USER MANUAL

ENGLISH

SYLVANIA is aregistered trademark of OSRAM Sylvania Inc. used under license.

SDPF7904-DG

Key Points

This manual includes security measures and correct operating methods. For personal

safety, please make sure to read this manual before using. Thank you!

1. The machine adopts capacitive touch screen, you can just touch it by finger or click with

capacitive pen for operation. (Never use the sharp objects to click the screen, or the touch

screen may be damaged).

2. Do not put the device at any high temperature, high humidity or dusty place.

3. Do not drop or crash the device to prevent the violent impacting between the display and

the capacitive touch screen. Or the customers have to take the consequence by them-

selves.

4. Don’t use the different type charger or it may make the device burned. We assume no

liability for the damage. Please contact with our agent if you need the original adaptor.

5. Do not disconnect the device while formatting, or it may make the error.

Our company won’t bear the duty for the loss of the memory erasing on account of the

damage, repair or some other reason. Please operate the device according to the user

manual rightly and backup the important data in time.

6. Do not dismantle this device by yourself, and do not polish it with alcohol, dilution,

or benzene.

7. Do not use this device where electronics is forbidden, such as on the airplane.

8. Do not use this device while walking and driving, avoiding traffic accident.

9. USB is for connecting u-disk only.

For any support needed for this device please contact the

company or the authorized

dis-tributor. Any unauthorized dismantling of the device will make the warranty null and

void.

We reserve the right to keep the change of the products, the specification and design is

subject to change without notice!

4. Micro SD

2. USB

3.RESET

Use a needle or paper clip to reset unit.

5. DC

Connect DC adapter to power on the device.

1. POWER

Load external micro SD memory cards here.

After connecting power adapter, please press and hold power button for approximately 5 seconds

(until screen turns on).

When it is on, press and hold power button for approximately 3 seconds to access reboot or power off

menu. Short press on power button will turn off/onscreen (but leave the photo frame in on position).

Packing contents:

1 photo frame, 1 adapter, 1 stand, 1 screw, 1 user manual

RESET

USB DC

This micro USB port is for uploading photos from USB drive only, it is not for connecting

computer.Connect a USB flash drive with OTG cable (not included). Can import photos from USB

flash driver to photo frame, can’t copy photos from photo frame to USB flash driver, can’t play

photos from USB flash driver directly.

Getting started

Thank you for purchasing your very own frameo.

First, to set up your frame follow the ‘Quick start guide’ included in the package. If you are

new to using frameo then start by following the frameo quick setup on page or follow the on

screen guide when powering it on for the first time.

Once you have set up your Frameo frame, start connecting it to your friends and family.

Frameo app

To send photos to your frame, use the frameo app for iOS or Android

Find the frameo app on:

Google play by searching for “frameo” or scan this QR code

App Store by searching for frameo or scan this QR code

Frameo quick setup

When starting your frame for the first time, you will need to setup the frame.

󱕰First you start by selecting a language. This will be the language used throughout

frameo.

󱕰 Connect your frame to the internet by connecting it to a Wi-Fi.

If a newer version of the frameo software is available, then you will be prompted

with an update dialog. It is recommended to update your frame immediately if

prompted.

󱕰Enter your name, and the location where you have placed your frame e.g. “Living

room”, “Kitchen” or “Office” and finally set the timezone if not correct.

Start using frameo

Start by connecting with your friends and family by providing them with a unique code from

your frame.

If you want to be able to send photos to the frame yourself, start by downloading the app for

iOS or Android on App Store or Google Play. Then use the code to connect your frame and

app as described below.

Connecting a new friend:

󱕰Make sure that your friend has downloaded and installed the frameo app

󱕰 Click the add friend icon on your frame . A dialog will appear showing a

unique code which is valid for 12 hours.

󱕰 Now share this code in whatever fashion you prefer e.g. SMS, E-Mail, IM, phone

call, to your friend.

󱕰Once your friends have added the code in their frameo app, they will automatically

appear on your frame and be able to send you photos.

󱕰Read chapter Change options for a friend to allow connected friends, to

retrieve and share the connection code via the smartphone app.

Navigating your frameo

Swipe left or right to go through your photos.

To access the menu, simply tap once on the screen.

In the menu you will find the most used features.

Add friend

This will generate a code that you can share with your friends and family so they can connect and

send photos to your frame.

Gallery

Opens a gallery which allows for easy and fast navigation through your photos.

Settings

Opens the Settings.

Hide photo

Hides the current photo. This means that the photo will no longer be shown in the slideshow. If

needed the photo can be shown again through the settings menu.

Fit to frame/Fill frame

This toggles how the photo is shown.

The Fill frame option is the default. The photo is scaled so that it fills the whole screen. It will be

centered around what is selected as the most important part. See the first picture below.

Fit to frame will make sure that the entire photo is shown on the screen. See the second picture

below.

