Oontz ANGLE 3 PLUS Manuel utilisateur
Waterproof Portable Bluetooth Speaker
In the Package
Micro USB Charging Cable
Quick-Start Guide
Lanyard
Note: The cable and lanyard are packed below the
insert in the box. Slide out the insert to locate them.
Waterproof Portable Bluetooth Speaker
Buttons, Lights, Connectors and Built-in Mic
Attaching the Lanyard
Battery Features and Charging the Battery
Turning On and Off
Pair & Connect with Your Device
Using the OontZ app for Alexa
Using the OontZ app for Speaker Updates
Amazon Alexa App
IPX7 Water Resistance
Talk to Siri Wireless Hands Free Personal Speakerphone
To Play with Non-Bluetooth Devices Use a 3.5mm Stereo Audio Cable
Reset Function
Contacting Customer Support
Safety and Precautions
Table of Contents Pages
1 - 3
4
5 - 7
8
9 - 10
11-14
15-16
17
18
19
20
21
22
23 - 24
Buttons
Page 1
Important - The volume control on your device and the speaker work independently of each other.
To play the speaker at the loudest volume, set the volume on your device to maximum and raise the volume on the speaker to maximum.
Important - Some apps may not support track back, track forward, or play/pause
Track Forward and Track Back
Press-to-Talk
Power
Play/Pause
Bluetooth (Dual Function)
Press and Release to Pause/Play
Press and Release to
activate Alexa
Volume Down
Press to decrease volume
Volume Up
Press to increase volume
Press and Release to go to the next
track.
Hold for 1 second and Release to
go to previous track
Lights
Page 2
Red Light lit when charging:
- Slowly flashing Red
battery is charging
- Solid Red
battery is fully charged
- Rapidly flashing Red when playing
indicates battery charge is low
Blue Light lit when speaker is on:
- Flashing Blue
speaker is in Bluetooth pairing mode
- Solid Blue
speaker is connected
- Blue Light will turn to Solid Green
when a 3.5mm audio cable is plugged
into the AUX IN Jack
Connectors & Built-in Mic
AUX IN Jack
Micro USB
Charging Connector
Built-in Mic for Alexa, Siri
and Speakerphone
Page 3
Rubber Flap
- covers connectors
- pull gently from the top to access
connectors, it is a snug fit as part
of the waterproofing
IMPORTANT:
The rubber flap needs to be closed before
the speaker is exposed to water.
The speaker is not water- resistant or
waterproof when the flap is open.
Page 4
- Slide the smaller lanyard
loop through one of the
lanyard attachment holes at
the top of the speaker
- Slide the larger lanyard loop
through the smaller lanyard loop
that has passed though the other
attachment hole
- The lanyard is not for use by children under 6 years of age. Small parts can present a choking hazard.
- Pull the larger lanyard loop
completely through the
smaller lanyard loop to fasten
the lanyard to the speaker
Attaching the Lanyard
Battery Features
Music Play Time
Up to 14 hours on a full charge, at 2/3 volume.
Louder volumes will reduce the battery play time.
Page 5
- The rechargeable battery comes with a partial
charge and the speaker is ready to play.
- For maximum playtime, fully charge the battery.
- You can play while charging.
Low Charge Remaining
- When the battery charge has less than 15%
remaining the Red Light will begin flashing rapidly.
- The volume will decrease to preserve the
remaining battery charge.
* Exception: certain devices, including the Amazon Echo Dot and
Amazon Echo, disable the Power Saving Feature and the speaker will
remain on until you turn the power off.
Power Saving Feature
- When playing from battery power the OontZ Angle 3 Shower - PLUS
Edition will turn off after 30 minutes of not playing audio to conserve the
battery charge. *
- When plugged into a charging source the OontZ Angle 3 Shower - Plus
Edition will remain on until you turn the power off.
- You can continue to keep the speaker plugged into a charging source even
when it is fully charged, keeping the speaker turned on and available
Charging the Battery
Page 6
- Insert the small end of the Micro
USB Charging Cable into the
Charging Connector as shown. DO
NOT force when inserting, the small
end will only insert in one direction.
Inserting with too much force in the
wrong direction will damage the
Charging Connector on the speaker.
- Insert the larger end of the Micro
USB Charging cable into a USB wall
charger for a Smartphone or
iPhone, or a USB port on your
laptop/computer to charge the
battery (see illustrations on page 7).
Charging Time:
- Up to 5 hours to fully charge
a low battery.
Red Light lit
when charging:
- Slowly flashing Red
battery is charging
- Solid Red
battery is fully charged
Important: When the OontZ Angle 3 Shower - PLUS Edition speaker is
plugged in to a charging source with the Micro USB charging cable, never
use the speaker in the shower, bath, or near water, to prevent risk of electric shock.
Insert the larger end of the Micro USB charging cable into a USB wall charger for a Smartphone or iPhone (USB wall charger*
that is 5V 1.0A up to 5V 2.4A maximum), or a USB port on your laptop/computer to charge the OontZ Angle 3 Shower -
PLUS Edition battery.
*
Only use a USB wall charger that is UL listed. A UL listed USB wall charger will have the logo printed on it.
Charging the Battery (continued)
Page 7
