Installation Manual
30012724s1uk
1
www.oneremote.dk
Getting Started 3
Direct Control or CableLink Control ............................................................3
Connection to Bang & Olufsen Equipment 4
Set Up for Direct Control ............................................................................5
Set Up for CableLink Control .......................................................................5
Option Programming –fit the tuner to the B&O set up 6
Setup wizard 7
Access Wireless Network ............................................................................8
Connecting to a Wired Network .................................................................9
Shift to Wireless Network ...........................................................................9
Access Code...............................................................................................10
Start the Setup Wizard..............................................................................10
View SW Version and Tuner ID .................................................................10
Connection to Bang & Olufsen Equipment 11
The Direct Control Option: ........................................................................11
The CableLink Control Option: ..................................................................11
Antenna Connection 12
Source & Option Selection 13
BeoSound 5 ...............................................................................................13
BeoSound 5 Encore ...................................................................................13
BeoCenter 2...............................................................................................13
BeoSound 4 ...............................................................................................14
BeoSound 1 ...............................................................................................14
BeoSound Century.....................................................................................14
BeoSound 9000 .........................................................................................15
BeoSound 3000 BeoSound 3200 ...............................................................15
BeoSound Ouverture.................................................................................15
BeoSystem 2500 BeoCenter 2500.............................................................16
BeoCenter 2300.........................................................................................16
BeoMaster 3300........................................................................................16
BeoMaster 5500........................................................................................16
BeoMaster 3500........................................................................................17
BeoMaster 4500........................................................................................17
BeoMaster 6500........................................................................................17
BeoMaster 7000........................................................................................17
BeoCenter 8000.........................................................................................17
BeoCenter 8500 BeoCenter 9000 BeoCenter 9500 ...................................17
BeoCenter 9300.........................................................................................18
BeoSystem 3..............................................................................................18
2
www.oneremote.dk
Connection via a BeoLink Converter 1611/ 1612. 19
Connection via a BeoLink Active in any Link Room 20
Connection to a 21 Pin AV Socket on any Bang & Olufsen TV. 21
Setup the Media Player 22
Windows Media Player 11 Shared Media Set Up .....................................22
Setup Media Sharing in the MAC OS.........................................................23
Troubleshooting 24
3
www.oneremote.dk
Getting Started
This OneRemote DAB+/FM/WiFi tuner has been re-designed for operation in a Bang & Olufsen remote
control system, allowing full control with a Bang & Olufsen remote control terminal either directly or via
connection to Bang & Olufsen equipment.
Thus the tuner is BeoLink compatible.
If the Bang & Olufsen system comprises one or more link rooms in a BeoLink System, sound may be
distributed to these rooms, and in some cases –see below –the tuner might even be controlled from
there.
Operation details described below require correct connection of the tuner to the Bang & Olufsen system.
When initially powered up the DabWiFi2 tuner is programmed to be switched on by pressing bor
yon the Bang & Olufsen remote. In most cases though reprogramming shall be carried out during
this initial installation. See below.
Hereafter the daily operation shall –in most cases - be limited to selecting a pre-set favorite program.
The OneRemote DabWiFi2 tuner is supplied with a DataLink cable enabling connection to most Bang &
Olufsen radios. But some system configurations require an adaptor as shown later in this manual and
explained in detail in the Installation Manual.
Direct Control or CableLink Control
The OneRemote DabWiFi2 tuner connects to Bang & Olufsen equipment with the 7-pin DIN-cable with or
without adaptor, and through option programming it may be controlled as follows:
1. Via the tuner’s built in IR-receiver,”Direct Control”
Direct Control is used, when connection to an input with control data is not possible. The tuner is
controlled directly with a regular Bang & Olufsen remote.
2. Via the cable connected Bang & Olufsen equipment,”CableLink Control”
CableLink Control is used, when connection to an input with control data is possible with the 7-pin
DIN cable. All the control data passes through the connected Bang & Olufsen equipment.
B&O Remote control model
Source
Beo4, Beo5, Beo6 or BeoOne
b
Beolink 1000
y
If DabWiFi2 is not connected to the Bang & Olufsen equipment as a b/ysource, the option
programming has to be changed to the source corresponding to the used input. Check Option
Programming below.
The OneRemote DabWiFi2 tuner is supplied initially programmed for direct control.
4
www.oneremote.dk
Connection to Bang & Olufsen Equipment
This OneRemote DabWiFi2 tuner may be connected to any Bang & Olufsen BeoSound, BeoCenter,
BeoMaster, BeoSystem or BeoVision TV and controlled with a Bang & Olufsen remote control terminal. It
may also be connected to equipment of any other brand, but it still needs to be controlled with a Bang &
Olufsen remote control terminal.
