2 3
Setup
Streamer Pro is connected directly to the UI770 box using the included
interface cable.
Interface cable (PABX
RJ/JACK). Included in
the digital oce
phone kit.
Connect the interface
cable to the UI770
headset port.
Phone cable to digital
oce phone
Interface cable to
Streamer Pro
Connect the other
end of the cable to
the Streamer Pro’s
mini jack.
}Note:
Please refer to the UI770 Instructions For Use manual for details on conguring
the phone and/or phone handset to the UI770.
In most cases, the UI770 box is connected to the digital oce phone using a
phone cable to connect the headset port on the digital oce phone to the
UI770's Phone socket.
Control settings on the bottom of the UI770 interface:
*Set the ABC switch to the position that provides the best sound quality.
*Rotate the small volume control dial to achieve the best balance of sound
quality and volume for both parties.
With the ConnectLine digital office phone kit,you can
improve phone conversation with many digital office
phone systems.
How does it work?
By using the ConnectLine system in combination with the Sennheiser
Communication UI770 Interface (UI), the ConnectLine digital oce phone
solution enables Streamer Pro and the hearing instruments to function as a
headset for digital oce phones.
There are two setup options:
• A wired connection directly to Streamer Pro from the UI770 Interface, OR
• A wireless connection using the ConnectLine Phone Adapter 2.0 in
combination with the UI770 Interface
Cable Setup
