INDEX
Features and Specications......................................................... 3
Installation ..................................................................................... 4
Wiring ............................................................................................. 8
Plumbing........................................................................................ 9
Operation..................................................................................... 10
Sanitizing...................................................................................... 11
Winterizing................................................................................... 11
Troubleshooting.......................................................................... 13
Warranty ...................................................................................... 15
Thank you for purchasing the
ONSEN 3.0 DIAPHRAGM RV / MARINE WATER PUMP
Please take the time to read this manual carefully before attempting to
install or operate the pump. Improper use or installation may void the war-
ranty.
If you have any questions about how to use this product, please contact
onsenproducts.ca 800-996-5559
3
support@onsenproducts.ca
ENGLISH
Self-Priming
6 Feet Suction Lift
Runs Dry Without Damage
Quiet Operation
Low Power Draw
FEATURES AND SPECIFICATIONS
Snap-In Port Fittings
Corrosion Resistant Materials
Soft Noise Absorbing Mounts
Built-In Check Valve And
Thermal Overload
Model Voltage Amp Flow
Rate
Pressure
Rating
Control
Type Valves Diaphragm Chambers
Onsen
3.0 12 7.5 3.0 GPM
/ 11.3L
55 PSI /
3.8 BAR
Switch &
Bypass EPDM Santoprene 4
Height (in/cm) Length (in/cm) Width (in/cm) Weight (lb/kg)
4.25 in / 10.8 cm 8.5 in / 21.59 cm 4.5 in / 11.43 cm 4.18 lbs / 1.90 kg
0.16 in
4.0 cm
4.25 in / 10.8 cm
4.5 in / 11.43 cm8.5 in / 21.59 cm
8.87 in / 7.3 cm1.02 in / 2.6 cm
4onsenproducts.ca 800-996-5559
support@onsenproducts.ca
NOTE: When installing the pump, some water from factory testing may spill
out.
INSTALLATION
Before installing the pump, check that all of the following components and
accessories are included in the box:
Water pump
Strainer
2 X ½” hose barb adapters
2 X ½” threaded adapters
12 volt battery alligator clips (w/ 15A fuse)
onsenproducts.ca 800-996-5559
5
support@onsenproducts.ca
ENGLISH
Make sure to install the pump indoors in a dry area.
Mount the pump horizontally or vertically. If mounting vertically, make
sure to mount with pump head down to avoid damaging the motor in
case of leakage.
Secure the feet with 4 screws.
STEP 1
MOUNT PUMP
City Water
Inlet
Water
Tank
Water
Heater
Check
Valve
Strainer
6onsenproducts.ca 800-996-5559
support@onsenproducts.ca
Insert the included hose barb or threaded quick connect adapters in the
inlet and outlet pump ports , and slide clips to lock port connec-
tions.
If using the included strainer, insert into the inlet port and slide clip to
lock port connection.
Use ½” (13mm) I.D. exible hose (preferably braided or reinforced) to
connect to the inlet and outlet of the pump. Use hose clamps to secure
the hose to the hose barb connectors (if hose barb adapters are being
used).
A
A B C
C
C
B
STEP 2
CONNECT WATER LINES
onsenproducts.ca 800-996-5559
7
support@onsenproducts.ca
ENGLISH
Connect the positive red wire to the positive (+) terminal of your battery
and the negative black wire to the negative (-) terminal of your battery.
A 15 amp switch is recommended and should be installed on the
positive red wire.
Use a 15 amp fuse protection on the positive red wire to protect the
pump.
STEP 3
CONNECT PUMP TO 12V BATTERY
Ft. (m) AWG (mm2)
0-30 (0-9) AWG14
30-50 (9-15) AWG12
50-65 (15-19) AWG10
NOTE: Connect using stranded wire with gauge size in relation to
distance or length as dened in the table below.
Black (-)
(-)
Red (+) (+)
Fuse
Switch
Battery
8onsenproducts.ca 800-996-5559
support@onsenproducts.ca
WIRING
The pump should be wired on its own dedicated circuit protected by the
recommended fuse indicated in this Operating Manual.
It is highly recommended to install an approved marine duty (ignition
protected) switch rated at 15 amps or above to control power to the
pump.
Make sure to shut o power to the pump when not being used for ex-
tended periods of time.
Proper wire sizing is required for good pump operation. If the wire is
too small, low voltage will aect the pump performance and can create
a re hazard.
The total current draw on the circuit must not exceed 15 amps. If the
pump is used in conjunction with other components, overload current
protection (fuse or circuit breaker) and wire size must be for the total
amp requirements of all devices on the circuit.
onsenproducts.ca 800-996-5559
9
support@onsenproducts.ca
ENGLISH
The inlet and outlet hose must be a minimum ½” (13mm) I.D. exible
hose to both ports. Using a hose with a smaller diameter can cause high
backpressure, cycling, low ow and noise.
Installation of a strainer is required to prevent debris from entering
the pump. Pump failure due to foreign debris is not covered by the
warranty.
Mount the pump within 5 feet of the tank (or any other water source) for
best performance and pump life. The greater the distance between the
pump and the water source, the greater the strain on the pump.
Plumb the system using high pressure, braided, exible hose to mini-
mize vibration and noise. The pump’s ports and strainer should not
be connected to plastic or rigid pipes. The pump’s normal oscillation
motion will transmit through rigid plumbing, causing noise and possibly
loosening or cracking components.
To prevent rapid cycling (pulsating ow) caused by excessive back pres-
sure, check for the following restrictive elements within your plumbing
system:
Water lters / puriers NOT on separate feed lines
Flow restrictors in faucets and showerheads
I.D. hoses and pipes smaller than ½” (13mm) throughout the plumbing
system
PLUMBING
10 onsenproducts.ca 800-996-5559
support@onsenproducts.ca
OPERATION
NOTE: This pump is designed for intermittent duty only. Continuous
duty usage will shorten the life of the pump and is not covered under
the warranty.
Make sure the pump is installed properly according to the installation
instructions above (wait before powering the pump).
Make sure the battery being used to power the pump is fully charged.
Open the water source (showerhead, faucets, etc.) connected to the pump.
Switch ON power to the pump. Water will begin to ow and ll the
water lines connected to a water heater, toilet, shower, etc. The goal
is to remove the air from the plumbing system and ll it with water.
Once the lines are completely lled with water, shut o all water x-
tures (showerhead, faucets, etc.).
When all water xtures are shut o, the pump will stop automatically
(if the pump fails to stop, switch OFF power to the pump and refer to
the Troubleshooting section of this Operating Manual).
The pressurized plumbing system is now ready for use. Open the water
xture needed and the pump will automatically start pumping water to it.
1
2
3
4
5
6
7
ALWAYS SWITCH OFF POWER TO THE PUMP WHEN
LEAVING IT UNATTENDED OR WHEN NOT IN USE.
CAUTION
