Opus Air OPUS OP2 Guide de l'utilisateur
OWNERS
HANDBOOK
PCT Patent Pending GB/2017/050391 &
Australian Patent Pending 2017220045,
2018204104 Design registration No
201714813, 201714812, 201714811, 201714810
PCT Patent Pending GB/2017/050391 &
Australian Patent Pending 2017220045,
2018204104 Design registration No
201714813, 201714812, 201714811, 201714810
CONTENTS
opuscamper.com.au 01
PCT Patent Pending GB/2017/050391 & Australian Patent Pending 2017220045,
2018204104 Design registration No 201714813, 201714812, 201714811, 201714810
Vehicle Identification Number (VIN) page 2
Specifications Page 3 - 4
Dimensions Page 5
11 Quick Tips to set up your Air OPUS® Page 6 - 7
Hitching & Trailer Electrics Page 8
Air OPUS® Brake Set Up Page 9
Setting Up your Air OPUS® Camper Page 10 - 11
Understanding the Air OPUS® Switchboard Page 12
Understanding the air valves when setting up your Air OPUS® Camper Page 13
Air OPUS® Water System Page 14 -15
Air OPUS® Gas System Page 16
Air OPUS® 240 Volt Mains Power Page 17
Air OPUS® 12 Volt Power Page 18
Air OPUS® Fridge Slide Page 19
Setting up the Additional Day Bed Page 20
Installing your Air OPUS® Annexe Page 21 - 23
Installing your Air OPUS® Ensuite Page 24
Air OPUS® Care & Maintenance Page 25 - 30
Page 31 - 33Air OPUS® Warranty
VEHICLE IDENTIFICATION
NUMBER (VIN)
opuscamper.com.au 02
About Your Vehicle Identification Number
Every Air OPUS® has a Vehicle Identification Number (VIN). The VIN Plate can
be found on the exterior of your Air OPUS® to the left of the door secured, to
the draw bar. We recommend making a note of your VIN in the template
below. This will be required by insurance companies.
opuscamper.com.au 03
SPECIFICATIONS
- 2 SLEEPER
Body Work Baked enamel finish 2
Box Material Main body aluminium frame & composite panel exterior, with
galvanlized steel chassis and draw bar
Dimension (Closed) 5695 x 2025 x 1730
Dimension (Open) 6580 x 2605 x 3500
Ground clearance 490mm
Ride Height 1550mm
Chassis 500 x 1870 x 720mm
Drawbar 2600 x 1390 x 150mm
King Size Bed 1950 x 1600
Trailer Tare Weight 1415kg (canopy and annexe included)
Ball Weight
Ball Weight
140kg
ATM 1990kg
150kg
Coupling DO35
Suspension Independent Coil Spring Suspension
Shock Absorber Quad Shock: Dual Gas Shock Absorber per side
Kitchen Fully Stainless Steel Kitchen with 4 burner stove & sink with
electric tap with slide out extension
Water System 2 x Electric Water Pump
Water Tank 2 x Stainless Steel Tanks (1 x 35L, 1 x 85L)
Water Tank Guard 1.5mm checker plate
Fridge Tray 1070L x 540W x 500H
Stabiliser Legs 4 x Drop down lockable
Jockey Wheel Adjustable height swing up
Jerry Can Holders
Stone Guard
2 x 20L
Gas Bottle Holders Twin 9kg adjustable gas rings
Front Surface coated with anti chip deadener
Spare Wheel
Wheels & Tyres 15” Alloy Wheels 235/75R15 All Terrain Tyres
15” Alloy 235/75R15 All Terrain Tyre
Lights
Brake System 12” Electric brakes with hand brake and electric break
away switch
LED
External Shower
Portable Toilet Standard
Cold water supplied from tank
Features
opuscamper.com.au 04
SPECIFICATIONS
- 2 SLEEPER
Power Supply 12V & 240V
Towing 7 PIN flat plug & Anderson plug
Stereo System Stereo System with 2x speakers, Radio, USB inputs, CD
& DVD player
Battery 2x 100Ah deep cycle AGM batteries with 240V charger
Trailer Lights LED tail lights, clearance lights, internal lights, number
plate light, tool box lights, kitchen light, annexe light
Electrical
Material 340g Micro Weave Poly Cotton
Tropical Roof Waterproof and UV Protective Tropical Roof
Annexe Fully Enclosed Annexe with removable doors & side walls
Awning Annexe with doors & end walls removed
Ensuite Room Removable ensuite with floor
Tent/Canopy
Foldable Roof Rack +80kg tare weight (200kg load capacity)
e-Go Movers Remote controlled
LED Light Kit Flexible Strip lighting system
Optional Accessories
DIMENSIONS
- 2 SLEEPER
opuscamper.com.au 05
6580mm
5695mm
1730mm
1950mm
3500mm
1730mm
2025mm with roof rack
opuscamper.com.au 06
11 QUICK TIPS TO SET UP
AND PACK UP YOUR
AIR OPUS®
Invest in a cordless drill and
19mm hex head bit to adjust
stabiliser legs rather than
manually winding them.
