iConverter GX/TM2 Plug-in Module QUICK START GUIDE

The Omnitron iConverter®GX/TM2 Plug-In media converter and

Network Interface Device (NID) provides 10BASE-T ,100BASE-TX

or 1000BASE-T UTP to 1000BASE-FX fiber media conversion.

The GX/TM2 conforms to Ethernet in the First Mile (EFM) fiber

standards to support Fiber-to-the-X (FTTX) in Metropolitan access

and Enterprise LAN networks. Built-in Operation, Administration

and Maintenance (OAM) functionality enables the GX/TM2 to

operate as a managed demarcation point at the customer premises

and network edge, offering Quality of Service capabilities.

The GX/TM2 module can be managed using Omnitron’s

NetOutlookTMSNMPManagementSoftware,third-partySNMPClient,

Telnet or the Command Line Interface (CLI).

For more information, including the complete User Manual on the GX/TM2 Plug-in

module, access Omnitron’s documentation download web page to view all relevant

documents: http://www.omnitron-systems.com/downloads.php

INSTALLATION PROCEDURE

1) Configure DIP-Switches

2) Install Module in Chassis and Connect Cables

3) Configure Module via Command Line Interface

4) Verify Operation

1) CONFIGURE DIP-SWITCHES

DIP-SWITCH BANK 1

SW1 - FIBER AUTO/MANUAL NEGOTIATION

“AN MAN”

WhenthisDIP-switch is in the LEFT “AN” position

(factory default), the fiber optic port automatically

determines the duplex and pause modes of the

connecting fiber optic device. If the connecting

fiberopticdevicecannotprovidetheproper signal

to indicate its own mode of operation, the DIP-

switchshouldbe settothe RIGHTfiberoptic “Man”

position. When in manual mode, no capabilities

are advertised.

NOTE: The fiber optic port of the GX/TM2 is always in Full-Duplex mode.

SW2 - UTP AUTO/MANUAL NEGOTIATION “AN/MAN”

When this DIP-switch is in the LEFT UTP “AN” position (factory default), the UTP port

automatically determines the Speed, Duplex and Pause mode of the connecting UTP

device. If the connecting UTP device cannot provide the proper signal to indicate its

own mode of operation, then the DIP-switch should be set to “Man” position. Manual

mode requires manually configuring the UTP port to match the Speed and Duplex

mode of the connecting UTP device using the “10/100” and “FDX/HDX” DIP-switches.

Management Options iConverter, Serial Agent

Network Management

1: Chassis and Module Management

2: Set Module Name Preferences

Management Module Preferences

3: IP and Control Preferences

4: SNMP Preferences

5: Abandon Preference Changes

6: Save Preference Changes

7: Restore Factory Defaults

8: Restart Management Module

9: Other Networking Features

Management Module Maintenance

10: Firmware Update

11: Set Date/Time

IP Address = 192.168.1.220

Chassis Number = 1

Enter Choice, <H>elp, E<x>it >

Figure C: Command Line Interface Menu Options

TheCLIinterface allows for thedetailedconfiguration ofthemodule. Itis recommended

to configure the module with an IP address associated with the attached network.

Also, SNMP traphost address should be configured if the module is managed with an

SNMP-based Management System. See the GX/TM2 User Manual for complete

information.

4) VERIFY OPERATION

Oncethemodulehasbeeninstalled

andconfiguredpersteps1-3,verify

themoduleis operational by viewing

the LED indicators.

The Power LED indicates the

module is receiving power from the

chassis.

The Fiber Optic link LED indicates

the fiber optic connection has been

established. Verify the Link Mode

selection is set to Link Segment

(LS). Until a stable link is

established, leave the Link Mode

configured for LS. After a Link

presence is established, the Link

Mode selection can be modified.

The UTP link LED indicates the

module has established a

connection across its UTP port.

Bank 2

Bank 1

Switch 1

Switch 4

Switch 1

Switch 8

Figure A: DIP-Switch Locations

LED Function

"Legend" Color Off State On / Blinking State

Power "Pwr" Green No power On: Module has power

Power Supply

Status # X Green Chassis Power

Supply not installed

On: Power available from

installed Power Supply # X.

