Optiview DVRJ4 Manuel utilisateur

4-ch Standalone Network DVR

User’s Manual

Rel.061207

DVRJ4

1. Product introduction

1.1. System specification

2. Product operation

2.1. Various split screen

2.2. 1 channel audio recording & playback

2.3. USB backup

2.4. System upgrade through USB stick

2.5. Network client program with various

functions

2.6. Front panel and buttons

2.7. Back panel connection

2.8. Remote controller

3. Various display mode

3.1. QUAD mode

3.2. PIP mode

3.3. FULL screen mode

3.4. AUTO rotation mode

3.5. TRIPLEX mode

4. DVR installation and operation

4.1. Recording

4.2. Playback

4.3. Searching

4.4. Zooming

4.5. Freezing

4.6. USB backup

4.7. System information

5. Menu

5.1. Setup menu

5.2. System menu

5.3. Video menu

5.4. Recording menu

5.5. Network menu

5.6. Sensor / Motion menu

5.7. Backup menu

5.8. Schedule recording menu

6. Network client software

6.1. Program installation and

operation

7. Router

7.1. Virtual server

7.2. Router IP check

7.3. Access

App. A. Troubleshooting

App. B. Product specification

DVRJ4 User’s manual

Before operating

This User‟s manual is explanation of DVRJ4 installation and operation. If you are not familiar with DVR, please

contact professional technicians for installation and operation. Please read thoroughly before you operate the unit

for your safety.

Be careful!

Do not install the unit where vibration and shock can be made. This can cause trouble.

Turn the unit off when you do cleaning and make sure to use dry towel.

Do not expose the unit to water or moisture.

Install the unit on even place and maintain the proper temperature.

Do not put heavy things on the unit.

DVRJ4

1. Product Introduction

DVRJ4 supports full triplex (recording / playback / backup) and GUI for setup.

Storage

Up to 500GB

(supporting 24 Bit, 48 Bit)

Two (2) hard drives

Compression M-JPEG (Modified JPEG)

Video input 4 (NTSC/PAL) channel

Recording resolution 704 x 240(288), 352 x 240(288)

Recording speed 1fps ~ 120fps totally @ CIF

Recording mode

Manual recording

Event recording

- Motion, Alarm detected.

Remote recording through network

Playback mode FF : 2X ~ 32X, REW : 2X~16X,

Display 120fps

Display mode - QUAD, MUX, PIP, Automated rotation

Multi Task Triplex (recording, playback, backup at the same time)

Motion detection 5 levels, 16 x 12 grids area

Audio Input 1 port

Output 1 port

1.1. System Specification

User’s manual

DVRJ4

Backup

Backup through network

AVI file backup

Watermark

USB memory stick, USB 2.0

Can be viewed by WINDOWS

Firmware update via USB stick

Network viewer Setup, Search, Backup

User’s manual

DVRJ4

2. Product operation

2.1. Various split screen

Processes 4channel video input by real time, and provides various split screen (QUAD, FULL, PIP, AUTO,

FREEZE).

2.2. 1 channel audio recording and playback

2.3. Backup to USB Thumb drive

Supports USB thumb drive backup and USB 2.0. You can play back the data via remote client program.

2.4. Firmware upgrade via USB stick

When you try to update the system through USB stick, save the firmware after you change the name to

„update.bin‟. And put it in the DVR USB port, and get in „USB SETUP MENU‟ of the DVR menu to select

“FIRMWARE UPDATE‟. Then it automatically begins updating. It takes about 4 ~ 5 minutes. After that, it will reset

itself.

2.5. Various function of network client software

- It supports various display (1channel/4 channel/PIP/AUTO rotation/Triplex).

- You can save the data that are being viewed on network viewer now on your PC.

- You can convert the data saved on your PC into AVI file.

- You can search the recorded data.

User’s manual

DVRJ4

2.6. Front panel and buttons

NO Items Details

Status LED

- POWER : DVR is on, then LED is on.

-HDD : It lights when HDD‟s are read or recorded.

- REC : It gets on when images are recorded.

- PLAY BACK : It lights when recorded data are played back.

- NETWORK : DVR is accessed by client program, then it gets on.

- BACKUP : If backup is being done, it gets on.

QUAD - You can use this when you want to view 4 cameras at the same time.

PIP - You can view a few smaller screen in a main screen.

TRIPLEX - It shows live images, playback images on one screen.

AUTO - It shows one channel by one channel from #1 channel through #4 channel. It rotates

automatically.

CH1, CH2, CH3,

CH4

- You can view one channel in a full screen.

①

②

③

④

⑤

① ② ③ ④⑤ ⑥ ⑦ ⑧

⑨ ⑩ ⑪ ⑫

⑥

⑬ ⑭ ⑮

User’s manual

DVRJ4

NO Items Details

ZOOM - You can zoom the current screen by 2x2.

⑧FREEZE - You can view the paused screen.

⑨SEARCH - RECORD START-STOP search

You can start or stop the recorded data.

- EVENT search

You can search the Event data which is motion and/or sensor(alarm).

- TIME search

You can designate your target time.

⑩PLAY-BACK - You can view the recorded data from the hard drive of the DVR. If you press this button

without any other action, the latest recorded data will be played back.

⑪REC - You can record images manually with this button. If you press it one more time, recording

will stop.

⑫SET/EXIT - For Setting of DVR

- To move upper menu or main menu

⑬BACKUP - This is for USB thumb drive backup.

⑭ARROW KEYS - For menu setting or moving to other setting.

⑮USB PORT - USB thumb drive

⑦

User’s manual

DVRJ4

2.7. Back panel connection

CH1 CH2 CH3 CH4

AUDIO IN

AUDIO OUT

MON

DC 12V

① ② ③ ④ ⑤ ⑥

NO Items Details

①VIDEO INPUT

(1~4 CHANNEL)

4 composite video inputs with BNC jack.

②MONITOR For monitor, CCTV monitor

③AUDIO INPUT /

OUTPUT

Supports line level audio in/out which uses RCA mono type connector. You need external

amplifier to connect to mic.

④ETHERNET RJ-45, 10/100Mbps

ETHERNET AL IN AL OUT PAN/TILT

User’s manual

DVRJ4

NO Items Details

⑤ALARM/PTZ - Alarm input (AL IN)

Supports 4 alarm inputs.

- Alarm output (AL OUT)

Supports 1 output and out internal buzzer. If alarm goes off, you can press „ENTER‟

on the front panel to reset the alarm status. Maximum volt is +5V.

⑥POWER External DC power supply (12V/5A)

User’s manual
