT AUDIO(R) OUTPUT (11) VIDEO OUTPUT

(6) Dolby 5.1 CH CENTER AUDIO OUTPUT (12) POWER CORD

Autres manuels pour DVD3000

Table des matières

Autres manuels Palsonic Lecteur DVD

Palsonic

Palsonic DVD3632USB Manuel utilisateur

Palsonic

Palsonic DVD2050DX Manuel utilisateur

Palsonic

Palsonic DVD5000 Manuel utilisateur

Palsonic

Palsonic DVD9300PS Manuel utilisateur

Palsonic

Palsonic DVD2040 Manuel utilisateur

Palsonic

Palsonic DVD2060DX Manuel utilisateur

Palsonic

Palsonic DVD8000 Manuel utilisateur

Palsonic

Palsonic DVD7000 Manuel utilisateur

Palsonic

Palsonic DVD2040 Manuel utilisateur

Palsonic

Palsonic DVD2045DX Manuel utilisateur

Palsonic

Palsonic DVD/CD/MP3 DVD2030 Manuel utilisateur

Palsonic

Palsonic DVD2880PS Manuel utilisateur

Palsonic

Palsonic PVP150 Manuel utilisateur

Palsonic

Palsonic DVD9100 Manuel utilisateur

Palsonic

Palsonic DVD4000 Manuel utilisateur

Palsonic

Palsonic DVD2042USB Manuel utilisateur

Palsonic

Palsonic DVD3000 Fiche d'information produit

Palsonic

Palsonic DVD9200 Manuel utilisateur

Palsonic

Palsonic DVD2080HD Manuel utilisateur

Palsonic

Palsonic DVD2000 Manuel utilisateur

Palsonic

Palsonic DVD2050BK Manuel utilisateur

Palsonic

Palsonic DVD2000 Fiche d'information produit

Palsonic

Palsonic DVD7500 Manuel utilisateur

Palsonic

Palsonic TFTV100A Manuel utilisateur

Manuels Lecteur DVD populaires d'autres marques

Sony

Sony DVP-F11 Manuel utilisateur

Philips

Philips DVP3560K/F8 Manuel utilisateur

LENCO

LENCO DVP-740 X2 Manuel utilisateur

JVC

JVC XV-N650BEU Manuel utilisateur

Aiwa

Aiwa XD-DV370 Manuel utilisateur

MedeaWiz

MedeaWiz Sprite 4K DV-S4 Manuel utilisateur

Denon

Denon DVM-1805 - DVD Changer Manuel utilisateur

Toshiba

Toshiba SD-3815 Manuel utilisateur

Tevion

Tevion 44330 Manuel utilisateur

Samsung

Samsung DVD-HD860 Manuel utilisateur

Sylvania

Sylvania DP170SL8 Manuel utilisateur

Toshiba

Toshiba SD-P1200 Manuel utilisateur

JVC

JVC XV-D9000E Manuel utilisateur

Dolby Laboratories

Dolby Laboratories CP650 Manuel utilisateur

Philips

Philips DVD737K/931 Manuel utilisateur

Denon

Denon DVD-5900 Manuel utilisateur

Philips

Philips DVD 951 Manuel utilisateur

Philips

Philips DVDR3460 Manuel utilisateur