When
operating
the winches
ensure that
the winch
strap remains
flat when
using or
retracting.
To avoid placing too much pressure
on the latches and breaking the
latch hook, make sure you latch
down the back of the camper first
(furthest from the hinge).
TIP 1
TIP 4
TIP 2
Take special care to ensure all
canvas is tucked away on all sides
especially around gas struts, hinge
points.
TIP 5
When using your key to open and
unlock the door, push the door
inwards on the seal to take pressure
off the lock and it will open easier
for you.
TIP 6
You can adjust the latch by turning
it along the thread, thus extending
it to avoid excessive pressure on the
latches. You can close your camper
with the latches longer, and then
return to tighten these up.
TIP 3
opuscamper.com.au 07
11 QUICK TIPS TO SET UP
AND PACK UP YOUR
AIR OPUS®
During canopy inflation make sure
all external air valves are closed off
and the main air valve is open
before turning air pump on.
TIP 7
During annexe inflation make sure the air valves
are closed off before turning air pump on BUT
MAKE SURE the cross filling tube valve is OPEN
so that the air from the canopy can purge/travel
through to the air beams on to help.
TIP 8
Remember to turn the MAIN
INFLATION valve in the camper to
the horizontal CLOSED position when
inflation is complete otherwise the
canopy may slowly deflate over time.
TIP 9
Before you set off on your first trip,
do a couple of full set ups and while
you have all the canopy and annexe
up, remember to weather-in the
canvas and allow to dry completely
before packing up!
TIP 11
If the beams are losing air slightly you can turn
the inbuilt air pump ON and that will top up
the air pressure in all air beams back to the
desired pressure, the pump will turn OFF
automatically.
TIP 10
External Inflating / DeflatingAir Valve To OPEN valve turn counter clockwise.
To CLOSE valve turn clockwise until firm.
CLOSED OPEN
IMPORTANT
Remember to open the
main valve while inflating.
opuscamper.com.au 08
HITCHING & TRAILER
ELECTRICS
About your Coupling
7 PIN FLAT PLUG
The Air OPUS® is fitted with a 7-pin flat plug
that connects all the exterior trailer lighting
and the electric brakes to the towing vehicle.
A standard 7 pin plug is required on your tow
vehicle for this to connect to.
ANDERSON PLUG
The Air OPUS® is also fitted with a standard 50
amp Anderson Plug which is connected to the
Air OPUS® batteries. If you have an Anderson
plug on your towing vehicle that is connected
to your vehicle battery then you can attach
these two together whilst towing. Disconnect
these plugs when the engine of the towing
vehicle is not running, as it will continue to
draw current and you may end up with a flat
battery on your towing vehicle.
You can also use this Anderson plug to attach
a solar panel which will also charge your Air
OPUS® batteries. Your solar panel must have
a built in regulator. The Anderson Plug runs
through its own fused system located in the
battery box.
About your Electrical Plugs
The Air OPUS® comes with a DO35
off-road coupling.
When hitching the Air OPUS® to your towing
vehicle you must ensure that someone is close
to the handbrake in order to maintain control
of the trailer, particularly when manoeuvering
on uneven ground or a slope.
IMPORTANT
Wheel nuts should be checked
after first 100km and then
every 1000km.
