Oreck Edge Manuel utilisateur

EdgeTM Series Upright

Important!

Read this manual carefully,

and keep for future reference.

User’s

Guide

high

low

Other Oreck accessories available at:

Thank You for purchasing our top-of-the-line Oreck Edge Series

Upright. The Edge Series Upright features a 10 year warranty

and 10 annual tune-ups, with variable speed control – higher

speeds for carpets, lower speeds for bare floors and delicate

surfaces. The HEPA-CELOC filtration traps 99.9997% of

particulates down to .3 microns including pollen, mold

spores and pet dander. And because it’s an Oreck, it can help

restore the nap of your carpet the very first time you use it.

Welcome to our Call. Click. Visit. customer service

program. To speak with an Oreck representative call, click or

visit using the information below.

Enjoy

Click

Call

Visit

USA: 1•800•989•3535

Canada: 1•888•676•7325

On the web, point and click at: www.oreck.com

or visit www.oreck.com and click locate a store on

the top right.

Visit us in person at one of over 450 store

locations. To find the nearest store, please call

888•oreck (1•888•673•2578).

Contents

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

GeneralWarnings..........................4

Polarized Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Parts......................................6

Product Components & Accessories . . . . . . . . . . . . .6

Features....................................8

Assembly...................................9

Attaching the Handle Tube . . . . . . . . . . . . . . . . . . . .9

Attaching the Suction Hose . . . . . . . . . . . . . . . . . . .9

Use ......................................10

OperatingtheVacuum......................10

Using the Light Duty Cleaning Wand . . . . . . . . . . . . 11

To Dock Light Duty Cleaning Wand . . . . . . . . . . . . . 11

Cleaning Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Maintenance................................13

Replacing Disposable Odor Fighting Inner Bag. . . . . 13

Stufﬁng or Blockage . . . . . . . . . . . . . . . . . . . . . . . 14

Troubleshooting .............................16

Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Safety

IMPORTANT SAFETY

INSTRUCTIONS

General Warnings

Read all instructions before using this vacuum cleaner

WARNING! To reduce the risk of fire, electric shock, or injury

when using an electrical appliance, basic precautions should

always be followed, including the following:

Do not leave appliance unattended when plugged in.

Unplug from outlet when not in use and before servicing.

Do not use outdoors or on wet surfaces.

Do not let the unit run while in any one stationary position

for any period of time. Keep the unit moving while in

operation.

Do not allow to be used as a toy. Close attention is

necessary when used by or near children.

Use only as described in this manual. Use only manufac-

turer’s recommended attachments.

Do not use with damaged cord or plug. If appliance is not

working as it should, has been dropped, damaged, left

outdoors, or dropped into water, return it to a service center

or call customer service at: US: 1-800-989-3535

Canada: 1-888-676-7325

Do not pull or carry by cord, use cord as a handle, close

door on cord, or pull cord around sharp edges or corners.

Keep cord away from heated surfaces.

Do not run appliance over cord.

Do not unplug by pulling on cord. To unplug, grasp the

plug, not the cord.

Do not handle plug or appliance with wet hands.

Do not put any object into openings. Do not use with any

opening blocked; keep free of dust, lint, hair and anything

that may reduce air flow.

Keep hair, loose clothing, fingers and all parts of body

away from openings and moving parts.

Do not use to pick up anything that is burning or smoking,

such as cigarettes, matches, or hot ashes.

•

Do not use without filter bag assembly in place.

Turn off all controls before unplugging.

Use extra care when cleaning on stairs.

Do not use to pick up flammable or combustible liquids,

such as gasoline or lighter fluid, or use in areas where they

may be present.

Do not use appliance in an enclosed space where flamma-

ble, explosive or toxic vapors are given off by oil base paint,

paint thinner, some mothproofing substances, or in an area

where flammable dust is present.

Do not pick up toxic material such as chlorine bleach, drain

cleaner, gasoline, etc. with this appliance.

Use caution when vacuuming over area rug edges

and fringe.

Polarized Plug

•

SAVE THESE

INSTRUCTIONS

A polarized plug has one rounded prong and one straight prong.

The rounded end goes into the longest socket slot. To reduce

the risk of electric shock, this equipment has a polarized plug

(one blade is wider than the other). This plug will fit in a polar-

ized outlet only one way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does not fit, contact qualified

personnel to install the proper outlet. Do not alter the plug in

any way.

Rounded prong

For household use only

high

low

high

low

PULL

Parts

Product Components & Accessories

1. On/off switch

2. Variable speed control

3. Helping Hand®handle

4. Handle tube

5. Outer bag

6. Rear wheels

7. Protective front bumper

8. Headlight

9. Fan housing (front)

10. Odor-fighting inner bag

11. Bag dock

Front View

12. Cord dump

13. Light duty cleaning wand

14. Hose clip

15. Cord wrap / carry handle

16. Suction hose

17. Fan housing (back)

18. Hose intake

19. Power cord

20. Edge Brushes

21. Brushroll

22. Intake opening

Back and Bottom View

high

low

high

low

PULL

Parts

Product Components & Accessories

1. On/off switch

2. Variable speed control

3. Helping Hand®handle

4. Handle tube

5. Outer bag

6. Rear wheels

7. Protective front bumper

8. Headlight

9. Fan housing (front)

10. Odor-fighting inner bag

11. Bag dock

Front View

12. Cord dump

13. Light duty cleaning wand

14. Hose clip

15. Cord wrap / carry handle

16. Suction hose

17. Fan housing (back)

18. Hose intake

19. Power cord

20. Edge Brushes

21. Brushroll

22. Intake opening

Back and Bottom View

PULL

high

low

high

low

Features

1. Variable Speed Control

The Edge Series Upright offers variable speed

control. Lower speeds for delicate and hard floor

surfaces. Higher speeds for carpet. Press “high”

to speed up motor through three speed settings.

