OpenVox D210E Manuel utilisateur
User Manual
深圳开源通信有限公司
OpenVox-Best Cost Effective Asterisk Cards
OpenVox D210E D410E User Manual
Written by: James.zhu
Date:21/12/2007
Version: 0.01
1
User Manual
深圳开源通信有限公司
OpenVox-Best Cost Effective Asterisk Cards
OpenVox Communication Co. Ltd.
Address: F/2,Building No.14,Shangsha Science & Technology Park,
No.9283,Binhe Road, Futian District,ShenZhen ,Guangdong 518048,China
Tel:+86-755-82535095,82535461,Fax:+86-755-82535174
IM for Sales: [email protected] [email protected]
IM for Technical Support: [email protected],[email protected],[email protected]
Business Hours: 9:30AM-17:30PM from Monday-Friday
URL：www.openvox.com.cn
2
Thank You for Choosing OpenVox’s Products!
User Manual
3
Table of Contents
Chapter 1 Overview………………………………………………………………… 4
Chapter 2 Card Installation and Configuration……………………………… 5
Chapter 3 R e f e r e n c e ……………………………………………………… 12
Chapter 4 Hardware Setting……………………………………………………… 13
User Manual
4
Chapter 1 Overview
1. What is D410E/D210E
The D410E/D210E series supports E1, T1 and J1 environments and is selectable on a
per-card or per-port basis. This feature enables signaling translation between E1
and T1 equipment and allows inexpensive T1 channel banks to connect with E1 circuits.
With the improved I/O speed, the card reduces CPU usage and increased card density
per server. D410E/D210E series is fully compatible with Asterisk applications. The
open source driver supports an API interface for custom application development.
D410E/D210E series supports industry standard telephony and data protocols
including Primary Rate ISDN (both N. American and Standard Euro) protocol families
for voice, PPP, Cisco, HDLC, and Frame Relay data modes. Both line-side and
trunk-side interfaces are supported.
Other Features Include:
Supporting PCI Express 1.0
Be easy to install: Support wct4xxp driver included in original zaptel without any
patch
RoHS compliant
Certificates: CE and FCC
2. What is Asterisk:
The Definition of Asterisk is described as follow:
Asterisk is a complete PBX in software. It runs on Linux, BSD,Windows (emulated)
and provides all of the features you would expect from a PBX and more. Asterisk does
voice over IP in four protocols, and can interoperate with almost all standards-based
telephony equipment using relatively inexpensive hardware.
User Manual
Figure 1: Asterisk Setup
Source (http://www.siriusit.co.uk/uploads/images/consulting/asteriskSetup.gif)
Asterisk provides Voicemail services with Directory, Call Conferencing, Interactive
Voice Response, Call Queuing. It has support for three-way calling, caller ID
services, ADSI, IAX, SIP, H.323 (as both client and gateway), MGCP (call manager
only) and SCCP/Skinny(voip-info.org).
5
User Manual
Chapter 2 Card Installation and Configuration
1. Hardware Installation and Setup
Before inserting the D410E/D210E card in to PC, customer should set the jumpers
correctly. If customers can not sure the difference of the PCI and PCI Express,
please check that from below:
（Source：http://www.geeks.com/techtips/2006/Images/motherboard.gif
）
There are three steps that customers should check:
1) SPAN Type Setup
DIP Switch S1 controls the function of each span at E1 or T1 mode, for more
detail, please refer chapter 4.
2) CardID: if customers only have one D410E/D210E card in pc PCI express slot,
customers should set SW1 to 0, otherwise set to SW1 of each card to different
values, and it must start from 0 to card number -1.
2. Software Installation and Setup
D410E/D210E supports original zaptel wct4xxp driver. Customers can download
zaptel driver from asterisk.org. There are few steps to install wct4xxp drivers.
1) Checking the D410E/D210E hardware by command: lspci -v
6
User Manual
2) Downloading and compiling
Before installing libpri, zaptel and asterisk, make sure that all supporting
packages have been installed in system.
Note that if there is no kernel source in the system, user should install
them. User can run yum again:
yum install kernel-devel
. If the kernel is smp
kernel, please run this command:
yum install kernel-smp-devel
.
It is time to check for the availability of some other packages:
rpm -q bison
rpm -q bison-devel
rpm -q ncurses
rpm -q ncurses-devel
rpm -q zlib
rpm -q zlib-devel
rpm -q openssl
rpm -q openssl-devel
rpm -q gnutls-devel
rpm -q gcc
rpm -q gcc-c++
If any of those packages are not installed install them by using yum
yum install bison
yum install bison-devel
yum install ncurses
yum install ncurses-devel
yum install zlib
yum install zlib-devel
yum install openssl
yum install openssl-devel
yum install gnutls-devel
yum install gcc
yum install gcc-c++
Here，assuming the three packages are stored in /usr/src directory. Customers
compile those packages as following in order:
7
1. Installing libpri:
cd /usr/src/libpri
User Manual
8
make clean
make
make install
2. Installing zaptel
cd /usr/src/zaptel
make clean
make
make install
3. Installing asterisk
cd /usr/src/asterisk
make clean
make
make install
make samples
3) Configuration for zaptel.conf and zapata.conf
1) Modify the zaptel.conf by vi /etc/zaptel.conf
# Span 1: TE4/0/1 "T4XXP (PCI) Card 0 Span 1"
span=1,1,1,ccs,hdb3
# termtype: te
bchan=1-15,17-31
dchan=16
# Span 2: TE4/0/2 "T4XXP (PCI) Card 0 Span 2"
span=2,2,1,ccs,hdb3
# termtype: te
bchan=32-46,48-62
dchan=47
# Span 3: TE4/0/3 "T4XXP (PCI) Card 0 Span 3"
span=3,3,1,ccs,hdb3
# termtype: te
bchan=63-77,79-93
dchan=78
# Span 4: TE4/0/4 "T4XXP (PCI) Card 0 Span 4"
span=4,4,1,ccs,hdb3
# termtype: te
bchan=94-108,110-124
dchan=109
# Global data
loadzone = us
defaultzone = us
User Manual
9
4) Edit the zapata.conf by vi /etc/asterisk/zapata.conf:
[channels]
context=zap-in
switchtype=euroisdn
pridialplan=national
signalling=pri_cpe
usecallerid=yes
hidecallerid=no
callwaiting=yes
callwaitingcallerid=yes
threewaycalling=yes
transfer=yes
cancallforward=yes
echocancel=yes
rxgain=0.0
txgain=0.0
group=1
callgroup=1
pickupgroup=1
immediate=no
callprogress=no
callerid=asreceived
group=1
signalling=pri_cpe
channel => 1-15,17-31
group=2
signalling=pri_cpe
channel => 32-46,48-62
group=3
signalling=pri_cpe
channel => 63-77,79-93
group=4
signalling=pri_cpe
channel => 94-108,110-124
5) Loading wct4xxp driver for D410E/D210E:
modprobe zaptel
modprobe wct4xxp
ztcfg –vvvvvvvv
User Manual
dmesg
10
