ORIGO CF1517 Manuel utilisateur

立體搖擺對流座地扇

3D convection stand fan

Instruction Manual

CF1517

*使用風扇前，請先細閱使用說明，並請妥善保存以便將來翻閱。

***本說明書可於本公司網站下載 www.origin.hk。

*Read all instructions carefully before using the FAN, and keep this instruction for furture

reference when necessary.

使用說明書

***This instruction manual can be acquired at www.origin.hk.

Important Safety Information

重要安全提示

拔除插頭時不可拉扯電源線，必須緊握插頭

，把插頭拔出。

Do not pull the power cord to disconnect

from power source. Always grasp the plug

to pull out.

請使用獨立插座。使用萬能插頭或拖板，容

易發生危險。

Avoid using extension cord as it may

overheat and casue fire.

使用風扇前，請確定規格標貼上所示的額

定電壓與當地供電電壓相同。如有疑問可

向供應商查詢。

Before using the Fan, check if the

voltage marked on the rating label

corresponds to the mains at your

home.

220-240V~ 50-60Hz

包裝物料並非玩具，不可讓小孩玩耍。

Do not let children play parts of

package.

打開包裝，檢查風扇。如發現產品有損壞

，請勿使用及即時聯絡供應商。

Open the package and ensure that the

Fan is undamaged. In case of doubt

do not use the FAN and contact your

supplier.

必須按照使用說明指示操作本風扇，否則

可能引致產品損壞、短路、火警或人命損

傷。

Use this Fan only as described in

this manual. Any other use not

recommended by the manufacturer

may casue fire, electrical shock or

injury to persons.

使用本風扇前，請先細閱使用說明。

Read all instructions carefully before

using the Fan.

本機不是為體質、感覺或智力有障礙人士(包

括小孩)或缺乏經驗及知識者使用，除非他們

曾經接受負責安全人士的監督或指示，大人應

指導小孩不可把玩電器。

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure

that they do not play with the appliance.

立體搖擺對流座地扇

3D convection stand fan

Important Safety Information

重要安全提示

不可在潮濕或有積水的環境使用，不可將風

扇擺放於浴缸或大型容器上面。

The Fan is not intended for use in wet

or damp locations. Never locate the

Fan where it may fall into a bathtub or

other water container.

請保持清潔以維持風扇處於良好狀態

(詳細請參閱清理及維護部份)。

Keep the Fan clean to maintain in good

condition (refer to maintenance

section).

切勿將

風扇

擺放在發熱源頭或火源附近。

Do not place the

Fan

near a source

of heat or fire.

警告；清理前必須先拔除電源插頭。若電

源線損壞，必須交由製造商或其代理指定

維修服務中心檢查及修理。

WARNING: To avoid danger of electric

shock, unplug from outlet when not

in use and before cleaning. If the

power cord is damaged, it must be

replaced by the manufacturer, its

service agent or similarly qualified

persons in order to avoid hazard.

本風扇不適用於室外及作工業用途。

This Fan is intended for household

use ONLY and not for industrial

or outdoor use.

非使用風扇時請拔除插頭，切斷電源。

Do not leave the Fan unattended.

Always unplug the Fan Cooler when

not in use.

切勿將任何異物放入風扇內；或阻擋風扇

出風口及入風口，皆因以上一切行為均可

能導致風扇損壞。

Do not insert any objects into the Fan

as it may cause an electric shock or

damage. Do not block or tamper with

the Fan in any manner while it is in

operation.

警告：開/關鍵不應作為切斷電源的用途。

WARNING: The On/Off switch should

not be used as the sole means of

disconnecting power. Always unplug

the power cord before servicing or

moving the unit.

如須移動風扇，請先拔除插頭切斷電源。

Always disconnected the Fan from the

power supply when moving it from

one location to another.

本產品含有可回收材料，不可把本產

品作為未分類廢物。請聯繫當地就近

指定回收點。

This product contains recyclable

materials. Do not dispose this

product as unsorted municipal

waste. Please contact your local

municipality for the nearest collection

立體搖擺對流座地扇

3D convection stand fan

移除網罩前

，必須確保風扇已拔掉電源。

Ensure that the fan is switched off from

the supply mains before removing the

guard.