Depress “low” to lower the motor speed through

three speed settings.

2. Disposable Odor Fighting Dust Bags

Disposable Odor Fighting dust bags play a

very important role in the efficiency of your

ORECK vacuum cleaner. The purpose of the

dust bag is to trap dirt, but at the same time it

must be porous enough to allow air to pass

through. If the dust bag becomes clogged,

no air can pass through the cleaner and

cleaning cannot take place, regardless of the

cleaner’s power. Change your dust bag fre-

quently to increase your vacuum’s performance.

3. HEPA-Celoc® Hypo-Allergenic Filter System

The outer bag and inner bag design of the Edge

offers HEPA filtration of 99.997% particulates

down to .3 microns. It is important to wipe the

inside of your outer bag depending on use.

The Celoc layered disposable inner dust bag is

designed for optimal performance. Depending on

cleaning environment, it may need to be changed as

often as once a month. Change it more often if it is

used in extremely dirty areas. Increase the cleaning

power of your vacuum by changing the bag often.

4. Light Duty Cleaning Wand

The on-board light duty cleaning wand is designed

for quick, light duty corner and above the floor

cleaning. The orange tipped crevice tool extends

out of the wand for additional reach.

Note: For heavier above the floor and crevice

clean-ups use the Edge Series handheld canister.

Assembly

high

low

high

low

high

low

high

low

high

low

Attaching the Handle Tube

1. Place the vacuum on its back with the handle facing

up. Remove the two lower screws from the

interconnect, and set them aside.

2. Push the top handle down onto the handle tube.

3. Fasten the screws you removed in step one into

the two lower screw holes located behind the outer

bag. Tip! You may need to bend the outer bag back

slightly to expose the bottom screw holes.

Attaching the Suction Hose

1. Align the slot on the

suction hose with the

tab inside the suction

hose opening.

2. Insert the suction hose into the

opening and turn clockwise.

Interconnect

high

low

Use

Operating the Vacuum

1. Make sure the Disposable Odor Fighting

dust bag is in place. DO NOT operate the

cleaner without a dust bag.

2. Release the cord: twist cord dump located

on Helping Hand®handle one-half turn.

Slide the cord off the handle.

3. Plug the power cord into an electrical outlet.

4. Press the power button when ready to

operate. Press the high or low button

depending on the speed you wish to use.

5. Up-Position Lock:

Place your foot on the

power head and lean

handle back gently to

release lock for vac-

uum use. Return

handle to the full

upright position

to engage lock.

Important! Ensure the Oreck Edge upright vacuum disposable

dust filter bag is securely in place and the outer bag is zipped.

Dust and debris will be released into the room if this step is

not taken.

6. Carry Handle: Use the carry handle located

on back of the vacuum for easy lifting,

carrying, and stair vacuuming. Carry handle

also serves as the lower cord wrap.

high

low

Autres manuels pour Edge

Table des matières

Langues :

Autres manuels Oreck Aspirateur

Oreck

Oreck APU255 Manuel utilisateur

Oreck

Oreck VENTURE Manuel utilisateur

Oreck

Oreck XL U3640RH Manuel utilisateur

Oreck

Oreck U4300 Graphite series Manuel utilisateur

Oreck

Oreck XL Zip Vac Ultra ZIP100 Series Manuel utilisateur

Oreck

Oreck XL2090RHM Manuel utilisateur

Oreck

Oreck XL SIMPLY AMAZING dutchTech DTX 1400A Manuel utilisateur

Oreck

Oreck ELEVATE Conquer UK30300COM Manuel utilisateur

Oreck

Oreck XL BB877-RD Manuel utilisateur

Oreck

Oreck XL2090RSM Manuel utilisateur

Oreck

Oreck CC1400A Mode d’emploi

Oreck

Oreck XL2000RH Manuel utilisateur

Oreck

Oreck Upright Bag Vacuum Cleaner Manuel utilisateur

Oreck

Oreck STEAM 75 Manuel utilisateur

Oreck

Oreck XLPRO6 Manuel utilisateur

Oreck

Oreck Simply Amazing XL2000HH Manuel utilisateur

Oreck

Oreck U3771 Manuel utilisateur

Oreck

Oreck U4151 Manuel utilisateur

Oreck

Oreck magnesium Manuel utilisateur

Oreck

Oreck DP-460 Manuel utilisateur

Oreck

Oreck XL U4490HH Manuel utilisateur

Oreck

Oreck Steemer XLS700 Manuel utilisateur

Oreck

Oreck XL U2200RD Manuel utilisateur

Oreck

Oreck magnesium Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur

Nobles

Nobles 608669 Manuel du produit
