PR-SC886

SERVICE MANUAL

Ref. No. 4102

092008

MODEL PR-SC886

Black models

RC-690M

SAFETY-RELATED COMPONENT

WARNING!!

COMPONENTS IDENTIFIED BY MARK ON THE

SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE

CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.

REPLACE THESE COMPONENTS WITH ONKYO

PARTS WHOSE PART NUMBERS APPEAR AS SHOWN

IN THIS MANUAL.

MAKE LEAKAGE-CURRENT OR RESISTANCE

MEASUREMENTS TO DETERMINE THAT EXPOSED

PARTS ARE ACCEPTABLY INSULATED FROM THE

SUPPLY CIRCUIT BEFORE RETURNING THE

APPLIANCE TO THE CUSTOMER.

B MDD 120V AC, 60Hz

B MMP 220-240V AC, 50Hz

AV CONTROLLER

INPUT SELECTOR

LISTENING MODE

ON STANDBY

GNITUMYALPSID

RC-

690

DIMMER

CDR/MD

SAT

TAPE/AMP

SLEEP

MACRO

REMOTE MODE

SUBTITLE

AUDIO

REPEAT

PLAY MODE

---

10 11 12

VIDEO OFFOPEN/CLOSE

TV CH

TV VOL

PLAYLIST

RANDOM

DVD

AUX1AUX

GAME/TV

CBL/SATVCR/DVR

D. TUN

TUNER

TAPE

PHONO

VCRVCR DVDDVD HDDHDD

S. RESTORE

REC

ENTER

TEST TONE

AUDIO SEL

CH SEL

SURR

DIRECT

THX

PURE A

STEREO

LEVEL

L NIGHT

ALL ST

VOL

DISC

ALBUM

VCR

CABLE DOCK

DVD

RECEIVER

123

ZONE

INPUT

+10 0

CLEAR

123

456

789

Re-EQ

AV CONTROLLER PR-SC886

EXPLODED VIEW

PR-SC886

MP Type

P101

U017

MP Type A315

P9008

U28

A321

x 2 pcs.

A070

x 4 pcs.

A067

x 4 pcs.

A085

x 2 pcs.

A170

x 2 pcs.

A085

x 2 pcs.

A114

x 6 pcs.

A112

x 3 pcs.

A085

x 2 pcs.

A085

x 5 pcs.

U12 P102

A108

x 6 pcs.

A056

x 10 pcs.

A068

x 4 pcs.

A112

x 4 pcs.

A112

x 5 pcs.

A120

x 4 pcs.

A089

A114

x 2 pcs.

A112

x 71 pcs.

A094

x 2 pcs.

A078

x 3 pcs.

A076

x 2 pcs.

A109

x 4 pcs.

A066

A084

A400

A089

A072

A411

F9000

A410

A086

A172

A107

A087

A104

A090

A100

U05

A106

A110

P101

P2801

A089

A087

F2501

F5000

F5001

F5002

F5003

F2502

U07

U27

U14

P205

U01

U04

U16

U13

U15

A085

T905

T903

T904

A111

A132

A128 A067

U25

U06

U20

U26

U08

U10

U09 A058

U02

U03

F9301

A116

A118 A113

A092

A098

A096

A085

x 3 pcs.

A085

x 2 pcs.

A085

x 15 pcs.

A085

x 2 pcs.

A142

x 2 pcs.

A112

x 8 pcs.

A112

x 2 pcs.

A112

x 2 pcs.

A070

x 3 pcs.

A137

A270

A205

A219A239

A223

A085

A221

A209

A211

A213

A215

A303

A311

A313

A207

A217

A201

A261 A085

A253

A251

A255

A301

A259

A281

P7501

U17

U21

U24

U22

U18

A085

x 2 pcs.

U19

U23

DD Type

A069

x 4 pcs.

