ARM-EVAC® 250 & 200 SYSTEMS
Pace ARM-EVAC® 250 & 200 SYSTEMS
FUME EXTRACTION SYSTEMS
OPERATION &
MAINTENANCE
MANUAL
30/03/2021

ARM-EVAC® 250 & 200 SYSTEMS
MANUAL NO. 8881-0955
REV. A APRIL 1999
Warning
Read the safety and applications information section in
this manual thoroughly before installing and using your
fume extraction system.
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page 2 sur 18

ARM-EVAC® 250 & 200 SYSTEMS
PACE
PACE Incorporated retains the right to make changes to specifications contained herein at any
time, without notice.
Contact your local authori ed PACE Distributor or PACE Incorporated to obtain the latest
specifications
The following are registered trademarks and/or scrvicemarks of PACE Incorporated. Laurel
Maryland U.S.A. and may only be used to identify genuine PACE products or services:
Arm-Evac. Cir-Kit. ConducTwee , CRAFT. Flo-D-Sodr, Heat Wave. HotSpot. LapFlo, MBT, Micro
Portable. MicroChine. MiniChine, Mini-Wave. PACE, Pacenter, Pik-Tip, PETS, Prep-Set,
ResisTwee , SenseTemp, Snap-Vac, Sodr-Pen, Sodr-X-Tractor, ST, StripTwee , Thermo-Drive.
ThermoFlo, ThermoJet, ThermoPart, ThermoPik, ThermoTwee .
The following arc trademarks andfor servicemarks of PACE Incorporated, Laurel Maryland
U.S.A.and may only be used to identify genuine PACE products or services:
Sodrtek, Toolnet
Since 1958. PACE Incorporated has provided advanced technology training in
all
aspects of hand soldering, rework and repair.
Additional copies of this manual or other PACE literature may be obtained from:
PACE Europe Ltd. PACE Incorporated
Shcrboume House Sales Administration
Sherboume Drive 9893 Brewers Court
Tilbrook Laurel MD 20723-1990
Milton Keynes USA
MK7 81IX Td: (44)01908 277666 Tel: (301)490-9860
England Fax: (44)01908 277777 Fax: (301)498-3252
© 1999 PACE Incorporated, Laurel MD. All rights reserved. Printed in the U.K.
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page 3 sur 18

ARM-EVAC® 250 & 200 SYSTEMS
TABLE OF CONTENT
TITLE PAGE
General Information 5
Use of this Manual 5
Introduction 5
Environmental Specifications 5
Central Filtration Unit 6
Safety and Applications 8
Installation 10
General 10
Configurations 11
Connecting One Or Two Flex Arms 11
Connecting One Or Two Bench Mounted Flex Arms 11
Connecting the 45mm (1.75") and 50mm (2") Static-Safe Metal Flex Arm 12
Operation 12
Arm-Evac 200 12
Arm-Evac 250 13
Self-Calibration Feature 13
Self-Calibration Procedure 13
Arm-Evac 250 Filter Condition Display 14
Optional Benchtop Controller for Arm-Evac 250 14
Arm-Evac 250 RS232C Output for ISO 14000 Software 15
Maintenance 16
General Tips 16
Filter Replacement 16
Fuses 17
Motor 17
Accessories 17
Replacement Filters 18
TABLES
Table 1: Central Filtration Unit Specifications 6
Table 2: Replacement Filters 18
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page sur 18

ARM-EVAC® 250 & 200 SYSTEMS
GENERAL INFORMATION
USE OF T IS MANUAL
This manual will provide the user with the basic knowledge to properly operate and maintain the
PACE Arm-Evac 250 and Arm-Evac 200 Fume Extraction Systems. If you encounter any difficulty
operating your system or have any questions, call your local authori ed PACE dealer or contact
PACE Applications Engineering directly at the United Kingdom Office at
Tel. (44) 01908 277666, Fax (44) 01908 277777, or PACE Product Management at the U.S. Office at
Tel. (301) 490-9860, Fax (301) 604-8782.
Warning
Read the safety and applications information section in this manual thoroughly before installing
and using your fume extraction system.
INTRODUCTION
The PACE Arm-Evac 250 and Arm-Evac 200 Fume Extraction Systems represent the latest
technology in fume extraction. They feature a heavy-duty, maintenance-free brushless motor along
with a filtration process that includes a pre-filter for coarse particle removal, and a High Efficiency
Particulate Air (I IEPA)/Gas Filter cartridge. The HEPA/Gas Filter is ideal for use in applications
where high efficiency particulate removal is required with the additional benefit of a gas media
blend to neutrali e and adsorb noxious gases. Optional filters are also available.
The Arm-Evac 250 Fume Extraction System also incorporates an innovative filter condition
monitoring system, a self-calibration feature and an RS 232 computer interface for computeri ed
communication. PACE Arm-Evac 250/200 Fume Extraction Systems use specially designed
extraction accessories that can be conveniently mounted on any workbench or tabletop. The Arm-
Evac 250 and Arm-Evac 200 systems are designed to extract fumes from one or two work stations.
ENVIRONMENTAL SPECIFICATIONS
Ambient Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -40°C to 125°C (-40°F to 257°F)
Ambient Operating Humidity: 90% relative humidity maximum non-condensing
Storage Humidity: 90% relative humidity maximum non-condensing
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page 5 sur 18

