214 Solid State Relays G3@-VD G3F/G3FD

Solid State Relays G3@-VD

G3F/G3FD

Refer to Warranty and Application Considerations (page 1), Safety

Precautions (page 4), and Technical and Safety Information (page 6).

International Standards for G3F Series,

Same Profile as MY Power Relays

• Shape-compatible with mechanical relays.

• Certified by UL, CSA, and VDE (model numbers with a suffix of

“-VD”).

• Socket type, same size as MY Power Relays.

• Operation indicator provided to confirm input (model numbers

with “N” before the suffix).

Model Number Structure

■Model Number Legend

1. Basic Model Name

G3F: Solid State Relay

2. Rated Load Power Supply Voltage

2: 200 VAC

3. Rated Load Current

02: 2 A

03: 3 A

4. Terminal Type

S: Plug-in terminals

5. Zero Cross Function

Blank: Equipped with zero cross functions

L: Not equipped with zero cross function

6. Operation Indicator

Blank: Not equipped with operation indicator

N: Equipped with operation indicator

7. Certification

VD: Certified by UL, CSA, and VDE

1. Basic Model Name

G3F: Solid State Relay

2. Load Power Supply Type

D: DC

3. Rated Load Power Supply Voltage

X: 50 VDC

1: 100 VDC

4. Rated Load Current

02: 2 A

03: 3 A

5. Terminal Type

S: Plug-in terminals

6. Operation Indicator

Blank: Not equipped with operation indicator

N: Equipped with operation indicator

7. Certification

VD: Certified by UL, CSA, and VDE

1234 56 7

G3F-@@@@@-@

1234 56 7

G3FD-@@@@-@

Solid State Relays G3@-VD G3F/G3FD 215

Ordering Information

■List of Models

Note: 1. Product is labelled “250 VAC”.

2. Product is labelled “50 VDC”.

3. When ordering, specify the rated input voltage.

■Accessories (Order Separately)

Connecting Sockets

Refer to page 297 for details.

Specifications

■Ratings (at an Ambient Temperature of 25°C)

Input

Isolation Zero cross

function Indicator Rated output load Rated input voltage Model

Photocoupler Yes Yes 3 A at 100 to 240 VAC (See note 1.) 5 to 24 VDC G3F-203SN-VD

2 A at 100 to 240 VAC (See note 1.) 100/110 VAC G3F-202SN-VD

200/220 VAC

Phototriac coupler No 3 A at 100 to 240 VAC (See note 1.) 5 VDC G3F-203SLN-VD

12 VDC

24 VDC

Photocoupler 3 A at 4 to 48 VDC (See note 2.) 5 to 24 VDC G3FD-X03SN-VD

2 A at 5 to 110 VDC 100/110 VAC G3FD-102SN-VD

200/220 VAC

5 to 24 VDC

Photocoupler Yes No 3 A at 100 to 240 VAC (See note 1.) 4 to 24 VDC G3F-203S-VD

Phototriac coupler No 5 VDC G3F-203SL-VD

12 VDC

24 VDC

Photocoupler 3 A at 4 to 48 VDC (See note 2.) 4 to 24 VDC G3FD-X03S-VD

2 A at 5 to 110 VDC G3FD-102S-VD

Item PYF08A-E PY08 PY08-02 PY08QN(2)

Connecting Front connecting Back connecting

Mounting method/

Terminal type Track mounted/

screw terminals Solder terminals PCB terminals Wrapping terminals

Hold-down clip PYC-A1 PYC-P

Model Rated voltage Operating voltage Impedance Voltage level

Must operate voltage Must release voltage

G3F-203SN-VD 5 to 24 VDC 4 to 28 VDC 15 mA max. (See note.) 4 VDC max. 1 VDC min.

G3F-202SN-VD 100/110 VAC 75 to 125 VAC 41 kΩ±20% 75 VAC max. 20 VAC min.

200/220 VAC 150 to 250 VAC 72 kΩ±20% 150 VAC max. 40 VAC min.

216 Solid State Relays G3@-VD G3F/G3FD

Note: Constant-current input circuit.

Output

G3F-203SLN-VD 5 VDC 4 to 6 VDC 390 Ω±20% 4 VDC max. 1 VDC min.

12 VDC 9.6 to 14.4 VDC 900 Ω±20% 9.6 VDC max.

24 VDC 19.2 to 28.8 VDC 2 kΩ±20% 19.2 VDC max.

G3FD-X03SN-VD 5 to 24 VDC 4 to 28 VDC 1.5 kΩ+20%/–10% 4 VDC max.

G3FD-102SN-VD 5 to 24 VDC 4 to 28 VDC 1.5 kΩ+20%/–10% 4 VDC max.

100/110 VAC 75 to 125 VAC 41 kΩ±20% 75 VAC max. 20 VAC min.

200/220 VAC 150 to 250 VAC 72 kΩ±20% 150 VAC max. 40 VAC min.

G3F-203S-VD 4 to 24 VDC 3 to 28 VDC 15 mA max. (See note.) 3 VDC max. 1 VDC min.

G3F-203SL-VD 5 VDC 4 to 6 VDC 390 Ω±20% 4 VDC max.