BLOCK DIAGRAMS-1

AUDIO SECTION

PR-SC886PR-SC886

BCDEFGH

SPDIF

RX0

RX5

MCH SR

RX6

RX7

DAC_FL

DAC_SL

DAC_SR

DAC_SBR

DAC_SBL

V_OUT_L

V_OUT_R

DAC_FR

DAC FL

MIX L

MIX R

DAC FR

DAC_CT

DAC_SW

MCH C

DAC C

MCH SW

DAC SW

MCH SL

MAIN L

MAIN R

DAC SL

DAC CT2

DAC SW2

MCH_SBR

MCH_SBL

MCH_SR

MCH_SL

MCH_SW

MCH_CT

VCR/DVR OUT

TAPE OUT

TAP E

VCR/DVR IN

CBL/SAT

GAME/TV

DVD

OUT

MAIN,SUB

IN 1-4

ch6

ch4

ch13

RS232

Q3031 ICL3221E

INTERFACE

OPTICAL IN 1

DIGITAL IN

(FRONT)

COAX IN 2

COAX IN 1

HDMI

SBL

HDMI

I/F

FLASH ROM

SD_RAM

I2S

DSD

+20dB

SW2

I2S

DSD

PHONO

OPTICAL IN 2

SBR

FRONT

SURROUND

BACK

SUBWOOFER

CENTER

PRE OUT

BALANCE

PRE OUT

BALANCE

INPUT

DD Type Only

TUNER UNIT

HD RADIO:

DD Type only

AM LOOP

ANTENNA

ZONE2 PRE OUT/LINE OUT

TONE

Q4204 R2S15211FP

0dB FIX

ZONE3 PRE OUT/LINE OUT

ADC

-6dB

Q3041

CS42516

MAIN B

SBL

SBR

BALANCE TERMINAL BOARD

NATRM-9108 SD-18

SBL

SBR

FRONT L

FRONT R

CENTER

SURROUND L

SURROUND R

SURROUND BACK L

SURROUND BACK R

HEADPHONES

(DVD audio,etc)

0dB

0dB -6dB

-6dB

Q4405

CS3318

AUX 2 IN

(FRONT)

AUX 1

Q4029

TC94A46CFG

ch14

ch12

ch11

ch10

ch9

ch8

ch1

ch2

RIAA

Sirrus

MAIN A

DIR

TONE

0dB FIX

Q4305

NJU7313A

Analog Switch

ch5

ch7

ch3

Q4304

NJU7312A

Q4304 NJU7312A

Analog Switch

0dB FIX

SETUP MIC

OPTICAL OUT

COAX IN 3

MULTI CHANNEL INPUT

SBL

SBR

PCM1796

DAC

PCM1796

DAC

Q3701 Q3721 Q3741 Q3761 Q3781

PCM1796

DAC

PCM1796

DAC

PCM1796

DAC

TC74VHC157FT MULTIPLEXER

I2S/DSD

MULTIPLEXER

TC74VHC157FT

Q3001

TC74VHC157FT

<Note>

Refer to SCHEMATIC DIAGRAM-5 and -19 (SD-5 and SD-19)

for digital audio signal flow waveforms.

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

+6dB

VLSC

IR OUT

IR IR IN B

IR IN A

12V TRIGGER OUT B

12V TRIGGER

CONTROL

REMOTE

SENSOR

12V TRIGGER OUT A

12V TRIGGER OUT C

INTERFACE

MAIN MICROPROCESSOR

Q7001

M3087BFKBGP

NALAN-9079 SD-17

E-CONTROL BOARD ETHERNET

(E-CONTROL)

DSP BLOCK

SD-6 and 7

2nd DSP Q3501: TMS320D788E001BRFP266

(SD-11)

1st DSP Q3401: TMS320D790E001BZDH300

(SD-10)

3rd DSP Q3601: TMS320D707E001BRFP250

(SD-11)

HDMI BOARD

NAHDM-9114

SD-11 to 15

NAVD-9052 SD-3

NADG-9074 SD-5

Q4306

NJU7311A

Q4305

NJU7313A

Video REC

Analog Switch

Audio Selector, Volume, Tone

Analog Switch Array

Analog Switch Volume

BLOCK DIAGRAMS-1

AUDIO SECTION
