Digital Color Camera Series
P/N : 3810-0092A
(Ver.0701E) Color Video Camera Series
Design and specifications are subject to
change without notice.
4
2
5
6 7
3
COLOR VIDEO CAMERA
Color CCD
COLOR VIDEO CAMERA
Color CCD
OWNER'S MANUAL
DIGITAL CAMERA SERIES
COLOR VIDEO CAMERA
Super Digital Noise Reduction
On-Screen Display
DSP
•
O
S
D
(
O
n
S
c
r
e
e
n
D
i
s
p
l
a
y
)
•
S
u
p
e
r
D
i
g
i
t
a
l
N
o
i
s
e
R
e
d
u
c
t
i
o
n
•
5
3
0
T
V
L
i
n
e
s
INFORMATION
This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at their own expense.
WARNING
The manufacturer could void the user's authority to operate the equipment.
CAUTION - To prevent electric shock and risk of fire hazards:
Do NOT use power sources except for that specified.
Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and should abide to all local codes.
CAUTION! TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Explanation of two Symbols
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of un-insulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance-
(servicing) instructions in the literature accompanying the appliance.
THE GRAPHIC SYMBOLS WITH SUPPLEMENTAL MARKING ARE ON THE BOTTOM OF THE SYSTEM.
"WARNING-TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE"
. User Information
1. SAFETY INSTRUCTIONS
2. PRECAUTIONS
3. FEATURES
4. NAME AND FUNCTIONS
5. OPERATING CAMERA
6. INSTALLATION (LENS)
5
6
7
8
11
36
37
38
7. COMPOSITION
8. CONNECTIONS
9. SPECIFICATIONS
39
40
41
42
42
44
Before using this camera, please read this operation manual carefully to obtain
the best result and keep this manual for future reference.
Thank you for purchasing this COLOR VIDEO CAMERA.
. Lens Connector
. Back-focus Adjustment
. Mounting a Lens
. AC 24V / DC 12V Input Model
. DC 12V Input Model
. Contents
Handling
Do not disassemble the camera and never touch
parts inside the camera. Be sure the ambient temperature is less than
40ఁin installation intended for long term
continuous operation.
Avoid installing in a humid or dusty place.
Avoid installing in places where there are
strong magnetic fields and electric signals.
Avoid installing in places where the camera
would be subject to strong vibrations.
Never expose the camera to rain and water.
Installation and storage
Do not point the camera at the sun. This could
damage the camera whether it is operating or not.
Do not install the camera where the temperature
could exceed the allowable range.
Do not drop the camera or subject it to shocks
and vibrations to avoid possible damage.
When attaching or removing the lens, handle
with care in order to that moisture and dust do
not enter the camera.
2. PRECAUTIONS
Read Instructions
Read all of the safety and operating instructions
before using the product.
Installation
Do not place this product on an unstable cart, stand,
or table. The product may fall causing serious injury
to a child or adult, and damage to the product.
Use only with a cart or stand recommended by the
manufacturer, or sold with the product.
Mounting should follow the manufacturer's instructions,
and should use a mounting accessory recommended
by manufacturer.
Power source
This product should be operated only from the type
of power source indicated on the marking label.
If you are not sure of the type of power supplied to
your home, consult your dealer or local power
company.
Retain Instructions
Save this instructions for later use.
Cleaning
Unplug this appliance from wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
Water and Moisture.
Do not use this product near water or moisture.
(For example. near a bathtub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, or near a
swimming pool,etc)
1. SAFETY INSTRUCTIONS
High sensitivity 1/3 Inch Sony Super HAD CCD
Min. lllumination (F1.2, 30 IRE) : 0.1 Lux (Color)
0.0008 Lux (DSS x128)
Electronic day & night mode selectable.
High performance menus for functions
DNR (Digital Noise Reduction)
It has an assistant reducing image noise efficiently and It shows clear and
sharp image display even in the dark
• Privacy zone selectable.
• Motion detection selectable.
• Various BLC Mode Selectable (OFF/ LOW/ MIDDLE/ HIGH)
• Sharpness enhanced adjustable.
• Flickerless On/Off
• Electronic Sensitivity-up (SENS-UP)
3. FEATURES