ARM-EVAC® 250 & 200 SYSTEMS
GENERAL INFORMATION
Central Filtration Unit
Specifications
Arm-Evac 250 Systems Arm-Evac 200
Systems System Part Numbers
8889-0250 (230V) 8889-0255 (110V)
System Part Numbers
8889-0200 (230V) 8889-0205 (110V)
System Power Requirements
220/240V, 50H , 1.3 A 110V, 60H , 3 A
System Power Requirements
220/240V, 50H , 1.3 amps 110V, 60H , 3 amps
Specifications Common To All Arm-Evac 250 and Arm-Evac 200 Systems
Weight: 14.0 kg. (32 lbs.) Inlets: 2 inlets, 75mm (3") dia.
Si e: (Width X Depth x Height) 280 x 300 x
395mm (11 x 13 x 15.5 inches)
Flow Rate 340 m3/h (200 cfm)
With Dual Inlets: [170 m3/h (100 cfm) per inlet]
Housing: 18 gauge steel with epoxy finish Flow Rate With Single Inlet: 290 m3/h (170 cfm)
Noise Level: 59dBA at 2 meters (6.5 ft.) Motor Type: Single Stage Centrifugal
Pre-Filter: Part Number 8883-0111-P5 Multi-Stage Polyester Media, 254 x 254 x 178
mm (10 x 10 x 7 inches)
Combo
HEPA/Gas Filter:
Part Number 8883-0931 HEPA filter composed of borosilicate media . Gas
filter composed of chemisorptive and adsorptive media blend.
Arm-Evac 250 Supplemental Specifications
Filter Condition Gauge: Five (5) color LED display
Filter Condition Pressure Sensor: Laser trimmed thick film ceramic with integrated circuitry
Filter Condition Calibration: Sequential multi-point self-calibration for ero and span levels
Fan Speed Control: Front-panel mounted on/off with integral three-speed (3)
variable switch
Calibration Lockout: Tamperproof keyed switch
Outputs: Remote control and RS232C communication ports
Table 1: Central Filtration Unit Specifications
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page 6 sur 18

ARM-EVAC® 250 & 200 SYSTEMS
SAFETY AND APPLICATION
PACE Fume Extraction systems are designed to reduce the level of harmful contaminants from the work
environment and to assist in the achievement of recommended health and safety requirements for local
exhaust ventilation and contaminant removal. Be sure to follow all Application and Maintenance
guidelines contained herein and precautions contained in other relevant product safety literature (i.e.,
Material Safety Data Sheets) provided with the substances and equipment producing the fumes to be
extracted.
DISCLAIMER
PACE hereby disclaims all responsibility for any personal injury, property damage, fine, citation or
penalty imposed by any government or private entity which results from any use, misuse or mis-
application of this product, failure of the user to regularly maintain the product according to the
recommended guidelines, or failure to adequately monitor fume extraction exhaust air and the ambient
workplace air for the presence of harmful levels of gases, fumes and particulates. Compliance with all
applicable environmental and personnel safety regulations is the sole responsibility of the user and
adequate self-monitoring of exhaust air released into the atmosphere or the workplace as well as
monitoring of the ambient workplace air is strongly recommended. To insure continued effective
performance, the following guidelines must be followed.
SAFETY
DANGERS
1. PACE Fume Extractors are not intended to be used as a substitute for devices such as personal
protective respirators which are designed to remove poorly adsorbed substances including carbon
monoxide, methane, hydrogen, acetylene and other gases. Risk of serious injury or death, fire or
explosion may result from improper use. If in doubt, consult with your industrial hygienist or PACE.
2. Never use PACE Fume Extraction Systems to extract fumes from highly flammable liquids and gases
such as Ether, Gasoline (Petrol) and others. Risk of serious injury, death, fire or explosion may result.
3. High concentrations of airborne contaminants such as Methyl Ethyl Keytone, Cyclohexone,
O one and others, when contacted with activated carbon, can undergo oxidation, decomposition or
polymeri ation resulting in exothermic reactions or heat generation. PACE Fume Extraction Systems
must not be used to extract fumes from these substances when high concentrations are present.
4. Failure to comply with the application and maintenance guidelines, filter replacement schedules,
monitoring recommendations and safety guidelines contained herein and in other relevant product
safety literature (i.e., Material Safety Data Sheets) provided with the substances and equipment
producing the fumes to be extracted could result in risk of serious injury, fire or explosion.
WARNINGS
1. Do not attempt to clean any PACE fume extraction filters for reuse. Cleaning the filters will severely
damage the filter media and, consequently, the filter's performance. This will result in unfiltered,
contaminated air being returned to the working environment. Unfiltered air can also damage the motor
pump.
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page 8 sur 18

