Oregon Scientific Smart Dynamo 2 Manuel utilisateur
HELP CONTENT & FAQ
Version 1.1 (2014/10/07)
ENGLISH
Due to printing limitations, the displays shown online may differ from the actual display.
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
1 von 75 28.04.2015 11:26
Introduction
Number Description
1Operation button
• Press to display the last messages, current time and mobile device notification summary.
• Press and hold to start/end sleep mode or find my phone.
2 Snap button holes
3 Metal Plate (PE289 - Dynamo 2+ only)
4 Display screen
5 Buckle
6 Smart core
Dynamo 2/Dynamo 2+
USB Charger (AD288)
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
2 von 75 28.04.2015 11:26
The illustrations as shown above may differ from the actual product.
Package Items
The package includes the following items:
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
3 von 75 28.04.2015 11:26
1 x Dynamo 2/Dynamo 2+ Activity Tracker
1 x Charger Pod (AD288)
1 x Oregon Scientific™ Warranty Card
1 x Quick Start Guide
1 x Extension cable
How to charge
Before you start using the activity tracker, please charge it for at least 1 hour before use.
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
4 von 75 28.04.2015 11:26
1. Align the two metal connection points of the charger pod with the pair on the smart core.
2. Make sure the clips of the charging pod are aligned with the sides of the smart core, then gently push the
smart core into the charger pod as shown in the diagram below. You will hear a click when it is securely
inserted in to the pod.
3. Plug the charger pod into USB port of your PC or other power supply.
4. Once the smart core is correctly connected with the charger pod, the battery charging animation will appear
on the display.
Battery indicator
Battery indicator
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
5 von 75 28.04.2015 11:26
Indicators Status Action
Charging Connect the smart core with the
charger pod and link it to USB power
supply.
Charging completed Remove the smart core from the
charger pod.
Low battery Charge the smart core until fully
charged.
When the smart core is fully charged, it lasts about 5-7 days. The operation time varies
depend on actual usage.
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
6 von 75 28.04.2015 11:26
Indicators Status Action
ls Charge
Compatible models
Dynamo 2/Dynamo 2+ supports iOS and Android smart devices. For the latest compatible list, please visit
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
7 von 75 28.04.2015 11:26
iOS 7.0 or above
iPhone 4s/5/5c/5s
iPad mini WiFi
iPad mini Wi-Fi + Cellular
iPad Wi-Fi (3rd/4th generations)
iPad Wi-Fi + Cellular (3rd/4th generations)
iPad Air Wi-Fi
iPad Air Wi-Fi + Cellular
iPad mini WiFi with Retina display
iPad mini Wi-Fi + Cellular with Retina display
iPod touch (5th generation)
Android 4.3 or above
Google Nexus 5
Nexus 7 (2013)
Samsung
Galaxy Note III
Galaxy S4 (version 4.3)
Galaxy S5
for details.
http://ssmart.oregonscientific.com/dynamo2
How to wear
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
8 von 75 28.04.2015 11:26
Your Dynamo 2/Dynamo 2+ is adjustable to fit most wrist sizes. Please follow the below steps:
1. Insert the smart core into the wristband. Align the button side of both wristband and smart core before
inserting.
2. Insert the buckle into the appropriate buttonholes.
3. Gently press both the buckle and the wristband between your thumb and forefinger until the wristband is
securely fastened. Do not make the Dynamo 2/Dynamo 2+ too loose as this could cause inaccurate readings.
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
9 von 75 28.04.2015 11:26
4. To make sure the Dynamo 2/Dynamo 2+ is securely fastened, pull the smart core with some pressure to
make sure it is not easily loosened from your wrist.
Download the App
The app is available in both Apple App Store and Google Play Store. Search “Ssmart Fit” in the search engine
Oregon Scientific| Ssmart Dynamo 2 | PE288 http://ssmart.oregonscientific.com/dynamo2/um/ios_eng/index.html