Adjust photo

The adjust photo feature is only available when the photo is set to fill frame. It allows you to adjust the

position of photo in the frame for an even better fit.

Interacting withvideos

When a video is shown two additional controls are shown. One for play/pause of the video and one

for mute/unmute of the video.

Press to start the video playback. Pressing will pause the video playback.

Pressing will mute the video while pressing will unmute the video.

Power menu

Tap the power icon in the top right corner of the screen to access the power menu. Here you can

power off or restart your frame and make it go into sleep mode.

NB. Make sure to always use the power off button on the device or in the power menu to turn

Frameo off. Never disconnect power when Frameo is running.

Settings

Through settings, you can personalize your frame to your needs.

My frame

Frame name:

Changes the name of your frame. This is also the name the connected friends and family will

see in their list of connected frames.

Frame location:

Changes the location of your frame. This is the location displayed on your friends' and family's

list of connected frames which can help to distinguish frames from each other.

Set language:

Sets the language throughout your frame.

Enable/Disable 24-hour format

Enables, and disables, 24-hour time format.

Set time zone

Sets the timezone that should be used on your frame.

Sleep mode:

frameo offers a sleep mode which turns off the screen to reduce power consumption while

you

e.g. are sleeping. Its default setting is to turn off the screen at 23:00 and turn on the screen

again at 07:00. To change this just set the sleep mode start/end time.

Your frame is not powered down or in standby, so you will still be able to receive photos

during sleep mode.

Manage photos

Show/hide photos:

Select which photos to hide by tapping the particular photos you wish to hide. Hidden photos

will NOT be deleted from your frame, you can always select them to be shown again.

Use to hide or show all photos.

Delete photos:

Select photos that you want to permanently delete from your frame by tapping the photo. Use

to select or deselect all and to delete the selected photos.

My Friends

This list contains all the people that are allowed to send photos to your frame.

Change options for a friend

Click the options icon to open the friend options menu. From here you can allow/disallow if

a friend may share the code to the frame. If this is enabled the friend can retrieve and share

the code to the frame from his/her app.

From the options menu you can also delete a friend, by pressing the DELETE FRIEND

button. This will remove the friend from the list and thereby remove their permission to send

photos to the frame. You will then be asked to confirm the removal and if you would like to

remove all photos previously received from this friend.

Remove person

To remove a person from this list, thereby removing their permission to send you photos, tap

the delete icon . You will then be asked to confirm the removal and if you would like to

remove all photos received from this person.

Export photos

Allows you to export photos from the frame to external storage (e.g. microSD card).

The export function will export all photos on the frame as well as profile pictures.

Import photos:

Allows you to import photos from an external Micro SD card.

BEFORE YOU TRY TO IMPORT PHOTOS FROM A Micro SD CARD

MAKE SURE YOU HAVE A Micro SD

CARD WITH PHOTOS ON INSERTED INTO YOUR FRAME.

Start by selecting the photos that you want to import onto your frame.

Note:

1. It can not zoom in and out when playing the pictures.

2. When the picture is not in center, please tap the picture then there will appear a dialog,

tap the icon ‘Fit to frame’ to fit the picture to the frame, or tap‘adjust photo’ to move the

picture up and down, and then tap the icon ‘󱆻’ or ‘X’ to confirm the picture in center.

IT IS CURRENTLY NOT POSSIBLE TO ADD A CAPTION OR DEFINE THE MOST IMPORTANT PART OF

THE PHOTO WHEN USING THE IMPORT FUNCTION.ALTERNATIVELY ADD YOURSELF TO YOUR

FRIEND LIST AND SEND THEM USING THE APP.

Once selected tap the import button to start the import process.

To allow a new person to send you photos, simply tap the add friend button and share

the presented code in whatever way you prefer.

Display and slideshow

Timer

Define the duration a photo should be displayed.

Show caption

Sets whether or not to display the captions that your friends have sent with the photo. Check

to display captions. Uncheck to hide captions.

Fill frame

Sets the default frame photo setting. Check to set default to fill which makes the photos fit the device

screen according the most important part of the photo. Uncheck to make the photo fit inside the

screen of the device, adding blurred bars on the sides or top/bottom

Photo display order

Sets the order in which your photos are displayed on the frame.

󱕰 By date: Photos are shown newest to latest.

󱕰 Shuffle: Photos are shuffled and shown in a random order.

Brightness level

Adjust the brightness level of the screen.

Notification volume

Adjust the volume level for notification sounds on the frames, e.g. for received new photo

notification.

Autoplay

Enables/disables autoplay of videos in the slideshow. Videos can always be manually started

regardless of this setting.

Video playback

Determines how videos should be played when autoplay is enabled.

󱕰 Loop videos: The video will loop until the slideshow timer is up.

󱕰 Play once: The video will play once and show it’s thumbnail until the timer is up.

Add person