Control Panel

控制面版

Rear Grille

後網

Front Grille

前網

Remote Receiver

遙控訊號接收窗

Main Parts

各部名稱

Air Oulet

出風口

Air Inlet

入風口

Power Cord

電源線 Plug

插頭

立體搖擺對流座地扇

3D convection stand fan

圖片只供參考

，

一切以實物為準

The picture is for reference only, everything in kind shall prevail.

Remote Control Dock

搖控器儲存盤

Function Setting

功能設定

1. Place the Fan on a stable and flat surface. Plug the Power Cord into an 220-240V~

50-60Hz electrical outlet.

將風扇擺放於穩固的平面上，將插頭插入交流電壓220-240V~50-60Hz的獨立插座，

風扇可使用控制面板按鍵操控(如圖1)，或改用遙控器操控。

2. POWER: Turn the Fan ON by pressing the key, the Fan start at speed 3.

圖1

Figure 1

開/關:按開/關鍵，風扇以第3段風速啟動。

The Fan may be operated by the control panel (as shown in Figure 1) or by your

remote control.

立體搖擺對流座地扇

3D convection Stand fan

圖片只供參考

，

一切以實物為準

The picture is for

reference only,

everything in kind

shall prevail.

超強風速

GALE

風速/上調

SPEED/UP

風速/下調

SPEED/DOWN

開/關

ON/OFF

上下送風

U/D OSC

左右送風

L/R OSC

預約開機

AUTO ON

定時關機

AUTO OFF

3. 風速: 按風速(+) / (-)鍵，設定所需1至8段不同風速，LED顯示燈同時亮起。

按鍵，風扇以超強風速運作，約3分鐘後，風速會自動由超強風速返回

之前設定的風速繼續運作。

3. S

PEED: Press the (+)/(-) key to adjust the fan speed to the desired level (1 to 8 level).

The speed setting is displayed on the LED light. Press the key to adjust

the wind speed to “Gale” speed, after 3 minutes, the wind speed will

automatically return to the previously set wind speed from "Gale" speed to

continue to operate.

5. 定時關機: 在風扇運行時，按下定時設置鍵，選定3個不同的自動關機時間，分別由

1、2、4小時，LED定時設置顯示燈將會亮起，並會顯示所選關機時間。

5. AUTO OFF: When the Fan is running, pressing the key to set desired auto power

off time, There are 3 time intervals, from 1,2,4-hour. The LED of timer

will be on and displayed the off time setting.

搖擺

OSC 自然風

NATURAL

4. 搖擺送風: 按下搖擺送風鍵，風扇以自動左右搖擺模式送風。

按下搖擺送風鍵兩次，風扇以自動上下搖擺模式送風。

按下搖擺送風鍵三次，風扇以自動上下左右搖擺模式送風。

如欲停止自動上下左右搖擺送風，再按此鍵一次。

4. OSC: Press the key to allow the Fan to LEFT/RIGHT oscillate the wind direction.

Press the key twice to allow the Fan to UP/DOWN oscillate the wind direction.

Press the key three times to allow the Fan to LEFT/RIGHT & UP/DOWN

oscillate the wind direction.

To stop the oscillation, press the key again.

Function Setting

功能設定

立體搖擺對流座地扇

3D convection Stand fan

6. 預約開機: 在待機模式下，按下定時設置鍵，選定3個不同的預約開機時間，分別

由1、2、4小時，LED顯示

屏

將會顯示所選開機時間及長亮，當LED顯

示

屏長亮

時，可同時設置搖擺送風、自然風模式及風速等功能。

6. AUTO ON: In Standby mode, pressing the key to set desired preset power

start time, There are 3 time intervals, from 1,2,4-hour. The LED will

be light on and displayed the start time setting on the LED screen.

OSC, NATURAL MODE and SPEED can be set at the same time when

the LED indicator light on.

