OPERATION MANUAL
Digital Gas Detector/Controller
TABLE OF CONTENTS
1.0 General Description
1.1 Applications
1.2 Features
1.3 Specications
1.4 User Interface
2.0 Model Selection Guide
3.0 Installation
3.1 Sensor Placement
3.2 Wiring
3.3 Installation Check List
4.0 Operation
4.1 Screen Display
4.2 Default Settings
4.3 Changing Settings
4.4 List of Settings
5.0 Network Conguration
5.1 Using CAN Network, Central Controller
5.2 Using CAN Network No Central Controller
5.3 Defaults Conguration
5.4 Creating Zones or Groups
5.5 Addresses
5.6 Output Relays
6.0 Maintenance Guide
6.1 Calibration Procedure
7.0 BACnet Network Conguration
6000 Series Digital Gas Detector/Controller
6000 Series Digital Gas Detector/Controller
Safety Information
This manual describes information required to install, operate
and maintain series 6000 gas detectors. Read and study before
attempting to install or operate sensors. Installation and operation
not in accordance with this manual can result in sickness or death.
Relay connections may be used to control 120 vac equipment.
Ensure power is disconnected from relays before attempting to
service this unit.
1.0 General Description
Series 6000 gas detectors are versatile, self-contained dual gas
sensor monitors, used for automated ventilation control and/or
warning systems. They can easily be networked together, with or
without a central controller into groups.
1.1 Applications:
• VehicleEmissions
• CombustibleGases
• RefrigerantGasLeakDetection
• IndustrialHealthandSafety
1.2 Features:
• Stand-aloneoperationwith1or2adjustablealarmrelays,
indicators and strobe
• BACnetLaboratory(BTL)listedSmartSensor,upto76,800baud
• BACnetMS/TPRS485interface
• CANnetworkinterfaceformaster-slaveoperationorcentral
control via model 6000 controller.
• Pre-calibratedplug-and-playsensormodulesavoidthe
need to recalibrate when upgrading expired sensors.
• Impactresistant,waterresistantenclosure,withtopwire
entry and drip proof wire guide.
1.0 General Description
1.3 Specications
• Supply24vac50/60hz(17-28vac)0.21amps,5va
• Relays(1or2)SPDT,5amp@125vac,non-inductive
Ondelay;0-999seconds(16minutes)
Offdelay;0-999seconds(16minutes)
• Operatingtemperature-20ºCto40ºC(-4ºFto104ºF)
• Forindooruse
• FlameresistantPolycarbonateABSenclosureratedUL94
V0, 5VB, and 5VA
• Standards.ConformstoUL61010-1,CSAC22.2
61010-1-12, ANSI/ISA 61010-1, CSA C22.2 no. 205-12
• Analogue4-20maor2-10v(model6000-A)
• Pollutiondegree2
• InstallationcatagoryII
• Altitude2000m
• Humiditymax80%rh.80%totemperaturesupto31ºC
88ºF,decreasinglinearityto50%rhat40ºC(104ºF)
1.4 User Interface:
• BacklitLCDdisplayshowsgasconcentration,user
settings, calibration controls
• RedLEDalarmindicators,gaslevel1and2
• HighintensitywhiteLEDstrobeonlevel3
• Audiblealarm,85dbat1meter
• 4pushbuttonuserkeypad
• Passwordcontrolforsettings
6000 Series Digital Gas Detector/Controller
2.0 Model Selection Guide
6000-B
•2 relays
•noanalogueoutputs
6000-A
•1 relays
•2analogueoutputs
60xx-xx-B 60xx-xx-A
Controller Only
Example: 6002-14-B Detector for CO + NO2
Gas Type
(seechart)
Gas type
if second
sensor
installed
Gas Type
(seechart)
Gas type
if second
sensor
installed
Gas Type
(seechart)
55-xx
Controller with
Sensor(s)inside
Sensor Replacement
Module
2.0 Model Selection Guide
Gas Type Range
NH3Ammonia 04 0-250 ppm
Ar Argon(O2depletion) 23 0-50%O2
C4H10 Butane 05 0-50%LEL
CO2Carbondioxide(AQ) 15-2000 0-2000 ppm
CO2Carbondioxide(refrigerant) 15-5000 0-5000 ppm
CO Carbon Monoxide 02 0-100 ppm
CO Carbon Monoxide 02-250 0-250 ppm
COnilH2CarbonMonoxide,nilH202nilH2 0-100 ppm
CL2Chlorine 17 0-10 ppm
C2H4(OH)2Ethylene glycol 07 0-50%LEL
C2H5OH Ethanol 07 0-50%LEL
HCFCs 13
HFCs 20
He Helium(O2depletion) 23 0-25%O2
H2O in air Humidity(relative) 25 0-100%RH
H2Hydrogen 08 0-50%LEL
H2SHydrogenSulde 16 0-50 ppm
C4H10 Iso-butane 05 0-50%LEL
C3H7OH Iso-propyl Alcohol 07 0-50%LEL
CH4Methane 05 0-50%LEL
CH3OH Methanol 07 0-50%LEL
N2Nitrogen(oxygendepletion) 23 0-50%O2
NO2Nitrogen Dioxide 14 0-10 ppm
VOCs Organic Vapors 01 0-1000 ppm
O2Oxygen Leak 22 0-50%O2
O2Oxygen Depletion 23 0-50%O2
C3H8Propane 06 0-50%LEL
6000 Series Digital Gas Detector/Controller
3.0 Installation
3.1 Sensor Placement
Coverage
Guidelines for sensor placement of diffusion type sensors are
based on the reasonable delay for gas to get from the source to
the sensor. All sensors are created equal in this regard.
