Instructions TVBOX
1
HD Network Player
TVBOX -005
Manual
V1.0
Instructions TVBOX
2
Dear user：
Thank you very much for choosing this product，We sincerely hope
you can get long-lasting enjoyment.，wish you the best experience from the
product!
This manual contains all the information in the time of publication are
subject to stringent calibration，ensuring accurate. However, due to
continuous product upgrades and enhancements, to your device, on the
appearance and functionality, and use, there may be associated with this
manual describe the discrepancy, and we hope you the actual
productprevail, and you are welcome to call our service personnel
consulting.
This in this manual for your use of this product as an operating
reference, thank you again for choosing this product.
Instructions TVBOX
3
Table of Contents
1、Products..........................................................................2
1.1 Product Description....................................................2
1.2、Product configuration information............................3
1.3、Products and accessories Description…...…..….…..4
1.4、Accessory function Description………..…………..5
1.5、Interface introduced…………………………..……..5
2、First use…………………………………….………….6
2.1、Connection………………………….…...………6
2.2、Connection instructions………….….…..………7
2.3、Operations Guide………………………..………7
3、Note…………………………………………………….12
3.1、Cautions................................................................12
3.2、Cause of the problem and troubleshooting……....12
4、Remarks……………………………………………….13
Instructions TVBOX
4
1、Products
1.1 Products
Dear customer, the machine of your choice is a high performance,
support network function, carrying Android4.0 OS, high-definition
network media player using infrared remote control operation, while
supporting the local variety of formats of media player. Support
HDMI HD output, but also supports standard definition AV output, fit
your TV to bring you the same visual and auditory experience.
All you need family cable network or wireless LAN, simple
configuration, the network capabilities of this machine can be
achieved, so you can enjoy the impact of the TV screen to bring the
network.
The machine to accept any TF card, USB interface, storage
peripherals, audio and video file playback, maximum support 1080P
HD video output for your audio-visual experience extraordinary!
Now, let us become familiar with the machine, grasp the basic
operation of the machine, allowing you to handy home multimedia
experience unparalleled bring pleasure!
Instructions TVBOX
5
1.2 Product configuration information
※Machine size, 103 * 114 * 10mm, provide you with ultra-thin
visual enjoyment
※Super Cortex A8 1.5GHZ many-core processor, 512MB
DDR3 internal memory, built-in capacity of 4GB of space available to
you to store files
※To support the wireless network connection RJ45
connector of the cable network ，To meet your environmental needs
※Plug-in TF card ，The maximum support for 32G※USB
2.0 OTG, HOST interface support the connected computers, and storage
devices to connect the machine allows you to enjoy the time of joy
※Using the infrared wireless remote control and touch buttons
as an input tool, easy to use
※Equipped with Android4.0 operating system ，More
convenient, more stable
※Support up to dozens of screen formats：AV I（H.264, DIVX,
DIVX, XVID, rm, rmvb, MKV（H.264, DIVX, DIVX, XVID), WMV,
MOV, MP4（H.264, MPEG, DIVX, XVID), MPEG, MPG, FLV（H.263，
H.264)
※Covering a full range of audio formats：WAVE、AIFF、AU、
MP3、MIDI、WMA、RealAudio、VQF、OggVorbis、AAC、APE
Instructions TVBOX
6
1.3 Products and accessories Description
Open the package, you will see the following machine and
accessories：
●Machine one units
●Accessories4pieces
●If you buy a high-definition HDMI cable
Instructions TVBOX
7
1.4 Accessory function Description
Accessories 1：USB-network adapter cable for connection to
the wired network interface and the LAN interface, a wired
network connection
Accessory 2：Power adapter 5V/2A power supply for the
process of the machine
Accessories 3：AV adapter cable for connecting the native AV
interface and TV AV interface
Accessories 4 ：Remote control for the vast majority of
human-computer interaction, and a variety of input operation
Accessories (optional)：HD HDMI cable, for connecting a
native HDMI interface and high definition TV HDMI interface
1.5 The machine interface
1、HDMI，Connecting high-definition HDMI cable
2、OTG，Connecting computers and other devices with OTG
function
Instructions TVBOX
8
3、HOST，USB HOST interface for connecting U disk and
other devices
4、LAN，By Accessories USB-network switch to the wiring
adapter cable network
5、AV，Accessories 3 AV adapter cable to connect the TV's AV
interfaces
6、DC，Accessories power adapter input DC power to the
machine's power supply
7、TF card slot，Is used to plug TF card.
2、First use
2.1 Connection
As shown below
2.2 Connection detailed description of
※The definition of the figure "1" wired network interface, DC
(DC power) interface, AV interface, "5 the" HDMI Interface
※Connections on the diagram for the whole interface to
Instructions TVBOX
9
connect your TV, if already identified as "5" HDMI interface, need
to be connected is identified as "3" AV interface, otherwise the
contrary
※If you already have a wireless network, WI-Fi signal, you do
not need to connect the accessories 1 and identifies the interface for
the "1"
※Parts 2, power adapter, in accordance with the purchase plug
norms, placed in a suitable AC out
※Operations such as network settings, use the remote control to
open the machine settings, in accordance with the Android standard
settings, such as setting difficulties, please be familiar with the
Android operating system
※For playback of local audio and video files, please ensure that
the case of power failure, the device is connected to the appropriate
choice of the USB interface of the machine or insert TF card
2.3 Operations Guide
◎Connection diagram according to the diagram, depending on
the actual connection, switch TV TV / AV to the
corresponding mode until the emergence of the TV display
properly
◎According to your needs, Internet, press the remote control
to enter set -- Wireless and network -- Open
WI-FI—The WI-FI settings
—To find the name of the corresponding network—Enter a pass
word,to show the connection
◎If you need media player using the remote control to choose
the right player to open, locate the file you want to play, press OK
◎If you want to achieve other functions, in accordance with the
requirements of the Android using the remote control
Instructions TVBOX
10
◎Remote control operation guide:
1、Press the power button control system sleep, long
press the power button control system shutdown.
2、The nine key position, the squared button is pressed, via
digital keys quickly move the mouse position.
The entire screen is evenly divided into nine in the, as shown
below. Digital keys, move the mouse to the corresponding region.
Press the button again, the number keys to restore the number sign
and the abolition of the fast-moving mouse.