Blinking: No power available

from installed Power Supply # X

1000Mbps

Fiber Optics

"FO" Green No Fiber Link On: Fiber Link

Blinking: Fiber Data Activity

Chassis

Management

Master/Slave

"Msr/Slv" Green Chassis in Slave

Mode

On: Chassis Master Mode

Blinking: Operating in OAM

Mode

UTP port

100Mbps

"100" Green Not linked at

100Mbps On: UTP linked at 100Mbps

Blinking: UTP Data Activity

UTP port

1000Mbps

"1000" Green Not linked at

1000Mbps On: UTP linked at 1000Mbps

Blinking: UTP Data Activity

UTP port

10Mbps

"100" + "1000" Green Not linked at

10Mbps On: UTP linked at 10Mbps

Brinking: UTP Data Activity

UTP port

Full-Duplex

"FDX" Green Half-Duplex when

any UTP link is

active

On: Full-Duplex when any UTP

link is active

Figure D: LED Indicators

Form 040-8920N-002 B

Omnitron Systems Technology * 140 Technology Dr.* #500 * Irvine, CA 92618

949.250.6510 tel * 949.250.6514 fax * www.omnitron-systems.com

SW3 - MASTER/SLAVE

When the GX/TM2 module is installed in a chassis with an iConverter management

module such as a 10/100M2, set the DIP-switch to the LEFT “M/SL” position (factory

default), the assignment of mastership is automatically negotiated by the installed

managementmodules. Todesignate the GX/TM2 module as the master ofthechassis,

set the DIP-switch on the module to

theLEFT“M/SL” position, andsetthe

DIP-switch on the other installed

management modules to the RIGHT

“SL” position to enable Slave-Only

mode.

SW4 - RESERVED

This DIP-switch is for factory use only and must always remain in the LEFT position

(factory default).

2) INSTALL MODULE IN CHASSIS AND CONNECT CABLES

a. Carefully slide the module into an open slot in the chassis. Align the module with

the installation guides and ensure that the module is firmly seated against the

backplane. Secure the module by fastening the front panel thumbscrew (push in

and turn clockwise to tighten) to the chassis front. Verify the “Pwr” LED is ON

(indicating the chassis is powered).

b. When using a GX/TM2 SFP model (8939N-0), insert the SFP Fiber transceiver into

the Port 1 SFP receptacle on the GX/TM2.

NOTE: The release latch of the SFP Fiber transceiver must be in the closed

position before insertion.

c. Connect the UTP port via a Category 5 cable to a 10BASE-T, 100BASE-TX or

1000BASE-T Ethernet device.

d. Connect an appropriate multimode or single-mode fiber cable to the fiber port of

the installed module. It is important to ensure that the transmit (Tx) is attached to

the receive side of the device at the other end and the receive (Rx) is attached to

the transmit side. Single-fiber (SF) media converter models operate in pairs. The

Txwavelength mustmatchthe Rxwavelengthat theotherend andtheRx wavelength

must match the Tx wavelength at the other end

3) CONFIGURE MODULE VIA COMMAND LINE INTERFACE

To access the Command Line Interface (CLI), connect the GX/TM2 RS-232 Console

Port to the COM port of a computer equipped with terminal emulation software such as

HyperTerminal. The Console Port (DCE) is a mini DIN-6 female connector which can

be changed to a DB-9 connector with the included adapter. The GX/TM2 Console Port

is a standard asynchronous serial interface.

Start HyperTerminal and select the correct COM Port in the HyperTerminal “Connect

To:” window. Set the serial port to the following:

Bits Per Second 57,600

Stop Bits 1

Data Bits 8

Parity NONE

Hardware Flow Control NONE

Once connected, press <ENTER> to bring up a command line prompt on the attached

PC.

SW3 - UTP SPEED GIGABIT/10-100 “1000/10-100”

When the “1000/10-100” DIP-switch is in the “1000” position (factory default), the

UTP port operates in 10/100/1000Mbps Auto-Negotiation mode. The UTP port

auto-negotiates to a speed of 10Mbps, 100Mbps or 1000Mbps with the connected

UTP device. In this mode, the UTP “AN/Man” and UTP “100/10” DIP-switches have no

effect.

When the “1000/10-100” DIP-switch is in the “10-100” position and the UTP “AN/Man”

DIP-switch is in the “Man” position, the UTP port operates at the Speed and Duplex

modes set by the “100/10” and “FDX/HDX” DIP-switches.

When the “1000/10-100” DIP-switch is in the “10-100” position and the UTP “AN/Man”

DIP-switch is in the “AN” position, the UTP port maximum auto-negotiation setting

for the Speed and Duplex mode is determined by the “100/10” and “FDX/HDX”

DIP-switches.

SW4 - UTP 100/10MBPS “100/10”

WhentheUTP“AN/Man”DIP-switch(described above) is in the manual “Man” position,

the “100/10" DIP-switch determines the speed of operation for the UTP port. Set the

“100/10” DIP-switch to match the speed of the connected UTP device.

SW5 - UTP FULL/HALF DUPLEX “FDX/HDX”

WhentheUTP“AN/Man”DIP-switch(described above) is in the manual “Man” position,

the “FDX/HDX" DIP-switch determines the duplex mode of the UTP port. Set the

“FDX/HDX” DIP-switch to match the duplex mode of the connected UTP device.