ARM-EVAC® 250 & 200 SYSTEMS
SAFETY AND APPLICATION
2. Use with inappropriate chemicals or substances, failure to provide regular maintenance or other
misuse of your Fume Extraction System may result in contaminated air being recirculated into the
work environment.
CAUTIONS
1. Failure to supply the correct voltage to the unit will result in damage to the motor. NOTES 1. To
ensure the highest level of performance, use only PACE replacement filters in your PACE Fume
Extraction System. 2. BE SURE the new filter cartridge is installed with the airflow arrow pointing
downward.
FILTER CARTRIDGE NOTES
PACE Fume Extraction Systems are equipped with filters designed to capture particulates and
noxious gases and odors that are present in the air being filtered. The Fume Extraction systems are
equipped with combinations of pre-filters for coarse particle removal, HEPA filters for fine particle
removal, and gas filter media to remove gaseous compounds. Over time, the HEPA filter will
gradually become clogged, impeding air flow through the system, and the capacity of the gas filter
will be reached, reducing its ability to continue to neutrali e and adsorb noxious gases and odors.
Filter Cartridges must be replaced at regular intervals to ensure that the fume extraction system is
operating effectively. These intervals will vary depending on the type of work being performed, the
level of use, and the amount and composition of airborne contaminants produced. The exhaust air
stream from the central filtration unit as well as the ambient air in the workplace should be
monitored with appropriate and adequate measuring/detection devices to assure compliance with
all applicable Health and Safety regulations.
Flammable vapors and gases (i.e. Isopropyl Alcohol) are removed by and accumulate in the gas
portion of the Filter Cartridge presenting a potential fire ha ard. Therefore, the user must exercise
appropriate precautions when extracting such fumes or when handling and disposing of filters
containing such flammable substances.
Follow all fire safety and personnel protection guidelines contained in the Material Safety Data
Sheet (MSDS) for the substance(s) producing the extracted vapors and gases (fumes). When
disposing of used filters, extreme care must be taken to comply with all applicable environmental
regulations. Carefully consult the MSDS supplied with the material(s) producing the fume. If in
doubt, check with your local Environmental Authority.
Extreme care must be exercised when disposing of a used Filter Cartridges containing potentially
ha ardous substances. When disposing of filters, appropriate and adequate personal protective
equipment (i.e. gloves, respirators, plastic containment bags, etc.) must be used when ha ardous
substances such as asbestos, lead, radioactive or bioha ard materials may be present. Consult the
Material Safety Data Sheet (MSDS) of the materials generating the extracted fume.
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page 9 sur 18

ARM-EVAC® 250 & 200 SYSTEMS
INSTALLATION
GENERAL
The Arm-Evac 250 and Arm-Evac 200 have been designed with maximum installation flexibility in
mind. A number of configurations may be used. (See the "Configurations" section.) The following
are recommended guidelines for setting up your system. If you have any specific questions that this
section does not cover please consult your PACE Representative or call PACE directly.
1. Placement
There are 3 major considerations that need to be addressed for proper placement of the central
filtration unit.
• Exhaust Port: This is located on the back of the filtration unit, next to the power inlet. When
positioning the unit, make sure that the exhaust port is not blocked or that airflow from the exhaust
port is not restricted in any way.
• Unit Location: The filtration unit should be positioned so that it will not block aisleways or impede
normal operating traffic or material handling pathways. It is important to position the unit to allow
for proper clearance to remove the filter access cover and replace the filter as needed.
• Proximity to the work area: The filtration unit should be placed as close to the work area as
possible. If using a flex hose, it is advantageous to keep the length of flex hose as short as
possible. Do not kink or create any sharp bends in the flex hose, as this will reduce airflow.
2. Power
The Arm-Evac 250/200 will plug into a standard 110 volt or 230 volt electrical outlet, depending on
the model you purchased. A line cord is provided with each system. Be sure the unit you have is
rated for the intended power supply.
Caution
Failure to supply the correct voltage to the unit will result in damage to the motor.
3. Self-Calibration Procedure
IMPORTANT
This procedure must be performed on the Arm-Evac 250 before initial
operation.
4. Filters
Before operating the unit, make sure the filters are correctly positioned. The pre-filter is always
located on top, and the direction of airflow is clearly marked on the filter cartridge. Airflow is
always in a downward direction for the Arm-Evac 250/200.
5. Inlet Caps
If an inlet port is not connected to a collection device, it must be covered with the inlet cap
provided.
Orion Industry – 16 chemin de la Guy – 91160 Ballainvilliers – France - Tel +33 1 69 3 53 11
E mailto:info@orion-ind stry.com- W http://www.orion-industry.com/ Page 10 sur 18
Autres manuels pour Arm-Evac 250
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Pace Équipement de laboratoire
Manuels Équipement de laboratoire populaires d'autres marques

Agilent Technologies
Agilent Technologies 5800 ICP-OES Manuel utilisateur

Endress+Hauser
Endress+Hauser Cleanfit CPA875 Manuel utilisateur

NI
NI PXI-5422 Manuel

Collomix
Collomix Aqix Manuel utilisateur

SPEX SamplePrep
SPEX SamplePrep 6875 Freezer/Mill Series Manuel utilisateur

Ocean Insight
Ocean Insight FLAME-NIR+ Manuel utilisateur