12 VDC 9.6 to 14.4 VDC 900 Ω±20% 9.6 VDC max.

24 VDC 19.2 to 28.8 VDC 2 kΩ±20% 19.2 VDC max.

G3FD-X03S-VD 4 to 24 VDC 3 to 28 VDC 1.5 kΩ+20%/–10% 3 VDC max.

G3FD-102S-VD

Model Rated voltage Operating voltage Impedance Voltage level

Must operate voltage Must release voltage

Model Rated load

voltage Applicable load

Load voltage range Load current Inrush current

G3F-203SN-VD

G3F-203SLN-VD

G3F-203S-VD

G3F-203SL-VD

100 to 240 VAC 75 to 264 VAC 0.1 to 3 A 45 A (60 Hz, 1 cycle)

G3F-203SN-VD 100 to 240 VAC 75 to 264 VAC 0.1 to 2 A 45 A (60 Hz, 1 cycle)

G3FD-X03SN-VD

G3FD-X03S-VD 4 to 48 VDC 3 to 52.8 VDC 0.1 to 3 A 18 A (10 ms)

G3FD-102SN-VD

G3FD-102S-VD 5 to 110 VDC 3 to 125 VDC 0.1 to 2 A 10 A (10 ms)

Solid State Relays G3@-VD G3F/G3FD 217

■Characteristics

Item G3F-203SN-VD

G3F-202SN-VD

G3F-203S-VD

G3F-203SLN-VD

G3F-203SL-VD G3FD-X03SN-VD

G3FD-X03S-VD G3FD-102SN-VD G3FD-102S-VD

Operate time 1/2 of load power

source cycle + 1 ms

max. (DC input)

3/2 of load power

source cycle + 1 ms

max. (AC input)

1 ms max. 0.5 ms max. 0.5 ms max. (DC in-

put)

20 ms max. (AC input)

0.5 ms max.

Release time 1/2 of load power

source cycle + 1 ms

max. (DC input)

3/2 of load power

source cycle + 1 ms

max. (AC input)

1/2 of load power

sourcecycle+1ms

max.

2 ms max. 2.5 ms max. (DC in-

put)

20 ms max. (AC input)

2.5 ms max.

Output ON voltage drop 1.6 V (RMS) max. 1.5 V max.

Leakage current 5 mA max. (at

100 VAC)

10 mA max. (at

200 VAC)

2.5 mA max. (at

100 VAC)

5 mA max. (at

200 VAC)

5 mA max. (at

50 VDC) 0.1 mA max. (at

100 VDC) 0.1 mA max. (at

100 VDC)

Insulation resistance 100 MΩmin. (at 500 VDC)

Dielectric strength 2,000 VAC, 50/60 Hz for 1 min 1,500 VAC, 50/60 Hz for 1 min

Vibration resistance Destruction: 10 to 55 to 10 Hz, 0.75-mm single amplitude

Shock resistance Destruction: 1,000 m/s2

Ambient temperature Operating: –30°C to 80°C (with no icing or condensation)

Storage: –30°C to 100°C (with no icing or condensation)

Ambient humidity Operating: 45% to 85%

Certified standards G3F: UL508, CSA C22.2 No. 14, EN60947-4-3

G3FD: UL508, CSA C22.2 No. 14, EN60950

Weight Approx. 50 g

218 Solid State Relays G3@-VD G3F/G3FD

Engineering Data

Load Current vs. Ambient Temperature Characteristics

One Cycle Surge Current: Non-repetitive

Dimensions

Note: All units are in millimeters unless otherwise indicated.

Ambient temperature (°C) Ambient temperature (°C)

Load current (A)

G3F-203SN-VD/203S-VD/203SLN-VD/

203SL-VD

G3FD-X03SN-VD/X03S-VD

G3F-202SN-VD

G3FD-102SN-VD/102S-VD

2010

Non-repetitive (Keep the inrush current to half the rated value if it occurs repetitively.)

G3FD-X03SN-VD/X03S-VD G3FD-102SN-VD/102S-VD

Inrush current (A. Peak)

Ener

ized time (ms)

Inrush current (A. Peak)

Ener

ized time (ms)

Inrush current (A. Peak)

Ener

ized time (ms)

G3F-203SN-VD/203S-VD/202SN-VD/

203SLN-VD/203SL-VD

8(+)

12(−)

−+

(+)

(−)

( )

Load

Input

Load

Input voltage

28 max.

21.5 max. 36.5 max.

42.5 max.

Terminal Arrangement/

Internal Connections

Load power

supply

Note: The plus and minus symbols shown

in parentheses are for DC loads.

In the interest of product improvement, specifications are subject to change without notice.

ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.

To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.

Cat. No. K055-E1-05

Solid State Relays G3@-VD G3F/G3FD 219

Safety Precautions

■Precautions for Correct Use

Please observe the following precautions to prevent failure to

operate, malfunction, or undesirable effect on product performance.

Connection

The SSR for DC switching use can connect to a load regardless of

the polarity of the positive and negative output terminals.

Close Mounting of Multiple Relays

If multiple Relays are mounted side by side, be aware that the outer

wall of each SSR works as a heat sink.

The SSR casing serves to dissipate heat. Install the Relays so that

they are adequately ventilated. If poor ventilation is unavoidable,

reduce the load current by half.

Protective Terminal

When using for AC inductive loads, connect the load terminals of the

SSR to an inrush absorber (varistor).