• For air quality control of exhaust emissions and
accumulations of toxic gases the generally acceptable
maximumradiusofcoverageis50feet(15meters).
Approximately7500squarefeet(700squaremeters).
• For leak detection of combustible gases, ammonia,
refrigerationgasesthemaximumradiusis30feet(10meters)
since they can escape more quickly and the risk is greater.
The radius of coverage of any sensor does not extend beyond
any obstruction that impedes natural circulation of air. This
includes walls, stairs, elevators, shelving with solid ll, tool
chests, etc. The sensor must “see” the area of coverage; if not,
anothersensor(s)isrequired.
Mounting Heights
Mounting heights for gas sensors are based on their density,
relative to air. There are three groups;
1. Lighter than air and will be more concentrated near the
ceiling;hydrogen,methane(naturalgas),ammonia,helium.
Install at 1 to 3 feet from ceiling.
2. Similar density to air and will be diluted in air equally at
all levels; - carbon monoxide, nitrogen dioxide, hydrogen
sulde,oxygen,carbondioxide.Installfrom3feet(1
meter)offoortoonehalfoftheceilingheight.Forvehicle
emissions carbon monoxide detectors combined with
nitrogendioxidedetectorsareinstalledat3to5feet(1
to2meters)fromtheoorwhentheceilingis7to10feet
high. If the ceiling height is higher than 10 feet, for example
for heavy equipment, the carbon monoxide detectors are
installedat3to5feet(1to1.5meters)fromtheooras
per the requirements of the Canada building code and the
nitrogendioxidedetectorsshouldbeinstalledat50%ofthe
ceiling height and above the vehicle height. If the exhaust
pipes of diesel vehicles are below the vehicles, then the
nitrogen dioxide detectors should be installed at 3 to 5 feet
(1to1.5meters)fromtheoor.Inallcasesthedetectors
must be installed above obstructions blocking circulation of
air in front of the detectors; example, maintenance garages
in automobile dealerships where tool chests, work tables and
storage racks typically line all walls.
3. Heavier than air andwillconcentrateneartheoor;-HFCs,
HCFCs,propane,chlorine,mostorganicvapors(consult
Opera),butane.Install1-3feet(30cmto1meter)fromoor.
For all types of sensors avoid drafts, obstacles, aerosols, silicones.
Place sensors in the center of its coverage area as much as
possible.
3.0 Installation
6000 Series Digital Gas Detector/Controller
3.2.1 Wiring Model 6000-A
24 Vac
or
120 Vac
Independant
Circuit
120 Vac
To magnetic starter coil or
control relay coil for ventilation
Transformer
120/24 Vac
To Other
Detectors
BACnet
MSTP
network
CAN
network
Binary
input
to limit
switch
EOL CAN
Up Position 4-20Ma
or
Down Position 2-10V EOL BACnet
5 Va for
each unit
NO COM
Relay 1
NC ANA1 G
Analogue Output
ANA2
–
+
SHIELD
(noconnect)
High
Low
Shield
(on 1rst unit only)
3.2.2 Wiring Model 6000-B
24 Vac
or
120 Vac
Independant
Circuit
120 Vac
To magnetic starter coil or
control relay coil for ventilation
Transformer
120/24 Vac
To Other
Detectors
BACnet
MSTP
network
CAN
network
Binary
input
to limit
switch
EOL CAN EOL BACnet
5 Va for
each unit
NO COM
Relay 1
NC NO COM
Relay 2
NC
3.2 Wiring
–
+
SHIELD
(noconnect)
–
+
Shield
(no connect)
High
Low
Shield
(on 1rst unit only)