7. 自然風模式: 按自然風模式鍵，風扇以自然風運作。LED顯示燈將會亮起。

- 第1或第2段風速 - 微自然風。

- 第3或第4段風速 - 低自然風。

- 第5或第6段風速 - 中自然風。

- 第7或第8段風速 - 高自然風。

在自然風模式下，按風速(+) / (-)鍵可變更所需的自然風風速。

如欲停止自然風模式送風，再按自然風模式鍵一次。

7. NATURAL MODE: Press the key to set the Fan as Natural mode. The mode is

displayed on the LED light.

- Speed 1-2 acts like a micro natural wind.

- Speed 3-4 acts like a low natural wind.

- Speed 5-6 acts like a medium natural wind.

- Speed 7-8 acts like a high natural wind.

In Natural Mode, pressing the (+) / (-) key to adjust the desired natural wind speed.

To stop the NATURAL MODE, press the key again.

***注意：當完成功能設定後15秒，

LED顯示燈

會自動變喑。

Remarks: After settings, the

LED indicator

will change dumb automatically

after 15 seconds.

Maintenance

清理及維護

Remote Control

遙控器

1.遙控器操作方式與機身按鍵操作方式相同。

2.更換電池 : 使用一枚3伏特鋰電池。

1. All functions performed by the Remote Control work are identical

to the Manual.

2. Battery replacement:Install one 3V Lithium battery.

警告

請把電池放在兒童碰不到的地方，如果孩子吞下電池，需立即致電咨詢醫生。

不要對電池進行充電或隨意棄置在有火源的地方。

應保持電池存放於乾燥，陰涼的地方。

以正確的方向插入電池。

電池的處理 - 請按相關地區的法律規定處理曾經使用的電池。

WARNING

1. Keep batteries out of reach of children. Should a child swallow a battery,

consult a doctor immediately.

2. Do not recharge or dispose in fire.

3. Keep in a dry and cool place.

4. Insert battery in rigdt direction.

Battery disposal - Please dispose the used battery per municipal or

provincial law.

警告：不使用風扇時，經常保持拔除電源，及切勿將風扇浸於水或其他液體中。在

清潔本風扇前，先將風扇關掉及把電源線從插座拔出。

House: Clean the outside of the Fan with a soft cloth, to remove presistent dirt or grime

wipe down with a cloth that has been dampened with warm soapy water.

注意：切勿使用含有腐蝕性的清潔劑或溶液清理風扇。

儲存：連同使用說明，把風扇存放於清涼及乾爽的地方。

WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR SERVICING. DO NOT

IMMERSE THE FAN IN WATER! BEFORE CLEANING, MAKE SURE THAT THE UNIT HAS BEEN

SWITCHED OFF AND IT IS UNPLUGGED FROM THE MAIN OUTLET.

外殼：清理時切勿將風扇浸於水或其他液體中。使用濕潤軟布抹擦清潔，頑固污垢可用軟

布沾上含肥皂的溫水抹擦。

CAUTION: Do NOT use gasoline, benzene, thinner, harsh cleaners, etc., as they will damage

the Fan. NEVER use ALCOHOL or any other SOLVENTS.

STORAGE: Store the Fan with these instructions in the original box in a cool and dry place.

立體搖擺對流座地扇

3D convection Stand fan

CF1517

Specification

技術規格

型號 Model Number

電源 Power Supply

額定功率 Rated Power

產品尺寸 Product Dimension

CF1517

220-240V~ 50-60Hz

18W

266 x 312 x 701 mm (約/Approx.)

Origin Map

源澤地圖

辦公時間

10:30am - 12:30pm (星期一至五)

02:30pm - 05:30pm (星期一至五)

10:30am - 12:30pm (星期六)

(星期日及公眾假期休息)

OFFICE HOURS

10:30am - 12:30pm (Mon to Fri)

02:30pm - 05:30pm (Mon to Fri)

10:30am - 12:30pm (Saturday)

(Closed on Sunday and Holiday)

立體搖擺對流座地扇

3D convection Stand fan

產品保用証(一年自攜服務)

產品:

立體搖擺對流座地扇

型號: CF1517

此產品由購買日期起計算，本公司將根據下列條款及細則，提供一年保養服務(商業用享為3個月):

