1-1
Installing a Fingerprint Scanner
on a 1-, 2-, and 3-Cell
The fingerprint scanner on a 1-, 2-, and 3-cell cabinet is located on the card reader bracket and
should always be installed with the card reader bracket as a single piece.
Install the Fingerprint Scanner
1. Perform a graceful shutdown of the G4 cabinet and unplug the power cord from the back of
the unit.
2. Open the printer door.
3. Remove the filter access cover.
Figure 1-1. Remove the filter access panel
1-2 Installing a Fingerprint Scanner on a 1-, 2-, and 3-Cell
Install the Fingerprint Scanner
Fingerprint Scanner & Card Reader Guide/67-2100 Rev A © 2011 Omnicell, Inc.
4. Use the # 2378 cam lock key to unlock the E-Box.
Figure 1-2. Unlock the eBox
5. Slide the console out until it locks into place.
6. Place the scanner and card reader bracket in place on the end of the eBox console.
Figure 1-3. Put the card reader and fingerprint scanner in place
© 2011 Omnicell, Inc. Fingerprint Scanner & Card Reader Guide/67-2100 Rev A
Installing a Fingerprint Scanner on a 1-, 2-, and 3-Cell 1-3
Install the Fingerprint Scanner
7. Secure the fingerprint scanner bracket with the four screws provided.
Figure 1-4. Secure the scanner to the console with the four screws
1-4 Installing a Fingerprint Scanner on a 1-, 2-, and 3-Cell
Install the Fingerprint Scanner
Fingerprint Scanner & Card Reader Guide/67-2100 Rev A © 2011 Omnicell, Inc.
8. If installing a fingerprint scanner and card reader combo, route the two USB cables through
the plastic cable clip provided on the side of the console. If only a scanner or card reader is
being installed, route the single USB cable through the plastic clip provided.
Figure 1-5. Route the cable(s) through the cable clip
9. Route the cable(s) through the clips on the top of the eBox console.
Figure 1-6. Route the cable(s) through the plastic routing clips on top of the console
© 2011 Omnicell, Inc. Fingerprint Scanner & Card Reader Guide/67-2100 Rev A
Installing a Fingerprint Scanner on a 1-, 2-, and 3-Cell 1-5
Install the Fingerprint Scanner
10. Route the cable(s) through the two clips near the USB ports.
Figure 1-7. Route the cable(s) tough the two clips near the USB ports
11. Plug the USB cable(s) into the USB ports on the side of the eBox. The fingerprint scanner USB
ca ble should be plugged into USB0 and the card reader USB cable should be plugged into
USB1.
Figure 1-8. Plug the USB cable(s) into the USB ports
12. Push the eBox console back into the cabinet.
1-6 Installing a Fingerprint Scanner on a 1-, 2-, and 3-Cell
Install the Fingerprint Scanner
Fingerprint Scanner & Card Reader Guide/67-2100 Rev A © 2011 Omnicell, Inc.
13. LAdd the M4x14 security screw to the top of the printer enclosure, securing it to the console
cover.
Figure 1-9. Add the M4x14 security screw
14. Lock the CT PC console into place using the #2378 key. Turn the key vertical to lock the G4
console into place.
Figure 1-10. Power on the cabinet
15. Replace the filter access panel.
© 2011 Omnicell, Inc. Fingerprint Scanner & Card Reader Guide/67-2100 Rev A
Installing a Fingerprint Scanner on a 1-, 2-, and 3-Cell 1-7
Install the Fingerprint Scanner
16. Power on the cabinet.
17. Close the keyboard door.
18. Power up the G4 console.
19. Test the fingerprint scanner to ensure it is working properly.
