One Remote DabFmBlue1 Manuel utilisateur
OneRemote DabFmBlue1
Advanced tuner for Bang & Olufsen systems handling
DAB/DAB+ –FM - Bluetooth
User Guide
Control with Bang & Olufsen remotes
30012004u2uk
www.oneremote.dk
2
DAILY OPERATION WITH BANG & OLUFSEN REMOTES
Go to ”Older Bang & Olufsen Remotes” if Ois not a key on your remote.
OO Press twice to select
A Switch to DAB reception
S Switch to Bluetooth
O D Menu
DA Maneuvering in menus
FS Maneuvering in menus
0–9Select a preset channel
wStand by key
www.oneremote.dk
3
Contents
Daily Operation with Bang & Olufsen Remotes .................................................................................................................. 2
Alternative Controls with Bang & Olufsen Remotes...................................................... Fejl! Bogmærke er ikke defineret.
Get Started –Quick Guide .................................................................................................................................................. 4
Presets - Favorite Channels ................................................................................................................................................ 5
SELECT OPERATION ................................................................................................................................... 6
DAB+ Channels.................................................................................................................................................................... 6
FM Channels ....................................................................................................................................................................... 6
Bluetooth ............................................................................................................................................................................ 7
MAIN MENU ................................................................................................................................................... 7
OLDER BANG & OLUFSEN REMOTES..................................................................................................... 7
Daily Operation with Older Bang & Olufsen Remotes ........................................................................................................ 8
Alternative Controls with Older Bang & Olufsen Remotes................................................................................................. 8
www.oneremote.dk
4
GET STARTED –QUICK GUIDE
Advanced OneRemote circuitry has been added to this tuner, OneRemote DabFmBlue1, enabling it
to be part of a remotely controlled Bang & Olufsen system. Complete control is obtained with a
Bang & Olufsen remote control terminal.
•DabFmBlue1 is a beocompatible tuner
•DabFmBlue1 may be controlled by any Bang & Olufsen system remote from 1988 and on.
•DabFmBlue1 may be controlled via the app UNDOK in iPhones, iPods, iPads or in Android
phones and tablets.
DabFmBlue1 may be connected to any
Bang & Olufsen system and controlled
by Bang & Olufsen remotes.
When switching on the DabFmBlue1 with a
Bang & Olufsen remote the Bang & Olufsen
system is switched on too and the input with
the DabFmBlue1 automatically selected.
If the DabFmBlue1 is to be used only for
handling DAB+, FM channels or music via
Bluetooth, no further installation is required.
DabFmBlue1 is connected to the system input
that is selected by pressing AMEM or ATAPE
on the Bang & Olufsen remote.
If the Bang & Olufsen system has no AMEM or ATAPE operated input available, the DabFmBlue1
needs to be connected to a different input socket and reprogramming of the DabFmBlue1 is
required accordingly. See the Installation Guide.
•Bang & Olufsen link-systems not only allow for listening to system sources from the main
room in any connected link room but also controlling them remotely. Thus a link
connected kitchen speaker not only plays music from the main room, but allows for
control of the system. DabFmBlue1 may be part of that system. See the Installation
Guide.
www.oneremote.dk
5
PRESETS - FAVORITE CHANNELS
Enter favorite channels as presets selectable by pressing single digits on a Bang & Olufsen remote.
A total of 10 presets are available for FM, DAB+ and Internet Radio each. Presets may be changed
at any time by pressing a single key on the Bang & Olufsen remote.
www.oneremote.dk
6
SELECT OPERATION
DAB+ CHANNELS
Switch on the DabFmBlue1 tuner with the Bang & Olufsen remote by pressing the key selected to
handle the tuner on the Bang & Olufsen system.
Press Aand DabFmBlue1 shifts to reception of DAB radio.
Select one of the presets by pressing a digit 0–9, or press DorFto display
a list of the available DAB channels.
The preset number and the signal quality are displayed at the very bottom of the display.
Other control options during DAB handling:
q4 Info O0 –9Save preset
q8 Rescan for stations q4 DRC
FM CHANNELS
Switch on the DabFmBlue1 tuner with the Bang & Olufsen remote by pressing the key selected to
handle the tuner on the Bang & Olufsen system.
Press DorFand DabFmBlue1 shifts to reception of FM Radio.
Select one of the presets by pressing a digit 0–9.
Press to display a list of the available channels.
The preset number and the signal quality are displayed at the very bottom of the display.
If the FM disable option is set, it is not possible to select FM reception.
Other control options during FM handling:
q4 Info O0 –9Save preset
DF Set frequency.
www.oneremote.dk
7
BLUETOOTH
Switch on the DabFmBlue1 tuner with the Bang & Olufsen remote by pressing the key selected to
handle the tuner on the Bang & Olufsen system.
Press Sto select reception via Bluetooth.
The Bluetooth logo flashing on the DabFmBlue1 tuner’s display indicates the tuner waiting for
connection to a source.
Switch on a Bluetooth source and pair it with the DabFmBlue1 tuner. If a password is required, use
0000.
flashing stops with completed pairing
MAIN MENU
OD Gives access to the main menu. The menu concist of a single line, in the button of the
display. When chosen different receiver options are available.
Adjustment in this menu is required only under installation.
OLDER BANG & OLUFSEN REMOTES
The DabFmBlue1 tuner may be controlled by all Bang & Olufsen system remotes.
Through the years Bang & Olufsen has marketed various models, where keys have been added or
removed. Some keys have just changed names.
As an example the Pkey has been replaced by the Okey.
If the remote does NOT have a Okey or a small joystick, control the DabFmBlue1 tuner in
accordance with below tables.
www.oneremote.dk
8
DAILY OPERATION WITH OLDER BANG & OLUFSEN REMOTES
P p Press twice to select
A Switch to DAB reception
S Switch to Bluetooth
P F Switch to FM reception
P D Menu
DX Maneuvering in menus
F Z Maneuvering in menus
0–9 Select a preset
ALTERNATIVE CONTROLS WITH OLDER BANG & OLUFSEN REMOTES
p1 Store channel playing as preset 1
p2 Store channel playing as preset 2
p3 Store channel playing as preset 3
p4 Store channel playing as preset 4
p5 Store channel playing as preset 5
p6 Store channel playing as preset 6
p7 Store channel playing as preset 7
p8 Store channel playing as preset 8
p9 Store channel playing as preset 9
p0 Store channel playing as preset 10