1. 於購買後一年內，經本公司技術員判斷為正常運作下損壞之產品，

可獲免費維修和/或零件更換。

2. 以下情況不被包括在保養範圍內：

-若產品是因為濫用、錯誤使用、疏忽及/或意外而遭致損壞；

-未經授權之自行處理、維修及/或改裝；

-任何搖控、機殼、面蓋、扇葉，以及配件。

3. 需要檢查或維修時，請將產品送往本公司服務中心，並於修理妥當後自行取回。

4. 更換後之任何損壞零件，均屬本公司所有。

5. 本保養服務只適用於香港特別行政區。

6. 顧客必須同時出示零售商之正式發票，方可得到免費維修服務。

*** 額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免費延長保用期3個月，即15個月免費保用(商業用途

除外)。請即登入網站: www.origo.hk

服務中心

源澤市務有限公司

香港新界葵涌青山公路403號(近華星街12號)匯城集團大廈21樓H室

電話: 2156 8238

www.origo.hk

Warranty Card(1 year carry-in)

Item : 3D Convection Stand Fan

Model : CF1517

Service Centre

ORIGIN MARKETING LIMITED

Unit H, 21/F., Reason Group Tower (nearby 12 Wah Sing Street), 403 Castle Peak Road,

Kwai Chung, N.T., Hong Kong.

Tel: 2156 8238

www.origo.hk

This product is warranted for 1year (commercial use for 3 months) from the date of purchase under the

following conditions:

1. For any defect, in the judgment of our technician, if it is caused under normal use, we are responsible for

repairing the product, and/or replacing parts at free of charge.

2. This warranty DOES NOT apply to:

- If the product has been damaged through abuse, misuse, negligence or accidents;

- Unauthorized repair, alteration/modification;

- The remote control, housing, cover, blade or accessories.

3. The customer is requested to bring the unit to and from our Service Centre whenever

service is needed.

4. Any defective parts, which had been replaced, shall be of our property.

5. This warranty is valid in H.K.S.A.R. only.

6. Please show the Invoice to get free service.

***Extra 3 months warranty: just complete Online Warranty Registration within 10 days from the date of

receipt, free warranty will be extended to 15 months (not applicable to commercial use). Please enter our

website: www.origo.hk

www.origo.hk

立體搖擺對流座地扇

3D convection Stand fan

Table des matières

Autres manuels ORIGO Ventilateur

ORIGO

ORIGO CF-1311 Manuel utilisateur

ORIGO

ORIGO TF-136L Manuel utilisateur

ORIGO

ORIGO CF-1308R Manuel utilisateur

ORIGO

ORIGO CF1515 Manuel utilisateur

ORIGO

ORIGO Crudus TF342 Manuel utilisateur

ORIGO

ORIGO TF-292RC Manuel utilisateur

ORIGO

ORIGO Crudus TF-47RC Manuel utilisateur

ORIGO

ORIGO DF-1201 Manuel utilisateur

ORIGO

ORIGO CF-1308R Manuel utilisateur

ORIGO

ORIGO CF-1320 Manuel utilisateur

ORIGO

ORIGO SF1621 Manuel utilisateur

ORIGO

ORIGO CF1518 Manuel utilisateur

ORIGO

ORIGO SF-028 Manuel utilisateur

ORIGO

ORIGO FTF36-LED Manuel utilisateur

ORIGO

ORIGO DF-M05 Manuel utilisateur

ORIGO

ORIGO MF-01 Manuel utilisateur

ORIGO

ORIGO CFM90 Manuel utilisateur

ORIGO

ORIGO CF-1512 Manuel utilisateur

ORIGO

ORIGO SF-1603 Manuel utilisateur

ORIGO

ORIGO Crudus TF-295RC Manuel utilisateur

ORIGO

ORIGO CF-M88 Manuel utilisateur

ORIGO

ORIGO TF-146L Manuel utilisateur

ORIGO

ORIGO CF-1701 Manuel utilisateur

ORIGO

ORIGO Crudus TF301 Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
