User Manual

Thank you for purchasing Aroma Diffuser GLAZE. Be sure to read this manual thoroughly

in order to use the product properly.

Please keep this manual for reference in the event any problems or questions arise.

Safety Precautions (Read the following precautions carefully)　

● Please follow the instruction below (to ensure proper use)

To prevent injury of user and other people or damage of property, the following indications must

be followed. Read the precautions carefully to ensure proper use.

This indicates precautions for which improper usage

“may result in death or serious injury”.

This indicates precautions for which improper usage “may result in slight

injury or damage of property”.

● The following symbols distinguish contents which should be avoided or followed.

Indicated “Prohibition -what must NOT do”.

Indicated “Compulsion -what must do”.

WARNING

Do not touch the ultrasonic vibration plate while the

product is operating. It may cause burn injury.

Keep out of reach of children or throw away the

plastic packaging bags to prevent children

suffocation.

Do not modify, repair or rebuild the product.

It may cause fire or electric shock. Do not use the

product in a way that is not described in this

manual. It may cause injury or failure.

Do not step on, drop down or strongly slap on the

product. Damage of product may cause fire or

electric shock. Stop the power supply while any

damage is found. It may cause fire and electric

shock if keep using.

Do not handle the body part of the product, DC plug

and USB plug with wet hands. It may cause failure,

fire or electric shock.

Do not allow the body part or accessories to get wet.

Do not use or keep the product in a high humid area,

such as bathroom, changing room and greenhouse.

It may cause failure, fire or electric shock. When

water spills out, turn off the power, stop using the

product. It may cause fire or electric shock if keep

using.

Place the product in somewhere out of reach and

use of toddler. Unintentional injuries may be

caused easily due to the collapse of the body part

or imporper use.

Do not intentionally breath in the mist direct

coming out from the mist outlet. It may be harmful

to health. This product is not a medical respirator.

Do not use this product out of purpose of aroma

mist or diffusion.

Do not use detergent except kitchen detergent to

clean the main body. Detergent leaving in the

water tank may cause toxic gases or failure.

Unplug the USB plug (from the USB port of

computer) before cleaning to avoid electric shock

or injury.

Warning

Caution

Do not stab or insert any sharp, metal such as

needle, pin into the product of mist outlet, air inlet

and air oulet. It may cause electric shock or injury.

Do not block the mist outlet, air inlet and air outlet.

Disturbance of normal operation may cause

malfunction, overheating or failure.

Do not touch the body part right after the operation.

Be aware of the high temperature of mist or water

in the water tank.

Do not remove the ceramic cover or the lid of the

water tank while the product is operating. Water

and essential oil may spill out, damage the

surrounding stuff and cause failure.

Exchange tap water in the water tank every day

and make sure the water tank is clean. There may

be water stains or mineral attachment if the water

tank is not cleaned properly and may cause poor

performance. Moreover, mould or bacteria may

cause stingy smell and harmful to health. Be aware

of allergies caused by mould and bacteria

Caution

Use tap water in room temperature. Mould or

bacteria may grow easily if mineral water,

alkaline-ion water, well water, or filtered water is

used.

Use essential oil that is 100% extracted from

plant naturally. Do not use synthetic fragrance.

Add 2-3 drops of essential oil into 80mL water, do

not add too much since it may cause failure.

Do not place the product near any electrical

compliance such as computer, TV, piano, painted

furniture and special processed wall surface.

Touching or spilling of mist or water may cause

failure or damage of properties.

Do not place anything on the product or place the

product somewhere unstable. It may fall down

and cause injury.

Drain and keep the water tank dry if water may

be frozen. Ultrasonic vibration plate may be

damaged if the internal structures get frozen.