Through the years Bang & Olufsen equipment has had input sockets added, removed and renamed. A
newer Bang & Olufsen remote control has the button N.MUSIC, which is identical to SHIFT A.TAPE or
A.TAPE2 on older remotes.
Below tables, see Source & Option Selection, are showing available input sockets and their designation
on various Bang & Olufsen equipment. The tables below also show the source that has to be selected to
open a given input.
Thus with identified Bang & Olufsen equipment and the selected input socket the required option for the
tuner to be operable may be determined. Some input sockets allow for the CableLink option to be
selected, whereas most of the newer audio equipment requires the Direct Control option to be used. See
the special application with a BeoLink Converter below.
5
www.oneremote.dk
Set Up for Direct Control
The Bang & Olufsen remote terminal controls both the OneRemote DabWiFi2 tuner and the Bang &
Olufsen audio equipment.
When selecting the tuner connected source with the Bang & Olufsen remote the corresponding input
socket is opened, and the tuner is turned on simultaneously.
The tuner can be listened to in any connected link room, but not controlled from there.
Direct Control
Set Up for CableLink Control
The Bang & Olufsen remote terminal controls the OneRemote DabWiFi2 tuner via the Bang & Olufsen
audio equipment that is transmitting control data via the 7-pin DIN connection cable.
When selecting the tuner connected source with the Bang & Olufsen remote terminal the corresponding
input socket is opened, control data transmitted via the connection cable and the tuner is turned on.
Control data is only available via some input sockets in various Bang & Olufsen audio equipment.
A OneRemote DabWiFi2 tuner connected via CableLink can be controlled from any connected link room.
CableLink Control
6
www.oneremote.dk
Option Programming –fit the tuner to the B&O set up
Option programming is only required for the initial installation of the tuner. The programming itself is
carried out with a Bang & Olufsen remote, pointing directly towards the tuner. The tuner does not need
to be connected to a Bang & Olufsen device, in order to be Option programmed.
The objective is to fit the tuner’s performance to the actual audio set up.
Some installations require the tuner to be operated as an ysource, whereas in some other
installations only the Bsource might be available.
The option programming procedure is always initiated by pressing the programming switch on the
tuner’s back shortly to make it ready for programming.
The programming sequence itself using the Bang & Olufsen remote, starts off with pressing the L
key followed by 3 digits and finished by pressing the wkey.
All allowed options have a 3 digit configuration.
If the programming procedure is not successful the first time, repeating it is recommended.
Option 106 is programmed as follows:
L*1 106w
*1 Using a Beolink 1000, MK I or II Lhas to be replaced by h.
Allowed options are listed in the tables found in Source & Option Selection below.
LINK
7
www.oneremote.dk
Setup wizard
When the tuner is turned on initially,
“Setup wizard” is being displayed after
a few seconds.
The Setup Wizard is a guide through the
basic set up of the tuner.
Prior to the initial power up the tuner should be connected to the Bang & Olufsen equipment and
programmed correctly. See the chapter about Option programming.
With the Factory set option:
The tuner will power on, when bor yis pressed,
on a Bang & Olufsen remote control, pointed directly at the tuner.
Select”YES” by using A/S and confirm by pressing OO.
Select 12 or 24 hour format and
press OO.
Select automatic update via DAB or
Network and press OO.
Select correct time zone and
press OO.
Decide on automatic daylight saving
change or not and pressOO.
Select the correct WLAN region and
press OO.
Select the appropriate network SSID
and press OO.
If the selected network is not encrypted
the tuner automatically connects to the
internet and display:
8
www.oneremote.dk
With an encrypted network the required
password has to be entered via the
displayed entry screen.
Use A/S to move the cursor
to the desired character and select by
pressingOO.
WEP/WPA passwords are case sensitive!
The entered password is stored permanently,
and no re-entry is required.
The correct password has been entered.
Press OOto exit the setup wizard.
Access Wireless Network
With the Setup Wizard completed select
Station list and press OO.
Various internet sources are available:
If ‘Network error’is displayed:
-Check the router.
-Relocate the tuner to
obtain a better signal.
Check the entered password.
9
www.oneremote.dk
Connecting to a Wired Network
Connect LAN cable to the tuner’s LAN
socket. Open Main Menu by pressing
OO.
Move cursor to System settings and
select by pressing OO.
Select Network and confirm by
pressing OO.
Move cursor to Manual settings
and confirm by pressing OO.
Select Wired and then DHCP enable
and confirm by pressing OO.
Connection of the tuner to the wired LAN
has been completed.
Shift to Wireless Network
Refer to above display
Connection type
Select Wireless by pressing OO.
Select DHCP enable by pressingOO.
Enter the name of the router.
Access to the wireless network has been
established.