SW6, SW7, SW8 - LINK MODES

These three DIP-switches configure the link mode settings. The following table details

possible Link Mode DIP-switch configurations.

Switch Left

(Factory Default) Right SW6 SW7 SW8 Link Mode Selection

SW1 AN:

Fiber Auto-Negotiation Man:

Fiber Manual Negotiation Left Left Left Link Segment (LS)

(Factory Default)

SW2 AN:

UTP Auto-Negotiation Man:

UTP Manual Right Left Left Link Propagate (LP)

SW3 1000:

UTP 1000Mbps 10-100:

UTP 10-100Mbps Left Right Left Remote Fault Detect + Link

Segment (RFD + LS)

SW4 100:

UTP 100Mbps 10:

UTP 10Mbps Right Right Left Remote Fault Detect + Link

Propagate (RFD + LP)

SW5 FDX:

UTP Full-Duplex HDX:

UTP Half-Duplex Left Left Right Symmetrical Fault Detect (SFD)

SW6

See Link Mode Selection

Right Left Right Asymmetrical Link Propagate

Port 1 to Port 2 (ALP P1-P2)

SW7 Left Right Right Asymmetrical Link Propagate

Port 2 to Port 1 (ALP P2-P1)

SW8 Right Right Right Asymmetrical RFD+LP

Port 1 to Port 2 (ARFDP1-P2)

Figure B: DIP-Switch Bank 1

DIP-SWITCH BANK 2

SW1, SW2 - BACKPLANE ENABLE

When the DIP-switch is in the LEFT “DS” position (factory default), the Backplane Port

oftheGX/TM2isisolatedfromthechassis’Ethernet Backplane. WhenthisDIP-switch

is in the RIGHT “EN” position, the Backplane Port is enabled. This allows Ethernet

Backplane connectivity to an adjacent module via the chassis Backplane Link “A” or

“B” depending on the switch setting.

witch Left (Factory Default) Right

SW1 A-DS: Port A Disabled A-EN: Port A Enabled

SW2 B-DS: Port B Disabled B-EN: Port B Enabled

SW3 M/SL:

Master/Slave Auto-Select SL:

Slave-Mode Only

SW4 Reserved Reserved

Figure C: DIP-Switch Bank 2

Autres manuels pour Omnitron iConverter GX/TM2

Autres manuels Omnitron Systems Technology Convertisseur de média

Omnitron Systems Technology

Omnitron Systems Technology iConverter T1/E1 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology miConverter GX/T Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter 2GXM2 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter 10T/2 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter XGT+ Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter T3/E3 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter Gx AN Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology OmniConverter GPoE+/SX Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology 4/16 Token Ring Fiber Converter OmniHawk Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iconverter t3 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology Omnitron iConverter 10/100M2 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology 10/100/1000 UTP to 100/1000X Ethernet Media Converter FlexPoint... Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology OmniRepeater AS400/3X Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology 8249-0 iConverter Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter 2GXM Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter GM4-PoE+ Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology iConverter X21 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology FlexPoint 100Fx/Tx Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology OmniConverter GPoE+/S Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology Omnitron iConverter 10/100M2 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology Omnitron iConverter 10/100M Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology OmniConverter FPoE/SL Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology miConverter 10/100 Manuel utilisateur

Omnitron Systems Technology

Omnitron Systems Technology Omnitron iConverter GX/TM2 Manuel utilisateur

Manuels Convertisseur de média populaires d'autres marques

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuel utilisateur

SPROLINK

SPROLINK VA1 Manuel utilisateur

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuel utilisateur

Nikon

Nikon AF-S TC-20E III Manuel utilisateur

Axis

Axis AXIS Q7406 Manuel utilisateur

Omega

Omega TAC80B-J Manuel utilisateur

Zoom

Zoom Thunderbolt TAC-2R Manuel utilisateur

OST

OST iConverter 10/100M Manuel utilisateur

Vertiv

Vertiv Netsure Manuel utilisateur

birddog

birddog MINI Manuel utilisateur

Roland

Roland GI-10 Manuel utilisateur

Wallenstein

Wallenstein WX310 Manuel utilisateur

Pace

Pace MSS 200-1 Manuel utilisateur

Solar Converters

Solar Converters EQ 12/24-50 Manuel utilisateur

CYP

CYP EL-7400V Manuel utilisateur

TIE

TIE MIDI 1i1o Manuel utilisateur

DCS

DCS Vivaldi Upsampler Manuel utilisateur

Westermo

Westermo MCW-211 SERIES Manuel utilisateur