Water tank lid

(※hereinafter

called lid)

Body part

Light switch Mist switch

Ceramic Cover

(※hereinafter

called cover)

Mist outlet

Water level

indicator

Drainage Direction

Drainage

DC jack

Water tank

Air outlet

Ultrasonic Vibration

Plate

• USB cable

USB plug DC plug

Air inlet

Accessories

Name of parts

Drainage Direction

Preparation

Caution

cover lid

DC jack

DC plug

USB plug

ultrasonic vibration

plate cover

How to use

Remove cover and lid When using in first time

Remove the buffer material between the cover

and body part.

Make sure ultrasonic vibration plate cover is

installed

※ Mist would not generate if the ultrasonic vibration plate cover

has not been installed.

※ Place the product on a stable surface

《Using in USB port of computer》

Insert the supplied USB cable to USB port of

computer or mobile battery and connect to DC

jack on a stable surface.

※ Mist may not generate normally or power may be off

depending on different computer.

Do not connect with USB hub

USB hub cannot ensure stable power supply, the

product may not operate normally.

Place the product on a stable surface which is

not near the connected computer.

Computer failure may be caused if it exposes to mist.

Connect USB cable before adding water.

Use USB port with 1.0A output.

lid cover

※

5. Add 2-3 drops of essential oil into the water tank

※ Essential oil is sold separately. Prepare 100% extracted

Natural Essential oil.

2-3 drops of

essential oil

Water line

Do not add

water directly

under the tap

Pour 80ml tap water into the water tank.

The volume of the water tank is 80ml, do not add

water over the water level indicator.

Return the lid and the cover to their places.

Make sure there are no gap between the body part

and the lid, also between the body part and the cover.

There may be leakage between the gaps.

Do not tilt the product while adding water. It may cause

failure if water entered internal part via air outlet.

The product must be switched off when adding water.

Spilling of water may cause failure.

Do not add water when the product is operating. High

temperature vapor and water may blow out.

Remove the cover and lid before adding water with a

container. Do not add water directly into the mist outlet

without taking out the lid or place the water tank directly

under the tap. Spilling of water may cause failure.

Do not add cold water since the mist generation would be

affected.

Mist cannot generate if water is over the

water line.

Do not allow DC plug and USB cable to get wet.

Essential oil must be added when the water tank

is full (80ml).

Do not add essential oil directly onto the

ultrasonic vibration plate.

Do not add too much essential oil.

It may cause failure.

Caution

Drainage Direction

Intermittent 6hrs mode: 30 seconds on/ 30 seconds off

repetition.

Automatically power off when no water in the water tank.

When operating with mist function, the light would be off

if mist stops automatically.

The product is able to turn on the light only without mist

generation.

Press mist switch to choose the operation mode.

Press light switch to choose light mode.

Turn off the product by pressing the mist switch and

the light switch a few times.

Press mist switch to turn on the power, the first mode is

continuous 1 hour.

Different operation modes would be shifted as the

following rotation by pressing the mist switch.

Press light switch to turn on the light.

Different light modes would be shifted as the following

rotation.

Continuous

1hr mode

Continuous

3hrs mode

Intermittent

6hrs mode Power OFF

※

Light switch Mist switch

Operation

Light on strong Light on weak Light Off

Turn off the power

Unplug the USB plug.

Remove DC plug.

Be aware of spilling out water from the tank. Do not allow

water to enter the air outlet while removing the DC plug.

Remove the lid and cover.

Pour out water according to the following the

Drainage direction.

Pour out water on the opposite side of the air outlet, see the

picture on the right.

When finished using the product or preferring to change

essential oil, pour out all the water in the water tank and clean it.

Press light switch/mist switch to turn the power off.

Do not allow water to get into the air outlet.

Caution

Keep Cleaning

Read the instruction P.12 “Care”

Keep the product completely dry after using it.

Air outlet

Drainage

Direction

How to drain the water tank

Drainage Direction

The below instructions must be followed

・ Do not move the product when it is operating. Before moving it, switch off and drain all the

water from the water tank. Follow the Drainage Direction to pour out the water. Do not

allow the air outlet to get wet when draining. When moving the product, beware to hold the

body part and the cover to prevent dropping.

