OpenEye OE-C2012B8-S Manuel utilisateur

OE-C2012B8-S Hardware Manual - Features and Contents

Important Safeguards

Warranty

Product Description

Camera Dimensions

Connections

Resetting the Camera

Features

Box Contents

Important Safeguards

View Important Safeguards before installing the camera.

Warranty

View the Product Warranty for the camera.

Product Description

The OE-C2012B8-S is a 8MP outdoor bullet camera equipped with a 2.8~12mm varifocal, autofocus, zoom lens and

person, vehicle, and line crossing analytics. True WDR and true day/night functionality allow the camera to adapt to

changing lighting conditions throughout the day to ensure high-quality images.

The IK10 and IP67-rated housing and large size make it well-suited for installation in high-traffic areas to provide a

strong visual deterrent without concern for inclement weather or vandalism. Adaptive IR technology prevents

overexposure of objects close to the camera further enhancing the low-light performance.

The OE-C2012B8-S is compatible with multiple accessories allowing it to be mounted in a broad range of applications,

making it an excellent choice for users looking for a rugged and smart bullet camera.

Combine the analytics capabilities of this camera with OpenEye Web Services to receive real-time alerts, on person,

vehicle or line crossing detection, sent directly to your mobile device or PC.

Camera Dimensions

Connections

1 RJ45 For network and PoE connections

2 Power (12vDC) Power Connection (12vDC power input should be plugged when not in use)

3 Audio I/O

Ground

Audio In

Audio Out

4 Alarm I/O

Ground

Alarm In

Alarm Out -

Alarm Out +

Power Connection

For an adequate power connection, use a 12vDC adaptor. Alternatively, you can power the camera by PoE if a Power

Sourcing Equipment (PSE) switch is available. Ensure that the camera’s power cable is correctly and firmly connected.

NOTE: OpenEye recommends against using more than one power source at a time. Do not use a PoE power

source when providing the camera with 12vDC power.

If using Power over Ethernet (PoE), make sure Power Sourcing Equipment (PSE) is in use in the network.

Resetting the Camera

1 Reset

To restore the camera to factory defaults:

1. Disconnect power for 30 seconds.

2. Reconnect power and wait 30 seconds.

3. Close the jumper connection with a proper tool for 20 seconds.

2 MicroSD Card Slot Supports up to 512GB microSD card for Edge storage.

Do not add or remove the microSD card when the camera is powered on.

Features

• Person, Vehicle, Line Crossing Analytics

• 2.8 ~ 12mm VF, AF, Zoom Lens

• 8MP | Up to 20FPS

• Excellent Low Light Performance

• NDAA Compliant

• Adaptive IR | up to 164’

• True WDR @ 8MP

• Audio I/O

• Alarm I/O

• IK10 Impact Protection Rating

• IP67 Ingress Protection Rating

• Large size creates a strong visual deterrent

Box Contents

OpenEye C2012B8-S cameras come with self-tapping screws and plastic anchors, mounting template, and a waterproof

cable connector. Identify the following components to make sure everything has been properly included with your new

recorder. If any of the following items are missing, contact the dealer to arrange a replacement.

OE-C2012B8-S Bullet Camera

Self-Tapping Screws and Plastic Anchors x3

Mounting Template Waterproof Cable Connector