・ Do not allow essential oil to get contact to parts other than the water tank. If essential oil is

attached, wipe it off with a wet cloth immediately.

・ After the product stops automatically, do not use it for 30 mins. Overheating of the

ultrasonic vibration plate may cause failure.

・ Do not switch on the product if the water tank is empty. It may cause product damage,

failure or water leaking.

・ Do not pour water over 80ml (max. Capacity of the water tank). Mist may not be generated

normally.

・ If water level in the water tank is low, the product would stop automatically even timer is

not finished.

・ Volume of mist may be low depending on operation environment, such as water tempera-

ture or water quality. Volume of mist would become stable after few minutes.

・ It is possible that mist cannot be easily seen due to temperature, humidity or airflow, but it

is not failure.

・ There may be water drops inside the lid. Open it in a place that can get wet and use a towel

to wipe the water drops.

・ As this product is an Aroma Diffuser applying ultrasonic humidifier principle, it does not

have functions as an ordinary humidifier.

・ Floor, wall or furniture may get wet due to mist from the product if the room humidity is

high. In this case, switch off and stop using the product.

●

Before Use

Way of taking out

Mist may not be generated if there are bubbles attached on the Ultrasonic

Vibration Plate. If there are bubbles, switched off the product and take out the

Ultrasonic Vibration Plate Cover. Use a cotton swab to clean up the bubbles.

Pull the Ultrasonic Vibration

Plate Cover up from the body

part to take it out.

Way of installation

Match the Waist of the Ultrasonic

Vibration Plate Cover with the

Hook on the Ultrasonic Vibration

Plate to install.

Cover of

Ultrasonic

Vibration

Plate

Hook

Waist

About handling the Ultrasonic Vibration Plate Cover

Be aware of bubbles attached on the Ultrasonic Vibration Plate

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Oregon Scientific Accessoires

Oregon Scientific

Oregon Scientific UVR128 Manuel utilisateur

Oregon Scientific

Oregon Scientific RGR122 Manuel utilisateur

Oregon Scientific

Oregon Scientific THGR122NX Manuel utilisateur

Oregon Scientific

Oregon Scientific WA633 Manuel utilisateur

Oregon Scientific

Oregon Scientific THGR968 Manuel utilisateur

Oregon Scientific

Oregon Scientific HWI0003 Manuel utilisateur

Oregon Scientific

Oregon Scientific THGR810 Manuel utilisateur

Oregon Scientific

Oregon Scientific WTGR800 Manuel utilisateur

Oregon Scientific

Oregon Scientific THWR800 Manuel utilisateur

Oregon Scientific

Oregon Scientific UVN800 Manuel utilisateur

Oregon Scientific

Oregon Scientific THGR328NH Manuel utilisateur

Oregon Scientific

Oregon Scientific THWR288 Manuel utilisateur

Oregon Scientific

Oregon Scientific RGR968 Manuel utilisateur

Oregon Scientific

Oregon Scientific THR28 Manuel utilisateur

Oregon Scientific

Oregon Scientific THGN122N Manuel utilisateur

Oregon Scientific

Oregon Scientific WS909 Manuel utilisateur

Oregon Scientific

Oregon Scientific HWI0005 Manuel utilisateur

Oregon Scientific

Oregon Scientific EMR898A Manuel utilisateur

Oregon Scientific

Oregon Scientific THGR328NH Manuel utilisateur

Oregon Scientific

Oregon Scientific THC138 Manuel utilisateur

Oregon Scientific

Oregon Scientific THR238NF Manuel utilisateur

Oregon Scientific

Oregon Scientific UVR128 Manuel utilisateur

Oregon Scientific

Oregon Scientific UVR138 Manuel utilisateur

Oregon Scientific

Oregon Scientific HWI0002 Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
